SERVICE MANUAL
XJ6S(Y)
2009
36C-28197-E0
XJ6SA
❄❆❍✤✤❇ ✣  

❄❆❍✤✤❇ ✤  

EAS20040
XJ6S(Y)
XJ6SA
SERVICE MANUAL
©2009 by Yamaha Motor Co., Ltd.
First edition, January 2009
All rights reserved.
Any reproduction or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
❊❏❍✤❇ ✣  

EAS20071
IMPORTANT
This manual was produced by the Yamaha Motor Company, Ltd. primarily for use by Yamaha dealers
and their qualified mechanics. It is not possible to include all the knowledge of a mechanic in one man-
ual. Therefore, anyone who uses this book to perform maintenance and repairs on Yamaha vehicles
should have a basic understanding of mechanics and the techniques to repair these types of vehicles.
Repair and maintenance work attempted by anyone without this knowledge is likely to render the vehi-
cle unsafe and unfit for use.
Yamaha Motor Company, Ltd. is continually striving to improve all of its models. Modifications and sig-
nificant changes in specifications or procedures will be forwarded to all authorized Yamaha dealers and
will appear in future editions of this manual where applicable.
TIP
Designs and specifications are subject to change without notice.
EAS20081
IMPORTANT MANUAL INFORMATION
Particularly important information is distinguished in this manual by the following notations.
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid pos-
sible injury or death.
A WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to
the vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
❊❏❍✤❇ ✤  

EAS20090
HOW TO USE THIS MANUAL
This manual is intended as a handy, easy-to-read reference book for the mechanic. Comprehensive
explanations of all installation, removal, disassembly, assembly, repair and check procedures are laid
out with the individual steps in sequential order.
●
The manual is divided into chapters and each chapter is divided into sections. The current section title
is shown at the top of each page “1”.
●
Sub-section titles appear in smaller print than the section title “2”.
●
To help identify parts and clarify procedure steps, there are exploded diagrams at the start of each
removal and disassembly section “3”.
●
Numbers are given in the order of the jobs in the exploded diagram. A number indicates a disassem-
bly step “4”.
●
Symbols indicate parts to be lubricated or replaced “5”.
Refer to “SYMBOLS”.
●
A job instruction chart accompanies the exploded diagram, providing the order of jobs, names of
parts, notes in jobs, etc “6”.
●
Jobs requiring more information (such as special tools and technical data) are described sequentially
“7”.
5
3
4
6
1
2
7
❊❏❍✤❇ ✥  

EAS20100
SYMBOLS
The following symbols are used in this manual for easier understanding.
TIP
The following symbols are not relevant to every vehicle.
G
M
BF
B
T
R
.
.
LS
M
S
LT
ENew
Serviceable with engine mounted
Filling fluid
Lubricant
Special tool
Tightening torque
Wear limit, clearance
Engine speed
Electrical data
Engine oil
Gear oil
Molybdenum disulfide oil
Brake fluid
Wheel bearing grease
Lithium-soap-based grease
Molybdenum disulfide grease
Silicone grease
Apply locking agent (LOCTITE®).
Replace the part with a new one.
SYMBOL DEFINITION SYMBOL DEFINITION
❊❏❍✤❇ ✦  

GENERAL INFORMATION
1
SPECIFICATIONS
2
PERIODIC CHECKS AND
ADJUSTMENTS
3
CHASSIS
4
ENGINE
5
COOLING SYSTEM
6
FUEL SYSTEM
7
ELECTRICAL SYSTEM
8
TROUBLESHOOTING
9
EAS20110
TABLE OF CONTENTS
❏❄✤❇ ✣  

❏❄✤❇ ✤  

1
2
3
4
5
6
7
8
9
GENERAL INFORMATION
IDENTIFICATION .......................................................................................... 1-1
VEHICLE IDENTIFICATION NUMBER ................................................... 1-1
MODEL LABEL........................................................................................ 1-1
FEATURES.................................................................................................... 1-2
OUTLINE OF FI SYSTEM ....................................................................... 1-2
FI SYSTEM.............................................................................................. 1-3
INSTRUMENT FUNCTIONS ................................................................... 1-4
OUTLINE OF THE ABS........................................................................... 1-7
ABS COMPONENT FUNCTIONS ........................................................... 1-11
ABS OPERATION ................................................................................... 1-16
ABS SELF-DIAGNOSIS FUNCTION....................................................... 1-19
ABS WARNING LIGHT AND OPERATION............................................. 1-22
IMPORTANT INFORMATION ....................................................................... 1-24
PREPARATION FOR REMOVAL AND DISASSEMBLY......................... 1-24
REPLACEMENT PARTS......................................................................... 1-24
GASKETS, OIL SEALS AND O-RINGS .................................................. 1-24
LOCK WASHERS/PLATES AND COTTER PINS ................................... 1-24
BEARINGS AND OIL SEALS .................................................................. 1-25
CIRCLIPS ................................................................................................ 1-25
CHECKING THE CONNECTIONS ................................................................ 1-26
REMOVING THE QUICK FASTENER .................................................... 1-27
INSTALLING THE QUICK FASTENER................................................... 1-28
SPECIAL TOOLS .......................................................................................... 1-29
❄❉❂❋✤❇ ✣  

IDENTIFICATION
1-1
EAS20130
IDENTIFICATION
EAS20140
VEHICLE IDENTIFICATION NUMBER
The vehicle identification number “1” is stamped
into the right side of the steering head pipe.
EAS20150
MODEL LABEL
The model label “1” is affixed to the frame. This
information will be needed to order spare parts.
1
