XS Scuba Brawn Regulator User manual

1
www.XSscuba.com
Quick Start Guide
To view the complete Regulator Owner’s Manual, please visit www.XSscuba.com

2www.XSscuba.com
Quick Start Guide

3
www.XSscuba.com
Introduction     04
Warnings,CautionsandNotes   05
GeneralPrecautionsandWarnings   06-07
EnrichedAirNitroxUse    08-09
YourRegulatorataGlance    10
PreparationandSetUp    10
VenturiLever     11
InhalationControlKnob    12-13
PreparingtoDive     14-15
Diving/PostDiveProcedure    16-17
CareandMaintenance    18-19
DealerInspectionandService   20
Warranty      21-22
AnnualServiceRecord    23
Table of Contents

4www.XSscuba.com
Introduction
Breatheeasy,youownanXSScubaRegulator!Youcandive
withcondenceknowingeachXSScubaregulatorisbuiltto
thehigheststandards.Yourregulatoristheresultofquality
engineering,materialselectionandpreciseassemblymethods.
EachXSScubaregulatoris100%testedpriortonalpackaging
soyouknowitworksrightthersttimeyoubreatheit.
Withpropercareandmaintenance,yourregulatorwillcontinue
todeliveritsfactory-newperformanceformany,manyyearsto
come.
XSScubahopesthatyouhavemanyexcitingunderwater
adventuresaheadofyou.Weareexcitedtobeapartofthose
adventures.


5
www.XSscuba.com
Warnings, Cautions and Notes
Itisimportanttopayspecialattentiontotheinformation
providedinwarnings,cautionsandnotes,whichare
accompaniedbythefollowingsymbols:


 AWARNINGindicatesanysituationthat,ifnot
 avoided,couldresultinseriousinjuryordeath.
 ACAUTIONindicatesanysituationortechnique
 thatcouldcausedamagetotheproduct,andcould
 subsequentlyresultininjurytotheuser.

 ANOTEisusedtoemphasizeimportantpoints,
 tips,andreminders.

6www.XSscuba.com
WARNING:Beforeusing
thisregulator,youmusthave
successfullyreceivedtrainingand
certicationinthetechniqueof
SCUBAdivingfromarecognized
trainingagency(oranyMilitary
orgovernmentoperateddiving
school).UseofSCUBAequipment
byuncertiedoruntrained
personsisdangerousandcan
resultinseriousinjuryordeath.
WARNING:Keepyour
regulatoringoodworking
conditionbyhavingit
servicedannuallyatanauthorized
XSScubaDealer.Service,
disassemblyoradjustmentmust
notbeattemptedbypersonswho
arenotproperlytrainedtowork
onthisregulator

WARNING:Thisregulator
isdesignedforuseinwater
thatis50°F/10°Candabove.
Useofthisregulatorinwater
temperaturesbelow50°F/10°C
couldresultintheregulator
freezingandnotperformingas
designed.
WARNING:DONOTleave
thecylinderstandingunsecured
withtheregulatorattachedtothe
valve.Shouldthecylinderget
knockedover,permanentdamage
mayoccurtotheregulatorand
thecylindervalve.

General Precautions and Warnings

7
www.XSscuba.com
WARNING:DONOTusetheregulatorrststageasa
carryhandlewhenliftingortransportingthecylinderasthis
candamagetheregulatorand/orthecylindervalve.

WARNING:Alwayspressurizetheregulatorgradually
byopeningthecylindervalveSLOWLY.
WARNING:Thisregulatorisnotconguredfor
commercialusewithsurfacesuppliedair.
General Precautions and Warnings

8www.XSscuba.com
WARNING:Thissection
containsimportantinformation
regardingtheuseofthisregulator
withenrichedairnitrox.Donot
usethisregulatorwithenriched
airnitroxifyoudonotfully
understandthissection.Todo
otherwiseputsyouatrisk
ofseriousinjuryordeath.
WARNING: Obtainan
enrichedairnitroxdiving
certication.Inordertofully
understandtherisksinvolvedwith
divingelevatedpercentagesof
oxygen(above21%),youmust
obtainacerticationinenriched
airnitroxfromarecognized
trainingagency.
YourXSScubaregulatorhasbeen
preparedforusewithenriched
airnitrox(EAN)wheretheoxygen
percentagedoesnotexceed
40%(EAN40).Thisisbecause
yourregulatorwasbuilttoahigh
standardofcleanlinessusingEAN
compatiblepartsandlubricant.
Ifitisyourintentiontouseyour
newXSScubaregulatorwithEAN
upto40%O2,itiscriticalthatyou
maintaintheinternalcleanliness
ofyourregulator(seesectionon
CareandMaintenance).
Ifitisyourintentiontouseyour
regulatorinterchangeablywith
breathingair,thebreathingair
shouldbe“oxygen-compatible”
or“hyper-ltered”whereasthe
condensedhydrocarbonsinthe
Enriched Air Nitrox Use

9
www.XSscuba.com
airdonotexceed0.1mg/m3.
YourlocalXSScubaDealercan
helpyoudeterminewhetherthe
breathingairtheyprovidemeets
thiscriterion.
Standardcompressedbreathing
air,oftenreferredtoas“Grade
E”doesnotnecessarilymeet
thiscriterion.GradeEbreathing
airmaycontaincertainlevelsof
hydrocarbons,includingtraces
ofcompressoroils,thatwhilenot
consideredharmfultobreathe,
canposeariskinthepresenceof
elevatedoxygencontent.
Passinghydrocarbonsthrough
avalveandregulatorcreates
acumulativeeffectwherethe
hydrocarbonsbuildupovertime
alongtheinternalpassageways
oftheequipment.Whenthese
hydrocarbonscomeincontact
withhighpressureoxygen
enrichedair,theycanposea
veryrealhazardthatcanleadto
combustion.
Therefore,ifaregulatorhasbeen
usedwithGradeEbreathingair,
itshouldreceiveoverhaulservice,
includinghydrocarboncleaning,
priortobeingputbackintonitrox
service.
Althoughsecondstage
componentsarenotsubjected
tohighpressureEAN,XSScuba
recommendsthatthesame
guidelinesapply.

10 www.XSscuba.com
Your Regulator at a Glance
Preparation and Set Up
Yourregulatorhas1or2high
pressureportsand4medium
pressureportstoattachyour
variousaccessories.Highpressure
portsarewhereyouwouldattach
suchitemsasyoursubmersible
pressuregauge,console,transmitter
orair-integratedcomputer.
Mediumpressureportsareforyour
primaryandalternatesecondstages,
BCinatorhoseandpossiblya
drysuitinatorhose.
CAUTION:XSScuba
recommendsthatyouhaveyourXS
ScubaDealerinstallyouraccessory
itemstopreventover-torquing
thehosettingsandtooptimize
placementofaccessoryhoses.
1Yokescrew
2Dustcap
3Yoke
4MPaccessoryport
5HPaccessoryport
6Mouthpiece
7Venturilever
8Inhalationcontrolknob
9Purgecover
10Ambientpressureports
1
3
3
2
4
10
59
9
7
1
24
5
7
8
6
6

11
www.XSscuba.com
Venturi Lever
Youwillnoticealeverontheside
ofthesecondstageoppositethe
hoseconnection.Movingthis
leverbackandforthchangesthe
directionoftheairinternallyin
thesecondstage.Whenpulled
back,towardsyourmouth,to
theplus“+”setting,theairow
createsa“venturi”effectwhich
createsaniceboostinbreathing
performance.Whenmoved
forward,awayfromthemouth,
totheminus“-”setting,the
venturieffectisinterruptedwhich
increasesyourbreathingeffort.
Thedeeperyougo,themore
noticeablethisbecomes.
Itisimportanttonote,thatwhen
theleverisontheplus“+”setting
andtheregulatorisoutofyour
mouth,thesecondstagecanget
bumpedandgointoafreeow
condition.Shouldthishappen,just
movethelevertotheminus“-”
positionandthefreeowwillstop.
NOTE:Thesimplestwayto
usethisperformancefeatureis
toplacetheleverintheplus“+”
positionwhentheregulatorisin
yourmouthandmoveittothe
minus“–”positionwhenitisout
ofyourmouth.

12 www.XSscuba.com
TheInhalationControlKnob,
locatednexttotheventurilever
oncertainmodelsecondstages,
adjuststheeffortrequiredto
initiatetheinhalationcycle.Asitis
turnedin(clockwise),theopening
effortwillincrease.Thiswillmake
thesecondstagelesssensitive
tosuddenchangesinambient
pressure.
Turningtheknob“out”(counter-
clockwise)willdecreasethe
openingefforttomakebreathing
easier.Sometimesaslighthissing
maybeheardinthissetting.Ifthis
occurs,turntheknobclockwise
justenoughtostopthehissing.
Inhalation Control Knob

13
www.XSscuba.com
TheInhalationControlKnob
isparticularlyusefulatdeeper
depths,orinvariableconditions
thataffecttheopeningeffortof
thesecondstage,suchasfacing
intostrongcurrentsorwhileusing
adiverpropulsionvehicle(DPV).
Itwillalsoallowcompensation
foradifferenceinthehydrostatic
pressurebetweenyoursecond
stageandthecenterofyour
lungs,suchaswhenyouarein
ahead-downposition.Youcan
usetheInhalationControlKnob
totuneyourregulatortomaintain
itspeakperformancethroughout
thecourseofyourdive,or
youcanleaveitsetinitsmid-
rangepositionanddivewithas
youwouldanynon-adjustable
secondstage.


14 www.XSscuba.com
Preparing to Dive
Partiallyloosentheyokescrewto
removethedustcap
Ventasmallamountofairfrom
thecylindervalvetoblowoutany
dust,debrisormoisture
Inspecttheconditionofthe
cylindervalveo-ring.Replaceif
damagedormissing.
Placetheregulator’sconnection
yokeoverthevalvesothatthe
inletttingoftheregulatorseats
againstthevalveo-ringANDthe
primarysecondstagehoseroutes
overthediversrightshoulder.
Holdinplacewhileyouturn
theyokescrewclockwiseuntil
snug.Conrmthattheyokescrew
engagesthesmalldimpleonthe
backofthecylindervalve.

CAUTION:Over-tighteningthe
regulatoronthevalvecancause
damageandmakeitdifcultto
removetheregulatorafterthedive.
Itisthevalveo-ringthatformsthe
seal,notexcessivetighteningof
theyokescrew.
Placetheventurileverinthe
minus“-”position.Turnthe
inhalationcontrolknob,if
applicable,clockwise,alltheway
inward.
Makesurethatyourpressure
gaugeorcomputerfacesaway
fromyou.

15
www.XSscuba.com
WARNING:Donotdiveifyour
regulatororitsaccessoriesare
leaking.
Depressthepurgebuttonbriey
toensuresufcientairowandto
blowoutanydustordebris.
Placetheregulatorinyourmouth.
Movetheventurilevertothe
plus“+”position.Ifapplicable,
turntheinhalationcontrolknob
counterclockwise,allthewayout.
Thenturnit,clockwise,backinuntil
theregulatorbreathescomfortably
foryouwithoutbeingoverly
sensitive.Inhaleandexhaleslowly
anddeeply.Theregulatorshould
breatheeasilywithoutnoticeable
resistance.
Pressurizetheregulatorby
SLOWLYopeningthecylinder
valve.Continuetoopenthevalve
allthewayandthenbacka
halfturn.
Listenforleaksnearbothstages
oftheregulator,anyaccessories
andalongthelengthofthehoses.
Ifthereisairleakingbetween
theregulatorandthecylinder
valve,followtheprocedures
forremovingtheregulatorfrom
thevalve.Replacethevalve
o-ringandreseattheregulator.
Ifleakagepersists,returnthe
regulatorwithcylindertoyour
localXSScubaDealerfor
inspectionandrepair.


16 www.XSscuba.com
Diving
Ifyouaremakinganentryor
aresurfaceswimmingwiththe
regulatoroutofyourmouth,be
suretosettheventurileverinthe
minus“-”positionandhavethe
inhalationcontrolknobturnedall
thewayin.Onceyouplacethe
regulatorintoyourmouth,move
theventurilevertotheplus“+”for
theremainderofthedive.Where
yousettheinhalationcontrolknob
willbebaseduponenvironmental
conditionsaswellasyoupersonal
preference.Seeearliersectionon
theInhalationControlKnob.
Goahead,enjoyyourdive.Ifyou
don’thavetothinkaboutyour
regulatorduringthedive,thenwe
succeeded!
Asareminder,thisregulatorisnot
designedforcoldwateruse
(<50°F/10°C)

WARNING:Thisregulatoris
designedforuseinwaterthatis
50°F/10°Candabove.Useofthis
regulatorinwatertemperatures
below50°F/10°Ccouldresult
intheregulatorfreezingandnot
performingasdesigned.
Post Dive Procedure
NOTE:Iffreshwaterisreadily
available,rinseyourregulator
thoroughlypriortodepressurizing
it.Thiswillpreventwaterfrom
enteringtherststage.
NOTE:Whenyouremovethe

17
www.XSscuba.com
rststagefromthecylinder,exercise
cautionnottoletanywaterenterthe
rststagethroughtheinlettting,
wherethelterislocated.
Shutoffthecylindergassupplyby
turningthecylindervalvehandwheel
untilsnug.
Depressthesecondstagepurge
buttontodraintheremaininggasfrom
theregulatorandhoses.Keepthe
purgebuttonpressedinuntilnomore
gascanbeheardexitingtheregulator.
Turntheyokescrewcounterclockwise
toloosentheregulatoronthecylinder
valve.Whileremovingtheregulator,
keeptherststageinvertedwiththe
yokescrewfacingdown.Thiswill
preventwaterdropsforgoinginthe
inletareawherethelterislocated.

18 www.XSscuba.com
Care and Maintenance
Assoonaspossibleafterthedive,
itisimportanttosoakorrinseyour
regulatorinfreshwater.Warm
water(<120°F/49°C)isbest.
Thebestmethodistosoakit
inatubofwaterwhileitisstill
connectedtothecylinderand
pressurized.Thiskeepsrinse
wateroutofthehosesandthe
rststage.
Ifthisisnotpossible,then
youmaysoakitwhileitis
depressurizedaslongasyou
followthesesteps:
•Ensurethatthedustcapis 
makingawatertightsealover
theregulator’sinlettting.
•Ifyourregulatorhasan
inhalationcontrolknob,besure
toturnitclockwise,allthe
wayin.
•DONOTdepressthepurge
button.Thiswillallowwater
toentertheregulatorandmake
itswaydownthehosetothe
rststage.
•Keepthesecondstagelower
thantherststage.
Whilerinsing,movetheventuri
leverbackandforthseveral
timestoremoveanysalt,sandor
contaminants.

19
www.XSscuba.com
stagelowpressureseatwhilethe
regulatorisinstorage.Afterthe
regulatoriscompletelydry,you
maystoreitinaregulatorboxor
bag.

CAUTION:DONOTstore
yourregulatorinahotenvironment
ornearanelectricmotor,which
producesozone.Prolonged
exposuretoheat,ozone,chlorine
fumesorultravioletrayscancause
prematuredegradationofyour
regulator’ssoftpartsandhoses.
Ifsoakingisnotpossible,then,as
aminimum,rinsewithagarden
hose.Donotuseahighpressure
nozzleasthiscouldcompromise
the2ndstageinternalparts.Be
suretorinsetheinsideofthe
secondstageviathemouthpiece
aswellastheventurilever.If
applicable,besuretodirect
freshwaterintotheambient
pressureportsontherststage
toushoutthemainspringcavity.
Afterrinsing,shakeanyresidual
wateroutofthesecondstage.
Hangtheregulatorbytherst
stageinacool,dryenvironment,
outofdirectsunlight.Turnthe
inhalationcontrolknoballthe
wayout,counterclockwise,to
lessenspringtensiononthe2nd

20 www.XSscuba.com
Dealer Inspection and
Service
Donotassumethatyourregulator
isingoodworkingorderbecause
ithasreceivedlittleusesinceits
lastservicing.Storagecanbe
hardonaregulatorassealsand
othersoftpartscantakeasetand
dryout.
Youmustobtainfactory
authorizedservicefroman
XSScubaDealeratleastoncea
year.Yourregulatormayrequire
morefrequentservicedepending
ontheamountofuseitreceives
andthetypeofenvironmental
conditionsthatitissubjectedto.
Iftheregulatorisusedforrental
ortrainingpurposes,itwillrequire
factoryprescribedserviceevery
threetosixmonths.Chlorinated
swimmingpoolwaterisan
especiallydamagingenvironment
forscubaequipment,duetothe
highlevelsofchlorineandpH
balancingchemicalsthatcancause
certaincomponentstorapidly
deteriorate.
WARNING: Besuretohave
yourregulatorservicedatleast
onceayearbyanXSScuba
Dealer.Yourpersonalsafetyand
themechanicalintegrityofyour
regulatormaydependonit.
