XU1 XBLK-0185 User manual

Ozito Industries Pty. Ltd. 25 Fox Drive, Dandenong South, Victoria, Australia 3175
Telephone: [phone] (Aus), 0508 069 486 (NZ)
XU1 Power tools
XBLK-0185 1121
Operating Instructions
XBLK-0185
18V18V
Cordless Cordless
Blower KitBlower Kit

SAFETY
INSTRUCTIONS
1
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING! Read all safety
warnings and all instructions. Failure
to follow the warnings and instructions may
result in electric shock, re and/or serious
injury.
Save all warnings and instructions
for future reference. The term “power
tool” in all of the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered and
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while drugs,
alcohol or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always
wear eye protection. Personal protective equipment
such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will
reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the o󰀨-position before
connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying
power tools with your nger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe injury
within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the switch does
not turn it on and o󰀨. Any power tool that cannot
be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may a󰀨ect the power tools operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions and in the manner intended
for the particular type of power tool, taking
into account the working conditions and the
work to be performed. Use of the power tool for
operations different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specied by
the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of re when used
with another battery pack.
b) Use power tools only with specically
designated battery packs. Use of any other
battery packs may create a risk of injury and re.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a re.
Read instruction manual
DESCRIPTION OF SYMBOLS
Warning
V Volts
Hz Hertz
~ Alternating current
WWatts
dc/ Direct current
Ø Diameter
mA Milliamperes
noNo load speed
/min Revolutions or reciprocation per minute
Double insulated
Regulator compliance mark
Transformer Energy Rating (MEPS)
Do not incinerate
Cut-out protection
Indoor use only
Lithium Ion-battery
Sound power level
Recycle battery
Do not put in rubbish
Do not use in the rain or leave the tool
outdoors while raining
Do not get battery wet
Do not use or store battery in temperatures
exceeding 50°C
Wear hearing protection
Wear safety glasses
Keep bystanders away. Do
not operate whilst people
especially children or pets
are in the area.

2
BLOWER SAFETY
WARNINGS
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, ush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery
may cause irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modied. Damaged or modied
batteries may exhibit unpredictable behaviour resulting in
re, explosion or risk of injury.
f) Do not expose a battery pack or tool to re
or excessive temperature. Exposure to re or
temperature above 130°C may cause explosion.
g) Follow all charging instructions and do
not charge the battery pack or tool outside
the temperature range specied in the
instructions. Charging improperly or at temperatures
outside the specied range may damage the battery and
increase the risk of re.
6) Service
a) Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the safety of
the power tool is maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed by the
manufacturer or authorized service provider.
BATTERY & CHARGER
SAFETY WARNINGS
BEFORE USING THE CHARGER OR
BATTERY READ ALL INSTRUCTIONS
AND CAUTIONARY MARKINGS ON THE
CHARGER, BATTERY PACK AND THE
PRODUCT USING THE BATTERY PACK. DO
NOT LOSE THESE SAFETY INSTRUCTIONS.
Battery warnings
1. The battery pack is not fully charged out of the carton. First
read the safety instructions and then follow the charging
notes and procedures.
2. For optimum battery performance avoid low discharge
cycles. Charge the battery pack frequently.
3. Use and store the battery pack in dry conditions with low
humidity between 0-50°C, ideally at 15°C. Avoid exposing
battery pack and charger to direct sunlight.
4. Do not keep battery pack in places where temperatures are
liable to reach over 50°C, such as in a car, metal shed or
similar that is in direct sunlight.
5. Do not ignite the battery pack or expose it to re. There is a
risk of explosion!
6. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most common
cause of exhaustive discharge is long-term storage and
continued use of low-charge batteries. Always store the
battery with some charge. Charge the batteries every 2-3
months to restore charge. Stop working as soon as the
performance of the battery falls noticeably or the electronic
protection system triggers.
7. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside the
battery housing without this overheating being apparent
externally.
8. Avoid damage and shocks. Do not use batteries which
have been dropped from a height of more than one meter
or strong external impact, even if the housing of the battery
pack appears to be undamaged. The battery cells inside
the battery may have suffered serious damage.
9. If the battery pack suffers overloading and overheating,
the integrated protective cut-off will switch off the
equipment. Do not press the ON/OFF switch on the tool if
the protective cut-off has actuated. This may damage the
battery pack. Allow the battery to cool to room temperature
before use.
10. Use only original battery packs. The use of other batteries
may result in injuries, explosion and a re risk.
11. Protect your rechargeable battery against moisture, rain
and high humidity. Moisture, rain and high humidity can
cause dangerous cell damage. Never charge or use
batteries which have been exposed to moisture, rain or
high humidity.
12. Never attempt to open the battery pack for any reason. If
the plastic housing of the battery pack is damaged, do not
use the battery.
13. When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns or a re.
14. Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If accidental contact occurs, ush
with water and seek medical help immediately. Liquid
ejected from the battery may cause irritation or burns.
15. Do not use a battery pack or tool that is damaged or
modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
16. Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130
°C may cause explosion.
17. Never service damaged battery packs. Service of battery
packs should only be performed by the manufacturer.
18. Do not disassemble Battery. This may result in a risk of
electric shock, electrocution or re.
Charger and the charging process warnings
1. Please check the data marked on the rating plate of the
battery charger. Ensure to only connect the battery charger
to a power supply with the voltage marked on the rating
plate.
2. Protect the battery charger and its cable from damage
and sharp edges. Have damaged cables repaired by an
authorised service agent before use.
3. Keep the battery charger, batteries and the cordless tool
out of children’s reach.
4. Do not use damaged battery chargers.
5. Do not use the supplied battery charger to charge other
cordless tools. Only charge XU1 rechargeable batteries
with an XU1 Charger.
6. The battery pack may become warm during use. Allow
the battery pack to cool to room temperature before
commencing with the charging.
7. Do not over-charge batteries. Overcharging batteries
may result in a risk of re. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partly charged battery pack will result in over-charging and
cell damage. Do not leave fully charged batteries in the
charger.
8. Charge the battery pack in dry conditions with low humidity
between 0-25°C. Avoid exposing battery pack and charger
to direct sunlight. Charge indoors only.
9. Do not use batteries which have suffered deformation
during the charging process or shows any other signs
of abnormalities including, excessive curvature of the
housing, gassing, hissing or cracking.
10. Never fully discharge the battery pack. A complete
discharge of the battery pack will lead to premature
ageing of the battery cells.
11. Never charge the batteries unsupervised.
12. Do not cover or place any object on top of the charger,
place the charger away from heat sources.
13. To reduce risk of damage to the electric plug and cord,
pull by the plug rather than the cord when disconnecting
the charger.
14. Make sure the cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress.
15. An extension cord should not be used unless necessary.
Use of an improper extension cord could result in the risk
of re, electric shock or electrocution.
16. Do not disassemble charger. This may result in a risk of
electric shock, electrocution or re.
The appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction.
Young children should be supervised to ensure that
they do not play with the appliance.
• Always remove the plug from the mains socket before making any
adjustments or performing maintenance.
• To reduce the risk of re or explosion, never spray ammable liquids
in a conned area. If sparks come into contact with petrol vapours or
solvents, they may ignite the vapours and cause a re or explosion.
• Always wear adequate protective clothing when operating the blower
to avoid injuries to face, eyes, hands, feet, head or hearing. Use
safety glasses or a face shield, high boots or sturdy shoes, long
trousers, work gloves, a hard hat and ear defenders.
• Do not start the tool when it is upside down or when it is not in the
operating position.
• Switch the motor off and remove the battery when the tool is not
being used, left unattended, being cleaned or being moved from one
place to another.
• Do not operate the tool near people, especially children or pets. Turn
it off if they get too close. Maintain a safe distance of at least 5m
from other people when using the tool.
• Never direct the blower direction nozzle towards bystanders or pets.
Never blow debris in the direction of bystanders or pets. The operator
is responsible for accidents or hazards occurring to other people or
their property.
• Do not handle the battery or the tool with wet hands and do not use
the tool in the rain.
• Keep all the air intakes and the blower tube free of dust, lint, hair and
other material that may cause a reduction in air ow.
• Keep a balanced and stable stance while using the tool. Do not
switch on the tool in enclosed or poorly ventilated spaces or in the
presence of inammable and/or explosive substances such as
liquids, gasses and powders.
• Do not get distracted and always concentrate on what you are doing.
Use common sense. Never operate the tool when you are tired, sick
or under the inuence of alcohol or other drugs.
• Do not operate this appliance with long loose hair or loose tting
jewellery. Tie long loose hair back and remove loose tting jewellery.
• Only operate the tool during broad daylight or with adequate articial
light.
• When the tool is not in use, store it in a dry place and out of reach
of children.
• Only use the tool according to the instructions given in this manual.
• Check regularly that the screws are tight.
WARNING! When servicing, use only
identical replacement parts. Use of any other
parts may create a hazard or cause product
damage. To ensure safety and reliability, all
repairs should be performed by a qualied
service technician.
WARNING! This appliance is not intended
for use by persons (including children)
with reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of
the appliance by a person responsible for
their safety. Children should be supervised
to ensure that they do not play with the
appliance.
17. To reduce risk of electric shock, unplug the charger from
the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
18. Do not use the cordless tool or the battery charger near
vapours and inammable liquids.
19. Keep away from readily combustible material whilst
charging.
WARNING! Before connecting a charger
to a power source (mains switch power
point receptacle, outlet, etc.) be sure that
the voltage supply is the same as that
specied on the nameplate of the charger.
A power source with a voltage greater than
that specied for the charger can result in
serious injury to the user, as well as damage
to the charger. If in doubt, do not plug in the
charger. Using a power source with a voltage
less than the nameplate rating is harmful to
the charger.

“CLICK”
-
-
a
b
ChargingCharged
ChargingCharged
Press
ChargingCharged
ChargingCharged
Press
“CLICK”
a
b
-
-
AB
E
C
D
1. Blower Tube
2. Blower Tube Release
3. On/Off Switch
4. Soft Grip Handle
5. Air Intake Vent
6. Battery Seating
7. Battery Release Button
8. Battery Charge Indicators
9. Charge Indicator Button
10. Charger Adaptor
11. Charger LED Indicators
12. Charger Cradle
3
4
5 6
132
7 8 9
FG
HJ
12
11
10
I

Voltage: 18V
No Load Speed: 12,500/min
Max. Air Speed: 210km/hour
Battery: 1.5Ah Li-Ion
Charge Time: 4-5 Hours
Charger Input: 100-240VAC, 50-60Hz, 14.5W
Charger Output: 21V DC, 400mA
Tool Weight: 1.62kg
SPECIFICATIONS OPERATION
4
Inserting & Removing the Battery
1. To insert, align the ribs of the battery with the battery
recess and slide the battery in so that it clicks into
place. FIG. F.
2. To remove, rst press and hold the battery release tab
(a), then side the battery out (b). FIG. G.
Switching On and O󰀨
To turn the blower ON, press the on/off switch to the
“ I ”(ON position). FIG. H.
To turn the blower OFF, press the on/off switch to the
“O”(OFF position). FIG. I.
Blowing
The blower is ideal for blowing leaves, grass clippings
and other debris.
Hold the blower rmly, turn the switch on, point the jet
of air in front of you and move forward slowly. Move the
blower from side to side, with the tube several inches
above the ground. FIG. J.
Be careful where you point the jet of air as it can
move heavy material and cause injury or damage to
bystanders.
Note: Be aware of other people and animals in the
area where you are to be operating the blower.
Note: Avoid collisions with hard objects which could
damage your blower.
PROPER USE
This tool is intended for use in a DIY (Do It Yourself)
context or for hobbyist purposes. It is not built for
continuous daily use in a trade or professional capacity.
Before using the machine, carefully read these
instructions, especially the safety rules to help ensure
that your machine always operates properly.
Before attempting to operate the machine, familiarise
yourself with the controls and make sure you know how
to stop the machine quickly in an emergency.
Save these instructions and the other documents
supplied with this machine for future reference.
ASSEMBLY
Charging the Li-Ion Battery
WARNING! Ensure the tool is turned off
and battery disconnected before performing
any of the following operations. Wear gloves,
blades are sharp.
NOTE: The battery will not develop a memory, it does
not have to be fully discharged before recharging.
1. Connect the charging adaptor into the mains power
outlet.
2. The charger LED will ash green showing power is
being supplied to the charger.
3. With the battery sitting on a at surface, align the
raised ribs on the battery with the recess in the
charger cradle and slide onto the battery ensuring a
rm connection. FIG. C.
4. The charger LED will illuminate red signifying that the
battery is charging. Battery is fully charged after 4-5
hours, green LED will illuminate.
5. When removing the charger from the battery, rst
press the battery release tab, then slide the cradle from
its position. FIG. D.
WARNING! Do not use any attachments
or accessories not recommended by the
manufacturer of this product, as it can result in
serious personal injury.
WARNING! To reduce the risk of electrical
shock, we recommend the use of a residual
current device rated 30mA or less.
Charger LED Indicators
LED Indicator Situation
GREEN (Flashing) Stand By (no battery
pack is inserted)
RED (Illuminated) Battery is charging
(low charge)
GREEN (Illuminated) Battery is fully
charged.
GREEN & RED (Flashing) Battery is faulty
GREEN & RED
(Illuminated)
Battery is too hot.
Remove battery
from charger a let
cool. Insert battery
again when at room
temperature
BATTERY
Fitting the Blower Tube
1. Remove assembly screw from underside of motor
housing and put aside. Align the tube with the outlet
of the blower. FIG. A.
2. Push the blower tube onto the blower until the tube
release clicks into place. Ret assembly screw
removed in step 1. FIG.B.
Battery Charge Indicator
The included battery is equipped with a battery charge
indicator to show the state of the battery charge.
Press the charge indicator button and check to see
which LED light is illuminated. FIG. E
1 GREEN LED indicates that the battery has only a
low charge and requires charging.
2 GREEN LEDs indicate that the battery has mid
state of charge.
3 GREEN LEDs indicate that the battery is fully
charged.
Battery Protection System
The tool is equipped with the battery protection system,
which helps to ensure a long service life.
The output power automatically cuts off during operation
when the tool and battery are placed under the following
situations:
• When tool is overloaded:
If this occurs, turn off the tool and let it cool down for
10 mins, remove the cause of overload, then resume
operation.
• When the remaining battery capacity
becomes low:
Recharge the battery pack.
WARNING! Never use the blower unless
the blower tube is properly tted.
Allow at least 3 hours of charge time before initial use
of the battery. Charge the battery pack only with the
charger provided. The battery should be charged in a
cool dry place. It will take 2 to 3 charging/discharging
cycles before the battery achieves maximum run time
capacity.
WARNING! Dress properly. Do not wear
loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts.
Loose clothes, jewellery or long hair can be
caught in moving parts.

MAINTENANCE
WARRANTY
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR
WARRANTY. PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY
QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and remedies which are available to you at
law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to
a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty, however, where you have
suffered any additional direct loss as a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months from the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will be replaced in accordance with the terms of this warranty. Warranty
excludes consumable parts, for example: Blower tube.
WARNING
The following actions will result in the warranty being void.
• Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specied on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
XU1
Australia/New Zealand (Head Ofce)
Ozito Industries Pty. Ltd. 25 Fox Drive, Dandenong South, Victoria, Australia 3175
5
WARNING! Ensure the tool has completely
stopped and battery is disconnected before
performing any of the following operations.
CARING FOR THE
ENVIRONMENT
Power tools that are no longer usable should
not be disposed of with household waste but
in an environmentally friendly way.
Please recycle where facilities exist. Check
with your local council authority for recycling
advice.
Recycling packaging reduces the need for
landll and raw materials.
Reuse of recycled material decreases
pollution in the environment. Please recycle
packaging where facilities
exist. Check with your local council authority
for recycling advice.
Cleaning
• We recommend that you clean the appliance
immediately after you use it.
• Keep the safety devices free of dirt and dust as much
as possible. Wipe the equipment with a clean cloth.
• Keep air intake clean and air vents free of debris to
avoid overheating the motor.
• Do not use cleaning agents to clean the plastic
parts of the tool. A mild detergent on a damp cloth is
recommended. Water must never come into contact
with the tool.
• If the blower vibrates abnormally, stop motor
immediately. Abnormal vibration usually indicates a
mechanical problem. Continued operation could lead
to injury or damage.
• No lubrication is necessary as the motor is equipped
with lifetime lubricated bearings.
Storage
• Store the tool in a dry location which is not accessible
to unauthorised persons.
Note: Ozito Industries will not be responsible
for any damage or injuries caused by the
repair of the Blower by an unauthorised
person or by mishandling of the Blower.
This tool is designed for DIY use - use in
commercial or industrial environments will
void the warranty.
Problem Cause Remedy
Blower is not starting Possible clogging Clean the blower tube and
blower outlet of any leaves
or debris
Battery is low in charge Charge battery
Battery not inserted fully Insert battery pack fully
Blower is not operating at
full capacity
Possible clogging Clean the blower tube and
blower outlet of any leaves
or debris
Motor stop while operating Battery has no power Charge battery
TROUBLESHOOTING
