XtendLan KEYBPTZ3DPJ-LAN User manual

KEYBPTZ3DPJ-LAN
LAN PTZ Keyboard
User’s Guide

2
Contents
Welcome...................................................................................................................................4
Important Safeguarding and Warnings ................................................................................5
1Feature and Specification ...............................................................................................6
1.1 Feature ....................................................................................................................6
1.2 Specification ...........................................................................................................6
2Keyboard Function...........................................................................................................7
2.1 Keyboard Appearance ..........................................................................................7
2.2 Key Function List ...................................................................................................7
2.3 Keyboard Ports ....................................................................................................10
2.4 Port Features........................................................................................................10
2.5 Power.....................................................................................................................10
3Menu Tree.....................................................................................................................12
3.1 Input Method.........................................................................................................13
3.2 Log In.....................................................................................................................13
3.3 Log out...................................................................................................................13
4Menu Operation..............................................................................................................14
4.1 Local Setup...........................................................................................................14
4.1.1 Network Setup ...........................................................................................14
4.1.2 Time Setup .................................................................................................14
4.1.3 Address Setup ...........................................................................................14
4.2 CTL Point ..............................................................................................................15
4.2.1 ID..................................................................................................................15
4.2.2 Device Name .............................................................................................15
4.2.3 Device Type ...............................................................................................15
4.2.4 Connection Type .......................................................................................15
4.3 Advance ................................................................................................................16
4.3.1 Password....................................................................................................16
4.3.2 User Management.....................................................................................16
4.3.3 Set Local as Default..................................................................................17
4.3.4 Empty Control Point..................................................................................18
4.4 Assistant Setup ....................................................................................................18
4.4.1 Backlight Setup..........................................................................................18
4.4.2 Alarm Setup................................................................................................18
4.4.3 Language....................................................................................................18
4.4.4 Auto Lock....................................................................................................18
4.5 System Information..............................................................................................18
4.5.1 Search Point...............................................................................................18
5Keyboard Control DVR..................................................................................................20
5.1 Serial Port Connection ........................................................................................20
5.1.1 RS232 Serial Port Connection ................................................................20
5.1.2 Via RS485 Connection .............................................................................20
5.1.3 Multi-keyboard Level-link via RS485......................................................21
5.2 Network Connection (For Network Keyboard Only).......................................21
5.2.1 RJ45 port connection................................................................................22

3
5.3 DVR and Keyboard Setup ..................................................................................22
5.3.1 DVR Setup..................................................................................................22
5.3.2 Keyboard Setup after Serial Port Connection.......................................23
5.3.3 Keyboard Setup after Network Connection...........................................24
5.4 Operation ..............................................................................................................24
5.4.1 Login............................................................................................................24
5.4.2 Logout .........................................................................................................24
5.4.3 Record.........................................................................................................24
5.4.4 PTZ Control and Image Color .................................................................25
5.4.5 Tour and Single/Multiple Window Switch. .............................................25
5.4.6 Network keyboard backup (USB backup) .............................................25
6Network Keyboard Control Dome................................................................................27
6.1 Cable Connection ................................................................................................27
6.2 Keyboard Setup ...................................................................................................27
6.3 Operation ..............................................................................................................27
6.3.1 Direction Setup ..........................................................................................28
6.3.2 Preset..........................................................................................................28
6.3.3 Scan ............................................................................................................28
6.3.4 Tour .............................................................................................................29
6.3.5 PATTERN...................................................................................................30
6.3.6 Pan Rotation ..............................................................................................30
6.3.7 Light/Wiper/Assistant/Fan Setup ............................................................30
7Network Keyboard Upgrade .........................................................................................31
8Make Serial Port.............................................................................................................33
8.1 RS232 Serial Port ................................................................................................33
8.2 485 Port.................................................................................................................33
8.3 25-pin Port and Switch Box Connection ..........................................................33

4
Welcome
Thank you for purchasing our network keyboard!
This operating manual is designed to be a reference tool for the operation of your
keyboard.
Here you can find information about this keyboard features and functions, as well as
a detailed menu tree.
Before operation please read the following safeguards and warnings carefully!

5
Important Safeguarding and Warnings
All installation and operation should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation
All the examination and repair should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or
attempted repair.

6
1 Feature and Specification
1.1 Feature
This series keyboard has the following features
zOne keyboard can control multiple DVRs, or you can use multiple keyboards to
control one DVR.
zSupport dome operation.
zSupport RS485 port and RS232 port.
zSupport PTZ operation via joystick
zSupport all operations you get from DVR front panel function keys
zSupport keyboard lock function
zSupport multiple-level operation rights
zSupport level-link
zSupport single or multiple DVRs’s menu setup
zOn-screen menu, user-friendly procedure. It is very easy for you to operate
zCan control network video server and network video decoder
zSupport network ports connection
zReceive DVR alarm information, support one-channel activation on alarm,
zUSB port support network backup DVR video data.
1.2 Specification
Working
Temperature 0℃-+55℃
Weight 2．5Kg
Dimension 320mmx190mmx50mm
（Includes joystick height
100mm）
Working
Power 12VDC 1200mA
LCD
Dimension 84mm x 31 mm

7
2 Keyboard Function
2.1 Keyboard Appearance
Keyboard is shown as in Figure 2-1.
Figure 2-1
① Function key: There are three function keys: SETUP/ALARM/SHIFT
② LCD: Here is to display on-screen menu.
③ Indication light: There are six indication lights.
DVR/DOME/ALT/COM/ALARM/POWER.
④ DVR function: Here are operation keys for you to control DVR.
⑤ Public function: Here includes ten numeral keys, four direction keys, ESC/ENTER
and ID/CAM.
⑥ Dome matrix function: Here are operation keys for you to control dome or matrix.
⑦ Joystick
⑧ Assistant function: from AUX1 to AUX 6, log and lock key.
2.2 Key Function List
Serial numb Name Symbol Function
Setup SETUP Shortcut key to enter function setup menu
Alarm ALARM Shortcut key to enter alarm setup menu
Function
key
Shift SHIFT Switch between input methods
LCD Liquid
crystal
displayer
Display on-screen menu
DVR
indication
light
DVR Light turns on when connected with DVRIndication
light
Dome
indication
light
DOME Light turns on when connected with dome

8
Other
indication
light
ALT Light turns on when connected with other devic
e
Serial port
indication
light
COM Light turns on when connected with serial port
device
Alarm
indication
light
ALARM Light turns on when connected with alarm
devices
Power
indication
light
POWER Light turns on when keyboard connected with
power and works properly.
In single surveillance mode, click Fn1 to display
PTZ and image color setup menu.
In motion detection setup, working with other
keys
Assistant
function
key
Fn1
When playback, click Fn1 to display or hide
process bar.
DVR
assistant
function
key 2
Fn2 In DVR menu, click Fn2 to select an input
method.
Tour 3Activate tour function
Single
window
display
mode
Single window display mode
Four
window
display
mode
⊞Turn to four window display mode
Nine
window
display
mode
▦Turn to nine window display mode
Sixteen
window
display
mode
▦Turn to sixteen window display mode
Record zRecord/play
Backward
/Pause
/Video backward play or pause
Play fram
e
by frame
→Play video frame by frame
Play/pause
Play
/Pause XII When DVR is in real-time surveillance mode,
system goes
to video search menu,.
DVR
function key
Fast Fast backward playback

9
backward
Slow play ►Various slow play speeds
Fast
forward Various fast play speeds
Previous Play the previous video
Next Play next video
Reverse
play frame
by frame
←
Reverse play frame by frame
Character
and
numerals
0-9
Switch between numeral/characters, click Shift
to switch.
Device ID ID Shortcut key to go to ID control point search
Device
channel
number
CAM
Control DVR channel.
Cancel current operationCancel
ESC In playback mode, click this key to go back to
dynamic surveillance mode.
Confirm ENTER Confirm current operation
In single surveillance mode, click up/down to
switch between various channels.
Modify numeral
Modify setup
©up
ªdown
PTZ control switch
In dynamic surveillance mode, click left/right
key to switch between single window display
and multiple window display mode.
Public
function
Direction
keys
§left
¨right
PTZ control switch
Previous
page PREV In dome menu, working with other keys.
Dome
menu MENU In dome menu, click this key to enter dome menu shortcut key.
Next page NEXT In dome menu, working with other keys.
Scan SCAN System pops up scan menu
Tour AUTO-PAN System pops up auto tour menu
Pattern PATTERN System pops up pattern menu
Set
preset SET System pops up preset setup menu
GOTO
preset GOTO System pops up go to preset menu
Remove
preset REMOVE System pops up delete preset menu
Iris
zoom in TELE PTZ iris zooms in
PTZ P/T PTZ operation shortcut key
Iris
zoom out WIDE PTZ iris zooms out
Focus
zoom in NEAR PTZ focus zooms in
Dome/
Matrix key
function
Wiper WIPER Shortcut key to control dome wiper operation

10
Focus
zoom out FAR PTZ focus zooms out
Lens
zoom out CLOSE PTZ lens zoom out
Lens
zoom in OPEN PTZ lens zoom in
Light LIGHT Control dome light
Joystick Assistant menu and function key operation.
AUX1-----
AUX6 Assistant key
LOG LOG Shortcut key to search log files
Assistant
function
key
LOCK LOCK Shortcut key to lock keyboard
2.3 Keyboard Ports
Please refer to Figure 2-2 for keyboard port information.
Figure 2-2
1、RJ45 network port 2、USB port 3、IR
4、RS485 port 5、RS232 port 6、Power
2.4 Port Features
RS232 can directly connect with DVR. The distance should be within 10m.
RS-485 transmission distance is 1200 m（9600bps），max 3000 m.
In level-link mode, one RS-485 port can connect with as many as 16 keyboards.
You can connect RJ45 with DVR and realize front device multiplex control via the
central management software.
2.5 Power
The keyboard use +12V DC, you can use +12V adapter included in the accessories
package. See Figure 2-3.

11
Figure 2-3

12
3 Menu Tree
Keyboard menu tree is shown as below.
MENU
Net Setting
Time Setting
Address Setting
Local
CTL Point
ID
Device Name
Device Type
Connection Type
Password
User Management
Default
Empty Point
Version
Date
Current
Connection Type
Point Information
Menu operation
Advance
Assistant
System Infor
Control point
Machine
ID
IP
RS232
RS485
Alarm Setup
Language
Backlight
Network Connection
RS232
RS485
Language

13
3.1 Input Method
Click SHIFT, you can switch between numeral/capitalized character/small character.
zc: Numeral
zA: Capitalized character
z@ Small character.
3.2 Log In
Plug in power socket, power indication light is on. You can see welcome information
in LCD.
Click Enter or SETUP, system pops up a dialogue box. Now you can input user
name and password.
The default user is admin, password is 888888.
3.3 Log out
Please exit the menu and then unplug the power cable to log out.
Network keyboard
2006-12-20 14.00.00
User name:
Password:

14
4 Menu Operation
Menu operation includes five items:
zLocal setup
zCTL point
zAdvance
zAssistant
zSystem information
There are two ways for you to operate:
zUse left/right d keys to move cursor to select property and then use up/down to
select other menu to set. For special menu setup please click ENTER to confirm
or ESC to cancel.
zUse joystick to control. The joystick works as direction keys.
4.1 Local Setup
Local setup includes the following items
zNetwork setup
zTime setup
zAddress setup
4.1.1 Network Setup
Network setup is for you to input the following information.
zIP
zSub mask
zNet gate
zPort: Default setup is 37777.
You can use left/right key to highlight corresponding item and then input numeral.
4.1.2 Time Setup
Here is for you to input local device time. Move the cursor to highlight corresponding
item and then input the numeral.
4.1.3 Address Setup
Address value ranges from 0 to 255. Default factory setup is 0.
When in level-link mode, 0 has the highest priority.
IP ADD: 192.168.000.118
Sub Mask: 255.255.255.000
Net Gate: 192.168.000.001
Port:: 377
YY: 2006 Mo: 12 DD31
HH: 14 MI: 13 SE: 22
Address setting: 0

15
4.2 CTL Point
CTL point includes the following items:
zID
zDevice name
zDevice type
zConnection type
Network connection
RS232
RS485
4.2.1 ID
Here is for you to input front device ID.
Move the cursor to highlight ID and then use input numeral.
If there is a * before the ID number (such as *3), it means that front device has
control point setup.
You can view device *3 corresponding type and name.
4.2.2 Device Name
Here is for you to input device name. You can use various input methods to give a
name to the front device,
4.2.3 Device Type
There are several options: DVR/dome/matrix/NVS. You can use left/right key to
select.
4.2.4 Connection Type
There are several options: network/RS232/RS485. You can use left/right key to
select corresponding connection type.
Please refer to the following figure for more information.
ID:*3
Dev name: DVR-1
Dev Type: DVR
Connection type: RS232

16
After you have selected connection type, please click ENTER to go on connection
setup.
Note:
All the setup here should conform to you current connection type.
If your connection type setup is RS232, you front device should connect with
keyboard via RS 232 port. Otherwise you can not use keyboard to control current
device!
All listed items here should not leave in blank, otherwise you can not use fast search
function.
After all the setup, click ESC to exit, system prompt you to save current setting.
Please click ENTER to save current setup or click ESC to exit without saving current
modification.
4.3 Advance
4.3.1 Password
Here is for you to modify password.
We recommend you input a six-bit password including numeral and characters.
Administrator can modify password for all users.
Ordinary user can only modify login account password.
4.3.2 User Management
User management is for administrator only.
Administrator can add, delete or modify user, set power for each user.
User: admin
Password: c
Confirm
Save current setup?
YES: ENTER NO: ESC

17
Ordinary user can only modify its own password and operate all functions within
power setting limit.
Guest can not operate functions. He can only review DVR video or check version
information.
4.3.2.1 Add User
Here is for you to add a new user. You can input new user name and password.
Move the cursor to highlight Pwer, please use left key to modify user property
(User/guest) and then use right key to highlight user power and click Enter to confirm.
You can see there is an icon zafter your option.
zPan ctrl
zSystem
zBAK
zSenior
4.3.2.2 Delete user
You can select corresponding user and then click ENTER to delete.
4.3.2.3 Power setting
Here you can select power for each user.
Use left and right key to highlight correspond right and click ENTER to confirm..
Icon {means current user does not have this right
Icon zmeans current user has current right.
In the following image, current user is 1 and this account can operate Pan Ctrl and
system function, BAK and senior right is disabled.
4.3.3 Set Local as Default
Here is for you to restore factory default setup.
Note: when you operate this function, please be careful!
Add user
Delete user
Power setting
Set Local as Default?
Yes: ENTER No: Esc
User
Password
Confirm
Pwer:User c
User:1 Pan Ctrl z
Pwer:User System z
BAK {
Senior {

18
4.3.4 Empty Control Point
Here is for you to delete all control point information.
Click ENTER to clear all.
4.4Assistant Setup
Assistant setup includes the following items:
4.4.1 Backlight Setup
You can open LCD backlight. It will last for ten minutes.
When you log in the next time, backlight automatically turns on
4.4.2 Alarm Setup
You can turn on alarm function.
4.4.3 Language
There are three options: English/Simplified Chinese/Traditional Chinese.
4.4.4 Auto Lock
Here is for you to set auto lock interval. There are four options:10/30/60/close(Unit:
minute).
When keyboard is inactive for specified interval, it becomes locked. You need to log in
again to operate keyboard.
Close means disable auto lock function, keyboard always maintain active.
4.5System Information
System information includes the following items.
zVersion: here is to display system version.(for reference only)
zDate: here is to display system released date(for reference only)
zConnection type: here is to display current connection type.
You can click ENTER to view type (serial port or network)
zPoint information
4.5.1 Search Point
You can input either of the following information to search one device. System can
automatically connect with that device and you can use keyboard to control it.
Clear ALL CTL Point?
Yes: ENTER No: Esc
Back light: ON
Alarm: ON
Language: English
Version: 1.10
Date: 2006-12-29
Connection type: Network
Point Info: 0

19
Current Dev：Dome
RS232：3
ID：3
You can click ENTER to go to the above menu and then input corresponding property
to search.
E.g.: If you want to search a device of ID3. Input ID as 3 and then click ENTER to
confirm.
System pops up the following interface, ID 3 is a dome and its RS232 address is 3.
System automatically connects the dome. Now you can use keyboard to control
current dome.
Note: when you use keyboard to control DVR, please click ID and then click ESC to
go back to previous menu.
When you use keyboard to control other device, click ESC to go back to previous
menu.

20
5 Keyboard Control DVR
5.1 Serial Port Connection
5.1.1 RS232 Serial Port Connection
Use one RS232 cable to connect DVR serial port and keyboard serial port together.
DVR address number ranges from 1 to 255，please refer to DVR manual for more
information.
5.1.2 Via RS485 Connection
One RS232 port can only connect with one DVR.
You need to use RS 485 port once you want to control more than one DVRs.
You can user one standad RS485 to RS 232 box connect with DVR 232 port.
RS 485 port pins definition：
PIN1：+5V power supply
PIN2：Alarm output
PIN3：RS485 A line
PIN4：Blank
PIN5：GND
PIN6：Alarm input
PIN7：RS485 A line
PIN8：RS485 B line
PIN9：RS485 B line
DV
R
RS232 cable
PIN1PIN5
PIN6PIN9
