ZANEEN Tetra Parco User manual

30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 1 of 6
Installation Instruction
Tetra Parco
Safety and warnings for installation:
• Installation and start-up must be carried out by qualifed personnel only.
• Carry out operations on device only with device disconnected from power supply.
• Connect to mains following the installation regulations in force.
• Do not remove power cable.
• Connection to the mains must be performed with certifed screw connectors, 120V, 3 x 2.5 mm 2,3x
1.5 mm2,2x2.5mm
2or2x1.5mm 2, in junction box with protection level IP 67.
• Replace gasket at every relamping.
8
max. 30
Suggestions on keeping the product
Keep installation instructions in the event of maintenance or disassembly operations, or make them
available for the personnel in charge.
Safety and warnings for installation:
Use only UV-STOP lamps.
Replace lamp only when the device has cooled down and is not powered.
Use the device only with a complete disc.
UV
STOP

Tetra Parco IP65
35W HIT-TC-CE G8,5
1Led24W
70W HIT-TC-CE G8,5
1Led37W
Class Power supply
II 120V 60Hz
II 120V 60Hz
II 120V 60Hz
II 120V 60Hz
UV
STOP
UV
STOP
Tie Rod
200mm (7 7/8”)
Ø13mm (1/2”)
450mm (17 11/16”)
M12
A+
A+
A+
A+
L9A12000
30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 2 of 6
Installation Instruction
Tetra Parco

1500mm (59 1/16")
1930mm (76")
1330mm (52 3/8")
900mm (35 7/16")
1000mm (39 3/8")
140mm
140mm
(5 1/2")
(5 1/2")
13mm (1/2")
13mm (1/2")
13mm (1/2")
240mm (9 7/16")
240mm (9 7/16")
240mm (9 7/16")
200mm (7 7/8")
200mm (7 7/8")
200mm (7 7/8")
240mm (9 7/16")
240mm (9 7/16")
240mm (9 7/16")
200mm (7 7/8")
200mm (7 7/8")
200mm (7 7/8")
2600mm (102 3/8")
13mm (1/2")
240mm (9 7/16")
200mm (7 7/8")
240mm (9 7/16")
200mm (7 7/8")
2270mm (89 3/8")
900mm (35 7/16")
30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 3 of 6
Installation Instruction
Tetra Parco
140mm
140mm
(5 1/2")
(5 1/2")

Do not put device in contact with aggressive
chemical substances, such as fertilizers, etc.
We do not recommend switching on the fitting during the day with strong solar radiation
!
30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 4 of 6
Installation Instruction
Tetra Parco
LED MODUL
CAUTION: Make sure that the lines are protected from over-voltage.
Do not look into the beam. LED-Module Class 1.
In case of malfunctions with the LED module, please contact us
.

NO!
NO!
NO!
OK!
グ
グ
700mm (27 9/16")
500mm (19 11/16")
700mm (27 9/16")
30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 5 of 6
Installation Instruction
Tetra Parco

Ø 8÷13mm 3p 1,5mm max.
2
Connector’sata
8
max. 30
ON
OFF
30 Tycos Drive, Toronto, Ontario, Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: [phone] www.zaneen.com [email protected]m Page 6 of 6
Installation Instruction
Tetra Parco
CH 4
2 Nm
Only for lamp
The crossed–out wheeled bin means that within the
European Union the product must be taken to separate
collection at the product end-of life. This applies to your
device but also to any enhancements marked with this
symbol. Do not dispose of these products as unsorted
municipal waste.
