YARD KING 627858x43A User manual

F-031031L
Read and keep this book for future reference. This book contains important information on SAFETY,
ASSEMBLY, OPERATION, AND MAINTENANCE.
Lisez et conservez ce manuel pour référence. Ce manuel contient des informations importantes
concernant la SECURITE, LE MONTAGE, L’UTILISATION ET L’ENTRETIEN.
Instruction Book Snow Thrower Model 627858x43A
Manuel d’instructions chasse−neige modèle 627858x43A

2
F-031031L
NOTE: This unit is equipped with an internal combustion engine
and must not be used on or near any unimproved
forest-covered, brush-covered or grass-covered land unless
the engine’s exhaust system is equipped with a spark arrester
meeting applicable local or state laws (if any). If a spark arrester
is used, it must be maintained in effective working order by the
operator.
In the State of California, the above is required by law (Section
4442 of the California Public Resources Code). Other states
may have similar laws. Federal laws apply on federal lands. See
an Authorized Service Center for a spark arrester for the
muffler.
Engine Exhaust, some of its constituents, and
certain vehicle components contain or emit
chemicals known to the State of California to
cause cancer and birth defects or other repro-
ductive harm.
Battery posts, terminals and related accesso-
ries contain lead and lead compounds, chemi-
cals known to the State of California to cause
cancer and birth defects or other reproductive
harm. WASH HANDS AFTER HANDLING.
REMARQUE : cette machine est équipée d’un moteur à
combustion interne et ne doit pas être utilisée sur un terrain
forestier, buissonnant ou herbeux non préparé, à moins que le
dispositif d’échappement soit pourvu d’un pare-étincelles
conforme à la législation locale ou de l’état (le cas échéant). Si
un pare-étincelles est utilisé, celui-ci doit être maintenu en
parfait état de fonctionnement par l’utilisateur.
Au sein de l’état de Californie, la loi exige la prise en compte
des précautions mentionnées ci-dessus (clause 4442 du
California Public Resources Code). D’autres états peuvent
présenter des lois similaires. Les lois fédérales s’appliquent sur
les terres fédérales. S’adresser à un centre de maintenance
agréé pour l’achat d’un pare-étincelles pour l’échappement.
Les gaz d’échappement du moteur, certains
éléments de leur composition, ainsi que
certains organes du véhicule contiennent ou
émettent des substances chimiques qui, selon
l’État de Californie, peuvent causer le cancer,
des malformations à la naissance, ou
représentent un danger pour la reproduction.
Les bornes et pôles de batterie et autres
accessoires de ce type contiennent du plomb et
des composés de plomb, substances
chimiques qui, selon l’État de Californie,
peuvent causer le cancer, des malformations à
la naissance, ou représentent un danger pour la
reproduction.

3
F-031031L
1
2
3
5
6
4
15
7
17
19
18
16
7
8
91011
12
13
14
17
1
2
12
3
2
1
5
4
6
7
3
9
10
1
11
18
16
12
15
4
1
2
156
5
6
7

4
F-031031L
5
4
11
10
2
6
7
8
9
10
7 8
9
2
4
1
3
10
1
2
3
456
11
1
2

5
F-031031L
ÁÁÁ
ÁÁÁ
ÁÁÁ
Á
Á
1
12
213
65
5
1
3
7
1
“A”
14
11
15
16
6
2
1
3
1
4
17
6
5
7
8

6
F-031031L
1
2
10
11
14
16
13
15 9
4
12
3
13
17
18
18 19
20
4
5
21
5
6
8
3
2
3
“A”
22
2
3
4
23

7
F-031031L
4
5
6
8
4
24
2
3
4
25
3
4
5
6
26
11
3
3
2
10
27
11 12
15
28

8
F-031031L
11
7
16
16
19 20
8
714
13
13
7
29 30
17
17

9
F-031031L
31
1 - 71060 1 - 71042
2 - 306689
2- 3943
2- 9524 2 - 73826

ENGLISH
10
F-031031L
CONTENTS
PRODUCT INFORMATION 10
OWNER’S INFORMATION 10
INTERNATIONAL PICTORIALS 11
ASSEMBLY 13
OPERATION 13
MAINTENANCE 16
TROUBLE SHOOTING CHART 19
TWO YEAR LIMITED WARRANTY
Murray, Inc. warrants to the original purchaser
that this unit shall be free from defects in
material and workmanship under normal use
and service for a period of Two (2) Year from
the date of purchase; however, this warranty
does not cover engines, accessories (such as
electric starters) and Normal Wear Parts (except
as noted below) as the companies that
manufacture these items furnish their own
warranties and provide service through their
authorized field service facilities. For additional
information, see the warranties covering these
particular parts. If you are uncertain whether
your unit contains or is equipped with one or
more of these parts, consult your dealer prior to
purchase. Subject to the terms and conditions
noted in this Limited Warranty, we shall, at our
option, repair or replace at no cost to the original
purchaser any part covered by this Limited
Warranty during the applicable warranty period.
Normal Wear Parts are defined as drive belts,
augers, shear pins, tires and headlights. These
parts are warranted to be free from defects in
material and workmanship as delivered with the
product. Any claim for repair or replacement of
Normal Wear Parts must be made within thirty
(30) days of the date of purchase. No claims
involving damage caused from material use,
abuse or misuse will be honored.
This Murray, Inc. Two (2) Year Limited
Warranty is your exclusive remedy; however,
this warranty is void or does not apply to any
unit that has been tampered with, altered,
misused, abused or used for rental or other
commercial and/or professional
(non-homeowner) uses. Your warranty does not
cover minor mechanical adjustments which are
not due to any defect in material or
workmanship. For assistance in making such
adjustments, consult your Instruction Book.
To make a claim under this Murray, Inc. Two (2)
Year Limited Warranty, return the unit (or if
authorized in advance, the defective part) along
with your proof of purchase to an Authorized
Service Center near you. To locate the nearest
Authorized Service Center, call the Central Parts
Distributor for your area shown in the list
provided with your unit or check the Yellow Page
listings in your local telephone directory. If you
return the entire unit, we will repair the unit. If we
authorize the return of the defective part only, we
will either replace or repair the part.This Murray,
Inc. Two (2) Year Limited Warranty gives you
specific legal rights, and you may also have
other rights which vary from state to state. This
Limited Warranty is given in lieu of all other
expressed and implied warranties including
the implied warranty of merchantability and
warranty of fitness for a particular purpose. If
you need additional information on this written
warranty or assistance in obtaining service,
write:
USA - MURRAY, INC.
Outdoor Power Equipment
Customer Service Department
P.O. Box 268
Brentwood, Tennessee 37027
1-800-251-8007
CANADA - MURRAY CANADA, INC.
Factory Customer Service
1195 Coutneypark Drive East
Mississauga, Ont. L5T-1R1
1-800-661-6662
PRODUCT INFORMATION
The owner must be certain that all the product
information is included with the unit. This
information includes the INSTRUCTION
BOOKS, the REPLACEMENT PARTS and the
WARRANTIES. This information must be
included to make sure state laws and other laws
are followed.
OWNER’S INFORMATION
This instruction book is written for a person with
some mechanical ability. Like most service
books, not all the steps are described. Steps on
how to loosen or tighten fasteners are steps
anyone can follow with some mechanical ability.
Read and follow these instructions before you
use the unit.
Know your product: If you understand the unit
and how the unit operates, you will get the best
performance. As you read this manual, compare
the illustrations to the unit. Learn the location
and the function of the controls. To help prevent
an accident, follow the operating instructions
and the safety rules. Keep this manual for future
reference.
IMPORTANT: Many units are not assembled
and are sold in cartons. It is the responsibility of
the owner to make sure the assembly instruc-
tions in this manual are exactly followed. Other
units are purchased in an assembled condition.
On assembled units, it is the responsibility of the
owner to make sure the unit is correctly as-
sembled. The owner must carefully check the
unit according to the instructions in this manual
before it is first used.
WARNING: Look for this symbol to indicate
important safety precautions. This symbol
indicates: “Attention! Become Alert! Your
Safety Is At Risk.”
Responsibility Of The Owner
The responsibility of the owner is to
follow the instructions below.
1. Carefully read and follow the rules for safe
operation.
2. Follow all the assembly and preparation
instructions.
3. Inspect the unit.
4. Make sure that the operator of the unit
knows how to correctly use all standard
and accessory equipment.
5. Operate the unit only with guards, shields,
and other safety items in place and working
correctly.
6. Correctly adjust the unit.
7. Service the unit only with authorized or ap-
proved replacement parts.
8. Complete all maintenance on the unit.
Environmental Awareness
DDo not fill the engine’s fuel tank completely
full.
DDrain fuel for off-season storage.
DUse only unleaded gasoline.
DService the air cleaner regularly.
DChange oil regularly. Use 5W-30 oil.
DTune-up the engine regularly.
DKeep equipment in efficient operating
condition.
DDispose of used engine oil properly.

ENGLISH
11
F-031031L
INTERNATIONAL PICTORIALS
IMPORTANT: The following pictorials are lo-
cated on your unit or on literature supplied
with the product. Before you operate the
unit, learn and understand the purpose for
each pictorial.
32
Engine Off
Engine Stop On Choke Off Choke On Neutral
N
Slow Fast Electric Start Engine Start Engine Run
Throttle Primer Button Ignition Key Ignition Off Ignition On
Drive Clutch
Forward
Auger Clutch Auger Collector
Reverse
Engage
Ignition Key
Insert To Run, Pull Out To Stop.
Fuel Oil Fuel Oil Mixture
Discharge DOWN Discharge UP
Discharge LEFT Discharge RIGHT
KGS KGS
Weight Transfer
Lift Handle To Engage Weight Transfer Depress Pedal To Disengage Transmission
Push To Engage
Electric Starter
Control And Operating Symbols
Safety Warning Symbols
DANGER
Thrown Objects.
Keep Bystanders Away.
DANGER
Thrown Objects.
Keep Bystanders Away. WARNING
IMPORTANT
Read Owner’s Manual
Before Operating
This Machine.
DANGER
Avoid Injury From
Rotating Auger. Keep
Hands, Feet And
Clothing Away.
DANGER
Stop The Engine
Before Unclogging
Discharge Chute!
STOP
WARNING
Hot Surface

ENGLISH
12
F-031031L
Safe Operation Practices for Snow Throwers
As Recommended By: American National Standards Institute.
IMPORTANT: Safety standards require operator
presence controls to minimize the risk of injury.
Your snow thrower is equipped with such con-
trols. Do not attempt to defeat the function of the
operator presence control under any circum-
stances.
Training
1. Read the operating and service instruction
manual carefully. Be thoroughly familiar with
the controls and the proper use of the equip-
ment. Know how to stop the unit and disen-
gage the controls quickly.
2. Never allow children to operate the equip-
ment. Never allow adults to operate the
equipment without proper instruction.
3. Keep the area of operation clear of all per-
sons, particularly small children and pets.
4. Exercise caution to avoid slipping or falling
especially when operating in reverse.
Preparation
1. Thoroughly inspect the area where the equip-
ment is to be used and remove all doormats,
sleds, boards, wires, and other foreign ob-
jects.
2. Disengage all clutches before starting the en-
gine (motor).
3. Do not operate the equipment without wear-
ing adequate winter outer garments. Wear
footwear that will improve footing on slippery
surfaces.
4. Handle fuel with care; it is highly flammable.
a. Use an approved fuel container.
b. Never remove fuel tank cap or add fuel to
a running engine (motor) or hot engine
(motor).
c. Fill fuel tank outdoors with extreme care.
Never fill fuel tank indoors.
d. Replace fuel cap securely and wipe up
spilled fuel.
e. Never store fuel or snow thrower with fuel
in the tank inside of a building where
fumes may reach an open flame or spark.
f. Check fuel supply before each use, allow-
ing space for expansion as the heat of the
engine (motor) and/or sun can cause fuel
to expand.
5. For all units with electric starting motors use
electric starting extension cords certified
CSA/UL. Use only with a receptacle that has
been installed in accordance with local in-
spection authorities.
6. Adjust the snow thrower height to clear gravel
or crushed rock surface.
7. Never attempt to make any adjustments
while the engine (motor) is running (except
when specifically recommended by manufac-
turer).
8. Let engine (motor) and snow thrower adjust
to outdoor temperatures before starting to
clear snow.
9. Always wear safety glasses or eye shields
during operation or while performing an ad-
justment or repair to protect eyes from foreign
objects that may be thrown from the snow
thrower.
Operation
1. Do not operate this machine if you are taking
drugs or other medication which can cause
drowsiness or affect your ability to operate
this machine.
2. Do not use this machine if you are mentally
or physically unable to operate this machine
safely.
3. Do not put hands or feet near or under rotat-
ing parts. Keep clear of the discharge open-
ing at all times.
4. Exercise extreme caution when operating on
or crossing gravel drives, walks or roads.
Stay alert for hidden hazards or traffic.
5. After striking a foreign object, stop the engine
(motor), remove the wire from the spark plug,
thoroughly inspect snow thrower for any
damage, and repair the damage before re-
starting and operating the snow thrower.
6. If the unit should start to vibrate abnormally,
stop the engine (motor) and check immedi-
ately for the cause. Vibration is generally a
warning of trouble.
7. Stop the engine (motor) whenever you leave
the operating position, before unclogging the
auger/impeller housing or discharge chute
and when making any repairs, adjustments,
or inspections.
8. When cleaning, repairing, or inspecting, make
certain the auger/impeller and all moving
parts have stopped and all controls are dis-
engaged. Disconnect the spark plug wire and
keep the wire away from the spark plug to
prevent accidental starting.
9. Take all possible precautions when leaving
the snow thrower unattended. Disengage the
auger/ impeller, stop engine (motor), and re-
move key.
10. Do not run the engine (motor) indoors, except
when starting the engine (motor) and for
transporting the snow thrower in or out of the
building. Open the outside doors; exhaust
fumes are dangerous (containing CARBON
MONOXIDE, an ODORLESS and DEADLY
GAS).
11. Do not clear snow across the face of slopes.
Exercise extreme caution when changing
direction on slopes. Do not attempt to clear
steep slopes.
12. Never operate the snow thrower without
proper guards, plates or other safety protec-
tive devices in place.
13. Never operate the snow thrower near enclos-
ures, automobiles, window wells, drop- offs,
and the like without proper adjustment of the
snow discharge angle. Keep children and
pets away.
14. Do not overload the machine capacity by at-
tempting to clear snow at too fast a rate.
15. Never operate the machine at high transport
speeds on slippery surfaces. Look behind
and use care when backing up.
16. Never direct discharge at bystanders or allow
anyone in front of the unit.
17. Disengage power to the collector/impeller
when snow thrower is transported or not in
use.
18. Use only attachments and accessories ap-
proved by the manufacturer of the snow
thrower (such as tire chains, electric start kits,
ect.).
19. Never operate the snow thrower without good
visibility or light. Always be sure of your foot-
ing and keep a firm hold on the handles.
Walk;never run.
20. Do not over- reach. Keep proper footing and
balance at all times.
21. Exercise caution if operating on steep slop-
ing surfaces.
22. This snow thrower is for use on sidewalks,
driveways and other ground level surfaces.
23. Do not use the snow thrower on surfaces
above ground level such as roofs of resi-
dences, garages, porches or other such
structures or buildings.
Maintenance And Storage
1. Check shear bolts and other bolts at frequent
intervals for proper tightness to be sure the
equipment is in safe working condition.
2. Never store the snow thrower with fuel in the
tank inside a building where ignition sources
are present such as hot water and space
heaters, clothes dryers, and the like. Allow
the engine (motor) to cool before storing in
any enclosure.
3. Always refer to operator’s guide instructions
for important details if the snow thrower is to
be stored for an extended period.
4. Maintain or replace safety and instruction la-
bels, as necessary.
5. Run the snow thrower a few minutes after
throwing snow to prevent freeze- up of the
auger/impeller.

ENGLISH
13
F-031031L
ASSEMBLY
Read and follow the assembly and adjustment
instructions for your snow thrower. All fasteners
are in the parts bag. Do not discard any parts or
material until the unit is assembled.
WARNING: Before doing any
assembly or maintenance to the
snow thrower, remove the wire
from the spark plug.
NOTE: In this instruction book, left and right
describe the location of a part from the oper-
ator’s position behind the unit.
NOTE: Torque is measured in foot pounds
(metric N.m). This measurement describes
how tight a nut or bolt must be. The torque is
measured with a torque wrench.
NOTE: Illustrations begin on page 3.
NOTE: Fasteners and loose parts are shown
at full size in Figure 31.
Tools Required
1 Knife
1 Pliers
2 1/2 inch open end wrenches
2 9/16 inch open end wrenches
2 3/4 inch open end wrenches
1 Measuring tape or ruler
1 Screwdriver
How To Remove The Snow Thrower
From The Carton
1. (Figure 1) The snow thrower is shown in the
shipping position.
2. Cut and discard the plastic tie that secures
the crank assembly.
3. Cut down all four corners of the carton and
lay the side panels flat.
4. Locate all parts that are packed separately
and remove from the carton.
5. Remove and discard the packing material
from around the snow thrower.
6. (Figure 2) For shipping purposes, the height
adjust skids (7) are attached to the pallet.
Remove the screw (17) that secures each
height adjust skid (7) to the pallet.
7. Hold onto the lower handle and pull the snow
thrower off the pallet.
CAUTION: DO NOT back over cables.
8. Remove the packing material from the han-
dle assembly.
9. Cut the ties that secure the clutch control
cables (1) to the lower handle (2). Move the
cables away from the motor frame.
How To Assemble The Handle And
Crank Assembly
1. (Figure 3) Loosen, but do not remove, the
fasteners (1) in the upper holes of the lower
handle.
2. Remove the fasteners and the crank assem-
bly eyebolt (11) from the lower holes of the
lower handle.
3. (Figure 2) Put the shift lever (6) into first
forward position.
4. (Figure 3) Raise the upper handle (2) to the
operating position.
NOTE: Make sure the cables are not
caught between the upper and lower han-
dle.
5. Install the fasteners and the crank assembly
eyebolt (11) that were removed in step 2.
DO NOT tighten until all fasteners are in
place.
6. (Figure 4) Attach the crank rod assembly
(15) to the universal joint (16) with cotter
pin (12). To lock in place, spread the ends of
the cotter pin (12).
7. (Figure 4) Attach the crank rod (15) to the
universal joint assembly (16) with the hair
pin (12).
8. (Figure 3) Tighten nut on eye bolt (11).
Make sure eye bolt (11) is properly aligned
and the crank (8) can freely rotate.
9. Tighten all handle fasteners.
How To Install The Knobs
NOTE: If knobs are already installed, go to
the next selection.
Remote Chute Knob
1. (Figure 9) Assemble remote chute knob (1)
onto lever (3) until snug against nut (3). On
some models the remote chute knob (1) is
attached.
2. Make sure lip (4) on the remote chute knob
(1) is pointed toward the engine.
3. Tighten the nut (2) against the bottom of the
remote chute knob (1).
Speed Select Knob
(Figure 9) Install the speed select knob (11) to
the speed select lever (1). On some models the
speed select knob (11) is attached.
How To Install The Speed Control Rod
1. (Figure 8) Attach the ball joint (6), located
on the bottom end of the speed control rod
(2), to the shift yoke assembly (7). The fas-
teners (8) are attached to the ball joint (6)
at the factory.
The length of the ball joint (6) and speed
control rod (2) have been pre-adjusted at
the factory. If an adjustment is required, loos-
en the nut (9). Remove the fasteners (8) to
disconnect the ball joint (6) from the shift
yoke assembly (7). To lengthen or shorten
the speed control rod (2), turn the adapter
(10) to obtain the correct length.
2. (Figure 7) Attach the handle (11) onto the
speed select lever (5). On some models the
handle (11) is attached. To lock in position,
tighten the hex jam nut (10) against the bot-
tom of the handle (11).
3. Make sure the speed select lever (5) func-
tions correctly. Move the speed select lever
(5) through all speeds.
How To Assemble The Chute Deflector
1. (Figure 10) Remove carriage bolt (1).
2. Raise the chute deflector (2) into operating
position (3).
3. Fasten chute deflector (2) to flange (4) with
carriage bolt (1). Make sure to install with
the head of the carriage bolt (1) on the in-
side of the flange (2).
4. Fasten with washer (5) and locknut (6).
5. Tighten locknut (6) securely.
NOTE: Make sure all carriage bolts in flange
are tight. DO NOT OVERTIGHTEN.
Check The Cables
1. (Figure 5) Check the traction drive cable
(1) and the auger drive cable (2). If the bot-
tom of the cables have become discon-
nected, reinstall the cables.
2. (Figure 6) If the top of the cables (5) have
become disconnected from the drive levers
(6), attach the cables (5) to the “Z” fitting
(7).
How To Set The Skid Height (Figure 2)
The snow thrower is equipped with height ad-
justable skids (7) mounted on the outside of the
auger housing (4). To adjust the height of the
skids, see “How To Adjust The Height Of The
Skids” in the Maintenance section.
How To Assemble The Drift Cutter
(if equipped)
Drift cutters are used to cut a path through snow
deeper than the auger housing.
1. (Figure 11) Loosen the wingnuts (2) that
secure the drift cutters (1) to the auger
housing.
2. Raise the drift cutters (1) to the desired
height.
3. Tighten the wingnuts (2).
How To Prepare The Engine
Note: The engine was shipped from the fac-
tory filled with oil. Check the level of the oil.
Add oil as needed. Engine does not contain
GASOLINE.
WARNING: Follow the engine
manufacturer’s instructions for the
type of fuel and oil to use. Always
use a safety fuel container. Do not smoke
when adding gasoline to the engine. When
inside an enclosure, do not fill with gaso-
line. Before you add fuel, stop the engine.
Let the engine cool for several minutes.
Check the oil. See the engine manufacturer’s
instructions for the type of fuel and oil to use.
Before you use the unit, read the information on
safety, operation, maintenance, and storage.
Important! Before You Start Operating
rCheck the fasteners. Make sure all fas-
teners are tight.
rOn electric start models, the unit was
shipped with the starter cord plugged
into the engine. Before operating, un-
plug the starter cord from the engine.
rIf a bar code label is attached to the han-
dle, remove before operating.
OPERATION
NOTE: Illustrations begin on page 3.
Know Your Snow Thrower (Figure 2)
Read this Instruction Book and safety rules be-
fore operation the snow thrower. Compare the
illustration with your snow thrower to familiarize
yourself with the location of various controls and
adjustments.

ENGLISH
14
F-031031L
Traction Drive Lever (1) - Select the forward or
reverse direction of travel.
Crank Assembly (2) - Changes the direction of
the discharge chute.
Discharge Chute (3) - Changes the distance the
snow is thrown.
Remote Chute Control Lever (17) - Control the
distance the snow is thrown.
Auger Drive Lever (5) - Starts and stops the au-
ger and impeller (snow gathering and throwing).
Speed Shift Lever (6) - Selects the speed of the
snow thrower.
Height Adjust Skid (7) - Adjusts the ground
clearance of the auger housing.
Ignition Key (8) - Must be inserted to start the en-
gine.
Primer Button (9) - Injects fuel directly into the
carburetor for fast starts in cold weather.
Electric Start Button (10) - On electric start mod-
els, used to start the engine.
Switch Box (11) - On electric start models, used
to attach a 120 volt electric power cord.
Recoil Starter Handle (12) - Use to manually
start the engine.
Throttle Control (13) - Controls the speed of the
engine.
Choke Control (14) - Use to start a cold engine.
Shear Bolts (19) - To protect the machine, spe-
cial shear bolts are designed to break is an ob-
ject becomes lodged in the auger housing. The
use of a harder bolt will destroy the protection
provided by the shear bolt.
Drift Cutters (18) - (if equipped) Cuts a path
through snow higher than the auger housing.
How To Control
The Discharge Of The Snow
WARNING: Never direct the dis-
charge of snow toward bystanders.
WARNING: Always stop the engine
before unclogging the discharge
chute or the auger housing and be-
fore leaving the snow thrower.
1. (Figure 2) Turn the crank assembly (2) to
change the discharge direction of the snow.
2. (Figure 12) Push the remote chute lever (2)
forward to discharge the snow high and far.
Pull the remote chute lever (2) back to dis-
charge the snow down.
How To Stop
The Snow Thrower (Figure 2)
1. To stop discharging snow, release the auger
drive lever (5).
2. To stop the wheels, release the traction
drive lever (1).
3. To stop the engine, push the throttle control
lever (13) to off and remove the ignition key
(8).
How To Go Forward or Backward
(Figure 2)
1. To change the ground speed, first release the
traction drive lever (1) and then move the
speed shift lever (6) to the desired speed.
2. Ground speed is determined by snow condi-
tions. Select the speed by moving the speed
shift lever (6) into the appropriate notch on
the shift lever plate.
Speed 1, 2 Wet, Heavy
Speed 3 Light
Speed 4 Very Light
Speed 5, 6 Transport only
3. To go forward, engage the traction drive
lever (1). Maintain a firm hold on the handle
as the snow thrower starts to move forward.
Guide the snow thrower by moving the han-
dle either left or right. Do not attempt to push
the snow thrower.
4. To go backward, release the tractor drive
lever (1).
5. Move the speed shift lever (6) into either
first or second reverse.
6. Engage the traction drive lever (1).
IMPORTANT: Do not move the speed shift
lever (6) while the traction drive lever (1) is
engaged.
How To Throw Snow (Figure 2)
1. Engage the auger drive lever (5).
2. To stop throwing snow, release the auger
drive lever (5).
WARNING: The operation of any
snow thrower can result in foreign
objects being thrown into the eyes,
which can result in severe eye damage.
Always wear safety glasses or eye shields
while operating the snow thrower. We rec-
ommend standard safety glasses or use a
wide vision safety mask over your glasses.
How To Use The Wheel Lockout Pin
(Figure 13)
The right wheel is secured to the axle with a
lockout pin. The unit was shipped with the lock-
out pin in the locked position. For ease of ma-
neuverability in light snow conditions, disconnect
the lockout pin as follows.
1. Pull the knob (1) out to disengage the lock-
out pin.
2. To lock in the disengaged position, turn the
knob (1) 1/4 turn (90 degrees).
Before Starting The Engine
1. Before you service or start the engine, famil-
iarize yourself with the snow thrower. Be
sure you understand the function and loca-
tion of all controls.
2. Check the tension of the clutch cable before
starting the engine. See “How To Adjust The
Clutch Cable” in the Maintenance section of
this manual.
3. Make sure that all fasteners are tight.
4. Make sure the height adjust skids are proper-
ly adjusted. See “How To Adjust The Height
Of The Skids” in the Maintenance section of
this manual.
5. Check the air pressure in the tires. The cor-
rect air pressure is 14 PSI (1 BAR) to 17 PSI
(1.25 BAR). Do not exceed the maximum
amount of air pressure shown on the side of
the tire.
How To Stop The Engine (Figure 2)
To stop the engine, move the throttle control
(3) to the stop position and remove the ignition
key (8). Keep the ignition key (8) in a safe
place. The engine will not start without the igni-
tion key (8).
How To Start The Engine (Figure 2)
Models equipped with an Electric Starter
NOTE: An electric starter kit can be added to
recoil start engines. Electric starter kits are
available from your nearest authorized ser-
vice center.
WARNING: The starter is equipped
with a three- wire power cord and
plug and is designed to operate on
120 volt A.C. household current. The power
cord must be properly grounded at all times
to avoid the possibility of electrical shock
which can injure the operator. Carefully fol-
low all instructions in the “How To Start The
Engine” section. Make sure that your house
wiring is a three- wire grounded system. If
you are not sure, ask a licensed electrician.
If your house wire system is not a
three- wire grounded system, do not use
this electric starter under any conditions. If
your system is grounded but a three- hole
grounded receptacle is not available to start
the engine, have a three- hole grounded re-
ceptacle installed by a licensed electrician.
To connect a 120 volt A.C. power cord, al-
ways connect the power cord to the switch
box (11) on the engine first. Then, plug the
other end into the three- hole grounded re-
ceptacle. When disconnecting the power
cord, always unplug the end from the
three- hole grounded receptacle first.
How To Start A Cold Engine (Figure 2)
1. Check the engine oil.
2. Fill the fuel tank with regular unleaded petrol.
See “How To Prepare The Engine”.
3. Make sure the traction drive lever (1) and
the auger drive lever (5) are in the disen-
gaged (released) position.
4. Move the throttle control (13) to the fast
position.
5. Insert the ignition key (8) into the ignition
slot. Make sure the ignition key (8) snaps
into place. Do not turn the ignition key (8).
Remove the extra ignition key and keep in a
safe place.
6. Move the choke control (14) to the full
choke position.
7. (Electric Start) Connect the power cord to
the switch box (11) located on the engine.
8. (Electric Start) Plug the other end of the
power cord into a three-hole, grounded 120
VOLT, A.C. receptacle. (See the WARNING
in this section).
9. Push the primer button (9). Every time you
push the primer button (9), wait two sec-
onds. For the number of times required to
push the primer button (9), see the engine
manufacturer’s instructions.

ENGLISH
15
F-031031L
10.(Electric Start) Push on the electric start
button (10) until the engine starts. Do not
crank for more than 10 seconds at a time.
The electric starter is thermally protected. If
the electric starter overheats, it will automati-
cally stop and can only be restarted when it
has cooled to a safe temperature. A wait of
about 5 to 10 minutes is required to allow the
electric starter to cool.
11. (Recoil Start) Rapidly pull the recoil starter
handle (12). Do not allow the recoil starter
handle (12) to snap back. Slowly return the
recoil starter handle (12).
12.If the engine does not start in 5 or 6 tries,
See the “Trouble Shooting Chart” Instruc-
tions.
13.(Electric Start) When the engine starts, re-
lease the electric start button (10) and
move the choke control (14) to 1/2 choke
position. When the engine runs smoothly,
move the choke control (14) to the off posi-
tion.
14.(Electric Start) First disconnect the power
cord from the three-hole receptacle. Then,
disconnect the power cord from the switch
box (11).
NOTE: In temperatures below 05F, allow
the engine to warm up for several minutes
before blowing snow.
15.When throwing snow, always run the engine
with the throttle control (13) in the fast posi-
tion. WARNING: Never run the engine
indoors or in enclosed, poorly ven-
tilated areas. Engine exhaust con-
tains carbon monoxide, an odorless and
deadly gas. Keep hands, feet, hair and
loose clothing away from any moving parts
located on the engine or the snow thrower.
The temperature of muffler and nearby
areas may exceed 150°F. Avoid these
areas.
How To Start A Warm Engine (Figure 2)
If an engine has been running and is still warm,
leave the choke control (14) in the off position
and do not push the primer button (9). If the
engine fails to start, follow the instructions “How
To Start A Cold Engine”.
NOTE: Do not use the primer button (9) to
start a warm engine.
How To Start An Engine With A Frozen Electric
Starter (Figure 2)
If the electric starter is frozen and will not turn
the engine, follow the instructions below.
1. Pull out the recoil starter handle (12) as far
as possible.
2. Quickly release the recoil starter handle
(12). Allow the recoil starter handle (12) to
snap back against the recoil starter.
If the engine still fails to start, repeat the two pre-
vious steps until the engine starts. Then, contin-
ue with the directions “How To Start A Cold
Engine”.
To help prevent the possible freeze-up of the
recoil starter and of the engine controls, proceed
as follows after each snow removal job.
1. With the engine running, quickly pull the re-
coil starter handle (12) three or four times
with a continuous full arm stroke. This will
produce a loud clattering sound that is not
harmful to the engine or starter.
2. Stop the engine. Wipe all snow and moisture
from the carburetor cover, control levers and
cables. Also move the throttle control (13),
choke control (14), and recoil starter han-
dle (12) several times.
How To Remove Snow or Debris From
The Auger Housing (Figure 2)
WARNING: Do not attempt to re-
move snow or debris that may be-
come lodged in auger housing
without taking the following precautions.
1. Release the auger drive lever (5).
2. Move the throttle control (13) to the stop
position.
3. Remove (do not turn) the ignition key (8).
4. Disconnect the spark plug wire.
5. Do not place your hands in the auger hous-
ing (4) or the discharge chute (3). Use a
pry bar to remove any snow or debris.
Snow Throwing Tips
1. For maximum snow thrower efficiency,
change the ground speed, NEVER change
the engine speed. The engine is designed to
deliver maximum performance at full throttle
and must be run in the fast position at all
times. In deep, freezing, or wet snow, reduce
forward speed. If the wheels slip, also reduce
forward speed.
2. Most efficient snow throwing is accomplished
when the snow is removed immediately after
if falls.
3. For complete snow removal, slightly overlap
each previous path.
4. Whenever possible, discharge the snow
down wind.
5. For normal usage, set the skids so that the
scraper bar is 1/8” above the skids. For ex-
tremely hard-packed snow surfaces, adjust
the skids upward so that the scraper bar
touches the ground.
6. Rocks and gravel must not be picked up and
thrown by the machine. On gravel or crushed
rock surfaces, set the skids at 1-1/4 inch be-
low the scraper bar. See “How To Adjust The
Height Of The Skids” in the Maintenance
section.
7. After each snow throwing job, allow the en-
gine to idle for a few minutes. The snow and
accumulated ice will melt off the engine.
8. Clean the snow thrower after each use.
9. Remove ice, snow and debris from the entire
snow thrower. Flush with water to remove all
salt or other chemicals. Wipe snow thrower
dry.

ENGLISH
16
F-031031L
MAINTENANCE CHART
CUSTOMER RESPONSIBILITIES
SERVICE RECORDS
Fill in dates as you
complete regular
service.
Before
Each
Use
First
2
Hours
Every
5
Hours
Every
10
Hours
Every
25
Hours Each
Season Before Storage SERVICE DATES
Check Engine Oil Level √ √ √
Change Engine Oil √ √
Check And Tighten All Screws and Nuts √ √
Check Spark Plug √ √
Adjust Drive Belt √ √ √
Check Fuel √
Drain Fuel √
Check Auger Clutch Cable Adjustment
(See Cable Adjustment) √ √
Check Traction Clutch Cable Adjustment
(See Cable Adjustment) √ √
Lubricate All Pivot Points √√
Lubricate Auger Shaft
(See Shear Bolt Replacement) √ √
Lubricate Drive Chains and Sprockets √ √
MAINTENANCE
NOTE: Illustrations begin on page 3.
Use the following maintenance section to keep
your unit in good operating condition. All the
maintenance information for the engine is in the
engine manufacturer’s instructions. Before you
start the engine, read this book.
WARNING: Before you make an in-
spection, adjustment (except
carburettor), or repair, disconnect
the wire from the spark plug.
General Recommendations
The warranty on this snow thrower does not cov-
er items that have been subjected to operator
abuse or negligence. To receive full value from
the warranty, the operator must maintain the
snow thrower as instructed in this manual.
Some adjustments must be made periodically to
properly maintain the snow thrower.
After Each Use
GCheck for any loose or damaged parts.
GTighten any loose fasteners.
GCheck and maintain the auger.
GCheck controls to make sure they are
functioning properly.
GIf any parts are worn or damaged, replace
immediately.
All adjustments in the Maintenance section of
this manual should be checked at least once
each season.
As Required
The following adjustment should be preformed
more than once each season.
1. Adjust the auger drive belt after the first 2 to
4 hours, again at mid-season, and twice
each season thereafter. See “How To Adjust
The Auger Drive Belt” in the Maintenance
section.
Lubrication
Every 10 Hours
1. Lubricate the Zerk fittings (1) every ten
hours with a grease gun.
2. Each time a shear bolt is replaced, the auger
shaft must also be greased.
3. Lubricate all pivot points.
Every 25 Hours (Figure 15)
Chute Rotation Gear
(Figure 4) Lubricate the chute rotation gear (1)
with automotive type oil.
Chains
1. (Figure 2) Move the speed shift lever (6) to
first gear.
2. Remove the gas from the gas tank. Stand
the snow thrower up on the front end of the
auger housing (4).
WARNING: Drain the gasoline out-
doors, away from fire or flame.
3. (Figure 21) Loosen the bolts (3) on each
side of the bottom panel (2).
4. Remove the bottom panel (2).
5. (Figure 15) Lubricate the chains (5) with a
chain type lubricant.
6. Wipe the hexshaft and sprockets (6) with
5W30 motor oil.
NOTE: If grease or oil come in contact
with the disc drive plate (1) or the friction
wheel (3), damage can result. Clean off
any oil or grease with a alcohol base sol-
vent.
7. (Figure 21) Install the bottom panel (2).
8. Tighten the bolts (3) on each side of the bot-
tom panel (2).
Items Not To Lubricate (Figure 15)
1. Do not lubricate the hex shaft and sprock-
ets (6). All bearings and bushings are life-
time lubricated. For storage, put a slight
amount of 5W-30 motor oil on a cloth and
wipe the hex shaft and sprockets (6) to
prevent rust.
2. If grease or oil comes in contact with the
disc drive plate (1) or the friction wheel
(3), the friction wheel (3) can be damaged.
Make sure to thoroughly clean the disc drive
plate (1) and the friction wheel (3).

ENGLISH
17
F-031031L
CAUTION: Any greasing or oiling of the
above components can cause contamina-
tion of the friction wheel (3). If the disc
drive plate (1) or the friction wheel (3) be-
come contaminated with grease or oil,
damage to the friction wheel will result.
3. The auger gear case is lubricated at the fac-
tory and does not require additional lubrica-
tion. If for some reason the lubricant leaks
out, have the auger gear case checked by a
factory authorized service center.
How To Adjust The Height Of The Skids
(Figure 2)
This snow thrower is equipped with two height
adjustable skids (7). These skids elevate the
front of the snow thrower. For normal hard sur-
faces, such as a paved driveway or walk, adjust
the skids as follows.
1. Put the snow thrower on a level surface.
2. Make sure both tires are equally inflated.
The correct air pressure is 14 PSI (1 BAR) to
17 PSI (1.25 BAR). Do not exceed the maxi-
mum amount of air pressure shown on the
side of the tire.
3. Put the extra shear bolts (found in the parts
bag) under each end of the scraper bar (15)
next to the adjustable skids (7).
4. Loosen the mounting nuts (16) that hold the
adjustable skids (7). To bring the front of the
snow thrower down, raise each adjustable
skids (7) . Tighten the mounting nuts (16).
NOTE: For rocky or uneven surfaces, raise
the front of the snow thrower by moving the
adjustable skids (7) down.
WARNING: Be certain to maintain
proper ground clearance for the
area to be cleared. Objects such
as gravel, rocks or other debris, if struck
by the impeller, can be thrown with suffi-
cient force to cause personal injury, prop-
erty damage or damage to the snow throw-
er.
How To Adjust
The Scraper Bar (Figure 2)
After considerable use, the scraper bar (15) will
become worn. The scraper bar (15), in con-
junction with the skids, must be adjusted to allow
1/8 inch clearance between the scraper bar
(15) and the sidewalk or area to be cleared.
1. Put the snow thrower on a level surface.
2. Make sure both tires are equally inflated.
The correct air pressure is 14 PSI (1 BAR) to
17 PSI (1.25 BAR). Do not exceed the maxi-
mum amount of air pressure shown on the
side of the tire.
3. Loosen the carriage bolts and nuts that hold
the scraper bar (15) to the auger housing
(4).
4. Adjust the scraper bar (15) to allow 1/8 inch
clearance between the scraper bar (15) and
the sidewalk or area to be cleared.
5. Tighten the carriage bolts and nuts. Make
sure that the scraper bar (15) is parallel with
the sidewalk or area to be cleared.
6. To extended the life of the scraper bar (15),
remove and reverse the mounting of the
scraper bar (15).
How To Check And Adjust The Cables
The traction drive cable and the auger drive
cable are adjusted at the factory. During normal
use, a cable can become stretched and must be
checked and adjusted as follows.
How To Check The Cables (Figure 16)
1. To check for correct adjustment, disconnect
the “Z” fitting (1) from the drive lever (2).
2. Move the drive lever (2) forward until the
drive lever (2) is contacting the plastic
bumper (3).
3. The control cable is correctly adjusted if the
center of the “Z” fitting (1) is aligned (4)
with the hole in the drive lever (2) and there
in no droop in the cable.
How To Adjust The Auger Drive Cable
1. Remove the gas from the gas tank. Stand
the snow thrower up on the front end of the
auger housing.
WARNING: Drain the gasoline out-
doors, away from fire or flame.
2. (Figure 16) Disconnect the “Z” fitting (1)
from the drive lever (2).
3. (Figure 17) Pull the spring cover up to ex-
pose the spring (5). Push the cable (6)
through the spring (5) to expose the square
end (7) on the cable (6).
4. Hold the square end (7) with pliers and ad-
just the locknut (8) in or out until the excess
slack is removed.
5. Pull the cable (6) back through the spring
(5).
6. (Figure 16) Connect the “Z” fitting (1) to the
drive lever (2).
NOTE: When the auger drive belt is adjusted
or replaced, check and adjust the cable.
How To Adjust The Traction Drive Cable
1. Remove the gas from the gas tank. Stand
the snow thrower up on the front end of the
auger housing.
WARNING: Drain the gasoline out-
doors, away from fire or flame.
2. (Figure 21) Loosen the bolts (3) on each
side of the bottom panel (2).
3. Remove the bottom panel (2).
4. (Figure 16) Disconnect the “Z” fitting (1)
from the traction drive lever (2).
5. (Figure 26) Slide the cable boot (3) off the
cable adjustment bracket (4).
6. Push the bottom of the traction control
cable (5) through the cable adjustment
bracket (4) until the “Z” hook (6) can be re-
moved.
7. Remove the “Z” hook (6) from the cable
adjustment bracket (4). Move the “Z” hook
(6) down to the next adjustment hole.
8. Pull the traction control cable (5) up
through the cable adjustment bracket (4).
9. Put the cable boot (3) over the cable ad-
justment bracket (4).
10.(Figure 16) Install the “Z” fitting (1) to the
traction drive lever (2).
11. (Figure 15) To check the adjustment, de-
press the drive lever and check the length
“A” of the drive spring (7). In correct adjust-
ment, the length “A” of the drive spring (7)
is as follows:
minimum 3 inches (76 mm.)
maximum 3-3/8 inches (85 mm.).
12.(Figure 21) Install the bottom panel (2).
13.Tighten the bolts (3) on each side of the bot-
tom panel (2).
How To Adjust The Belts
The belts will stretch during normal use. If you
need to adjust the belts due to wear or stretch,
proceed as follows.
How To Adjust The Auger Drive Belt
If the snow thrower will not discharge snow,
check the adjustment of the auger drive cable.
See “How To Check And Adjust The Cables” in
the Maintenance section. If the adjustment is
correct, then check the condition of the auger
drive belt. If the auger drive belt is damaged,
replace the auger drive belt. See “How To Re-
place The Belts” in the Maintenance section. If
the auger drive belt is loose, adjust as follows.
1. Disconnect the spark plug wire.
2. (Figure 18) Remove screw (2) from belt
cover (1). Remove the belt cover (1).
3. (Figure 19) Loosen the nut (2) on the idler
pulley (3) Move the idler pulley (3) 1/8 inch
toward the auger drive belt (4).
4. Tighten the nut (2).
5. (Figure 20) Depress the auger drive lever.
Check the tension on the auger drive belt
(4). In correct adjustment, the auger drive
belt (4) will deflect 1/2 inch (5) with moder-
ate pressure. If the adjustment is not correct,
repeat the adjustment.
6. (Figure 18) Install the belt cover (1). Tighten
screw (2).
7. Check the adjustment of the auger drive
cable. See “How To Check And Adjust The
Cables” in the Maintenance section.
8. Attach the spark plug wire.
Traction Drive Belt
The traction drive belt has constant spring pres-
sure and does not require an adjustment. If the
traction drive belt is slipping, replace the belt.
See “How To Replace The Belts” in the Mainte-
nance section.
How To Replace The Belts
The drive belts are of special construction and
must be replaced with original factory replace-
ment belts available from your nearest autho-
rized service center.
Some steps require the assistance of a second
person.
How To Remove the Auger Drive Belt
If the auger drive belt is damaged, the snow
thrower will not discharge snow. Replace the
damaged belt as follows.
1. Disconnect the spark plug wire.
2. (Figure 21) Loosen the bolts (3) on each
side of the bottom panel (2).
3. Remove the bottom panel (2).
4. (Figure 18) Remove screw (2) from belt
cover (1). Remove the belt cover (1).

ENGLISH
18
F-031031L
5. (Figure 19) Loosen the belt guide (9). Pull
the belt guide (9) away from the auger
drive pulley (10).
6. Pull the idler pulley (3) away from the auger
drive belt (4).
7. Remove the old auger drive belt (4) from
the auger drive pulley (10) and from the en-
gine pulley (11). Replace the auger drive
belt (4) with an original factory replacement
belt available from an authorized service
center.
8. Install the new auger drive belt (4) onto the
auger drive pulley (10) and onto pulley
(11).
9. Adjust the auger drive belt (4). See “How To
Adjust The Auger Drive Belt” in the Mainte-
nance section.
10.Adjust the belt guide (9). See “How To Ad-
just The Belt Guide” in the Maintenance sec-
tion.
11. (Figure 18) Install the belt cover (1). Tighten
screw (2).
12.Check the adjustment of the cables. See
“How To Check And Adjust The Cables” in
the Maintenance section.
13.(Figure 21) Install the bottom panel (2).
14.Tighten the bolts (3) on each side of the bot-
tom panel (2).
15.Connect the spark plug wire.
How To Remove the Traction Drive Belt
If the snow thrower will not move forward, check
the traction drive belt for wear or damage. If the
traction drive belt is worn or damaged, replace
the belt as follows.
1. Disconnect the spark plug wire.
2. Remove the auger drive belt. See “How To
Remove The Auger Drive Belt” in the Mainte-
nance section.
3. (Figure 19) Remove the e-ring (17) from
one end of the swing plate axle rod (18).
Remove the swing plate axle rod (18) to
allow the the swing plate to pivot forward.
4. Remove the traction drive spring (16).
5. Remove the old traction drive belt (13) from
the traction drive pulley (14) and from the
engine pulley (15). Replace the traction
drive belt (13) with an original factory re-
placement belt available from an authorized
service center.
6. Install the new traction drive belt (13) onto
the traction drive pulley (14) and onto en-
gine pulley (15).
7. Make sure the traction drive idler pulley
(12) is properly aligned with the traction
drive belt (13).
8. Attach the traction drive spring (16).
9. Install the swing plate axle rod (18) and se-
cure with the e-ring (17) removed earlier.
10.(Figure 29) The bottom of the swing plate
(20) must be positioned between the align-
ment tabs (19). Make sure the swing plate
(20) is properly secured.
NOTE: If the drive will not engage after
the traction drive belt has been replaced,
then check to make sure that the swing
plate is positioned between the alignment
tabs (19).
11. (Figure 19) Install and adjust the auger
drive belt (4). See “How To Remove The
Auger Drive Belt” in the Maintenance section.
12.Adjust the belt guide (9). See “How To Ad-
just The Belt Guide” in the Maintenance sec-
tion.
13.(Figure 21) Install the bottom panel (2).
14.Tighten the bolts (3) on each side of the bot-
tom panel (2).
15.(Figure 18) Install the belt cover (1). Tighten
screw (2).
16.Check the adjustment of the cables. See
“How To Check And Adjust The Cables” in
the Maintenance section.
17.Connect the spark plug wire.
How To Adjust The Belt Guide
1. Disconnect spark plug wire.
2. (Figure 18) Remove screw (2). Remove the
belt cover (1).
3. (Figure 2) Engage the auger drive lever (5).
4. (Figure 22) Measure the distance between
the belt guide (2) and auger drive belt (3).
The correct distance (4) is 1/8 inch (3.175
mm).
5. If an adjustment is necessary, loosen the
mounting bolt for the belt guide (2). Move
the belt guide (2) to the correct position
(4). Tighten the mounting bolt for the belt
guide (2).
6. (Figure 18) Install the belt cover (1). Tighten
screw (2).
7. Connect the spark plug wire.
How To Adjust Or Replace The Friction
Wheel
How To Check The Friction Wheel
If the snow thrower will not move forward, check
the traction drive belt, the traction drive cable or
the friction wheel. If the friction wheel is worn or
damaged, it must be replaced. See “How To
Replace the Friction Wheel” in this section. If the
friction wheel is not worn or damaged, check as
follows.
1. (Figure 2) Remove the gas from the gas
tank. Stand the snow thrower up on the front
end of the auger housing (4).
WARNING: Drain the gasoline out-
doors, away from fire or flame.
2. Disconnect the spark plug wire.
3. (Figure 21) Loosen the bolts (3) on each
side of the bottom panel (2).
4. Remove the bottom panel (2).
5. (Figure 2) Position the shift speed lever (6)
in the lowest forward speed.
6. (Figure 23) Note the position of the friction
wheel (4). The correct distance “A” from the
right side of the friction wheel (4) to the out-
side of the motorbox is as follows:
Tire Size Distance “A”
12 and 13 inch 4-1/8” (10.5 cm.)
16 inch 4-5/16” (10.95 cm.)
If the friction wheel (4) is not in the correct
position, adjust as follows.
How To Adjust The Friction Wheel
1. (Figure 2) Position the shift speed lever (6)
in the lowest forward speed.
2. (Figure 8) Loosen hex jam nut (9) on speed
select rod (2). Remove ball joint (6) from
shifter rod (7).
3. (Figure 23) Move the friction wheel (4) to
the correct position.against the snap ring
(1).
4. (Figure 8) Turn the adaptor (10) until the
ball joint (6) is aligned with the mounting
hole in the shifter rod (7). When aligned,
attach the ball joint (6) to the shifter rod (7).
5. (Figure 21) Install the bottom panel (2).
6. Tighten the bolts (3) on each side of the bot-
tom panel (2).
How To Replace The Friction Wheel
If the friction wheel is worn or damaged, the
snow thrower will not move forward. The friction
wheel must be replaced as follows.
1. (Figure 2) Remove the gas from the gas
tank. Stand the snow thrower up on the front
end of the auger housing (4).
WARNING: Drain the gasoline out-
doors, away from fire or flame.
2. Disconnect the spark plug wire.
3. (Figure 27) Remove the fasteners that se-
cure the right wheel (10). Remove the right
wheel (10) from the axle (11).
4. Loosen the bolts (3) on each side of the bot-
tom panel (2).
5. Remove the bottom panel (2).
6. (Figure 28) Remove the fasteners that se-
cure the drive sprocket (12) to the axle (11).
7. Remove the left wheel, axle (11), and drive
sprocket (12).
8. (Figure 29) Remove the four bolts (16) that
hold the bearings (7) on each side of the
hex shaft (8).
9. (Figure 30) Remove the hex shaft (8) and
bearings (7).
NOTE: Take special note of the position of
the washers (17) .
10.(Figure 24) Remove the three fasteners (4)
that hold the friction wheel (5) to the hub
(6).
11. (Figure 24) Remove the friction wheel (5)
from the hub (6). Slip the friction wheel (5)
off the hex shaft (8).
12.Assemble the new friction wheel (5) onto
hub (6) with the fasteners removed earlier.
13.(Figure 30) Install the hex shaft (8) and
bearings (7) with the four bolts removed ear-
lier.
Make sure the washers (17) are properly
installed in the original position. Also,
make sure the two washers (13) are prop-
erly aligned with the actuator arms (14).
14.Make sure the hex shaft (8) turns freely.
15.(Figure 28) Install the left wheel, axle (11),
and drive sprocket (12) with the fasteners
removed earlier. Install the chain (15) onto
the drive sprocket (12).
16.Check the adjustment of the friction wheel.
See “How To Adjust The Friction Wheel” in
this section.
17.Make sure the friction wheel and the disc
drive plate are free from grease or oil.
18.(Figure 21) Install the bottom panel (2).
19.Tighten the bolts (3) on each side of the bot-
tom panel (2).
20.(Figure 27) Install the right wheel (10) to the
axle (11) with the fasteners removed earlier.
21.Connect the spark plug wire.
How To Replace the Auger Shear Bolt
The augers are secured to the auger shaft with
special shear bolts. These shear bolts are de-

ENGLISH
19
F-031031L
signed to break and protect the machine if an
object becomes lodged in the auger housing.
Do not use a harder bolt as the protection pro-
vided by the shear bolt will be lost.
WARNING: For safety and to pro-
tect the machine, use only original
equipment shear bolts.
To replace a broken shear bolt, proceed as fol-
lows. Extra shear bolts were provided in the as-
sembly parts bag.
1. (Figure 2) Move the throttle control (13) to
the stop position. Disengage all controls.
2. Disconnect the spark plug wire. Make sure
all moving parts have stopped.
3. (Figure 14) Lubricate the auger shaft Zerk
fitting (1), if equipped, with a grease gun.
4. (Figure 25) Align the hole in the auger with
the hole in the auger shaft. Install the new
shear bolt (2), spacer (3) and locknut (4).
5. Connect the spark plug wire.
How To Prepare The Snow Thrower For
StorageWARNING: Do not remove gasoline
while inside a building, near a fire,
or while you smoke. Gasoline
fumes can cause an explosion or a fire.
1. Drain the fuel tank.
2. Let the engine run until it is out of gasoline.
3. Drain the oil from the warm engine. Fill the
engine crankcase with new oil.
4. Remove the spark plug from the cylinder.
Pour one ounce of oil into the cylinder. Slow-
ly pull the recoil-start grip so that the oil will
protect the cylinder. Install a new spark plug
in the cylinder.
5. Thoroughly clean the snow thrower.
6. Lubricate all lubrication points. See the Main-
tenance section.
7. Be sure that all nuts, bolts and screws are
securely fastened. Inspect all visible moving
parts for damage, breakage and wear. Re-
place if necessary.
8. Cover the bare metal parts of the blower
housing, auger, and the impeller with spray
rust preventative lubricant.
9. Put the unit in a building that has good ven-
tilation.
10.If the machine must be stored outdoors,
block up the snow thrower to be sure the en-
tire machine is off the ground.
11.Cover the snow thrower with a suitable pro-
tective cover that does not retain moisture.
Do not use plastic.
How To Order Replacement Parts
The replacement parts are shown either on the
back pages of this Instruction Book or in a
separate Parts List Book.
Use only manufacturer’s authorized or approved
replacement parts. The letter placed on the end
of the part number denotes the type of finish for
the part, C for chrome, Z for zinc, a PA for
purchased assembly. It is important that you
include this when ordering a part. Do not use
attachments or accessories not specifically
recommended for this unit. In order to obtain
proper replacement parts you must supply the
model number (see nameplate).
Replacement parts, except for the engine,
transmission, transaxle or differential, are
available from the store where the product was
purchased, a service shop recommended by the
store or from a “Murray, Inc. Central Parts
Distributor” listed on the back page of this
Instruction Book.
If you are unable to obtain parts or service in the
manner outlined above, then contact:
USA - MURRAY, INC.
Outdoor Power Equipment
Customer Service Department
P.O. Box 268
Brentwood, Tennessee 37027
1-800-251-8007
CANADA - MURRAY CANADA, INC.
Factory Customer Service
1195 Coutneypark Drive East
Mississauga, Ont. L5T-1R1
1-800-661-6662 Collect telephone calls will not
be accepted.
Replacement parts for the engine, transaxle, or
transmission, are available from the
manufacturer’s authorized service center found
in the yellow pages of the telephone directory.
Also, see the individual engine or transmission
warranties to order replacement parts.
When ordering the following information is
required:
(1) The Model Number
(2) Serial Number
(3) Part Number
(4) Quantity
TROUBLE SHOOTING CHART
TROUBLE CAUSE CORRECTION
Difficult starting Defective spark plug. Replace spark plug.
Water or dirt in fuel system. Use carburetor bowl drain to flush and refill with
fresh fuel.
Engine runs erratic Blocked fuel line, empty gas tank, or stale
gasoline Clean fuel line; check fuel supply; add fresh gasoline
Engine stalls Unit running on CHOKE. Set choke lever to RUN position.
Engine runs erratic;
Loss of power Water or dirt in fuel system. Use carburetor bowl drain to flush and refill with fresh fuel.
Excessive vibration Loose parts: damaged impeller Stop engine immediately and disconnect spark
plug wire. Tighten all bolts and make all
necessary repairs. If vibration continues, have
the unit serviced by a competent repairman.
Unit fails to propel itself Drive belt loose or damaged. Replace drive belt.
Incorrect adjustment of traction drive cable Adjust traction drive cable.
Worn or damaged friction wheel. Replace friction wheel.
Unit fails to discharge snow Auger drive belt loose or damaged. Adjust auger drive belt; replace if damaged.
Auger control cable not adjusted correctly. Adjust auger control cable.
Shear bolt broken Replace shear bolt
Discharge chute clogged. Stop engine immediately and disconnect spark
plug wire. Clean discharge chute and inside of
auger housing.
Foreign object lodged in auger Stop engine immediately and disconnect spark
plug wire. Remove object from auger.

FRANÇAIS
20
F-031031L
SOMMAIRE
INFORMATIONS SUR LE PRODUIT 20
INFORMATIONS DESTINEES AU
PROPRIETAIRE 20
PICTOGRAMMES INTERNATIONAUX 21
MONTAGE 23
FONCTIONNEMENT 24
MAINTENANCE 26
TABLEAU DE DEPANNAGE 30
GARANTIE LIMITEE DE DEUX ANS
Murray, Inc. garantie auprès de l’acheteur initial
que cette machine est dépourvue de défauts
matériels et de construction sous utilisation et
entretien normaux pendant une durée de deux
(2) ans à partir de la date d’acquisition ; cette
garantie cependant ne couvre pas les moteurs,
accessoires (tels que moteurs électriques) et
pièces d’usure normale (exceptées les pièces
mentionnées ci-dessous) étant donné que les
sociétés fabriquant ces articles offrent leurs
propres garanties et fournissent des réparations
par le biais de leurs centres de maintenance
spécialisés agréés. Pour plus d’informations, se
reporter aux garanties couvrant ces pièces
particulières. Si vous ne savez pas si votre
machine contient ou est équipée d’une ou
plusieurs de ces pièces, adressez vous à votre
revendeur avant l’acquisition. Sous réserve des
modalités et conditions de cette garantie limitée,
nous nous engageons à réparer ou remplacer, à
notre discrétion et gratuitement auprès de
l’acheteur initial, toute pièce couverte par cette
garantie limitée jusqu’à l’expiration de la garantie
applicable.
Les pièces d’usure normale comprennent les
courroies d’entraînement, les fraises
hélicoïdales, les goupilles de cisaillement, les
pneumatiques, et les phares. Ces pièces sont
garanties sans défaut matériel ou de
construction dans l’état où elles ont été livrées
avec le produit. Toute réclamation concernant la
réparation ou le remplacement d’une pièce
d’usure normale doit être effectuée dans les
trente (30) jours suivant la date d’acquisition.
Aucune réclamation ne sera honorée
concernant des dommages provenant de la
simple utilisation, d’un usage abusif, ou d’une
mauvaise utilisation.
Cette garantie Murray, Inc. de deux (2) ans
constitue votre recours exclusif ; cependant,
cette garantie est nulle ou ne s’applique pas aux
machines ayant été modifiées, endommagées,
fait l’objet d’une utilisation abusive, ou utilisées
lors d’une location ou à des fins commerciales
et/ ou professionnelles (autre que domestiques).
Votre garantie ne couvre pas les réglages
mécaniques mineurs non dus à des défauts
matériels de fabrication. Consultez votre manuel
d’utilisation pour obtenir une assistance
concernant ces réglages.
Pour effectuer une réclamation sous la garantie
limitée de deux (2) ans Murray, Inc., retourner
la machine, (ou, suivant notre autorisation
préalable, la pièce défectueuse) accompagnée
de votre preuve d’achat, auprès du Centre de
maintenance agréé le plus proche de chez vous.
Pour localiser le centre de maintenance le plus
proche, contactez le Distributeur de pièces
régional de votre région figurant sur la liste
fournie avec votre machine, ou consultez les
pages jaunes de votre annuaire téléphonique
local. Si vous nous retournez la machine
complète, nous réparerons celle-ci. Si nous
autorisons seulement le retour de la pièce
défectueuse, nous effectuerons soit la réparation
de celle-ci, soit son remplacement. Cette
garantie limitée Murray, Inc. de deux (2) ans
vous octroie des droits légaux spécifiques, et
vous pouvez également vous prévaloir d’autres
droits dont le contenu varie selon l’Etat où ils
s’appliquent. Cette garantie limitée est
délivrée en lieu et place de toute garantie
stipulée ou tacite, ceci incluant la garantie
tacite de commerciabilité et la garantie de
fonctionnalité pour une tâche définie. Si
vous souhaitez recevoir des informations
supplémentaires concernant cette garantie
écrite ou une assistance quant à l’obtention de
services de réparation, adressez-vous à :
USA - MURRAY, INC.
Outdoor Power Equipment
Customer Service Department
P.O. Box 268
Brentwood, Tennessee 37027
1-800-251-8007
CANADA - MURRAY CANADA, INC.
Factory Customer Service
1195 Coutneypark Drive East
Mississauga, Ont. L5T-1R1
1-800-661-6662
INFORMATIONS SUR LE
PRODUIT
Le propriétaire doit être certain que tous les
renseignements sur le produit sont inclus avec
la tondeuse. Ces renseignements comprennent
les MANUELS D’INSTRUCTION, les PIECES
DE RECHANGE, et les GARANTIES. Ces
renseignements doivent être inclus pour
s’assurer que les lois d’Etat et les autres lois
sont observés.
INFORMATIONS DESTINEES AU
PROPRIETAIRE
Ce manuel se dirige aux personnes familiarisées
avec ce genre de manipulations mécaniques. La
plupart des ouvrages de maintenance ne men-
tionnent pas toutes les étapes, et cet ouvrage ne
fait pas exception. Serrer ou desserrer des atta-
ches sont des manipulations que tout le monde
peut effectuer avec une certaine pratique. Lisez
et suivez ces instructions avant d’utiliser la ton-
deuse.
Apprenez à maîtriser l’appareil : si vous com-
prenez le fonctionnement de ce modèle, vous en
obtiendrez les meilleures performances. Au fur
et à mesure que vous lisez le manuel, reportez-
vous aux illustrations. Sachez repérer l’emplace-
ment des commandes et leur fonction. Afin de
prévenir tout risque d’accident, observez les ins-
tructions de fonctionnement et les règles de sé-
curité. Conservez ce manuel pour future
référence.
IMPORTANT : De nombreux appareils ne sont
pas assemblés et sont vendus démontés dans
leur carton d’emballage. Il est alors de la res-
ponsabilité du propriétaire de veiller à ce que les
instructions de montage présentes dans le ma-
nuel soient suivies en toute exactitude. D’autres
appareils sont vendus entièrement montés. En
ce qui concerne les machines déjà montées, il
est de la responsabilité du propriétaire de veiller
à ce que la machine soit correctement assem-
blée. Le propriétaire doit vérifier attentivement la
machine en fonction des instructions présentes
dans le manuel avant de commencer à utiliser
celle-ci.
DANGER : repérez ce symbole qui vous
indiquera les précautions de sécurité im-
portantes. Ce symbole signifie : “Attention!
Soyez prudent! Vous encourrez des ris-
ques.”
Responsabilité de l’utilisateur
La responsabilité de l’utilisateur est de
suivre les instructions ci-dessous.
1. Lire soigneusement ce manuel et suivre les
règles indiquées pour un usage de la ton-
deuse en toute sécurité.
2. Suivre les instructions de montage et de
préparation.
3. Inspecter la tondeuse.
4. S’assurer que l’utilisateur de la tondeuse
sait bien utiliser les équipements standards
et les accessoires.
5. N’utiliser la tondeuse qu’avec les équipe-
ments de protection, les écrans et autres
dispositifs de sécurité bien en place et en
bon état de marche.
6. Procéder aux réglages nécessaires.
7. Entretenir la tondeuse avec les pièces de
rechange autorisées ou agréées.
8. Veiller à ce qu’un entretien complet soit ef-
fectué sur la tondeuse.
Prise de conscience environnementale
DNe pas remplir le réservoir d’essence du
moteur au ras-bord.
DVider l’essence pendant le remisage hors
saison.
DN’utiliser que de l’essence sans plomb.
DEntretenir régulièrement le filtre à air.
DChanger l’huile régulièrement. Utiliser de
l’huile de grade 5W-30.
DEffectuer un réglage du moteur régulière-
ment.
DConserver le matériel en bon état de mar-
che.
DEliminer l’huile de vidange de façon écolo-
gique.
