LG GP9 Specification sheet

GAMING SPEAKER
www.lg.com
Copyright © 2021 LG Electronics Inc.
All Rights Reserved.
SIMPLE MANUAL
GP9
FOR THE GUARANTEE TERMS & CONDITIONS, PLEASE REFER TO
INNER PAGE.
MFL71805542
2110_Rev01

Download Manual
<Android> <iOS>
Download App

a
OPTICAL
OUT
b c
d

ENGLISH
Connecting and Using
the Speaker
a
Charge the speaker before using
it by opening the rear cover and
connecting the speaker to the
charging adapter.
b
Connect the speaker to the PC
via a USB cable
A
Connect the speaker to the PC via
a USB C-type cable.
B
Press the Power button on the
speaker to turn it on.
C
Press the Function button on
the speaker repeatedly until the
Function LED turns white.
If you are using a voice chat
through integrated microphone or
headset, press the Microphone
button.
c
Connect the speaker to the Game
Console via an optical cable
A
Connect the speaker to the Game
Console via an optical cable.
B
Press the Power button on the
speaker to turn it on.
C
Press the Function button on
the speaker repeatedly until the
Function LED turns red.
d
Connect the speaker to a
smartphone via Bluetooth
A
Press the Power button on the
speaker to turn it on.
B
Press the Function button on
the speaker repeatedly until the
Function LED ashes blue.
C
Press the Settings button
on the smartphone and select
Bluetooth . Turn on the
Bluetooth function.
(Off > On )

D
Find "LG-GP9 (XX)" on the
device list on the smartphone
and connect to it. Once the
smartphone is connected via
Bluetooth, the Function LED turns
blue.
E
On the smartphone, play a music
of your choice.
e
Connecting the LG XBOOM App
A
Find LG XBOOM app on the
Google Play or App Store and
install it on your smartphone.
B
Run the LG XBOOM app and use
more features (EQ, Voice Chat,
Setting etc.)
For EQ of Headset mode, the sound
effects button on the top of the product
may be different depending on the
product S/W version.
-After product S/W update, you can use
the DTS Headphone: X or Custom EQ
with the EQ button while the Headset
button is On. FPS or RTS cannot be
selected in Headset mode.
Press and hold the Headset button
for 2 seconds to turn the front lighting
on or off.
For using a headset or earphones
connect it to the terminal.
yDesign and specications are subject to
change without notice.
yFor more information, download the online
owner’s manual. http://www.lg.com

ENGLISH
Specication
Power Supply:
y19 V
0
2.1 A (AC Adapter)
yBuilt-in rechargeable battery
Power consumption
yRefer to the main label.
AC adapter
yModel : ADS-45SN-19-2 19040G
yManufacturer : SHENZHEN HONOR
ELECTRONIC CO.,LTD
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 19 V
0
2.1 A
Dimensions (W x H x D):
Approx. 376 mm x 86 mm x 108 mm
Operating Temperature: 5 °C to 35 °C
Operating Humidity: 5 % to 60 %
Attaching the ferrite core (optional)
Wind the headset's wire once around the
ferrite core.
Safety Information
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This lightning ash with
arrowhead symbol within an
equilateral triangle is intended to
alert the user to the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of sufcient
magnitude to constitute a risk of electric shock
to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing) instructions in the
literature accompanying the product.

WARNING:
yTO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
yDo not install this equipment in a conned
space such as a book case or similar unit.
yThis unit contains magnets which can
be harmful to some kind of object (Ex :
Magnetic card, Pacemaker etc..).
CAUTION:
yDo not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions. Slots and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the product
and to protect it from over heating. The
openings should never be blocked by placing
the product on a bed, sofa, rug or other
similar surface. This product shall not be
placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the manufacturer’s instruction
has been adhered to.
yThe apparatus should not be exposed to
water (dripping or splashing) and no objects
lled with liquids, such as vases, should be
placed on the apparatus.
yNo naked ame sources, such as lighted
candles, should be placed on the apparatus.
yTo avoid re or electric shock, do not open
the unit. contact a qualied personnel only.
yDo not leave the unit in a place near the
heating appliances or subject to direct
sunlight, moisture, or mechanical shock.
yThe Power Plug is the disconnecting device.
In case of an emergency, the Power Plug
must remain readily accessible.
yTo clean the unit, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth
lightly moistened with a mild detergent
solution. Do not use strong solvents such as
alcohol, benzine, or thinner, as these might
damage the surface of the unit.
yDo not use volatile liquids such as
insecticide spray near the unit. Wiping with
strong pressure may damage the surface.
Do not leave rubber or plastic products
in contact with the unit for a long period
of time.
yDo not place the unit over the vehicle’s air
bag. When the air bag deploys, it may result
in injury. Before using in the car, x the unit.
yDo not use the handsfree function during
driving a car.

yDo not leave the unit on an unstable place
such as high shelves. it may fall down
because of the vibration of the sound.
yDo not use high voltage products around
this product. (ex. Electrical swatter) This
product may malfunction due to electrical
shock.
CAUTION when using this product in
environments of low humidity.
yIt may cause static electricity in
environments of low humidity.
yIt is recommended to use this product after
touching any metal object which conducts
electricity.
NOTICE: For safety marking information
including product identication and supply
ratings, please refer to the main label on the
bottom or the other surface of the product.
CAUTION: Only use the AC adapter
supplied with this device. Do not use a
power supply from another device or
another manufacturer. Using any other
power cable or power supply may cause
damage to the device and void your
warranty.
CAUTION: Internal lithium battery in
the unit should not be replaced by user
because of danger of explosion if battery is
incorrectly replaced, and must be replaced
with the same type battery by expert.
Symbols
Refers to alternating current (AC).
0Refers to direct current (DC).
Refers to class II equipment.
1Refers to stand-by.
!Refers to “ON” (power).
Refers to dangerous voltage.

For models using a built-in battery
Do not store or transport at pressures lower
than 11.6 kPa and at above 15,000 m altitude.
yreplacement of a battery with an incorrect
type that can defeat a safeguard (for example,
in the case of some lithium battery types);
ydisposal of a battery into re or a hot oven, or
mechanically crushing or cutting of a battery,
that can result in an explosion;
yleaving a battery in an extremely high
temperature surrounding environment that
can result in an explosion or the leakage of
ammable liquid or gas; and
ya battery subjected to extremely low air
pressure that may result in an explosion or
the leakage of ammable liquid or gas.
For models using a battery
This device is equipped with a portable battery
or accumulator.
CAUTION: Risk of re or explosion if the
battery is replaced by an incorrect type.
How to Safely remove the batteries or
the battery pack from the equipment: To
Remove the old batteries or battery pack,
follow the assembly steps in reverse order. To
prevent contamination of the environment
and bring on possible threat to human and/or
animal health, the old batteries or the battery
pack must be put in an appropriate container
at designated collection points. Do not dispose
of batteries or battery pack together with
other waste. It is recommended that you use
local, free reimbursement systems batteries
or battery packs, (may not be available in your
area). The batteries or the battery pack should
not be exposed to excessive heat such as
sunshine, re or the like.

ENGLISH
Declaration of Conformity
Hereby, LG Electronics declares that the
radio equipment type GAMING SPEAKER
is in compliance with the relevant statutory
requirements. The full text of the UK
declaration of conformity is available at the
following internet address:
http://www.lg.com/global/support/cedoc/
cedoc#
Frequency range Output power
(Max.)
2402 to 2480 MHz 13 dBm
Hereby, LG Electronics declares that the radio
equipment type GAMING SPEAKER is in
compliance with Directive 2014/53/EU. The
full text of the EU declaration of conformity is
available at the following internet address:
http://www.lg.com/global/support/cedoc/
cedoc#
For consideration of the user, this device
should be installed and operated with a
minimum distance of 20 cm between the
device and the body.
Frequency range Output power
(Max.)
2402 to 2480 MHz 13 dBm
For models with earphone /
headphone jack
To prevent possible hearing damage, do not
listen at high volume levels for long periods.

WEEE
Disposal of your old appliance
1. This crossed-out wheeled bin symbol indicates
that waste electrical and electronic products
(WEEE) should be disposed of separately
from the municipal waste stream.
2.
Old electrical products can contain hazardous
substances so correct disposal of your old
appliance will help prevent potential negative
consequences for the environment and human
health. Your old appliance may contain reusable
parts that could be used to repair other
products, and other valuable materials that can
be recycled to conserve limited resources.
3. You can take your appliance either to the shop
where you purchased the product, or contact
your local government waste ofce for details
of your nearest authorised WEEE collection
point. For the most up to date information
for your country please see www.lg.com/
global/recycling
Battery
Pb
Pb
Disposal of waste batteries/accumulators
1. This symbol may be combined with chemical
symbols for mercury (Hg), cadmium (Cd) or
lead (Pb) if the battery contains more than
0.0005% of mercury, 0.002% of cadmium or
0.004% of lead.
2. All batteries/accumulators should be
disposed separately from the municipal
waste stream via designated collection
facilities appointed by the government or
the local authorities.
3. The correct disposal of your old batteries/
accumulators will help to prevent
potential negative consequences for the
environment, animal and human health.
4. For more detailed information
about disposal of your old batteries/
accumulators, please contact your city
ofce, waste disposal service or the
shop where you purchased the product.

(http://www.lg.com/global/sustainability/
environment/take-back-recycling/
globalnetwork- europe)
Removal of waste batteries and
accumulators
(Product with embedded battery ONLY)
In case this product contains a battery
incorporated within the product which
cannot be readily removed by endusers, LG
recommends that only qualied professionals
remove the battery, either for replacement
or for recycling at the end of this product’s
working life. To prevent damage to the
product, and for their own safety, users should
not attempt to remove the battery and
should contact LG Service Helpline, or other
independent service providers for advice.
Removal of the battery will involve
dismantling of the product case, disconnection
of the electrical cables/ contacts, and careful
extraction of the battery cell using specialized
tools. If you need the instructions for qualied
professionals on how to remove the battery
safely, please visit http://www.lge.com/
global/sustainability/environment/take-back-
recycling.
POWER: This unit operates on a mains
supply of 100 - 240 V ~ 50/60 Hz.
Wiring: This unit is supplied with a BS
1363 approved main plug. When replacing
the fuse, always use a fuse of the same
rating and approved to BS 1362. Never
use this plug with the fuse cover omitted.
To obtain a replacement fuse cover contact
your dealer. If the type of plug supplied is
not suitable for the mains sockets in your
home, then the plug should be removed and
a suitable type tted. Please refer to the
wiring instructions below:
Warning: A mains plug removed from the
mains lead of this unit must be destroyed. A
mains plug with bared wires is hazardous if
inserted in a mains socket. Do not connect
either wire to the earth pin, marked with
the letter E or with the earth symbol 6or
coloured green or green and yellow. If any
other plug is tted, use same rating of fuse
in the plug.

Important: The wires in this mains lead are
coloured in accordance with the following
codes:
- BLUE: NEUTRAL, BROWN: LIVE - As
the colours of the wires in the mains lead
of this unit may not correspond with the
coloured marking identifying the terminals
in your plug, proceed as follows: The wire
which is coloured blue must be connected
to the terminal which is marked with the
letter N or coloured black. The wire which is
coloured brown must be connected to the
terminal which is marked with the letter L
or coloured red.

Technology with the human touch
GUARANTEE
• LG Electronics U.K. Ltd. will provide the following services in order to
expedite this Guarantee.
1.
All faulty components which fail due to defective manufacture will be replaced
free of charge for a period of 12 months from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be reimbursed
for any labour provided in the repair of this LG equipment, for a period of
12 months from the original date of purchase. These claims must be made
in accordance with the published scale of service charges and relevant
claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if
unauthorised modifications are made to the apparatus, or if non standard
components are used or if the serial number of the apparatus is removed,
defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from
whom the equipment was originally purchased. The dealer may, before
carrying out service under guarantee, require a receipted account as
evidence of the date of purchase.
D. We respectfully point out that your dealer is not obligated to replace
batteries if they become exhausted or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this
guarantee.

This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAIN YOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OF YOUR
RECEIPT MUST BE SURRENDERED AT THE TIME GUARANTEE SERVICE IS
PROVIDED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model &
serial numbers and return it. This will enable LG to assist you in the future
should you lose your receipt, your units stolen, or should modifications be
necessary.
• To obtain information or assistance:
Call UK: 0344 847 5454 IE: 01 686 9454
MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*
In all cases of difficulty - consult your LG dealer from whom the product
was purchased
LGEUK Website : www.lg.com/uk
(Service website : www.lg.com/uk/support)

Other manuals for GP9
5
Table of contents
Other LG Speakers manuals
