YoLuke P1-4X User guide

WiFi IP CAMERA
QUICK OPERATION GUIDE
Apply for Model:P1-4X /P2-20X/P3-4X/ P9-5X/P14-4X
Note: Due to the continuous updating of the products and software,there may have some discrepancy
between the operating guide and APP interface.All the instructions are subject to the actual
operation interface.

Service Guarantee
If you have any other questions, please browse the official website of our company or consult the
customer service email address.It would be better for us to improve our service efficiency that if
you can write down your E-mial address,the model of the product and the order number you
bought.
Company Name: ShenZhen JideTech Development Co., Limited
Company Address: 9F Niulanqian Building
Minzhi Avenue, Minzhi Street, Long Hua District,
Shenzhen Guangdong, China, 518109
Website:http://www.gentlen168.com
Email: [email protected]
Tel: [phone]
WhatsApp: [phone]
Skype: Yoluke Tech
Facebook: Yoluke
Wechat: 135 4401 2806

Contents
1. Introduction.....................................................................................................................................................- 1 -
2. Installation.....................................................................................................................................................- 2 -
3. SD Card Slot.....................................................................................................................................................- 2 -
4. APP Download...................................................................................................................................................... - 2 -
5. Mobile APP CamHipro Connection................................................................................................................ - 3 -
5.1 Connect to IP Camera Hot-Spot and then Configure Wi-Fi................................................................. - 3 -
5.2 Add Camera.................................................................................................................................................- 4 -
5.3 Wi-Fi Setting............................................................................................................................................. - 4 -
5.4 Connect the Camera by Scan QR Code..............................................................................................- 4 -
5.5 Connect the Camera by Search Nearby Devices..................................................................................- 6 -
5.6 Mobile APP Function Introduction............................................................................................................- 7 -
5.6.1 Micro SD Card Video files playback and download................................................................ - 7 -
5.6.2 Local files, device list and add other new camera...................................................................- 8 -
5.6.3 Pre-set point and auto cruise (For PTZ)................................................................................... - 8 -
5.6.4 Change password.......................................................................................................................- 10 -
5.5.5 Set factory of the camera.......................................................................................................... - 11 -
5.6.6 Alarm management and notification........................................................................................ - 11 -
5.6.7 Motion Detection.........................................................................................................................- 12 -
5.6.8 Email settings..............................................................................................................................- 12 -
5.6.9 FTP setting.................................................................................................................................. - 13 -
5.6.10 Video setting and audio setting..............................................................................................- 13 -
5.6.11 SD card plan recording............................................................................................................- 14 -
5.6.12 Device time setting...................................................................................................................- 14 -
5.6.13 SD card setting......................................................................................................................... - 15 -
5.6.14 Default setting...........................................................................................................................- 15 -
6. Computer Browsing Access.......................................................................................................................... - 15 -
6.1 Search IP Camera....................................................................................................................................- 15 -
6.2 View Video by Browser............................................................................................................................- 16 -
6.3 Interface..................................................................................................................................................... - 17 -
6.4 Parameter Settings...................................................................................................................................- 18 -
6.4.1 SettingMedia.........................................................................................................................- 18 -
6.4.2 SettingNetwork.....................................................................................................................- 19 -
6.4.3 SettingAlarm.........................................................................................................................- 22 -
6.4.4 Setting Advanced...............................................................................................................- 24 -
6.4.5 Settings System.................................................................................................................- 29 -
7. Video Management Software (HIP2P Client).......................................................................................... - 31 -
7.1 Software installation.................................................................................................................................- 31 -
7.2 Add Camera...............................................................................................................................................- 32 -
Frequently Asked Questions·································································································- 35 -

-1-
1. Introduction
Thanks for buying YoLuke Security IP Camera. This manual describes all the
parameters, functional structures,usage,common problems and solutions for the
cameras in detail. This would help you know the camera quickly and use it easily.
If you have any problems with our camera or confused in the settings,
please contact with us, and we will provide technical support and service at
the first time.

-2-
2. Installation
3. SD Card Slot
4. APP Download
Download APP “CamHipro” or “CamHi”in Google Play or Apple Store,
or scan the QR Code to install.

-3-
5. Mobile APP CamHipro Connection
5.1 Connect to IP Camera Hot-Spot and then Configure Wi-Fi
Go to your cell phone’s Wi-Fi Setting -- search Wi-Fi signals -- connect the Wi-Fi.
The name of Wi-Fi Hot Spot is the UID on the camera (Wi-Fi name:IPCAM-900139)
Camera default Wi-Fi Hot Spot password: 01234567
Remark: Only when the mobile phone is 3-5 meters away from the camera can the hot spot signal be
detected,please close the mobile data when connect the camera Hot Spot.

-4-
5.2 Add Camera
Add your camera to ‘CamHipro’ APP follow the steps of the below pictures.
Step 1 Step 2 Step 3
5.3 Wi-Fi Setting
Set Wi-Fi for your camera with the your Router’s Wi-Fi,follow the steps below:
Step 1 Step 2 Step 3 Step 4
5.4 Connect the Camera by Scan QR Code
Note:
1. Please make sure that the camera has been connected to Network cable and power supply connection.
2. If there is no camera on the device list, please come close to the camera and refresh.
A) Connect the camera to the power supply and Network cable,the camera would turn into

-5-
self-test mode,which would take about 15 seconds. Open the ‘CamHipro’ APP.
B) Add the camera by Scan QR code/Search nearby devices follow the steps below:
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6

-6-
5.5 Connect the Camera by Search Nearby Devices
A）Connect the camera to the power supply and the camera would turn into self-test mode, which
would take about 15 seconds. Open the ‘CamHipro’ APP.
B）Add the camera by Search Nearby Devices follow the below steps.
Note:
1.Please make sure that the camera has been connected to router’s Wi-Fi.
2.Please make sure that your cell phone connects the same Wi-Fi as the camera connected.
3.If there is no camera on the device list, please come close to the camera and refresh.
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6

-7-
5.6 Mobile APP Function Introduction
5.6.1 Micro SD Card Video files playback and download
Opps:if you download the recorded video files from pc,then the files can only be played in hiplayer.

-8-
5.6.2 Local files, device list and add other new camera
Click to view the local file of different cameras.；click to change the camera device
list；click to add a new camera.
5.6.3 Pre-set point and auto cruise (For PTZ)
Click the camera into real-time monitor -- turn to next page -- preset position

-9-
Remarks: HD is a higher-definition display effect than SD (recommended to use when the network is
good)

- 10 -
Auto Cruise Function:
Number 1-16 means 16 points you want to set up
Adjust the camera rotation to the first point you want to monitor on the app; input "1" and Setting;
Adjust the camera rotation to the second point you want to monitor on the app; input "2" and Setting;
……until set up 16 points……
After you set up 16 points, input "41" and transfer. The camera will auto cruise.
Input "41" and Setting, auto cruise will stop
5.6.4 Change password
Click “Change Password”to modify the password. Old password:admin

- 11 -
5.5.5 Set factory of the camera
5.6.6 Alarm management and notification
Recording and alarm, default recording all day;APP push is off by default;Recording time period
and alarm time period can be customized

- 12 -
5.6.7 Motion Detection
5.6.8 Email settings

- 13 -
5.6.9 FTP setting
5.6.10 Video setting and audio setting

- 14 -
5.6.11 SD card plan recording
Need to change the camera time to the local time zone first
5.6.12 Device time setting

- 15 -
5.6.13 SD card setting
The files in the SD card cannot be deleted to keep the playback function coherent, the SD card will
automatically overwrite the earliest recording
5.6.14 Default setting
6. Computer Browsing Access
6.1 Download Search Tool
Download Software from the website ( http://www.gentlen168.com/security-camera/info/898.html) or
Mini CD in the package,open the file and install search tool in your computer. Click “next” to find IP
camera. Also You can select Network Card to search IP Camera.

- 16 -
6.2 Search IP Camera
Click “next”to find IP camera. You can select Network Card to search IP Camera.
6.3 View Video by Browser
Support IE, Google and Firefox browser, Install ActiveX before view video.

- 17 -
6.4 Interface
Region A
Multiple preview modes.
Region B
View memory card capacity and date.
Click on the capture and take the current image.
Local manual recording.
