Xtend Porch Manual

OUTDOORS Porch
Setup Instructions
INCLUDED IN KIT:
Ground Pegs
Fully extend your awning so the sail track groove in the
awning barrel is in the 3 o’clock position and attach the anti-ap kit.
Spreader Bar
9ft Pole
C-Clip Rafter
Sprung Guy Ropes
Canopy
4x
3x
4x
1x
6x
1x
C
C
STEP 1
Slide the canopy into the sail track on the anti-ap kit.
STEP 2
Feed the canopy into the sail track on the other side of the anti-ap kit.
STEP 3
AWNING AWNING
CANOPY
CANOPY
CANOPY
POCKETS
POCKETS POCKETS
SPREADER BAR
SPREADER BAR
CANOPY
ANTI-FLAP KIT ANTI-FLAP KIT
Measure out and extend the spreader bars to t the awning canopy holes.
STEP 4
Feed the spreader bars (x3) into the pockets on the underside
of the canopy.
STEP 5
www.xtendoutdoors.com.au 1300 783 776

OUTDOORS Porch
Setup Instructions
Adjust 4x 9ft poles to the same height as the rear of the anti-ap kit,
and front of the anti-ap kit.
STEP 6
Insert the 9ft pole spigot through the eyelets on the two spreader bars
and through the canopy corner eyelet. Repeat for all bars.
STEP 7
Rear of anti-ap
kit height
Front of anti-ap
kit height
CANOPY CORNER EYELET
SPREADER BAR
SPREADER BAR
9ft POLE
Raise the porch and adjust the poles and spreader bars until all are tight.
STEP 8
Secure the springs to the ground with pegs and attach rope loops over
9ft pole spigots on the top of your porch.
Tighten by pulling the wooden handle.
STEP 9
Attach C-Clip rafter between the front and rear spreader bars, and
adjust the length using the handle on the C-Clip rafter.
Your porch is now ready to use.
STEP 10
CANOPY
REAR SPREADER
BAR
FRONT SPREADER
BAR
C-CLIP RAFTER
