Yamaha XSR900 User manual

OWNER’S MANUAL
Read this manual carefully
before operating this vehicle.
MOTORCYCLE
BEA-28199-20
MTM890N (XSR900)
Location of important labels
Safety information
Description
Special features
Instrument and control functions
For your safety – pre-operation checks
Operation and important riding points
Periodic maintenance and adjustment
Motorcycle care and storage
Specifications
Consumer information
Index
1
2
3
4
5
6
7
8
9
10
11
12
BEA-28199-20_Hyoshi.indd 1 2022/01/12 14:25:39

EAU81565
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
BEA-28199-20_Hyoshi.indd 2 2022/01/12 14:25:39

Introduction
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the MTM890N, you are benefiting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MTM890N. The Owner’s Manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and
others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please read this manual carefully and completely before operating this motorcycle.
BEA-9-20-E0.book 1 ページ ２０２２年１月１２日 水曜日 午後３時７分

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
BEA-9-20-E0.book 1 ページ ２０２２年１月１２日 水曜日 午後３時７分

Important manual information
EAU10202
MTM890N
OWNER’S MANUAL
©2022 by Yamaha Motor Co., Ltd.
1st edition, December 2021
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in Japan.
BEA-9-20-E0.book 2 ページ ２０２２年１月１２日 水曜日 午後３時７分

Table of contents
Location of important labels........... 1-1
Safety information ........................... 2-1
Description ....................................... 3-1
Left view ......................................... 3-1
Right view ....................................... 3-2
Controls and instruments................ 3-3
Special features .............................. 4-1
Cruise control system ..................... 4-1
“D-MODE”....................................... 4-3
“TCS-MODE” .................................. 4-4
Quick shifter.................................... 4-6
BC................................................... 4-6
Instrument and control functions... 5-1
Immobilizer system......................... 5-1
Main switch/steering lock................ 5-2
Handlebar switches ........................ 5-3
Indicator lights and warning
lights............................................ 5-5
Display............................................ 5-8
Settings MENU ............................. 5-14
Clutch lever................................... 5-19
Shift pedal..................................... 5-19
Brake lever ................................... 5-20
Brake pedal .................................. 5-20
Brake control system (BC)............ 5-20
Fuel tank cap ................................ 5-22
Fuel............................................... 5-22
Fuel tank overflow hose ............... 5-24
Catalytic converter ....................... 5-24
Seat.............................................. 5-25
Rider footrest position .................. 5-25
Handlebar position ...................... 5-26
Adjusting the front fork ................. 5-26
Adjusting the shock absorber
assembly................................... 5-28
Auxiliary DC connectors............... 5-30
Sidestand ..................................... 5-30
Ignition circuit cut-off system........ 5-31
For your safety – pre-operation
checks .............................................. 6-1
Operation and important riding
points................................................ 7-1
Engine break-in .............................. 7-1
Starting the engine ......................... 7-2
Shifting ........................................... 7-3
Tips for reducing fuel
consumption ............................... 7-4
Parking ........................................... 7-5
Periodic maintenance and
adjustment ....................................... 8-1
Tool kit............................................ 8-2
Periodic maintenance charts.......... 8-3
Periodic maintenance chart for the
emission control system ............. 8-3
General maintenance and
lubrication chart .......................... 8-4
Side cover...................................... 8-8
Checking the spark plugs ............ 8-11
Canister ....................................... 8-12
Engine oil ..................................... 8-12
Why Yamalube ............................ 8-15
Coolant ........................................ 8-15
Air filter element........................... 8-16
Checking the engine idling
speed........................................ 8-17
Valve clearance ........................... 8-17
Tires............................................. 8-17
Cast wheels ................................. 8-20
Adjusting the clutch lever free
play........................................... 8-20
Checking the brake lever free
play........................................... 8-21
Brake light switches ..................... 8-21
Checking the front and rear brake
pads.......................................... 8-22
Checking the brake fluid level...... 8-22
Changing the brake fluid.............. 8-24
Drive chain slack.......................... 8-24
Cleaning and lubricating the drive
chain......................................... 8-26
Checking and lubricating the
cables ....................................... 8-27
Checking and lubricating the
throttle grip ............................... 8-27
BEA-9-20-E0.book 1 ページ ２０２２年１月１２日 水曜日 午後３時７分

Table of contents
Checking and lubricating the
brake and shift pedals............... 8-27
Checking and lubricating the
brake and clutch levers ............. 8-28
Checking and lubricating the
sidestand................................... 8-29
Lubricating the swingarm pivots ... 8-29
Checking the front fork ................. 8-29
Checking the steering................... 8-30
Checking the wheel bearings ....... 8-30
Battery .......................................... 8-31
Replacing the fuses...................... 8-33
Vehicle lights ................................ 8-35
License plate light......................... 8-35
Supporting the motorcycle............ 8-36
Troubleshooting............................ 8-36
Troubleshooting chart................... 8-37
Motorcycle care and storage .......... 9-1
Matte color caution ......................... 9-1
Care................................................ 9-1
Storage........................................... 9-3
Specifications ................................ 10-1
Consumer information .................. 11-1
Identification numbers .................. 11-1
Diagnostic connector .................... 11-2
Vehicle data recording.................. 11-2
Motorcycle noise regulation (for
Australia)................................... 11-3
Index ............................................... 12-1
BEA-9-20-E0.book 2 ページ ２０２２年１月１２日 水曜日 午後３時７分

1-1
1
2
3
4
5
6
7
8
9
10
11
12
13
Location of important labels
EAU10386
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label
is available from your Yamaha dealer.
1
2, 34, 5
6
BEA-9-20-E0.book 1 ページ ２０２２年１月１２日 水曜日 午後３時７分

Location of important labels
1-2
1
2
3
4
5
6
7
8
9
10
11
12
13
4AA-22259-40
WARNING
BEFORE YOU OPERATE THIS VEHICLE, READ
THE OWNER’S MANUAL AND ALL LABELS.
ALWAYS WEAR AN APPROVED MOTORCYCLE
HELMET, eye protection, and protective clothing.
1TP-2118K-A2
100kPa=1bar kPa,psi
250,36 290,42
290,42250,36
kPa,psi
BM6-21668-01
Use PREMIUM unleaded gasoline with
min. 95 octane (RON).
2S3-2817K-11
STATIONARY NOISE TEST INFORMATION
TESTED 95 dB(A) AT 5000 r/min
SILENCING SYSTEM : YAMAHA
IDENTIFICATION : B7N
BEA-2118G-10
28R-00 6270
39R-01 10013
41R-04 9730
53R-03 0816
78R-05 5247
E13
BEA-2811P-00
43
5
21
6
BEA-9-20-E0.book 2 ページ ２０２２年１月１２日 水曜日 午後３時７分

2-1
1
2
3
4
5
6
7
8
9
10
11
12
13
Safety information
EAU1028C
Be a Responsible Owner
As the vehicle’s owner, you are respon-
sible for the safe and proper operation
of your motorcycle.
Motorcycles are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements before
riding this motorcycle.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of motorcycle operation.
Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.
Obtain qualified training in safe
and proper riding techniques.
Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
Never operate a motorcycle with-
out proper training or instruction.
Take a training course. Beginners
should receive training from a cer-
tified instructor. Contact an autho-
rized motorcycle dealer to find out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks each
time you use the vehicle to make sure it
is in safe operating condition. Failure to
inspect or maintain the vehicle properly
increases the possibility of an accident
or equipment damage. See page 6-1
for a list of pre-operation checks.
This motorcycle is designed to car-
ry the operator and a passenger.
The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been caused
by an automobile driver who did
not see the motorcycle. Making
yourself conspicuous appears to
be very effective in reducing the
chance of this type of accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
• Never maintain a motorcycle
without proper knowledge. Con-
tact an authorized motorcycle
dealer to inform you on basic
motorcycle maintenance. Cer-
tain maintenance can only be
carried out by certified staff.
Many accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent motorcycle license.
• Make sure that you are qualified
and that you only lend your mo-
torcycle to other qualified opera-
tors.
• Know your skills and limits.
Staying within your limits may
help you to avoid an accident.
• We recommend that you prac-
BEA-9-20-E0.book 1 ページ ２０２２年１月１２日 水曜日 午後３時７分
