Yamaha MTM155 User manual

DIC183
MTM155
OWNER’S MANUAL
Read this manual carefully before operating this vehicle.
B1V-F8199-E0
[English (E)]

EAU46094
Readthis manual carefully before operatingthis vehicle. This manual shouldstay with this vehicle if it is sold.
UB1VE0E0.book Page 1 Tuesday, September 3, 2019 1:19 PM

Introduction
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the MTM155, you are benefiting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MTM155. The Owner’s Manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself
and others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and
this manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please readthis manual carefully andcompletely before operatingthis motorcycle.
UB1VE0E0.book Page 1 Tuesday, September 3, 2019 1:19 PM

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is usedto alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoidpossible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, couldresult in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoiddamage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
UB1VE0E0.book Page 1 Tuesday, September 3, 2019 1:19 PM

Important manual information
EAU37432
MTM155
OWNER’S MANUAL
©2020 by Thai Yamaha Motor Co., Ltd.
1st edition, July 2019
All rights reserved.
Any reprintingor unauthorizeduse
without the written permission of
Thai Yamaha Motor Co., Ltd.
is expressly prohibited.
Printedin Thailand.
UB1VE0E0.book Page 2 Tuesday, September 3, 2019 1:19 PM

Table of contents
Location of important labels ........... 1-1
Safety information............................ 2-1
Further safe-riding points ............... 2-5
Helmets .......................................... 2-6
Description ....................................... 3-1
Left view ......................................... 3-1
Right view....................................... 3-2
Controls and instruments ............... 3-3
Instrument and
control functions .............................. 4-1
Main switch/steering lock............... 4-1
Keyhole shutter .............................. 4-2
Indicator lights
and warning lights....................... 4-3
Multi-function meter unit ................ 4-4
Multi-function display ..................... 4-6
Handlebar switches........................ 4-9
Clutch lever .................................. 4-10
Shift pedal .................................... 4-10
Brake lever.................................... 4-11
Brake pedal .................................. 4-11
Fuel tank cap................................ 4-11
Fuel............................................... 4-12
Catalytic converter ....................... 4-13
Seat .............................................. 4-14
Helmet holder ............................... 4-14
Sidestand ..................................... 4-15
Starting circuit cut-off system ...... 4-15
For your safety – pre-
operation checks..............................5-1
Operation andimportant
ridingpoints ......................................6-1
Engine break-in...............................6-1
Starting the engine..........................6-2
Shifting ............................................6-3
Tips for reducing fuel
consumption................................6-3
Parking ............................................6-4
Periodic maintenance
andadjustment.................................7-1
Tool kit ............................................7-1
Periodic maintenance chart for
the emission control system........7-2
General maintenance
and lubrication chart....................7-4
Removing and installing
cowlings.......................................7-8
Checking the spark plug.................7-8
Canister.........................................7-10
Engine oil and oil filter element .....7-10
Why Yamalube..............................7-13
Coolant..........................................7-13
Air filter element
and check hose .........................7-14
Adjusting the engine
idling speed ...............................7-15
Adjusting the throttle
grip free play ............................. 7-16
Valve clearance............................. 7-16
Tires .............................................. 7-17
Cast wheels .................................. 7-18
Adjusting the clutch
lever free play............................ 7-19
Checking the brake
lever free play............................ 7-20
Brake light switches ..................... 7-20
Checking the front and rear
brake pads ................................ 7-21
Checking the brake fluid level ...... 7-22
Changing the brake fluid .............. 7-23
Drive chain slack........................... 7-23
Cleaning and lubricating
the drive chain........................... 7-25
Checking and lubricating
the cables.................................. 7-25
Checking and lubricating the
throttle grip and cable end........ 7-26
Checking and lubricating the
brake and shift pedals............... 7-26
Checking and lubricating the
brake and clutch levers ............. 7-27
Checking and lubricating
the sidestand............................. 7-27
Lubricating the
swingarm pivots ........................ 7-28
Checking the front fork................. 7-28
Checking the steering................... 7-29
UB1VE0E0.book Page 1 Tuesday, September 3, 2019 1:19 PM

Table of contents
Checking the wheel bearings ........7-29
Battery...........................................7-29
Replacing the fuses.......................7-31
Vehicle lights .................................7-31
Replacing a turn signal
light bulb ....................................7-32
Supporting the motorcycle............7-32
Front wheel....................................7-33
Rear wheel.....................................7-34
Troubleshooting ............................7-35
Troubleshooting chart ...................7-36
Motorcycle care andstorage..........8-1
Matte color caution .........................8-1
Care.................................................8-1
Storage............................................8-3
Specifications....................................9-1
Consumer information ...................10-1
Identification numbers...................10-1
Vehicle data recording ..................10-2
Index ................................................11-1
UB1VE0E0.book Page 2 Tuesday, September 3, 2019 1:19 PM

Location of important labels
1-1
1
EAU10385
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement
label is available from your Yamaha dealer.
12
UB1VE0E0.book Page 1 Tuesday, September 3, 2019 1:19 PM

Location of important labels
1-2
1
100kPa=1bar kPa, psi kPa, psi
225, 33 250, 36
225, 33 250, 36
B48-F1668-00
21
2BL-F1568-01
UB1VE0E0.book Page 2 Tuesday, September 3, 2019 1:19 PM

2-1
2
Safety information
EAU1028C
Be a Responsible Owner
As the vehicle’s owner, you are re-
sponsible for the safe and proper oper-
ation of your motorcycle.
Motorcycles are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements be-
fore riding this motorcycle.
He or she should:
zObtain thorough instructions from
a competent source on all aspects
of motorcycle operation.
zObserve the warnings and mainte-
nance requirements in this Own-
er’s Manual.
zObtain qualified training in safe
and proper riding techniques.
zObtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
zNever operate a motorcycle with-
out proper training or instruction.
Take a training course. Beginners
should receive training from a cer-
tified instructor. Contact an autho-
rized motorcycle dealer to find out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks
each time you use the vehicle to make
sure it is in safe operating condition.
Failure to inspect or maintain the vehi-
cle properly increases the possibility of
an accident or equipment damage.
See page 5-1 for a list of pre-operation
checks.
zThis motorcycle is designed to
carry the operator and a passen-
ger.
zThe failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been
caused by an automobile driver
who did not see the motorcycle.
Making yourself conspicuous ap-
pears to be very effective in reduc-
ing the chance of this type of
accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
• Never maintain a motorcycle
without proper knowledge.
Contact an authorized motorcy-
cle dealer to inform you on ba-
sic motorcycle maintenance.
Certain maintenance can only
be carried out by certified staff.
