Z-Lite 562PHBR-LED User manual

ASSEMBLY INSTRUCTIONS
562PHBR-LED
MOUNTING POST
WIRE CONNECTOR
POWER SUPPLY WIRE
GROUND WIRE
POST FITTER SCREW
LED MODULE
STEEL PANEL
ONE-SHAPED PANEL
FINIAL(1)
DECORATIVE KNOB(2)
DECORATIVE KNOB(3)
GLASS(4)
SCREW(6)
SCREW(5)
READ & SAVE
INSTALLATION & OPERATION INSTRUCTIONS
TOOLS & MATERIALS REQUIRED
Screwdriver Wire Cutters
Adjustable Wrench Wiring Supplies
CAUTION
Prior to assembly, refer to ELECTRICAL CONNECTIONS section. If you do not have
electrical wiring experience, refer to a do-it-yourself wiring handbook or have your
fixture installed by a qualified licensed electrician.
GENERAL
1. Be sure to read these instructions and review the diagrams thoroughly before

beginning.
2. Electrical connections must be in accordance with local codes, ordinances, or the
National Electric Code. If you are unfamiliar with methods of installing electrical wiring,
secure the services of a qualified licensed electrician.
3. Before starting the installation, disconnect the power by turning off the circuit
breaker or by removing appropriate fuse at fuse box. Turning the power off at the light
switch is not sufficient to prevent electrical shock.
PREPARE THE FIXTURE
NOTE: First turn off electricity
FINAL ASSEMBLY
1. Pull the black, white and ground wires out of mounting post.
2. While supporting the fixture, connect electrical wires. If your post has a ground wire
(green or bare copper), connect the fixture ground wire to it. If not, consult your
electrician for proper grounding.
ELECTRICAL CONNECTIONS 120V~, 60Hz
Connect white wire(s) from fixture to white neutral wire from supply circuit.
Connect black wire(s) to black hot wire from supply circuit. Connect green wire to
green or bare wire or grounding screw on mounting bracket. In all cases grounding
conductor to earth must be used. Use UL/CSA Listed wire connects suitable for the
size, type, and number of conductors. No loose strands or loose wires should be
present. Secure wire connectors with UL/CSA Listed electrical tape.
After wires are connected, tuck them carefully inside the post cup.
3. Align the lantern with mounting post and secure with screws
4. Installation is complete. Turn on the power at the circuit breaker or fuse box. Turn
the light switch on to activate the fixture.
5. LED replacement. Take down the finial(1), unscrew the decorative knobs(2), take
down the one-shaped panel, unscrew the decorative knobs(3), take down glass(4),
unscrew the screws(5), take down heatsink, unscrew the LED screws(6) then pull out
LED module, finally replace LED module by quick connector, secure the screws.
CAUTION: LED fixtures can operate at high temperatures
please use caution when touching during operation or after
operation.

Please observe local building/electrical
codes regarding the installation of your
post fixture. Please keep in mind your
geographic location and the depth that
the ground freezes to, when deciding
the depth of your installation.
