Bathroom Vanity Assembly Manual
V5009.24 / V5009.32 / V5009.39 / V5009.47
Models:
Shop At - XtremeAIRUSA.com

Page 2
A: ASSEMBLE MAIN BODY
Toggle Bolts
(Provided)
Pencil
1/8” bit
1/2” bit
Stud Finder
Power Drill with Screw Bit
#2. Screw in the long black screws
to all applicable places
#4. Place bottom back strip into
position on the base
TOOLS & MATERIALS NEEDED
2” Screws
Kitchen & bath Silicon Caulk
Level
Gloves
Tape Measure
Philip Screw Driver
#3. Insert wooden dowels
#1. The main body should be laid out as above

Page 3
#5. Place side panel into
position with the base
#6. Place the 3 remaining strips
into positions on the side panel
#7. Line up the other side
panel and put into position
B: ASSEMBLE TOP DRAWER
#11. Screw in the long black
screws to all applicable places
#8. Insert Cam locks into all their holes
and turn clockwise to secure into place
#9. Screw in metal brackets to the
inside top rear corners of the box
#10. The top drawer should be laid out as above

Page 4
#12. Place the two back walls of
the top shelf into place
#13. Place one side wall
of shelf into place
#14. Place the other side
wall of the shelf into place
#15. Place the shelf box onto the
front panel
#16. Insert Cam locks into all
their holes and turn clockwise to
secure into place
#17. Put the “U” gasket in
position and screw into
shelf frame
C: ASSEMBLE BOTTOM DRAWER
#19. Screw in the long black
screws to all applicable places
#18. The bottom drawer should be laid out as above

Page 5
#22. Place the other side wall
of the shelf into position
#23. Place the shelf box onto the
front panel
#24. Insert Cam locks into all their holes
and turn clockwise to secure into place
D: INSTALL DRAWER RAILINGS
#25. Line up the railings with the pre-drilled
holes in the side walls and screw into place
#20. Place the back wall of the shelf
into place
#21. Place one side wall
of shelf into place

Page 6
E: INSTALLATION- MOUNT THE VANITY ON THE WALL
Step 1. Use a level to mark the
height of the cabinet to be mounted
(recommended height is 36”
including countertop, check and
verify with your local code)
Step 2A. Remove 2 drawers
then lift and hold the cabinet
up to the mark.
Step 4. Insert and prepare toggle bolts.
Step 5. Add silicon to the back
of cabinet to help secure it to
the wall (highly recommended)
Step 8. Use stud finder to find the
stud and mark all places in both
the top and bottom rear panels
Step 2B. While the cabinet is holding
in place, use a 1/8” drill bit to drill
through the wall. Make sure within
the slot of the metal bracket only.
Step 3. Use the 1/2” drill bit to
enlarge the 1/8” drilled holes
(2 locations)
Step 6. Line up and insert
toggle bolts into the wall
by tapping them in
Step 7. Tighten the toggle bolts.
Make sure the cabinet is lining up
with the straight mark.

Page 7
Step 9. Use 2” screws to
screw all stud found marks.
Step 11. Install the countertop
Step 12. Install the faucet & plumbing*
Step 14. Screw front of drawer rails
into bottom of drawer.
Step 10. Add silicon to the top of
the cabinet to secure the countertop
(highly recommended)
Step 13. Re Install drawers.
A. Pull out railing and place drawer
on
B. Insert pins on back of railings into
back of drawer.
C. Holes on bottom sides of drawer
will go into the bolts sticking up
from railings
*This manual is intended for assembly and installation of the vanity cabinet only. XtremeAIR is not
responsible for anything that may arise from plumbing or faucet.
