Yeastar Technology TA100 User manual

Sales Tel: [phone]
E-mail: [e-mail]
Support Tel: [phone]
E-mail: [e-mail]
Web: http://www.yeastar.com
Version: 44.19.0.16
Revised:January 25, 2016

TA100/200 User Manual
2/52
Copyright
Copyright 2006-2015 Yeastar Information Technology Co., Ltd. All rights reserved.
No parts of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, photocopying, recording, or otherwise, for any
purpose, without the express written permission of Yeastar Information Technology
Co., Ltd. Under the law, reproducing includes translating into another language or
format.
Declaration of Conformity
Hereby, Yeastar Information Technology Co., Ltd. declares
that TA100/200 is in conformity with the essential
requirements and other relevant provisions of the CE, FCC.
Warranty
The information in this document is subject to change without notice.
Yeastar Information Technology Co., Ltd. makes no warranty of any kind with regard
to this guide, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose. Yeastar Information Technology Co., Ltd. shall not
be liable for errors contained herein nor for incidental or consequential damages in
connection with the furnishing, performance or use of this guide.
WEEE Warning
In accordance with the requirements of council directive 2002/96/EC on
Waste of Electrical and Electronic Equipment (WEEE), ensure that at
end-of-life you separate this product from other waste and scrap and
deliver to the WEEE collection system in your country for recycling.

TA100/200 User Manual
3/52
Contents
About This Guide....................................................................................................5
Installation...............................................................................................................6
TA100/200 Packing List........................................................................................................6
Specifications and Operating Environment...........................................................................6
Connecting Your TA100/200.................................................................................................7
Getting Started........................................................................................................8
Accessing Web GUI..............................................................................................................8
Web Configuration Panel......................................................................................................9
Making and Receiving Calls .................................................................................................9
Basic Operations..................................................................................................10
Voice Menu.........................................................................................................................10
Call Hold ............................................................................................................................. 11
Call Waiting......................................................................................................................... 11
Call Transfer........................................................................................................................ 11
Three-party Conference......................................................................................................12
Direct IP Call.......................................................................................................................12
Change TA100/200’s IP Address Using Analog Phones ....................................................12
Port Settings.........................................................................................................14
General Settings.................................................................................................................14
Advanced Settings..............................................................................................................16
FXS Settings.......................................................................................................................17
Dial Plan..............................................................................................................................18
Gateway Settings..................................................................................................20
Basic Preferences...............................................................................................................20
Feature Codes....................................................................................................................21
Speed Dial...........................................................................................................................23
System Prompts Settings ...................................................................................................23
Advanced Settings ...............................................................................................25
SIP Settings ........................................................................................................................25
Distinctive Ringtones ..........................................................................................................30
Network Preferences............................................................................................31
LAN Settings.......................................................................................................................31
Service................................................................................................................................32
VLAN Settings.....................................................................................................................33
VPN Settings.......................................................................................................................33

TA100/200 User Manual
4/52
Security Center.....................................................................................................35
Security Center...................................................................................................................35
AMI Settings........................................................................................................................36
Certificates..........................................................................................................................37
Firewall Rules .....................................................................................................................38
IP Blacklist ..........................................................................................................................40
System Preferences .............................................................................................42
Password Settings..............................................................................................................42
Date and Time.....................................................................................................................42
Auto Provision Settings.......................................................................................................43
Firmware Update ................................................................................................................45
Upgrade through HTTP ................................................................................................... 45
Upgrade through TFTP .................................................................................................... 46
Backup and Restore ...........................................................................................................47
Reset and Reboot...............................................................................................................47
Status ....................................................................................................................49
FXS Port Status ..................................................................................................................49
Network status....................................................................................................................50
System Info.........................................................................................................................50
Call Logs.............................................................................................................................50
System Logs.......................................................................................................................51
Packet Tool .........................................................................................................................52

TA100/200 User Manual
5/52
About This Guide
Thanks for choosing Yeastar TA100/200 Analog Telephone Adapter. Yeastar
TA100/200 provides 1 or 2 analog interfaces for residential and small business users
to convert existing analog equipment to IP-based networks cost effectively.
YeastarTA100/200 is ideal for small business to achieve quick and easy connection in
various network environments.
Audience
This manual will help you learn how to operate and manage your TA100/200 Analog
Telephone Adapter. In this guide, we describe every detail on the functionality and
configuration of TA100/200. We begin by assuming that you are interested in
TA100/200 and familiar with networking and other IT disciplines.
Safety when working with electricity
Feature Highlights
Connect up to 2 analog phones/faxes
Miniature in design
Fully compliant with SIP standard
High-quality voice call
Rich subscribe calling features
FTP, TFTP, HTTPAuto Provision
Powered by USB interface
Easy Web-based configuration
Learn more about Yeastar TA100/200 here:
http://www.yeastar.com/Products.html/Analog-Telephone-Adapter
Do not open the device when the device is powered on.
Do not work on the device, connect or disconnect cables when
lightning strikes.

TA100/200 User Manual
6/52
Installation
This chapter provides the following sections:
TA100/200 Packing List
Specifications and Operating Environment
Connecting Your TA100/200
TA100/200 Packing List
Upon receiving Yeastar TA100/200 gift box, please open the package and check if all
the items are supplied as TA100/200 Packing List. If there is any problem, please
contact your provider.
Table 2-1 TA100/200Packing List
Item
Unit
QTY
Description
TA100/200
PC
1
TA100/200 device unit.
USB power adapter
PC
1
USB cable
PC
1
Network cable
PC
1
Warranty card
PC
1
With Serial Number printed for Repair &
Return.
Quick installation guide
PC
1
Specifications and Operating Environment
Table 2-2 Specifications and Operating Environment
TA100/200
Description
Size (L×W×H)
85 mm ×58 mm ×24 mm
Power Supply
DC 5V,1A
Operating Temperature
0°C to 40°C, 32°F to 104°F
Storage Temperature
-20°C to 65°C, 4°F to 149°F
Humidity
10% to 90% (non-condensing)

TA100/200 User Manual
7/52
Connecting Your TA100/200
Yeastar TA100/200 is designed for easy configuration and easy installation.
Connection of Ethernet Port
Insert the Ethernet cable into the LAN port of TA100/200 and connect the other
end of the Ethernet cable to an uplink port (a router or a switch, etc.)
Connection of FXS Ports
Connect one end of a RJ11 phone cable to the FXS port, connect the other end to
the analog phone.
Power Connection
Connect TA100/200 to a power outlet using the included USB cable and USB
power adapter.
Figure 2-1 TA200 Interfaces
Table 2-3 Description of TA100/200 Connectors
Port
Description
Power Status
Power indicator.
Micro USB Port
DC 5V,1A, for connection to power supply.
LAN Port
For connection to your router or broadband network
device.
Phone Ports
For connection to analog phones/fax machines.
Micro USB Port
LAN
Phone Ports
Power Status

TA100/200 User Manual
8/52
Getting Started
In this chapter, we guide you through the basic steps to start with a new TA100/200:
Accessing Web GUI
Web Configuration Panel
Making and Receiving Calls
Accessing Web GUI
The TA100/200 attempts to contact a DHCP server in your network to obtain valid
network settings (e.g., the IP address, subnet mask, default gateway address and
DNS address) by default.
Please enable DHCP Server in your network to obtain the TA100/200 IP address.
How to check TA100/200 IP address:
1. Pick up the analog phone, then access the voice menu prompt by dialing “***”.
2. Dial "1" to check the IP address.
3. Dial "2" for web access address.
After entering the IP address in the web browser, users will see a log-in screen.
Check the default settings below:
Username: admin
Password: password
Figure 3-1 TA100/200 Login page

TA100/200 User Manual
9/52
Web Configuration Panel
There are 4 main sections on the Web Configuration Panel for users to check the
TA100/200’s status and configure it.
Status: check System Status, Port Status, Trunk Status, Network Status and
check call logs, system logs.
System: configure Network Settings, Security related Settings, System Date and
Time, Password, Backup and Restore, etc.
Gateway: configure FXS ports, gateway settings and SIP settings, etc.
Logout: log out TA100/200.
Note:
After saving the changes, remember to click the “Apply changes” button on the upper
right corner of the Web GUI to makethe changes take effect.
Making and Receiving Calls
You will need an active VoIP account from a VoIP service provider or PBX, which
provides a VoIP telephone number to allow you to make and receive calls.
Making internal calls (for TA200 only)
To place an internal call, pick up the analog phone and dial the other port’s caller
ID number.
For example, to reach the other port with caller ID number 300, dial “300”.
Making outbound calls
To make an outbound call, you need to dial according to the FXS port dial pattern.
By the default dial pattern, you can dial the desired outgoing number directly.
Answering calls
To answer a call, pick up the handset as you usually do.

TA100/200 User Manual
10/52
Basic Operations
In this chapter, we give instructions about how to operate on analog phones
connected to TA100/200 to use some features.
Voice Menu
Call Hold
Call Waiting
Call Transfer
Three-party Conference
Direct IP Call
Change TA100/200’s IPAddress
Voice Menu
TA100/200 provides a voice menu to guide you to configure the network settings for
the device. You need to press *** on the analog phone which is connected to
TA100/200’s FXS port to enter the voice menu.
The default password to enter “Advanced Settings”is 123456. You can change the
password on TA100/200 Web page.(Gateway→Gateway Settings→Feature
Codes→Voice Menu Password Settings)
Figure 4-1 TA100/200 Voice Menu
