York GM9S040A12DH11 Quick start guide

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
MODELS: GM9S*DH
GAS-FIRED
CONDENSING / HIGH EFFICIENCY
DOWNFLOW/HORIZONTAL FURNACES
92% TO 94% AFUE
NATURAL GAS
40 - 120 MBH INPUT
Due to continuous product improvement,
specifications are subject to change without notice.
Visit us on the web at www.york.com for the most
up-to-date technical information.
Additional rating information can be found at
www.gamanet.org.
EFFICIENCY
RATING
CERTIFIED
ISO 9001
Certified Quality
Management System
TECHNICAL
GUIDE
TECHNICAL
GUIDE
278177-BTG-A-0407
DESCRIPTION
These Category IV, highly efficient, compact, condensing
type furnaces are designed for residential and commercial
installations in a basement, closet, alcove, recreation room or
garage where the ambient temperature is above 32°F, or
higher. They may be either side wall or thru-roof vented using
approved plastic type combustion air and vent piping. All
units are factory assembled, wired and tested to assure
dependable and economical installation and operation.
WARRANTY
Lifetime limited warranty on both heat exchangers to the orig-
inal purchaser; a 20-year limited warranty from original instal-
lation date to subsequent purchaser.
10-year warranty on the heat exchanger in commercial appli-
cations.
5-year limited parts warranty.
FEATURES
• Compact, easy to install, ideal height 40" cabinet
• Blower-off delay for cooling SEER improvement.
• Easy to connect power/control wiring.
• Built-in, high level self diagnostics with fault code display.
• Low unit amp requirement for easy replacement applica-
tion.
• Integrated control module for reliable, economical opera-
tion.
• May be installed as either two-pipe (sealed combustion)
or single pipe vent (using indoor combustion air)
• Top intake & vent connection allows downflow installa-
tion in narrow locations.
• Electronic Hot Surface Ignition saves fuel cost with
increased dependability and reliability.
• Induced combustion system with inshot main burners for
quiet, efficient operation.
• No special vent termination kit required.
• 100% shut off main gas valve for extra safety.
• PSC four speed, direct drive motor with large, quiet
blower.
• 24V, 40 VA control transformer and blower relay supplied
for add-on cooling.
• Hi-tech tubular aluminized steel primary heat exchanger.
• Secondary (condensing) heat exchanger of 29-4C high-
grade stainless steel.
• Timed on, adjustable off blower capability for maximum
comfort.
• Easy access from front of unit for cleaning, maintenance
or service.
• Protection from intake, exhaust or condensate blockage.

2Unitary Products Group
278177-BTG-A-0407
C
19-1/4
1-1/4
1-1/4 5/8
5/8
23-5/8
D
2-1/4
23-1/4
20
B
BOTTOM IMAGE
SUPPLY END
TOP IMAGE
RETURN END
LEFT SIDE RIGHT SIDE
HORIZONTAL CONDENSATE
DRAIN OPENING 2”
JUNCTION BOX
HOLE 7/8”
GAS PIPE ENTRY 1-1/2”
CONDENSATE DRAIN
HOLE 7/8”
SIDE PIPING HOLE 3-3/8”
T-STAT WIRING 7/8” K.O.
HORIZONTAL CONDENSATE
DRAIN OPENING 1-3/4”
28-1/2
T-STAT WIRING 7/8” K.O.
HORIZONTAL CONDENSATE
DRAIN OPENING 1-3/4”
HORIZONTAL
CONDENSATE
DRAIN OPENING 1-3/4”
JUNCTION BOX
HOLE 7/8”
GAS PIPE
ENTRY 1-1/2”
CONDENSATE DRAIN
HOLE 7/8”
40
A
FRONT
CABINET AND DUCT DIMENSIONS
Models CFM Cabinet
Size
Cabinet Dimension
A (in.) B (in.) C (in.) D (in.)
GM9S040A12DH11 1200 A 14-1/2 13-1/4 12 1-3/4
GM9S060B12DH11 1200 B 17-1/2 16-1/4 15 1-3/4
GM9S080B12DH11 1200 B 17-1/2 16-1/4 15 1-3/4
GM9S080C16DH11 1600 C 21 19-3/4 18-1/2 2-1/8
GM9S100C16DH11 1600 C 21 19-3/4 18-1/2 2-1/8
GM9S100C20DH11 2000 C 21 19-3/4 18-1/2 2-1/8
GM9S120D20DH11 2000 D 24-1/2 23-1/4 22 2-1/2

Unitary Products Group 3
278177-BTG-A-0407
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
Wire size and overcurrent protection must comply with the National Electric Code.
NOTES:
1. For altitudes above 2000 ft. reduce capacity 4% for each 1000 ft. above sea level.
2. Wire size based on copper conductors, 60°C, 3% voltage drop.
3. Continuous return air temperature must not be below 55°F.
4. All filters must be high velocity cleanable type.
ELECTRICAL AND PERFORMANCE DATA
Models Input/
Cabinet Output Nominal
Airflow Cabinet Width Total Unit AFUE Air Temp.
Rise
MBH MBH CFM In. Amps % °F
GM9S040A12DH11 40/A 37 1200 14-1/2 9 94 35 - 65
GM9S060B12DH11 60/B 55 1200 17-1/2 9 92 35 - 65
GM9S080B12DH11 80/B 74 1200 17-1/2 9 92 35 - 65
GM9S080C16DH11 80/C 74 1600 21 12 92 35 - 65
GM9S100C16DH11 100/C 93 1600 21 12 92 35 - 65
GM9S100C20DH11 100/C 93 2000 21 14 92 35 - 65
GM9S120D20DH11 120/D 112 2000 24-1/2 14 92 35 - 65
Models Input/
Cabinet Max. Outlet Air Temp. Blower Blower
Size Max.
Over-current
Protect
Min. Wire Size
(awg) @ 75 ft.
One Way
Operation
Weight
MBH °F HP Amps In. Lbs.
GM9S040A12DH11 40/A 165 1/2 7.0 11 x 8 20 14 120
GM9S060B12DH11 60/B 165 1/2 7.0 11 x 8 20 14 130
GM9S080B12DH11 80/B 165 1/2 7.0 11 x 8 20 14 145
GM9S080C16DH11 80/C 165 3/4 10.2 11 x 10 20 14 155
GM9S100C16DH11 100/C 165 3/4 10.2 11 x 10 20 14 170
GM9S100C20DH11 100/C 165 1 12.7 11 x 11 20 12 175
GM9S120D20DH11 120/D 165 1 12.7 11 x 11 20 12 180

4Unitary Products Group
278177-BTG-A-0407
NOTES:
1. Airflow expressed in standard cubic feet per minute (CFM).
2. Motor voltage at 115 V.
3. NR = Operation at this static pressure is not recommended.
BLOWER PERFORMANCE CFM
AIRFLOW WITH TOP RETURN - WITHOUT FILTERS (CFM)
Models Speed
Tap External Static Pressure, Inches W.C.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
GM9S040A12DH11
High 1635 1590 1535 1480 1415 1340 1280 1185 NR NR
Medium High 1179 1170 1160 1140 1135 1098 1048 1026 NR NR
Medium Low 969 967 967 959 938 905 860 802 NR NR
Low 774 753 745 726 698 674 652 612 NR NR
GM9S060B12DH11
High 1687 1652 1631 1595 1557 1511 1456 1382 1313 1211
Medium High 1193 1183 1173 1162 1142 1115 1076 1036 982 950
Medium Low 933 933 921 911 902 872 825 793 771 712
Low 752 745 731 718 698 652 602 580 536 496
GM9S080B12DH11
High 1686 1658 1623 1572 1534 1465 1391 1305 1202 1091
Medium High 1257 1223 1218 1203 1177 1142 1094 1026 939 874
Medium Low 977 982 976 955 934 899 843 791 738 686
Low 775 777 757 733 698 663 627 584 549 490
GM9S080C16DH11
High 2071 2026 1981 1935 1864 1796 1713 1625 1532 1401
Medium High 1583 1590 1569 1554 1532 1502 1457 1409 1327 1221
Medium Low 1256 1275 1275 1288 1275 1265 1232 1187 1126 1023
Low 937 939 936 945 942 936 912 874 810 726
GM9S100C16DH11
High 1996 1961 1938 1896 1836 1779 1707 1625 1531 1399
Medium High 1449 1480 1495 1488 1488 1449 1417 1368 1299 1208
Medium Low 1167 1192 1192 1187 1202 1192 1182 1140 1097 1018
Low 932 900 871 840 805 761 710 663 641 623
GM9S100C20DH11
High 2404 2320 2225 2138 2034 1924 1816 1692 1559 1422
Medium High 2018 1955 1883 1815 1750 1670 1586 1497 1394 1246
Medium Low 1626 1581 1531 1488 1418 1363 1291 1225 1123 964
Low 1336 1291 1249 1205 1155 1091 1018 951 884 759
GM9S120D20DH11
High 2520 2432 2353 2251 2152 2042 1947 1815 1701 1525
Medium High 2018 1979 1945 1911 1863 1779 1705 1599 1493 1353
Medium Low 1586 1545 1501 1457 1407 1351 1287 1216 1081 926
Low 1321 1266 1213 1163 1111 1071 987 864 763 700

Unitary Products Group 5
278177-BTG-A-0407
FILTER PERFORMANCE
The airflow capacity data published in the “Blower Perfor-
mance” table listed above represents blower performance
WITHOUT filters. To determine the approximate blower per-
formance of the system, apply the filter drop value for the fil-
ter being used or select an appropriate value from the “Filter
Performance” table shown.
NOTE: The filter pressure drop values in the “Filter Perfor-
mance” table shown are typical values for the type of filter
listed and should only be used as a guideline. Actual pres-
sure drop ratings for each filter type vary between filter manu-
facturer.
NOTES:
1. Air velocity through throwaway type filters may not exceed 300
feet per minute. All velocities over this require the use of high
velocity filters.
RECOMMENDED FILTER SIZES
CFM Cabinet Size Top Return Filter in
1200 A (2) 14 x 20
1200 B (2) 14 x 20
1600 C (2) 14 x 20
2000 C (2) 14 x 20
2000 D (2) 14 x 20
FILTER PERFORMANCE - PRESSURE DROP INCHES W.C. AND (KPA)
Airflow Range Minimum
Opening Size Filter Type
Disposable Washable Fiber Pleated
CFM in2In W.C. In W.C. In W.C.
0 - 750 230 0.01 0.01 0.15
751 - 1000 330 0.05 0.05 0.20
1001 - 1250 330 0.10 0.10 0.20
1251 - 1500 330 0.10 0.10 0.25
1501 - 1750 380 0.15 0.14 0.30
1751 - 2000 380 0.19 0.18 0.30
2001 & Above 463 0.19 0.18 0.30
UNIT CLEARANCES TO COMBUSTIBLES
Application Top Front Rear Left
Side Right Side Flue Floor/
Bottom Closet Alcove Attic Line
Contact
Downflow130000 1"*Yes Yes Yes No
Horizontal030110CombustibleNoYesYes
Yes†
* Special floor base or air conditioning coil required for use on combustible floor.
† Line contact only permitted between lines formed by the intersection of the rear panel and side panel (top in horizontal position) of
the furnace jacket and building joists, studs or framing.

6Unitary Products Group
278177-BTG-A-0407
For additional connection diagrams for all UPG equipment refer to “Low Voltage System Wiring” document available online at
www.upgnet.com in the Product Catalog Section.
Thermostat Chart
AC1 Single Stage A/C w/Single Stage Furnace, 1 Stage Cooling Ready - (G,L)*8/9S, XYF80-U, XYF80-U*L, XYF90-U
HM1
Humidistat
Thermostat Installer Setup Number 1 -
System Type - must be set to 0 Selection of GAS/ELEC switch
on thermostat not necessary
Thermostat Installer Setup Number 15 -
Compressor Protection - must be set to 5
24V HUMIDIFIER
G
Fan G
Fan G
Fan G
Fan
W
First Stage Heat W
First Stage Heat W
First Stage Heat W
Single Stage Heat
RC
24-Volt Hot (Cool XFMR) RC
24-Volt Hot (Cool XFMR) RC
24-Volt Hot (Cool XFMR)
R
24-Volt Hot (Heat XFMR) RH
24-Volt Hot (Heat XFMR) RH
24-Volt Hot (Heat XFMR) R
24-Volt Hot
C
24-Volt Common C
24-Volt Common
Y
First Stage Cool Y
First Stage Cool Y
First Stage Cool Y/Y2
Single/Second Stage Cool Y
Single Stage Cool
*DN11C00124
C
24-Volt Common C
24-Volt Common Optional w/Batteries
*BN11C01124 *DP11C40124
PSC
FURNACE CONTROL SINGLE STAGE
AIR CONDITIONING
*BN11C00124 *BP11C50124 *PP11C70224
THERMOSTAT THERMOSTAT THERMOSTAT
HP1 W/031-01975- Series Demand Control
Single Stage H/P - E*RD, E*BD, ERHS, HPX13 - w/Single Stage Furnace, 1 Stage Cooling Ready - (G,L)*8/9S, XYF80-U, XYF80-U*L, XYF90-U
SINGLE STAGE
HEAT PUMP
*DN22U00124 *BP21H50124 *PP32H70124
THERMOSTAT THERMOSTAT THERMOSTAT PSC
FURNACE CONTROL
*BN21H00124 *DP21H40124
*DN21H00124
N/A N/A
C
24-Volt Common
R
24-Volt Hot
E
Emergency Heat
O
Reversing Valve–Energized in Cool
C
24-Volt Common C
24-Volt Common
Y
First Stage Heat/Cool Y/Y2
Single/Second Stage Cool Y
Single Stage Heat/Cool
R
24-Volt Hot R
24-Volt Hot
W1
Second Stage Heat
W
Single Stage Heat W1/66
First Stage Heat Out
G
Fan G
Fan W
First Stage Heat
Step 1 of Thermostat User Configuration Menu
must be set to Heat Pump 1
Step 9 of Thermostat User Configuration Menu
must be set to Pump OFF
O
Reversing Valve–Energized in Cool
L
Malfunction Light X/L
Malfunction Light

Unitary Products Group 7
278177-BTG-A-0407
APPLYING FILTER PRESSURE DROP TO
DETERMINE SYSTEM AIRFLOW
To determine the approximate airflow of the unit with a filter in
place, follow the steps below:
1. Select the filter type.
2. Determine the External System Static Pressure (ESP)
without the filter.
3. Select a filter pressure drop from the table based upon
the number of return air openings or return air opening
size and add to the ESP from Step 3 to determine the
total system static.
4. If total system static matches a ESP value in the airflow
table (i.e. 0.20, 0.60, etc,) the system airflow corre-
sponds to the intersection of the ESP column and Model/
Blower Speed row.
5. If the total system static falls between ESP values in the
table (i.e. 0.58, 0.75, etc.), the static pressure may be
rounded to the nearest value in the table determining the
airflow using Step 5 or calculate the airflow by using the
following example.
Example: For a 120,000 Btuh furnace operating on high
speed blower, it is found that total system static is 0.58" w.c.
To determine the system airflow, complete the following
steps:
1. Obtain the airflow values at 0.50" & 0.60" ESP.
Airflow @ 0.50": 2152 CFM
Airflow @ 0.60": 2042 CFM
2. Subtract the airflow @ 0.50" from the airflow @ 0.60" to
obtain airflow difference.
2042 - 2152 = -110 CFM
3. Subtract the total system static from 0.50" and divide this
difference by the difference in ESP values in the table,
0.60" - 0.50", to obtain a percentage.
(0.58 - 0.50) / (0.60 - 0.50) = 0.8
4. Multiply percentage by airflow difference to obtain airflow
reduction.
(0.8) x (-110) = -88
5. Subract airflow reduction value to airflow @ 0.50" to
obtain actual airflow @ 0.58" ESP.
2152 - 88 = 2064
ACCESSORIES
PROPANE (LP) CONVERSION KIT -
1NP0347 - All units
This accessory conversion kit may be used to convert natural
gas (N) units for propane (LP) operation. Conversions must
be made by qualified distributor or dealer personnel.
CONCENTRIC VENT TERMINATION -
1CT0302 (2")
1CT0303 (3")
For use through rooftop, sidewall. Allows combustion air to
enter and exhaust to exit through single common hole. Elimi-
nates unslightly elbows for a cleaner installation.
SIDEWALL VENT TERMINATION KIT -
1HT0901 (3")
1HT0902 (2")
For use on sidewall, two-pipe installations only. Provide a
more attractive termination for locations where the terminal is
visable on the side of the home.
COMBUSTIBLE FLOOR BASE -
1CB0314 - 14 1/2” Cabinet
1CB0317 - 17 1/2” Cabinet
1CB0321 - 21” Cabinet
1CB0324 - 24” Cabinet
COIL TRANSITION KIT -
1TK0914 - 14” Furnace
1TK0917 - 17” Furnace
1TK0921 - 21” Furnace
1TK0924 - 24” Furnace
These kits are required in downflow application when using
G*F* series coils. These kits are not required with MC/FC
series coils, but please ensure that the coil and furnace are
secured and that there are noair leaks.
CONDENSATE NEUTRALIZER KIT - 1NK0301
Neutralizer cartidge has a 1/2" plastic tube fittings for installa-
tion in the drain line. Calcium carbonate refill media is also
avaiable from the Source 1 Parts (p/n 026-30228-000).
HIGH ALTITUDE PRESSURE SWITCHES -
For installation where the altitude is less than 8,000 feet it is
not required that the pressure switch be changed. For alti-
tudes above 8,000 feet see kits below. Conversion must be
made by qualified distributor or dealer personnel.
1PS0901 - 060, 100, 120 MBH
1PS0902 - 080/1200 MBH
1PS0903 - 080/1600 MBH
1PS0904 - 040 MBH
ROOM THERMOSTATS - A wide selection of compatible
thermosets are available to provide optimum performance
and features for any installation.
1H/1C, manual change-over electronic non-programmable
thermostat.
1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.
1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the
price book or consult factory.

Subject to change without notice. Printed in U.S.A. 278177-BTG-A-0407
Copyright © by York International Corp. 2007. All rights reserved. Supersedes: 246730/036-21561-003 Rev. A (1205)
Unitary 5005 Norman
Products York OK
Group Drive 73069
NOTES
