IMPORTANT:
Read and follow all safety rules and operating
instructions before using this product.
Instruction
Manual
40 V Cordless Pole Saw
Battery (Sold Separately)
(40V, 2Ah Model # 060-1765-0)
Charger (Sold Separately)
(40V Model # 060-7541-6)

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
2
Type: Cordless, Battery-powered
Battery (sold separately): 40 V max 2 Ah, lithium-ion
Bar length: 8” (20.3 cm)
Chain pitch: 3/8” (9.5 mm)
Chain type: OREGON® (91PJ033X)
Chain bar type: 080NDEA318
Speed: 4200 RPM (no load)
Extended length: 8’ (2.4 m)
Collapsed length: 5’ (1.5 m)
Maximum limb size: 6” (15.2 cm) diameter
Weight (with battery): 9 lb 11 oz (4.4 kg)
Replacement battery: 060-1765- 0
Replacement chain: 054-5603-8
Replacement charger: 060-7541-6
SPECIFICATIONS 2
KNOW YOUR POLE SAW 3
SYMBOLS 4
SAFETY INFORMATION 6
EXPLODED VIEW 12
PARTS LIST 13
PREPARATION 14
ASSEMBLY INSTRUCTION 15
OPERATING INSTRUCTION 16
CARE AND MAINTENANCE 21
TROUBLESHOOTING 31
WARRANTY 32
Specifications Table of Contents

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
3
Know Your Pole Saw
1
2
3
4
5
6
7
8
9
10
11
1Handle pole
2Extension pole
3Power head pole
4Oil cap
5Safety lock button
6Collar
7Trigger switch
8Bar cover knob
9Bar cover
10 Chain tension screw
11 Scabbard

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
4
Symbols
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product more
efficiently and more safely.
SAVE THESE INSTRUCTIONS!
Symbols Name Designation/Explanation
VVolts Voltage
AAmperes Current
Hz Hertz Frequency (cycles per second)
WWatts Power
hrs Hours Time
n
o
No Load Speed Rational speed, at no load
/ min Per Minute Revolutions, strokes, surface speed, orbits etc., per
minute.
Lithium-ion Battery
Recycling
Designates that this tool is in compliance with Lithi-
um-Ion battery recycling program requirements.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Read the Operator’s
Manual
To reduce the risk of injury, users must read and under-
stand the operator’s manual before using this product.
Safety Alert Symbol Precautions that involve your safety.
Keep Bystanders
Away Keep all bystanders at least 50’ (15 m) away.
Risk of Electrocution DANGER! Risk of electrocution!
Gloves Wear non-slip, heavy-duty protective gloves when
handling the pole saw and the blade.
Safety Footwear Wear non-slip safety footwear when using this equip-
ment.
Eye and Head Pro-
tection
Wear eye and head protection when operating this
equipment.
Hearing Protection Wear hearing protection when operating this equipment.
Respiratory Protection Wear respiratory protection when operating this equip-
ment.
Electric Shock Failure to use in dry conditions and to observe safe
practices can result in electric shock.

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
5
!
Symbols
WARNING: To avoid serious personal injury, do not attempt
to use this product until you have read this Owner’s Manual
thoroughly and understand it completely. If you do not
understand the warnings and instructions in this Owner’s
Manual, do not use this product. Call 1.866.523.5218 for
assistance.
The operation of any power tool can result in foreign objects
being thrown into your eyes, which can result in severe eye
damage. Before beginning power tool operation, always
wear safety goggles or safety glasses with side shields and,
when needed, a full face shield. We recommend a wide vision
safety mask for use over eyeglasses or standard safety
glasses with side shields. Always use eye protection which is
marked to comply with ANSI Z87.1.
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
Symbol Signal Meaning
DANGER Indicates an imminently hazardous situation, which, if not
avoided, could result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that
may result in property damage.

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
6
Safety Information
!WARNING: Read and understand all instructions. Failure to follow all
instructions listed below may result in electric shock, fire, and/or serious
personal injury.
Save all warnings and instructions for future reference.
The term “power tool” in all of the warnings listed below refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1. WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2. ELECTRICAL SAFETY
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply.
3. PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equip-
ment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before con-
necting to battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites acci-
dents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enable better control of the tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair,clothing
and gloves away from moving parts. Loose clothes, jewellery, or long hair can be
caught in moving parts.

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
7
Safety Information
• If devices are provided for the connection of dust extraction and collection facili-
ties, ensure these are connected and properly used. Use of these devices can reduce
dust-related hazards.
4. POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the battery pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures re-
duce the risk of starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfa-
miliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts, break-
age of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poor maintenance.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cut-
ting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these in-
structions, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations different from those intended could result in
a hazardous situation.
5. BATTERY TOOL USE AND CARE
• Ensure the switch is in the off position before inserting battery pack. Inserting the
battery pack into power tools that have the switch on invites accidents.
• Recharge only with the charger specified by the manufacturer. A charger that is suit-
able for one type of battery pack may create a risk of fire when used with another battery
pack.
• Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects like paper
clips, coins, keys, nails, screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the battery terminals together may
cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
6. FOR ALL APPLIANCES
• Avoid dangerous environment. Don’t use appliances in damp or wet locations.
• Don’t use in rain.
• Keep Children Away. All visitors should be kept at a distance from work area.

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
8
• Dress Properly. Do not wear loose clothing or jewelry. They can be caught in mov-
ing parts. Use of rubber gloves and substantial footwear is recommended when
working outdoors. Wear protective hair covering to contain long hair.
• Don’t Overreach. Keep proper footing and balance at all times.
• Stay Alert. Watch what you are doing. Use common sense. Do not operate appli-
ance when you are tired.
• Store Idle Appliances Indoors – When not in use, appliances should be stored in-
doors in dry, and high or locked-up place – out of reach of children.
• Avoid Unintentional Starting. Don’t carry plugged-in appliance with a finger on the
switch. Be sure the switch is off when plugging in.
• Use safety glasses. Always use face or dust mask if operation is dusty.
• Use right appliance. Do not use appliance for any job except that for which it is in-
tended.
• Don’t grasp the exposed cutting blades or cutting edges when picking up or hold-
ing the appliance.
• Don’t force appliance. It will do the job better and with less likelihood of a risk of
injury at the rate for which it was designed.
• Maintain appliance with care. Keep cutting edge sharp and clean for best per-
formance and to reduce the risk of injury. Follow instructions for lubricating and
changing accessories. Inspect appliance cord periodically, and if damaged, have
it repaired by an authorized service facility. Inspect extension cords periodically
and replace if damaged. Keep handles dry, clean, and free from oil and grease.
• Check damaged parts. Before further use of the appliance, a guard or other part
that is damaged should be carefully checked to determine that it will operate prop-
erly and perform its intended function. Check for alignment of moving parts, bind-
ing of moving parts, breakage of parts, mounting, and any other condition that
may affect its operation. A guard or other part that is damaged should be properly
repaired or replaced by an authorized service centre unless indicated elsewhere
in this manual.
7. FOR BATTERYOPERATED APPLIANCES
• Prevent unintentional starting. Ensure the switch is in the off-position before con-
necting to battery pack, picking up or carrying the appliance. Carrying the appli-
ance with your finger on the switch or powered appliance that have the switch on
can cause accidents.
• Do not charge appliance in rain, or in wet locations.
• Do not use battery-operated appliance in rain.
• When replacing batteries, all batteries should be replaced at the same time.
Mixing fresh and discharged batteries could increase internal cell pressure and
rupture the discharge battery(ies). (Applies to products employing more than one
separately replaceable primary battery.)
• When inserting batteries into this product, the proper polarity or direction must be
observed. Reverse insertion of batteries can result in leakage or explosion. (Ap-
plies to product employing more than one separately replaceable primary battery.)
• Remove or disconnect battery before servicing, cleaning or removing material
Safety Information

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
9
Safety Information
from the gardening appliance.
• Use only the following type and size battery(ies): 060-1765-0 (40V 2Ah).
• Do not dispose of the battery(ies) in a fire. The cell may explode. Check with local
codes for possible special disposal instructions.
• Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if swallowed.
• Exercise care in handling batteries in order not to short the battery with conduct-
ing materials such as rings, bracelets, and keys. The battery or conductor may
overheat and cause burns.
• Wear full eye protection and protective clothing.
• If electrolyte contacts the skin, wash it off immediately with water.
• If electrolyte contacts the eyes, flush thoroughly and immediately with water. Seek
medical attention.
8. SERVICE
• Have your power tool serviced by a qualified repair person using only identical re-
placement parts. This will ensure that the safety of the power tool is maintained.
POLE SAW SAFETY WARNINGS
• Kickback is a dangerous reaction that can lead to serious injury. Kickback may
occur when the moving chain contacts an object at the upper portion of the tip of
the guide bar or when the wood closes in and pinches the chain in the cut. Contact
at the upper portion of the tip of the guide bar can cause the chain to dig into the object
and stop the chain for an instant. The result is a lightning-fast, reverse reaction which
kicks the guide bar up and back toward the operator. If the chain is pinched along the top
of the guide bar, the guide bar can be driven rapidly back toward the operator, which can
cause loss of control and may result in serious injury. Do not rely exclusively upon the
safety devices built into the product. With a basic understanding of kickback, you can re-
duce or eliminate the element of surprise. Sudden surprise contributes to accidents.
• Do not operate near electrical power lines. The unit has not been designed to pro-
vide protection from electric shock in the event of contact with overhead electric
lines. Consult local regulations for safe distances from overhead electric power lines and
ensure that the operating position is safe and secure before operating the pole saw.
• Use pole saw for cutting wood only. Do not use for cutting non-wood items.
• Make sure that the area in which you are cutting is free from obstructions. Do not
let the nose of the guide bar contact a log, branch, fence, or any other obstruction while
you are operating the unit. Have a planned retreat path.
• Keep all parts of the body away from the saw chain. Make sure the switch is off
when clearing jammed material. Saw chain continues to move after the switch is turned
off. A moment of inattention while operating the pole saw may result in serious personal
injury.
• Carry the pole saw by the handle with the saw chain stopped. When transporting
or storing the pole saw, always fit the saw chain device cover. Proper handling of the
pole saw will reduce possible personal injury from the saw chain.
• Hold the power tool by insulated gripping surfaces only, because the cutter blade

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
10
Safety Information
may contact hidden wiring or its own cord. A saw chain contacting a “live” wire may
make exposed metal parts of the pole saw “live” and could give the operator an electric
shock.
• Keep cable away from cutting area. During operation the cable may be hidden in
shrubs and can be accidentally cut by the saw chain.
• Do not use the pole saw in bad weather conditions, especially when there is a risk
of lightning. This decreases the risk of being struck by lightning.
• To reduce the risk of electrocution, never use near any electrical power lines. Con-
tact with or use near power lines may cause serious injury or electric shock resulting in
death.
• Always use two hands when operating the pole saw. Hold the pole saw with both
hands to avoid loss of control.
• Always use head protection when operating the pole saw overhead. Falling debris
can result in serious personal injury.
• Do not grasp the exposed cutting blades or cutting edges when picking up or hold-
ing the product.
• To protect yourself from electrocution, do not operate within 50’ (15 m) of overhead
electrical lines.
• Before starting the motor, make sure the chain is not contacting any object.
• To protect yourself from falling branches, do not stand directly under the branch
or limb being cut. This unit should not be held at an angle over 60° from ground
level.
• Turn off the motor and make sure cutting attachment has stopped before setting
unit down.
• Do not operate the saw with one hand! Serious injury to the operator, helpers, by-
standers, or any combination of these persons may results from one hand opera-
tion. This saw intended for two-handed use.
• Use extreme caution when cutting small-sized brush and saplings because slen-
der material may catch the saw chain and be whipped toward you or pull you off
balance.
• When cutting a limb that is under tension, be alert for spring back so that you will
not be struck when the tension in the wood fibers is released.
• To avoid accidental starting, never carry plugged in product with finger on switch.
Be sure switch is off when plugging in.
• DANGER — Keep hands away from blades.
• Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire explosion
or risk of injury.
• Do not expose a battery pack or appliance to fire or excessive temperature. Expo-
sure to fire or temperature above 130°C may cause explosion. The temperature of
130°C can be replaced by the temperature of 265°F.
• Follow all charging instructions and do not charge the battery pack or appliance
outside of the temperature range specified in the instructions. Charging improper-
ly or at temperatures outside of the specified range may damage the battery and

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
11
SAVE THESE INSTRUCTIONS!
increase the risk of fire.
• Have servicing performed by a qualified repair person using only identical re-
placement parts. This will ensure that the safety of the product is maintained.
• Do not modify or attempt to repair the appliance or the battery pack (as applica-
ble) except as indicated in the instructions for use and care.
Safety Information

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
12
1
2
3
4
5
6
7
8
9
10
12
11
Exploded View

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
13
ITEM PART No. DESCRIPTION QTY
1 34112320A Scabbard 1
2 32902320C Bar 1
3 32901320 Chain 1
4 311051770 Side cover assembly 1
5 311041770 Oil cap 1
6 311031770 Powerhead Pole Assembly 1
7 311021770 Intermediate Pole 1
8 311011770 Handle Pole Assembly 1
9 211011365 40V 2Ah battery (sold separately) 1
10 33902102-2 Sprocket 1
11 3290875-1 C-Clip 1
12 31106980 Charger (sold separately) 1
Parts List

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
14
Before beginning to operate this product, make sure all parts are present. Compare parts
with package contents list. If any part is missing or damaged, do not attempt to operate
the product.
Helpful Tools (not included): Cross-head screwdriver for tightening the chain.
UNPACKAGING
• Carefully remove the product and any accessories from the box. Make sure that all
items listed in the packing list are included.
• Inspect the product carefully to make sure no breakage or damage occurred during
shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.
• If any parts are damaged or missing, please call 1.866.523.5218 for assistance.
• If any parts are damaged or missing, do not operate this product
until the parts are replaced. Failure to heed this warning could result
in serious personal injury.
• Do not attempt to modify this product or create accessories not
recommended for use with this product. Any such alteration or
modification is misuse and could result in a hazardous condition
leading to possible serious personal injury.
• Do not install the battery until assembly is complete. Failure to
comply could result in accidental starting and possible serious
personal injury.
!
Preparation

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
15
CONNECTING THE POLES
Before using the pole saw, assembly is required.
• Remove packaging material and discard.
• Insert the extension pole into the handle pole and slide together.
• Lower the collar on the extension pole to the threaded base on the handle pole and rotate
clockwise to secure.
• Repeat this process to attach the extension pole to the power head pole.
• Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufficient to inflict
serious injury.
• Always wear safety goggles or safety glasses with side shields
when operating power tools. Failure to do so could result in objects
being thrown into your eyes, resulting in possible serious injury.
• Do not use any attachments or accessories not recommended
by the manufacturer of this product. The use of attachments or
accessories not recommended can result in serious personal injury.
• Failure to lock power head pole as directed above could result in
serious injury or death.
!
Collar
Collar
Powerhead Pole
Handle Pole
Intermediate Pole
Threaded Base
Threaded Base
Assembly Instructions

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
16
ADDING BAR AND CHAIN LUBRICANT
Use a bar and chain lubricant (not included) with this product. It is designed for chains and
chain oilers, and is formulated to perform over a wide temperature range with no dilution
required.
• Remove oil cap.
• Carefully pour the bar and chain oil into the tank.
• Wipe off excess oil. Replace oil cap.
• Check and fill the oil tank until the quick view oil indicator is below the second to last
indicator line.
• Repeat as needed.
Quick View
Oil Indicator
Oil Reser-
voir Cap
I
C
C
I
R
!NOTE: This pole saw comes from the factory with no
bar and chain oil added. The level should also be checked
after every 20 minutes of use and refilled as needed.
!NOTE: Do not use dirty, used or otherwise contaminated oils.
Damage may occur to the bar or chain.
!NOTE: It is normal for oil to seep from the saw when not in use.
To prevent seepage, empty the oil tank after each use, then
run for one minute. When storing the unit for a long period
of time (three months or longer), be sure the chain is lightly
lubricated; this will prevent rust on the chain and bar sprocket.
!IMPORTANT: To preserve natural resources, please recycle or
dispose of oil properly. Consult your local waste authority for
information regarding available recycling and/disposal options.
Operating Instructions

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
17
!
BATTERY
To install the battery:
1. Align the battery with the battery opening.
2. Insert the battery into the battery opening until the
battery release button locks into place.
3. Push down on the battery until it locks into place. You
should hear a “click” once it is installed.
To remove the battery:
1. Press the battery release button on the pole saw.
This will cause the battery to slightly raise out of the
tool.
2. Grasp the pole saw firmly and pull the battery out of
the handle.
WARNING: Follow these instructions in order to avoid injury and to
reduce the risk of electric shock or fire:
• Replace the battery or the charger immediately if the battery case
or charger cord is damaged.
• Verify that the switch is in the OFF position before inserting or
removing the battery pack.
• Verify that the battery is removed and the switch is in the OFF
position before inspecting, adjusting, or performing maintenance on
any part of the pole saw.
• Read, understand, and follow the instructions contained in the
charger manual.
IMPORTANT: The battery may not be charged when it is purchased.
Before using the pole saw for the first time, place the battery in the
battery charger and charge. Make sure to read all safety precautions
and follow the instructions in the battery and charger manuals.
!
IMPORTANT: This lithium-ion battery is equipped with an internal
circuit breaker which will automatically shut off the power to the tool
and then reset itself once cooled. Follow these steps if an overload
occurs while under heavy use:
1. Release the power switch and restart the tool by depressing the
switch.
2. The battery may need to be removed for approximately 1 minute,
allowed to cool and then reinstalled for use.
!
Operating Instructions

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
18
!
!
STARTING AND STOPPING
• Press the safety lock button. Squeeze the trigger switch to start.
• Release the trigger switch to stop.
ADJUSTING POLE SAW HEIGHT
• Rotate the collar counter-clockwise to loosen.
• Remove power head pole from extension pole by pulling up on it.
• Rotate the second collar counter-clockwise to loosen.
• Remove the extension pole from the handle pole by pulling it up.
• Rotate collar clockwise to tighten.
NOTE: To lock out the trigger, you can pull back the
safety lock with your thumb. To unlock the safety lock,
push it forward. When the pole saw is not in use, you
can use the safety lock to prevent activation during
storage or transport.
NOTE:
• Adjust your hand placement on the shaft of the pole saw
to keep proper balance.
• Assemble poles only to the length required to reach
the limb being cut. Do not extend the handle above waist
height.
Switch lock
Switch trigger
Collar
TRANSPORTING THE POLE SAW
• Always switch off the power tool, remove the battery and fit the chain scabbard - even
when you carry the unit for short distances. This avoids the risk of the motor starting
unintentionally.
Operating Instructions

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
19
PREPARATION FOR CUTTING
• Wear non-slip gloves for maximum grip and protection.
• Maintain a proper grip on the unit whenever the motor is running. Use your right hand to
firmly grip the rear handle while your left hand has a firm grip on the pole shaft.
• Hold the unit firmly with both hands. Always keep your left hand on the pole shaft and your
right hand on the rear handle, so your body is to the left of the chain line. Never use a left-
handed (cross-handed) grip, or any stance that places your body or arm across the chain
line.
• Never stand directly under the limb you are cutting.
• Be certain the collars are fully tightened before operating equipment; check them
periodically for tightness during use to avoid serious injury.
BASIC CUTTING PROCEDURE
Follow the steps below to prevent damage to tree or shrub bark. Do not use a back-and-forth
sawing motion.
• Make a shallow first cut (1/4 of limb diameter) on the underside of the limb close to the
main limb or trunk.
• Make a second cut from the top side of the limb outboard from the first cut. Continue the
cut through the limb until the limb separates from the tree. Be prepared to balance the
weight of the tool when the limb falls.
• Make a final cut close to trunk.
• Release the trigger as soon as the cut is completed. Failure to follow proper cutting
procedures will result in the bar and chain binding and becoming pinched or trapped in the
limb. If this should happen:
• Stop the motor and remove the battery from the pole saw.
• If the limb can be reached from the ground, lift the limb while holding the saw. This should
release the “pinch” and free the saw.
• If the saw is still trapped, call a professional for assistance.
Cutting Guide
Second Cut
LOAD
Final Cut
First Cut
1/4 Diameter
!NOTE: For second and final cuts (from top of limb or branch), hold
front cutting guide against the limb being cut. This will help steady
the limb and make it easier to cut. Allow the chain to cut for you;
exert only light downward pressure. If you force the cut, damage
to the bar, chain, or motor can result.
Operating Instructions

model no. 274-1754-8 | contact us: 1.866.523.5218 model no. 274-1754-8 | contact us: 1.866.523.5218
20
LIMBING AND PRUNING
This unit is designed for trimming small branches and limbs up to 6” (15 cm) in diameter. For
best results, observe the following precautions.
• Plan the cut carefully. Be aware of the direction in which the branch will fall.
• Branches may fall in unexpected directions. Do not stand directly under the branch being
cut.
• The most typical cutting application is to position the unit at an angle of 60° or less,
depending on the specific situation, as shown. As the angle of the pole saw shaft to ground
increases, the difficulty of making the first cut (from the underside of limb) increases.
• Remove long branches in several stages.
• Cut lower branches first to allow the top branches more room to fall.
• Work slowly, keeping both hands on the saw with a firm grip. Maintain secure footing and
balance.
• Keep the tree between you and the chain while limbing. Cut from side of tree opposite
branch you are cutting.
• Do not cut from a ladder; this is extremely dangerous. Leave this operation for professionals.
• Following proper cutting procedures will prevent stripping the bark from the main member.
• Do not use the pole saw for felling or bucking.
• To prevent electrocution, do not operate within 50’ (15 m) of overhead electrical lines.
• Keep bystanders at least 50’ (15 m) away.
(15 m)
60° MAXIMUM
Operating Instructions
