Z-Shade Company GAZEBO User manual
2 YEAR LIMITED WARRANTY
Z-Shade Company Ltd., manufacturer of the product, warrants to the original purchaser
who provides a dated sales receipt from an Authorized Dealer, each part of the Z-Shade
product to be free from defects in material or workmanship for a period of two (2)
years after the date of original purchase. The Z-Shade frame is covered under a limited
two (2) year warranty and guarantees the frame to be free from defects in material or
workmanship. This warranty applies only for normal and expected uses, as determined by
the manufacturer.
Z-Shade Company Ltd. obligation and liability under this warranty is limited to the repair or
replacement (at its option) of the product or its parts, after its own review and examination.
RETURN GOODS: Before returning any part or product to Z-Shade, please phone or write
to obtain specific return shipping instructions. All shipping costs must be prepaid, and
Z-Shade is not responsible for products damaged in transit.
CONDITIONS: This warranty shall be void as to any product which has been altered or
modified in any manner. This warranty does not apply to damages caused by wind, rain, or
other forces of nature, not to accidental or deliberate damage of the product, nor to use of
the product that does not conform with the product instructions.
This warranty is provided in lieu of all other warranties, expressed or implied.
Z-Shade Company Ltd.
(855) 4 Z-SHADE
(855) 497-4233
www.zshadeusa.com
PRODUCT INFORMATION:
Read this information before proceeding. It is the user’s responsibility to take the following precautions
at all times.
• Designedasatemporaryinstantgazebo,donotleaveupforextendedperiods.
• Donotuseinanypotentiallywindyorrainyweather.Windandraincandamageyourproductand
mayalsoresultininjurytoyouorothers.Therefore,donotrelyonproductforprotectioninheavy
or prolonged rain storms.
• AlwaysstakeorweighdownyourZ-Shade™product.
• UsecautionwhenhandlingtheZ-Shadeframe.Avoidpinchinghandsorngersasframeopensorcloses.
• DonotuseZ-Shadeproductinalightningstorm.
• DonotleaveyourZ-Shadeproductunattended.
• DonotbuildresunderZ-Shadeproduct.
PRODUCT CARE/MAINTENANCE:
ForlonglastingdurabilityandthebestpossibleprotectionforyourZ-Shadeproduct,followthesecareand
maintenance instructions:
• Useamildsoap(notdetergent)andplentyofwaterfortopcleaning.
• LettheZ-Shadetopandframedrycompletelybeforeclosingorstoringtoavoidmildew.
• TheZ-Shadeframewilloperateandlookbetterifoccasionallywipedwithsiliconespray,especiallybefore
andafteruseindampconditions.Removeexcesssiliconeresiduebeforeattachingtop.
• Slightlytightenboltsifframebecomesloose.
©2016 Z-Shade Company Ltd. All Rights Reserved.
Z S1313G A Z _ _ 111016
Instant GAZEBO
13ft. x 13ft.
(3.96m x 3.96m)
USER MANUAL
Place your Instant Gazebo
frame in the center of area
to be shaded. With partner,
grasp two outer legs, slightly
lift off the ground, and step
backwards, stopping at full
arms’ length.
INITIAL SET UP
PACKAGE INCLUDES
Spread the top vent fabric
(A) over the peak section
and slide the 4 fabric corners
over the 4 vent fingers.
2
Expand the frame to approx.
2/3 open. Spread the larger
fabric (B) over the frame,
tuck the fabric under the top
vent fabric fingers and using
the hook and loop strips,
secure the top to the trusses
at 8 different points.
3
• Instant Gazebo Frame
• Two-Tone Polyester Top
Top Fabric (A) / Larger Fabric (B)
• (4) Corner Skirts (C)
• Roll Away Bag
• 4-Piece Stake Kit
Please read each step before you attempt to set up. Save these instructions for future reference.
1
a) Insert extension rods in the top of the legs. b) Secure corner fabrics to the leg by pressing the 2
locking strips together. c) Finally, pull the fabric out over the end of the extension rods and secure
using the sewn pockets. Repeat on all 4 corners.
3
TAKE DOWN
With partner, slightly lift up 2
adjacent outer legs, depress snap
button to unlock and telescope
inner legs into outer legs.
Repeat on opposite legs.
1
Now, with the canopy in
lowered position, remove
extension rods.
1) Pull the fabric back out
from the sewn pockets to gain
access to extension rods.
2) Remove fabric by releasing
the 2 locking strips at the top
of each leg.
3) Carefully slide extension
rods out from the top of the
legs. Repeat on all 4 corners.
2
Release Pull Pin at each corner
by first lifting fabric away from
slider. With one hand push up
on truss near the Pull Pin,
pull the pin out to release.
NOTE: It is much easier to
release Pull Pin when the
canopy weight has been
removed from the Pull Pin.
3
With partner on opposite
side, grasp top and bottom
area of trusses.
Lift the
canopy up slightly and shake
it while stepping towards
your partner until the unit is
3/4 closed. With each
partner grasping two outer
legs, push frame together to
fully close it. Be careful not to
pinch fingers!
Store canopy in roller bag.
4
Pull
Pin
Snap
Button
a
a
b
b
c
c
ATTACH TOP FABRIC (A)
ATTACH LARGER FABRIC (B)
SET UP
With partner on opposite side
of canopy, grasp the top and
bottom of the truss on
opposite sides. Lift up and
step backward until canopy is
3/4 opened. Be careful not to
pinch fingers. Expand frame
to fully open. Make sure the
vent fingers are released –
over the LARGE FABRIC.
1
To engage Pull Pin slider at each
corner, first lift the fabric off of the
slider, then with one hand hold
the top of the leg while pushing
up on the slider with the other
hand. The Pull Pin will engage the
hole. Repeat on all 4 corners.
2
Lift outer legs up and slide out
the inner legs until the snap
button locks into the outer leg.
Repeat on opposite legs.
4
Snap
Button
1) Set frame to the lowest setting.
2) Wrap the skirt around the outside
of the leg with the clip on top.
Non-coated side facing
outward.
3) Connect the elastic clips around
the top truss on both sides.
4) Use the attached tie-back straps
to gather the skirt.
Repeat on all 4 corner skirts.
5(C) ATTACHING CORNER SKIRTS
Elastic
Clips
Locking
Strips
WARNING: Keep all flame and heat sources away from all product fabrics. These fabrics meet
the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact
with any flame source. The application of any foreign substance to the fabric may render the
flame-resistant properties ineffective. This product contains TDCPP and/or TCEP, flame retardant
chemicals known to the State of California to cause cancer.
