Yamaha Ego Avantiz User manual

B92-F8199-30B92-F8199-30
3FBEUIJTNBOVBMDBSFGVMMZCFGPSFPQFSBUJOHUIJTWFIJDMF
08/&34."/6"-

EAU46091
൘֯⭘䘉⭥অ䖖ԕࡽˈ䈧ݵ࠶֯⭘䘉ሿ᡻޼DŽ䘉᡻޼享Ԉо⭥অ䖖а䎧DŽ
EAU46091
Baca buku panduan dengan teliti sebelum mengendalikan motosikal ini. Buku panduan diberi bersama
dengan pembelian motosikal.
EAU46091
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.

Introduction
EAU10114
Welcome to the Yamaha world of motorcycling!
As the owner of the ego avantiz, you are beneting from Yamaha’s vast experience and newest technology regarding the
design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your ego avantiz. The Owner’s
Manual does not only instruct you in how to operate, inspect and maintain your scooter, but also in how to safeguard
yourself and others from trouble and injury.
In addition, the many tips given in this manual will help keep your scooter in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety rst!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your scooter and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA12412
Please read this manual carefully and completely before operating this scooter.

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP

Important manual information
EAUN0430
B92 -F8199-30
OWNER’S MANUAL
©2016 by Yamaha Motor Co. Ltd.
1st edition, March 2016
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co. Ltd.
is expressly prohibited.
Printed in Malaysia.
䈧ᛘⲴ⭥অ䖖ԓ⨶୶亶
єᕐݽ䍩Ⲵ㔤؞ধ

Table of contents
Location of important labels........... 1-1
Safety information............................ 2-1
Further safe-riding points ............... 2-5
Helmets .......................................... 2-6
Description ....................................... 3-1
Left view ......................................... 3-1
Right view....................................... 3-2
Controls and instruments ............... 3-3
Instrument and control functions... 4-1
Main switch/steering lock............... 4-1
Keyhole shutter .............................. 4-2
Indicator lights and warning light ... 4-3
Speedometer unit........................... 4-4
Handlebar switches........................ 4-4
Front brake lever ............................ 4-5
Rear brake lever ............................. 4-5
Rear brake lever lock...................... 4-5
Fuel tank cap.................................. 4-6
Fuel................................................. 4-7
Catalytic converter ......................... 4-8
Kickstarter ...................................... 4-9
Seat ................................................ 4-9
Helmet holders ............................. 4-10
Convenience hook........................ 4-10
Storage compartment .................. 4-11
Sidestand ..................................... 4-11
Ignition circuit cut-off system....... 4-12
For your safety – pre-operation
checks ...............................................5-1
Operation and important riding
points .................................................6-1
Starting the engine..........................6-1
Acceleration and deceleration ........6-2
Braking............................................6-2
Engine break-in...............................6-3
Parking ............................................ 6-3
General note....................................6-4
Periodic maintenance and
adjustment ........................................7-1
Owner’s tool kit...............................7-1
Periodic maintenance chart for
the emission control system........7-2
General maintenance and
lubrication chart...........................7-3
Removing and installing the
cowling and panels......................7-8
Checking the spark plug.................7-9
Engine oil and oil strainer..............7-11
Final transmission oil.....................7-13
Air lter and V-belt case air
lter elements ............................7-14
Checking the engine
idling speed ...............................7-16
Adjusting the throttle grip
free play ..................................... 7-16
Valve clearance.............................7-17
Tires .............................................. 7-17
Cast wheels .................................. 7-19
Checking the front brake lever
free play..................................... 7-19
Adjusting the rear brake lever
free play..................................... 7-19
Checking the front brake pads
and rear brake shoes ............... 7-20
Checking the brake uid level ...... 7-21
Changing the brake uid ............. 7-21
Checking the V-belt...................... 7-22
Checking and lubricating
the cables.................................. 7-22
Checking and lubricating the
throttle grip and cable............... 7-22
Lubricating the front and rear
brake levers............................... 7-23
Checking and lubricating the
centerstand and sidestand........ 7-23
Checking the front fork ................. 7-24
Checking the steering................... 7-25
Checking the wheel bearings ....... 7-25
Battery .......................................... 7-25
Replacing the fuse........................ 7-27
Headlight ...................................... 7-27
Replacing an auxiliary light
bulb ........................................... 7-28
Replacing a front turn signal
light bulb.................................... 7-28
Replacing a tail/brake light bulb
or a rear turn signal light bulb ... 7-28

Table of contents
Troubleshooting ............................7-29
Troubleshooting chart ...................7-31
Scooter care and storage ................8-1
Care.................................................8-1
Storage............................................8-3
Specications....................................9-1
Consumer information ...................10-1
Identication numbers...................10-1
Index ................................................11-1

Location of important labels
1-1
1
EAU10385
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difcult to read or comes off, a replacement
label is available from your Yamaha dealer.
21

Location of important labels
1-2
1
1CAUTION
Read this manual carefully
before operating this vehicle
B92-F8199-30
225, 33
225, 33
250, 36
250, 36
100kPa=1bar kPa, psi kPa, psi
2

2-1
2
Safety information
EAU1026B
Be a Responsible Owner
As the vehicle’s owner, you are re-
sponsible for the safe and proper oper-
ation of your scooter.
Scooters are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements be-
fore riding this scooter.
He or she should:
tObtain thorough instructions from
a competent source on all aspects
of scooter operation.
tObserve the warnings and mainte-
nance requirements in this Own-
er’s Manual.
tObtain qualied training in safe
and proper riding techniques.
tObtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
tNever operate a scooter without
proper training or instruction. Take
a training course. Beginners
should receive training from a cer-
tied instructor. Contact an autho-
rized scooter dealer to nd out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks
each time you use the vehicle to make
sure it is in safe operating condition.
Failure to inspect or maintain the vehi-
cle properly increases the possibility of
an accident or equipment damage.
See page 5-1 for a list of pre-operation
checks.
tThis scooter is designed to carry
the operator and a passenger.
tThe failure of motorists to detect
and recognize scooters in trafc is
the predominating cause of auto-
mobile/scooter accidents. Many
accidents have been caused by
an automobile driver who did not
see the scooter. Making yourself
conspicuous appears to be very
effective in reducing the chance of
this type of accident.
Therefore:
tWear a brightly colored jacket.
tUse extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for scooter accidents to
occur.
tRide where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
tNever maintain a scooter with-
out proper knowledge. Contact
an authorized scooter dealer to
inform you on basic scooter
maintenance. Certain mainte-
nance can only be carried out
by certied staff.

Safety information
2-2
2
tMany accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent driver’s license.
tMake sure that you are qualied
and that you only lend your
scooter to other qualied opera-
tors.
tKnow your skills and limits.
Staying within your limits may
help you to avoid an accident.
tWe recommend that you prac-
tice riding your scooter where
there is no trafc until you have
become thoroughly familiar with
the scooter and all of its con-
trols.
tMany accidents have been
caused by error of the scooter op-
erator. A typical error made by the
operator is veering wide on a turn
due to excessive speed or under-
cornering (insufcient lean angle
for the speed).
tAlways obey the speed limit and
never travel faster than warrant-
ed by road and trafc condi-
tions.
tAlways signal before turning or
changing lanes. Make sure that
other motorists can see you.
tThe posture of the operator and
passenger is important for proper
control.
tThe operator should keep both
hands on the handlebar and
both feet on the operator foot-
rests during operation to main-
tain control of the scooter.
tThe passenger should always
hold onto the operator, the seat
strap or grab bar, if equipped,
with both hands and keep both
feet on the passenger footrests.
Never carry a passenger unless
he or she can rmly place both
feet on the passenger footrests.
tNever ride under the inuence of
alcohol or other drugs.
tThis scooter is designed for on-
road use only. It is not suitable for
off-road use.
Protective Apparel
The majority of fatalities from scooter
accidents are the result of head inju-
ries. The use of a safety helmet is the
single most critical factor in the pre-
vention or reduction of head injuries.
tAlways wear an approved helmet.
tWear a face shield or goggles.
Wind in your unprotected eyes
could contribute to an impairment
of vision that could delay seeing a
hazard.
tThe use of a jacket, substantial
shoes, trousers, gloves, etc., is ef-
fective in preventing or reducing
abrasions or lacerations.
tNever wear loose-tting clothes,
otherwise they could catch on the
control levers or wheels and cause
injury or an accident.
tAlways wear protective clothing
that covers your legs, ankles, and
feet. The engine or exhaust sys-
tem become very hot during or af-
ter operation and can cause
burns.
tA passenger should also observe
the above precautions.

Safety information
2-3
2
Avoid Carbon Monoxide Poisoning
All engine exhaust contains carbon
monoxide, a deadly gas. Breathing
carbon monoxide can cause head-
aches, dizziness, drowsiness, nausea,
confusion, and eventually death.
Carbon Monoxide is a colorless, odor-
less, tasteless gas which may be
present even if you do not see or smell
any engine exhaust. Deadly levels of
carbon monoxide can collect rapidly
and you can quickly be overcome and
unable to save yourself. Also, deadly
levels of carbon monoxide can linger
for hours or days in enclosed or poorly
ventilated areas. If you experience any
symptoms of carbon monoxide poi-
soning, leave the area immediately, get
fresh air, and SEEK MEDICAL TREAT-
MENT.
tDo not run engine indoors. Even if
you try to ventilate engine exhaust
with fans or open windows and
doors, carbon monoxide can rap-
idly reach dangerous levels.
tDo not run engine in poorly venti-
lated or partially enclosed areas
such as barns, garages, or car-
ports.
tDo not run engine outdoors where
engine exhaust can be drawn into
a building through openings such
as windows and doors.
Loading
Adding accessories or cargo to your
scooter can adversely affect stability
and handling if the weight distribution
of the scooter is changed. To avoid the
possibility of an accident, use extreme
caution when adding cargo or acces-
sories to your scooter. Use extra care
when riding a scooter that has added
cargo or accessories. Here, along with
the information about accessories be-
low, are some general guidelines to fol-
low if loading cargo to your scooter:
The total weight of the operator, pas-
senger, accessories and cargo must
not exceed the maximum load limit.
Operation of an overloaded vehicle
could cause an accident.
When loading within this weight limit,
keep the following in mind:
tCargo and accessory weight
should be kept as low and close to
the scooter as possible. Securely
pack your heaviest items as close
to the center of the vehicle as pos-
sible and make sure to distribute
the weight as evenly as possible
on both sides of the scooter to
minimize imbalance or instability.
tShifting weights can create a sud-
den imbalance. Make sure that
accessories and cargo are se-
curely attached to the scooter be-
fore riding. Check accessory
mounts and cargo restraints fre-
quently.
tProperly adjust the suspension
for your load (suspension-ad-
justable models only), and
check the condition and pres-
sure of your tires.
tNever attach any large or heavy
items to the handlebar, front
fork, or front fender. Such items
can create unstable handling or
a slow steering response.
tThis vehicle is not designed to
pull a trailer or to be attached to
a sidecar.
Maximum load:
155 kg (342 lb)

Safety information
2-4
2
Genuine Yamaha Accessories
Choosing accessories for your vehicle
is an important decision. Genuine
Yamaha accessories, which are avail-
able only from a Yamaha dealer, have
been designed, tested, and approved
by Yamaha for use on your vehicle.
Many companies with no connection
to Yamaha manufacture parts and ac-
cessories or offer other modications
for Yamaha vehicles. Yamaha is not in
a position to test the products that
these aftermarket companies produce.
Therefore, Yamaha can neither en-
dorse nor recommend the use of ac-
cessories not sold by Yamaha or
modications not specically recom-
mended by Yamaha, even if sold and
installed by a Yamaha dealer.
Aftermarket Parts, Accessories, and
Modications
While you may nd aftermarket prod-
ucts similar in design and quality to
genuine Yamaha accessories, recog-
nize that some aftermarket accesso-
ries or modications are not suitable
because of potential safety hazards to
you or others. Installing aftermarket
products or having other modications
performed to your vehicle that change
any of the vehicle’s design or operation
characteristics can put you and others
at greater risk of serious injury or
death. You are responsible for injuries
related to changes in the vehicle.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing” when mounting accessories.
tNever install accessories or carry
cargo that would impair the per-
formance of your scooter. Careful-
ly inspect the accessory before
using it to make sure that it does
not in any way reduce ground
clearance or cornering clearance,
limit suspension travel, steering
travel or control operation, or ob-
scure lights or reectors.
tAccessories tted to the han-
dlebar or the front fork area can
create instability due to improp-
er weight distribution or aerody-
namic changes. If accessories
are added to the handlebar or
front fork area, they must be as
lightweight as possible and
should be kept to a minimum.
tBulky or large accessories may
seriously affect the stability of
the scooter due to aerodynamic
effects. Wind may attempt to lift
the scooter, or the scooter may
become unstable in cross
winds. These accessories may
also cause instability when
passing or being passed by
large vehicles.
tCertain accessories can dis-
place the operator from his or
her normal riding position. This
improper position limits the
freedom of movement of the
operator and may limit control
ability, therefore, such accesso-
ries are not recommended.
tUse caution when adding electri-
cal accessories. If electrical ac-
cessories exceed the capacity of
the scooter’s electrical system, an
electric failure could result, which
could cause a dangerous loss of
lights or engine power.

Safety information
2-5
2
Aftermarket Tires and Rims
The tires and rims that came with your
scooter were designed to match the
performance capabilities and to pro-
vide the best combination of handling,
braking, and comfort. Other tires, rims,
sizes, and combinations may not be
appropriate. Refer to page 7-17 for tire
specications and more information on
replacing your tires.
Transporting the Scooter
Be sure to observe following instruc-
tions before transporting the scooter in
another vehicle.
tRemove all loose items from the
scooter.
tPoint the front wheel straight
ahead on the trailer or in the truck
bed, and choke it in a rail to pre-
vent movement.
tSecure the scooter with tie-downs
or suitable straps that are at-
tached to solid parts of the scoot-
er, such as the frame or upper
front fork triple clamp (and not, for
example, to rubber-mounted han-
dlebars or turn signals, or parts
that could break). Choose the lo-
cation for the straps carefully so
the straps will not rub against
painted surfaces during transport.
tThe suspension should be com-
pressed somewhat by the tie-
downs, if possible, so that the
scooter will not bounce exces-
sively during transport.
EAU57600
Further safe-riding points
tBe sure to signal clearly when
making turns.
tBraking can be extremely difcult
on a wet road. Avoid hard braking,
because the scooter could slide.
Apply the brakes slowly when
stopping on a wet surface.
tSlow down as you approach a
corner or turn. Once you have
completed a turn, accelerate
slowly.
tBe careful when passing parked
cars. A driver might not see you
and open a door in your path.
tRailroad crossings, streetcar rails,
iron plates on road construction
sites, and manhole covers be-
come extremely slippery when
wet. Slow down and cross them
with caution. Keep the scooter up-
right, otherwise it could slide out
from under you.
tThe brake pads or linings could
get wet when you wash the scoot-
er. After washing the scooter,
check the brakes before riding.

Safety information
2-6
2
tAlways wear a helmet, gloves,
trousers (tapered around the cuff
and ankle so they do not ap), and
a brightly colored jacket.
tDo not carry too much luggage on
the scooter. An overloaded scoot-
er is unstable. Use a strong cord
to secure any luggage to the carri-
er (if equipped). A loose load will
affect the stability of the scooter
and could divert your attention
from the road. (See page 2-3.)
EAUU0033
Helmets
Operating this vehicle without an ap-
proved motorcycle helmet increases
your chances of a severe head injury or
death in the event of an accident. The
majority of fatalities from motorcycle or
scooter accidents are the result of
head injuries. The use of a safety hel-
met is the single most critical factor in
the prevention or reduction of head in-
juries.
Always select an approved motorcy-
cle helmet
Pay attention to the following when
choosing a motorcycle helmet.
tThe helmet must meet the safety
standard “SIRIM”.
tThe helmet size must match the
size of the rider’s head.
tNever subject a helmet to heavy
shocks.
Wearing the helmet correctly
Always connect the chin strap. In the
case of an accident, the helmet has a
much less chance of coming off if the
chin strap is connected.
Correct usage
Wrong usage
ZAUU0003
ZAUU0007

Safety information
2-7
2
tFull-type: use only for riding at low
to mid-range speeds
tFull-face-type: use for riding at
mid-range to high speeds
ZAUU0005 ZAUU0006

Description
3-1
3
EAU10411
Left view
123 4 7
8
91011121314
56
1. Front turn signal light (page 7-28/7-28)
2. Auxiliary light (page 7-28)
3. Headlight (page 7-27)
4. Battery (page 7-25)
5. Fuse (page 7-27)
6. Convenience hook (page 4-10)
7. Owner’s tool kit (page 7-1)
8. Air lter element (page 7-14)
9. Final transmission oil drain bolt (page 7-13)
10.Kickstarter (page 4-9)
11.Engine oil drain bolt B (page 7-11)
12.Engine oil drain bolt A (page 7-11)
13.Sidestand (page 4-11)
14.V-belt case air lter element (page 7-14)

Description
3-2
3
EAU10421
Right view
23
7
45 61
1. Rear turn signal light (page 7-28)
2. Tail/brake light (page 7-28)
3. Fuel tank cap (page 4-6)
4. Storage compartment (page 4-11)
5. Main switch/steering lock (page 4-1)
6. Front brake uid reservoir (page 7-21)
7. Dipstick (page 7-11)

Description
3-3
3
EAU10431
Controls and instruments
12345
6
1. Rear brake lever (page 4-5)
2. Left handlebar switches (page 4-4)
3. Speedometer (page 4-4)
4. Right handlebar switch (page 4-4)
5. Front brake lever (page 4-5)
6. Main switch/steering lock (page 4-1)

Instrument and control functions
4-1
4
EAU68550
Main switch/steering lock
The main switch/steering lock controls
the ignition and lighting systems, is
used to lock the steering, and is used
to open the seat. The main switch po-
sitions are described below.
TIP
The main switch is equipped with a
keyhole shutter. See page 4-2 for in-
structions on how to open and shut the
keyhole shutter.
EAUU1055
ON
All electrical circuits are supplied with
power, and the engine can be started.
The key cannot be removed.
TIP
The meter lighting comes on when the
key is turned to “ON”. When the engine
is started, the headlight, auxiliary light
and taillight come on automatically,
and will stay on until the key is turned
to “OFF” or the sidestand is lowered.
EAU10662
OFF
All electrical systems are off. The key
can be removed.
WARNING
EWA10062
Never turn the key to “OFF” or
“LOCK” while the vehicle is moving.
Otherwise the electrical systems will
be switched off, which may result in
loss of control or an accident.
EAU10686
LOCK
The steering is locked and all electrical
systems are off. The key can be re-
moved.
To lock the steering
1. Turn the handlebars all the way to
the left.
2. With the key in the “OFF” position,
push the key in and turn it to
“LOCK”.
3. Remove the key.
TIP
If the steering will not lock, try turning
the handlebars back to the right slight-
ly.
ZAUU0880 1. Push.
2. Turn.
12
