YORKVILLE Performance Y112M User manual

# Part# Description
Labeled Components
1 8511 BLK X-OVER DISH - PLASTIC
2 3924 1/4" JCK PCB MT VERT 2XTIP HI-CURRENT
3 3647 12V 18W SC BAYONET #1141 BULB
4 3641 S.C. BAYONET WIRE SOCKET TINNED
5 8879 M5 X 10 DIN 7985 MS ZINC SCREW
6 8886 NEOPRENE N252 DRIVER GASKET
7 M694 GENERIC DRIVER SUPPORT*
8 N252PP N252 REPLACEMENT PHASE PLUG
9 N252XN 8R 30W 1"DRIVER RCF-N252XN
10 M-73 N252 REPLACEMENT DIAPHRAM
Crossover Dish 11 Z243 Y112M GRILL*
12 8239 "Y" LOGO "Y" SERIES LARGED DOMED
13 7317 12" 8R 150WPGM SPEAKER
14 H07 HORN 60 X 40 1" STY 2000HZ
15 8569 CORNER, 2 LEGS NO LIP BLACK OXIDE
16 8562 CORNER, 3 LEGS, BLACK OXIDE
17 8484 ADAPTOR,SPEAKER STAND,PLASTIC,BLACK
18 8458 10.5" STRAP HANDLE, PLASTIC COVERS
19 8547 PLASTIC FOOT BLACK
HF Driver shown with mounting plate
Front view of Y112M with grill taken off Bottom and side view
*NOTE: Replacement grills & HF Driver supports are 'Special-Order' and are only available while the model is in production.
applicable to serial numbers prior to, and including
104xxxx
4
3
1
2
16
15
19
18
17
14
13
12
11
5
7
8
10 diaphram not shown
6
9
Parts-Serv-y112m-1v3.xls ftp.yorkville.com Speaker Enclosure
