XU1 XSD-363 User manual

25 Fox Drive, Dandenong South, Victoria, Australia 3175
Telephone: [phone]
XU1 Power tools
XSD-363 0721
Operating Instructions
XSD-363
3.6V3.6V
CordlessCordless
ScrewdriverScrewdriver

A B
E F
C
D
1. Battery Level Indicator
2. Handle Lock
3. Rotating Handle
4. Forward/Reverse Selector
5. Charging Indicator
6. Charging Port
7. On/Off Trigger
8. Worklight Switch
9. LED Worklight
10. Magnetic Hex Chuck
11. Phillips Head Driver Bit (PH1)
12. Phillips Head Driver Bit (PH2)
13. Square Head Driver Bit (SQ2)
14. Flat Head Driver Bit (#5)
3
3
4
5
6
7
10
9
1 2
8
11 12 13 14

Voltage: 3.6V
Battery Capacity: 1.5Ah Li-Ion
Chuck Size: 6.35mm (Hex)
No Load Speed: 200/min
Max. Torque: 3Nm
Charge Time: 3-5hours
Tool Weight: 0.38kg
SPECIFICATIONS OPERATION
4
CONTROLS
On/O󰀨 Trigger
1. Squeeze the On/Off Trigger to start the screwdriver.
2. To stop the screwdriver, release the On/Off Trigger.
Note: This screwdriver does not have variable speed.
Note: The On/Off Trigger can be locked by pushing the
Forward/Reverse Selector button into middle setting.
LED Worklight
1. Switch on the LED worklight by pressing the
Worklight Switch. FIG. C
2. Press the switch again to turn the light off.
Forward Reverse Selector
1. For forward rotation, push the Forward/Reverse
Selector towards the left side of the tool. FIG. D
2. For reverse rotation, push the Forward/Reverse
Selector towards the right side of the tool.
Rotating Handle
The ear handle of the screwdriver can be rotated
so that the tool can be operated in 2 different
congurations to assist with your job requirements.
The in-line orientation allows you to drive and remove
screws in hard to reach areas.
1. To operate the screwdriver in the in-line orientation,
press the Handle Lock Button (FIG. E) and then
rotate the Rear Handle. FIG. F
2. To operate the screwdriver in the angled position,
press the Handle Lock Button and then rotate the
Rear Handle.
Driving and Removing Screws
1. Depress and release the On/Off Trigger to ensure it
is not locked.
2. Check the Forward/Reverse Selector is in the desired
setting.
3. Ensure the workpiece is secured to stop it turning
whilst driving.
4. Hold the tool rmly and then press the On/Off Trigger.
5. Once complete, release the On/Off Trigger.
Note: Do not force the tool or apply side pressure to
elongate the hole. Let the tool do all the work.
PROPER USE
This tool is intended for use in a DIY (Do It Yourself)
context or for hobbyist purposes. It is not built for
continuous daily use in a trade or professional
capacity.
Before using the machine, carefully read these
instructions, especially the safety rules to help ensure
that your machine always operates properly.
Before attempting to operate the machine, familiarise
yourself with the controls and make sure you know
how to stop the machine quickly in an emergency.
Save these instructions and the other documents
supplied with this machine for future reference.
SETUP
Charging Your Battery
1. Plug the charging cable into the Charging Socket at
the bottom of the tool handle. FIG. A
2. Plug the charging adaptor into the power supply.
3. The Charging Indicator on the front of the tool
handle will illuminate, indicating the battery is
charging.
4. The battery will take 3-5 hours to charge.
Note: The battery status can be checked by pressing
the Battery Level Indicator. FIG. B
WARNING! Do not overcharge the tool.
Never leave the tool unsupervised while
charging.
WARNING! This charger must only be
used to charge product XSD-363 (Model:
WJA-Y050500500W).
Fitting Driver Bits
1. Slide the required driver bit into the Magnetic Hex
Chuck.
2. To remove the driver bit, simply pull the bit out of the
Magnetic Hex Chuck.
WARNING! Do not handle driver bits or
other accessories without gloves as they
are sharp and can become hot after use.
WARNING! The power supply for this
charger should be protected by a residual
current device (rated 30mA or less).

MAINTENANCE
Cleaning
Your tool has been designed to operate over a long
period of time with a minimum of maintenance. That
said, continuous satisfactory operation depends upon
proper tool care and regular cleaning.
1. Regularly clean the ventilation channels in the tool
using a soft brush or cloth.
2. Keep ventilation slots of the tool clean at all times.
If possible prevent foreign matter from entering
the vents. After each use, blow air through the tool
housing to ensure it is free from all dust particles
that may build up.
WARNING! Excessive build up of dust
particles may cause the tool to overheat
and fail.
3. If the enclosure of the tool requires cleaning, use
a soft, damp cloth only. Do not use solvents or
abrasive cleaners.
WARNING! Never immerse any part of
the tool in liquid.
Supply Cords
If replacement of the supply cord is necessary, this has
to be done by a certied electrician in order to avoid a
safety hazard.
Note: XU1 will not be responsible for any damage
or injuries caused by the repair of the tool by an
unauthorised person or by mishandling of the tool.
WARRANTY
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR
WARRANTY. PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF PURCHASE
AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY
QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and remedies which are available to you at
law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to
a major failure.
Generally you will be responsible for all costs associated with a claim under this warranty, however, where you have
suffered any additional direct loss as a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months from the original date of purchase and is intended for DIY
(Do It Yourself) use only. If a product is defective it will be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: driver bits.
Ozito Industries Pty. Ltd.
25 Fox Drive, Dandenong South, Victoria, Australia 3175
WARNING
The following actions will result in the warranty being void.
• Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specied on the tool.
• If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5
WARNING! Ensure the tool is turned off
and disconnected from the power supply
before performing any of the following
operations.

SAFETY
INSTRUCTIONS
1
GENERAL
POWER TOOL
SAFETY
WARNINGS
ELECTRICAL
SAFETY
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and
instructions for future reference.
The term “power tool” in all of the warnings
refers to your mains-operated (corded)
power tool or battery-operated (cordless)
power tool.
WARNING! Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate power tools in
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c. Do not expose power tools to rain or
wet conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
f. If operating a power tool in a
damp location is unavoidable, use
a residual current device (RCD)
protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the inuence of drugs, alcohol
Description of symbols
CARING FOR THE
ENVIRONMENT
Power tools that are no longer usable
should not be disposed of with household
waste but in an environmentally friendly
way.
Please recycle where facilities exist.
Check with your local council authority for
recycling advice.
Check with your local council authority for recycling
advice.
Recycling packaging reduces the need
for landll and raw materials. Reuse of
recycled material decreases pollution in
the environment. Please recycle packaging
where facilities exist.
WARNING! When using mains-powered
tools, basic safety precautions, including the
following, should always be followed to reduce
risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you
know how to switch the tool off in an emergency,
before operating the tool.
Save these instructions and other documents
supplied with this tool for future reference.
This tool has been designed for 230V and
240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools
are interchangeable for Australia and New Zealand.
Using an Extension Lead
Always use an approved extension lead suitable
for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and
ageing. Replace the extension lead if damaged or
defective.
When using an extension lead on a reel, always
unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or
which is damaged or defective may result in a risk of
re and electric shock.
The power supply for this product should be
protected by a residual current device (rated at
30mA or less). A residual current device reduces the
risk of electric shock.
Read instruction manual
Warning
Regulatory Compliance Mark (RCM)
VI
Transformer Energy Rating (MEPS)
Polarity
Double Insulated
Do not put in the rubbish
For indoor use only
Direct Current (DC)
V Volts
/min Revolutions per minute
n0No load speed
Nm Newton metres
Hz Hertz
W Watts
A Amperes

WARNING! The appliance is not
to be used by persons (including
children) with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they have been given supervision or
instruction.
Young children should be supervised
to ensure that they do not play with the
appliance.
Before connecting a tool to a power source (mains
switch power point receptacle, outlet, etc.) be sure
that the voltage supply is the same as that specied
on the nameplate of the tool. A power source with
a voltage greater than that specied for the tool
can result in serious injury to the user, as well as
damage to the tool. If in doubt, do not plug in the
tool. Using a power source with a voltage less than
the nameplate rating is harmful to the motor.
•Hold power tool by insulated gripping
surfaces, when performing an
operation where the drilling/screwing
accessory may contact hidden
wiring or its own cord. Accessories
contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give
the operator an electric shock.
•Do not use this tool for prolonged
periods of time. Take regular breaks. Use
gloves to provide extra cushioning in order to
avoid any injury from the vibrations of the tool.
WARNING! Some dust created by power
sanding, sawing, grinding, drilling and other
construction activities contain chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other
masonry products
• Arsenic and chromium from chemically treated
timber
Your risk from exposure to these chemicals varies,
depending on how often you do this type of work. To
reduce your exposure to these chemicals: work in a
well ventilated area and work with approved safety
equipment, such as dust masks that are specially
designed to lter out microscopic particles.
2
or medication. A moment of inattention
while operating power tools may result in serious
personal injury.
b.Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, gloves, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c. Prevent unintentional starting.
Ensure the switch is in the o󰀨-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying power
tools with your nger on the switch or energising
power tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e. Do not overreach. Keep proper
footing and balance at all times.
This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from
frequent use of tools allow you to
become complacent and ignore tool
safety principles. A careless action can
cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will do the
job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the
switch does not turn it on and o󰀨. Any
power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c. Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of starting the
power tool accidentally.
d. Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are dangerous
in the hands of untrained users.
e. Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
g. Use the power tool, accessories
and tool bits etc. in accordance
ADDITIONAL
SAFETY
WARNINGS FOR
SCREWDRIVERS
with these instructions, taking into
account the working conditions and
the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
h. Keep handles and grasping surfaces
dry, clean and free from oil and
grease. Slippery handles and grasping
surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type of battery
pack may create a risk of re when used with
another battery pack.
b) Use power tools only with
specically designated battery
packs. Use of any other battery packs may
create a risk of injury and re.
c) When battery pack is not in use, keep
it away from other metal objects,
like paper clips, coins, keys, nails,
screws or other small metal objects,
that can make a connection from one
terminal to another. Shorting the battery
terminals together may cause burns or a re.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs, ush
with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that
is damaged or modied. Damaged or
modied batteries may exhibit unpredictable
behaviour resulting in re, explosion or risk of
injury.
f) Do not expose a battery pack or tool
to re or excessive temperature.
Exposure to re or temperature above 130 °C
may cause explosion.
g) Follow all charging instructions and
do not charge the battery pack or
tool outside the temperature range
specied in the instructions. Charging
improperly or at temperatures outside the
specied range may damage the battery and
increase the risk of re.
6) Service
a) Have your power tool serviced by a
qualied repair person using only
identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery
packs. Service of battery packs should only
be performed by the manufacturer or authorized
service provider.
