Yamaha CD-S3000 User manual

G
Printed in Malaysia ZK20410
© 2013 Yamaha Corporation
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
ИНСТРУКЦИЯ ПО ЭКСПЛУАЦИИ
Compact Disc Player
Lecteur Compact Disc

A Living Tradition in Sound
A piano comes into this world through the perfect synergy of advanced technical
skill and artistry. Such a piano can create sound that truly reflects the player’s
feelings.
The final stage in piano production is called “voicing”. It is here that the
instrument is given its soul.
A highly skilled expert concentrates his mind and sensitivity on the sound of each
key, finely adjusting the dynamic feel of the hammers, bringing the tone and
vibrancy of all 88 keys together perfectly; a truly stunning achievement.
It is a quality of sound that can only be determined by an astute, sensitive ear. We
apply this very same concept to the manufacture of our audio products. The
technician performs exhaustive listening tests and every component is considered,
in order to finally achieve the ideal sound.
Yamaha’s tradition of audio quality stretches back over 125 years, and continues to
live on in all Yamaha products today.

NP-S2000
A-S2000
CD-S2000
Soavo-1
NS-10M
Excellence in Audio Achievement
First HiFi System introduced in 1920
We introduced numerous HiFi components
(turntables, FM/AM tuners, integrated
amplifiers, preamplifiers, power amplifiers
and speakers) in 1955 - 1965.
Natural Sound Speaker Series introduced
in 1967
NS-20 Monitor Speaker
CA-1000 Integrated Amplifier
Featuring A-Class operation, the CA-1000 set
the standard for integrated amplifiers.
NS-690 Natural Sound Speaker
NS-1000M Monitor Speaker
A truly legendary speaker still revered by HiFi
enthusiasts.
B-1 Power Amplifier
An innovative power amp that used vertical FETs in all
stages.
C-2 Control Amplifier
Received top prize at the Milan International Music
and HiFi Show.
NS-10M Studio Monitor Speaker
Became of the most popular studio monitors
in the world.
A-1 Integrated Amplifier
PX-2 Turntable
Yamaha’s first straight arm turntable.
B-6 Power Amplifier
Pyramid-shaped power amplifier.
GT-2000/L Turntable
First CD Player (CD-1) introduced in 1983
B-2x Power Amplifier
MX-10000 Power Amplifier and
CX-10000 Control Amplifier
Redefined the capabilities of separate components.
AX-1 Integrated Amplifier
GT-CD1 CD Player
MX-1 Power Amplifier and
CX-1 Preamplifier
Soavo-1 and Soavo-2 Natural Sound
Speaker Systems
A-S2000 Stereo Amplifier and
CD-S2000 Super Audio CD Player
NP-S2000 Network Player
English

4En
◆Full-stage balanced signal transmission beginning with the DAC
achieves the ultimate in CD reproduction
◆Independent power supplies with digital and analog completely
separated
◆Exclusive Yamaha loading mechanism and high precision CD drive
◆Left-right symmetrical design with rigid, stable construction
◆Pure Direct
◆Super sound from Super Audio CDs
◆Heavy feet with newly-developed antivibration spikes
◆DSD playback via 192 kHz, 24-bit USB DAC
■Supplied accessories
Please check that you have received all of the following parts.
• Power cable
• Remote control
• Batteries (AAA, R03, UM-4) (×2)
• Stereo pin cable
• SAFETY BROCHURE
■About this manual
•yindicates a tip for your operation.
• The color of images in this manual may vary from the original.
• Read the “SAFETY BROCHURE” before using this unit.
Contents
Controls and functions.......................................................................................................................................... 6
Connections.......................................................................................................................................................... 18
Playback of music files stored on a PC.............................................................................................................. 22
Specifications ....................................................................................................................................................... 26
Playable disc format............................................................................................................................................ 27
Troubleshooting................................................................................................................................................... 29

CONTROLS AND FUNCTIONS
5En
Controls and functions
In this chapter, you will learn the controls and functions of CD-S3000.

6En
Controls and functions
■Front panel (pages 6 to 9)
1STANDBY/ON/OFF switch
Turns on or off this unit.
STANDBY/ON (upper position):
In this position, you can select STANDBY or ON,
using the pCD key on the remote control.
OFF (lower position):
The power of this unit is turned off.
• When you turn on this unit, it will take a few seconds
before this unit can reproduce sound.
• If this unit is not operated for 30 minutes with no audio
signal detected, it goes to STANDBY mode (page 15).
• If you disconnect the power cable from the AC outlet and
connect it again when this unit is in STANDBY mode, the
power of the unit is turned on (page 20). If the unit is not to
be operated for a long time, set the STANDBY/ON/OFF
switch to OFF.
2STANDBY/ON indicator
Lit brightly:
Shows that the power of the unit is ON. In this
condition, you can switch the unit to STANDBY mode
using the pCD key on the remote control.
Lit dimly:
Shows that the unit is in STANDBY mode. In this
condition, press the pCD key on the remote control
to turn on the unit.
Off:
Shows that the power of the unit is OFF. In this
condition, you can turn on the unit using the
STANDBY/ON/OFF switch only.
STANDBY/ON
OFF
PURE DIRECT
SA-CD CD
SOURCE LAYER
LAYER
USB
OPTICAL COAXIAL DISC
SA-CD HYBRID TRACK TOTAL REMAIN PROG SHUFFLE REP OFF SALL A-B
SOURCE
2 41 3 5 7 8 6
Notes

7En
3PURE DIRECT key
Turns on the PURE DIRECT mode to improve audio
quality.
When this unit is in the PURE DIRECT mode:
• No signal is output from the DIGITAL OUT
(OPTICAL and COAXIAL) jacks on the rear panel
(page 10).
• The least indicators and messages appear on the
front panel display.
y
• Press this key again to turn off the PURE DIRECT mode.
• This setting is retained even if you turn off this unit.
4PURE DIRECT indicator
Lights when the PURE DIRECT mode is turned on.
5SOURCE key
Selects the audio source to be played back. Each time
you press this key, the audio source is switched.
y
The audio source setting is retained even if you turn off this
unit.
6SOURCE indicators
The indicator of the audio source selected with the
SOURCE key lights.
7LAYER key
Switches the playback layer of a hybrid Super Audio
CD between SA-CD and CD while playback is
stopped (page 27).
y
This setting is retained even if you turn off this unit.
When SA-CD layer is selected, audio signals are output only
from the BALANCED OUT and ANALOG OUT jacks.
8LAYER indicators
The indicator of the layer selected with the LAYER
key lights.
Note
(coaxial digital input) (optical digital input)
English

8En
Controls and functions
■Front panel (pages 6 to 9)
9Disc tray
Loads a disc.
0(Open/Close) key
Opens or closes the disc tray.
y
The disc tray also closes automatically when you press:
• the (Play) key on the front panel or on the remote
control.
• the front edge of the disc tray gently.
• a numeric button on the remote control.
A(Skip/Search backward) key
Press the key once to skip back to the beginning of the
current track.
Press it twice to skip to the beginning of the previous
track.
Press and hold it to search backward.
(Skip/Search forward) key
Press the key once to skip to the next track.
Press and hold it to search forward.
B(Play) key
Starts playback.
C(Pause) key
Pauses playback. Press the or key to resume
playback.
D(Stop) key
Stops playback.
STANDBY/ON
OFF
PURE DIRECT
SA-CD CD
SOURCE LAYER
LAYER
USB OPTICAL COAXIAL DISC
SA-CD HYBRID TRACK TOTAL REMAIN PROG SHUFFLE REP OFF SALL
SOURCE
GF
9 0
HI JEK

9En
ERemote control sensor
Receives signals from the remote control.
y
The remote control transmits a directional infrared beam.
Be sure to aim the remote control directly at the remote
control sensor on the front panel of this unit during operation.
FDisplay
The brightness can be adjusted with the DIMMER key
on the remote control (page 12).
G(playback) / (pause) indicator
Lights in the playback/pause mode.
HDisc type indicator
Indicates the type (SA-CD/CD/HYBRID) of the disc
in the disc tray.
ITime display mode indicator
Indicates the time display mode of the display. Change
the mode by pressing the DISPLAY key on the remote
control (page 13).
JPlayback mode indicator
Indicates the current playback mode.
PROG: Program playback (page 14)
SHUFFLE: Shuffle playback (page 13)
REP OFF: Repeat playback off (page 12)
REP S: Single repeat playback (page 12)
REP ALL: All repeat playback (page 12)
KInformation display
AB C D
3030 Approximately 6 m (20 ft)
See page 28 for more information on MP3/WMA
playback.
Elapsed time of the current track
Remaining time of the
current track
Total remaining time of the
disc
English

10 En
Controls and functions
■Rear panel
1BALANCED OUT jacks (male)
2ANALOG OUT jacks
3DIGITAL IN USB jack (Type B)
4DIGITAL IN OPTICAL jack
5DIGITAL IN COAXIAL jack
6DIGITAL OUT OPTICAL jack
7DIGITAL OUT COAXIAL jack
While playing the Super Audio CD layer, the audio signals are
output only from the BALANCED OUT and ANALOG OUT
jacks.
8SYSTEM CONNECTOR
Use this connector to connect a product testing device
for servicing.
9REMOTE IN/OUT jacks
Use these jacks to connect an external component for
remote operation.
For details on the connection, see page 21.
0AC IN inlet
Use this inlet to plug in the supplied power cable.
See page 20 for connection information.
SYSTEM CONNECTOR REMOTE
IN OUT
BALANCED OUT DIGITAL IN
COAXIAL
DI
OPTICOPTICALUSB
ANALOG OUT BALANCED OUT
GND +HOT
- COLD
2
3
1
AC IN
8
0
3 4 5
9
1 2
See page 18 for connection information.
Note
