YARDMAX YUS850 User manual

Save This Manual for Future Reference
34” Log Table
Operator’s Manual
For use on all Full Beam Yardmax Log Splitters
Model # YUS850
Length 34"
Width 12.5"
Weight 14.5 lbs
LOG TABLE ASSEMBLY
Refer to Figures 10 and 11 to install the work table. Remove
the bolts, at washers, and nuts from the inside holes. Move
the log cradle from the incline position to the horizontal
position. Align the holes on the log cradle with the outside
holes on the beam mount. Reinstall the bolts, at washers,
and nuts.
Place the work table over the holes in the log cradle and align
the 4 holes from the work table plate and log cradle. Insert
and tighten the M10x25 bolts, spring washers, at washers,
and nuts.
M10x25 (x4)
Work Table
Outside Holes
Log Cradle (Right)
Inside Holes
M10 X 25 X 4 8
16 mm
13 mm
18 mm
19 mm
30 mm
32 mm
Figure 11
