➲ 300 Watt Passive Loudspeaker Cabinet
➲ 60° x 40° Waveguide Horn Assembly
➲ 15-inch Woofer with 1-inch Voicecoil
➲
2-inch Titanium Diaphragm
➲Inset input-jack plates
➲Binding Post and 1/4" Phone Connectors
➲9 Fly Points and a Pullback
➲15mm 11-ply Birch Cabinet Construction
➲Two-year Unconditional Warranty*
*Warrany valid in Canada and the United States only
The high power 300 Watt C2560 contains a single 15" speaker and horn. Each enclosure
features a 2" titanium diaphragm, high frequency driver firing through a 1" exit hole to a
60ºx40º waveguide horn for unsurpassed sonic clarity. Time-tested passive crossover
networks (12 dB per octave) ensure sonic accuracy.
In the lower frequency range the higher power woofer combines solid performance with
outstanding reliability.The enclosures feature inset input-jack plates, which contain binding
post and 1/4" phone connectors. The enclosures are painted with a white two-part epoxy
and incorporate curved, anti-resonance speaker grille constructed of perforated 16-gauge
steel. Both enclosure and grille can be easily refinished and feature a grille clip attachment
system for easy removal and recovering. Painstaking attention to details is evidenced by
features such as the safety screw hidden under the embossed Yorkville logo, which ensures
that the grille does not inadvertently come loose.
The Coliseum series enclosures are constructed of highly rigid 15mm (.5906") Baltic birch
plywood. Their trapezoidal shape is conducive to array mounting and minimizes lobing
difficulties. The C2560 is equipped with four flypoints and a pullback. The flypoints are steel
reinforced and engineered to allow easy, flexible and safe enclosure suspension.
Coliseum C2560
Coliseum C2560
Features:
Overview:
yorkville.com
C2560 Specifications:
Model
SYSTEM TYPE
PROGRAM POWER (watts)
IMPEDANCE (ohms)
FREQ. RESPONSE (Hz +/-3dB)
SENSITIVITY (dB@1W/1m)
MAXIMUM SPL (dB)
X-OVER FREQUENCY (Hz)
LF DRIVER(S)
HF HORN
HF DRIVER
HF HORN THROAT DIAMETER
HF DISPERSION (H˚ x V˚)
HF PROTECTION
CONSTRUCTION
STOCK FINISH
GRILLE
INPUTS (1/4" / Binding Post)
FLYWARE TYPE / QUANTITY
FLYWARE LOCATIONS
OPTIONAL ACCESSORIES
DIMENSIONS (DxWxHxBW inches)
DIMENSIONS (DxWxHxBW cm)
WEIGHT (lbs / kg)
C2560
Passive 2-Way
300
8
60 - 16k
100
125
1200
15"
Waveguide
2" Titanium
1"
60 x 40
CTL™
15mm 11-ply Birch
White Painted
Perforated Metal
2 / 1 pair
3/8" x 9
All Corners / 1 Pull Back
-
20 x 21 x 27 x 12
52 x 54 x 68 x 32
71 / 31.8
15-inch Passive Loudspeaker Cabinet
15-inch Passive Loudspeaker Cabinet
