ZANKER ZKM 6520 DX Operation manual

User
information
Informations
pour les
utilisateurs
Informatie
voor de
gebruiker
Induction
hob
Table de
cuisson à
induction Inductiekook-
plaat
ZKM 6520 DX

2
Contents
Operating Instructions- - - - - - - - - - - - - - - 3
Safety instructions - - - - - - - - - - - - - - - - - 3
Description of the Appliance - - - - - - - - - - 4
Operating the appliance - - - - - - - - - - - - - 6
Tips on Cooking and Frying- - - - - - - - - - - 12
Cleaning and Care - - - - - - - - - - - - - - - - - 15
What to do if … - - - - - - - - - - - - - - - - - - - 16
Disposal - - - - - - - - - - - - - - - - - - - - - - - - 19
Installation Instructions- - - - - - - - - - - - - - 20
Service - - - - - - - - - - - - - - - - - - - - - - - - - 21
Assembly - - - - - - - - - - - - - - - - - - - - - - - 64
Rating Plate- - - - - - - - - - - - - - - - - - - - - - 67
Thank you for selecting our appliance
We wish you lots ofenjoyment with your new appli-
ance and wehope that you will considerour brand
again when purchasing household appliances.
Please read this user manual carefully and keep it
throughout the product life cycle as a reference doc-
ument.Theusermanualshouldbepassedontoany
future owner of the appliance.
The following symbols are used in this userinformation:
1
Warning!This must be read! Important advice for thesafety of persons and information on
avoiding damage to the appliance
3General information and advice
2Information on environmental protection
zDangerous voltage

3
Operating Instructions
1Safety instructions
Pleasecomplywiththeseinstructions.Ifyoudo
not,anydamage resultingisnotcoveredby the
warranty.
Correct use
•Thisapplianceisnotintendedforusebychil-
dren or other persons whose physical, sen-
sory or mental capabilities or lack of
experience and knowledge prevents them
from using the appliance safely without su-
pervision or instruction by a responsible per-
son to ensure that they can use the
appliance safely.
•Do not leave the appliance unattended dur-
ing operation.
•This appliance should be used only for nor-
mal domestic cooking and frying of food.
•The appliance must not be used as a work
surface or as a storage surface.
•Additions ormodifications tothe appliance
are not permitted.
•Donotplaceorstoreflammableliquids,high-
ly inflammable materials or fusible objects
(e.g. plasticfilm, plastic, aluminium) on or
near the appliance.
Children’s safety
•Small children must be kept away from the
appliance.
•Only let bigger children work on the appli-
ance under supervision.
•To avoid small children and pets unintention-
ally switching theappliance on, we recom-
mend activation of thechild safety device.
General safety
•The appliance mayonly beinstalled and
connected bytrained, registered service en-
gineers.
•Built-in appliances may only be used after
theyhavebuiltintosuitablebuilt-inunitsand
work surfaces that meet standards.
•In the event of faults with the appliance or
damage to the glassceramic (cracks,
scratches or splits), the appliance must be
switched off and disconnected from the elec-
trical supply, to prevent the possibility of an
electric shock.
•Repairstotheappliancemustonlybecarried
out by trained registered service engineers.
Safety during use
•Remove stickers and film from the glass ce-
ramic.
•There is the risk of burns from the appliance
if used carelessly.
•Cables from electricalappliances must not
touch the hot surfaceof the appliance or hot
cookware.
•Overheated fats and oils can ignite very
quickly. Warning! Fire hazard!
•Switch the cooking zones off after each use.
•Users with implanted pacemakers should
keep their upper body at least 30 cm from in-
duction cooking zones that are switched on.
•Risk of burns! Do not place objects made of
metal, such as knives, forks, spoons and
saucepan lids on the cooking surface, as
they can get hot.

4
Safety when cleaning
•Forcleaning,theappliancemustbeswitched
off and cooled down.
•For safety reasons, the cleaning of theappli-
ance with steam jet or high-pressure clean-
ing equipment is not permitted.
How to avoid damage to the appli-
ance
•The glass ceramic can be damaged by ob-
jects falling onto it.
•The edge of the glass ceramic can be dam-
aged by being knocked by the cookware.
•Cookwaremadeof castiron,castaluminium
or with damaged bottoms can scratch the
glass ceramic ifpushed across the surface.
•Objects that melt and things that boil over
can burnonto the glassceramic and should
be removed straightaway.
•Do not use the cooking zoneswith empty
cookware or without cookware.
•To avoid damaging cookware and glassce-
ramics, do not allow saucepans or frying
pans to boil dry.
•The ventilation gap of 5mm between the
worktop and front of the unit underneath it
must not be covered.
Description of the Appliance
Cooking surface layout
Induction cooking zone 2200 W
with power function 3100 W
Induction cooking zone 1800 W
Induction cooking zone 1400 W
Control panel Induction cooking zone 1800 W
with power function 2800 W

5
Control panel layout
Touch Control sensor fields
TheapplianceisoperatedusingTouchControl
sensor fields. Functions are controlled by
touching sensor fieldsand confirmedby dis-
plays and acoustic signals.
Touch the sensor fields fromabove, without
covering other sensor fields.
On/Off
with power indicator
Heat setting selection
Lock
Timer display
Power function
Cooking zone indicators
Timer function
Display
Timer
Sensor field Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power Switching the power function on and off

6
Displays
Residual heat indicator
1Warning! Risk of burns from residual
heat.After beingswitched off,the cooking
zones need some time to cool down. Look
at the residual heat indicator h.
3Residualheatcanbeusedformelting and
keeping food warm.
Theinduction cooking zones createthe
heat required forcooking directlyin the baseof
the cookware. The glass ceramic is merely
heated by the residualheat ofthe cookware.
The cooling fan switches itself on and off
depending upon the temperature of the elec-
tronics.
Operating the appliance
3Use the induction cooking zones with suit-
able cookware.
Switching the appliance on and off
3After switching on, within approx.
10 seconds a heat setting or a function
must be set, otherwise the appliance auto-
matically switches itself off.
Display Description
¾Cooking zone is switched off
¿- ÇHeat settings Heat setting is set
eFault Malfunction has occurred
fPan detection Cookwareisunsuitableortoosmallornocook-
ware has been placed on the cooking zone
hResidual heat Cooking zone is still hot
lChild safety device Lock/child safety device isengaged
pPower Power function is switched on
_Automatic switch off Switch off is active.
Control panel Display Pilot light
To switch on Touch for 1 second ¾/ hlights up
To switch off Touch for 1 second h/ none goes out

7
Setting the heat setting
Locking/unlocking the control
panel
The control panel, with theexception of the
“On/Off”sensorfield,canbelockedatanytime
in orderto prevent the settings being changed
e.g. by wiping over the panel with a cloth.
3When you switch the appliance off, the
locking function is automatically switched
off.
Using the child safety device
The child safety device preventsunintentional
use of the appliance.
Setting the child safety device
Control panel Display
Increase Touch ¿to Ç/ p
Decrease Touch Çto ¾
Switch off Touch and at the same time ¾
Control panel Display
Switch on Touch l(for 5 seconds)
Switch off Touch previously set heat setting
Step Control panel Display/Signal
1. Switch on the appliance
(Do not set a heat setting) ¾
2. Touch until the signal sounds Acoustic signal
3. Touch l
Appliance switches off. The child safety device is engaged.

8
Overriding the child safety device
The child safety device can be releasedin this
way for a single cooking session; it remains ac-
tivated afterwards.
Releasing the child safety device
Switching the power function
on and off
The power function makes more power
availabletotheinductioncookingzones,e.g.to
bring alargequantity of water to the boil quickly.
The power function is activated for 10 minutes
at most. After that the induction cookingzone
automatically switches back to heat setting 9.
3If the power function hasended, the cook-
ingzonesautomaticallyswitchbacktothe
heat setting set previously.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch and at the same time ¾/ acoustic signal
Until the appliance is next switched off, it can be used as normal.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch until the signal sounds Acoustic signal
3. Touch
Appliance switches off. The child safety device is released.
Control panel Display
Switch on Touch p
Switch off Touch Ç
Touch Ç

9
Power Management
Thecookingzonesofthecookingsurfacehave
a maximum power.
Themaximumpowerisreachedwhentheheat
setting 9 has been set for all cooking zones.
Twocookingzonesgenerateapair(seefigure)
and therefore, the power management shares
the maximum available power between these
cooking zones.
When the power functionis selected forone
cooking zone, the power management makes
theadditionalpowerforthiscookingzoneavail-
able by reducing the power of the correspond-
ing other cooking zone.
Example: the heat setting 9 is selected on one
cooking zone. The power function is switched
on for the correspondingcooking zone.The
power function is carried out but theheat set-
ting9ofone of thecookingzonesandthe pow-
erfunctionfortheothercookingzoneofthepair
exceed the maximum power for both at the
same time. For this purpose, the power man-
agement reduces the power of the cooking
zone that switched onfirst from 9 to example 5
and the display of thiscooking zonechanges
between9 and 5 and thenstays at the current
possible maximum 5. (If the display changes
between 9 and 5 or 9 and 3 or another value
depends on the type of appliance and the size
of the cooking zone.).
Using the timer
All cooking zones can use each use one of the
two timer functions at the same time.
3If a cooking zone is switched off,the timer
function set is also switched off. 3Ifaheatsettingissetonthiscookingzone
in addition to a countdown timer, the cook-
ing zoneis switched offafter the time set
has elapsed.
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches off
Countdown timer cooking zones not in use acoustic signal
00 flashes

10
Selecting a cooking zone
3The heat setting indicator of the selected
cooking zone goes out, as long as the tim-
er time can be set.
3Ifthepilotlightis flashingmoreslowly, the
heat setting indicator appears again and
the heat setting can be re-set or modified.
3If other timer functions are set, after a few
seconds the shortest remaining time of all
the timer functions is displayed and the
corresponding pilot light flashes.
Setting time
Step Control panel Display
1. Touch once Pilot light of the first cooking zone
flashes
2. Touch once Pilot light of the second cooking
zone flashes
3. Touch once Pilot light ofthe third cooking zone
flashes
4. Touch once Pilotlightofthefourthcookingzone
flashes
Step Control panel Grill setting
1. Selecting cooking zone Telltale ofcooking zone selected flashes
2. Touch or from the se-
lected cooking zone 01 to 99 minutes
3. Touch or from the se-
lected cookingzone formore
than 4 seconds
... 05...10...15... 20 or... 95... 90... 85...
80... (5-minute stepsfor easy setting)
After a fewseconds the power indicator flashes more slowly.
The time is set.
The time counts down.

11
Switching off the Timer function
Changing the time
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel Display
1. Select a cooking zone Pilotlightoftheselectedcookingzoneflashesmore
quickly.
Remaining time is displayed
2. Touch for the cooking
zone selected The remaining time counts down to 00.
The pilot light goes out.
The Timer function for the selected cooking zone is switched off.
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected flashes fast-
er
The time remaining is displayed
2. Touch or for the cook-
ing zone selected 01 to 99 minutes
After a fewseconds the pilotlight flashesmore slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selectedflashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch Acoustic signal to acknowledge.
Acoustic signal stops.

12
Automatic cut-out
Cooking surface
•If after switching on the cooking surface, a
heat setting is not set for a cooking zone
withinapprox. 10 seconds, the cooking sur-
face automatically switches itself off.
•If all cooking zones are switched off, the
cookingsurfaceautomaticallyswitchesitself
off after approx. 10 seconds.
Induction cooking zones
•If cookware that is not suitable is used, f
lightsup in the display and after2 minutes
theindicatorforthecookingzoneswitchesit-
self off.
•Ifoneofthecookingzonesisnotswitchedoff
after acertain time, or if the heat setting is
not modified, therelevant cooking zone
switches off automatically. _is displayed.
Before being used again, the cooking zone
must be set to ¾.
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowl-
edge,intensivebrowningoffood,especial-
ly in products containing starch, can
constituteahealthriskduetoacrylamides.
Therefore werecommend cooking at the
lowestpossible temperatures and not
browning foods too much.
Heat setting Switches off after
1- 26 hours
3- 45 hours
54 hours
6- 91.5 hours

13
Cookware for induction cooking zones
Cookware material
3*Cookwareforinductioncookingzones is
labelled as suitable by the manufacturer.
Suitability test
Cookwareissuitableforinductioncooking,if …
•...a littlewateronan inductioncookingzone
set to heatsetting 9is heated very quickly.
•...amagnetstickstothebottomofthecookware.
Cookware base
Thebottomofthecookwareshouldbe asthick
and flat as possible.
Pan size
Up to a certain limit, induction cooking zones
adapt themselves to the size of the bottom of
the cookware automatically. However, depend-
ingonthecookingzonesize,themagneticpart
ofthebottomofthecookwaremusthavea min-
imum diameter.
3Thecookwaremustbeplacedcentrallyon
the cooking zone.
Tips on energy saving
2Place cookware on the cooking zone be-
fore it is switched on.
2If possible, always place a lid on the cook-
ware.
Cookware material suitable
Cast iron +
Steel, enamelled steel +
Stainless steel +*
Multi-layer pan bottom +*
Aluminium, copper, brass -
Glass, ceramic, porcelain -
Diameter of cooking zone
[mm]
Minimum diameter of dish base
[mm]
210 180
180 145
145 120

14
Examples of cooking applications
The information in the table is for guidance only.
Thepowerfunctionissuitableforheatinglarge
quantities of liquid.
Heat
setting Cooking- process suitable for Cooking time Hints
0Off position
1 Keeping
food warm To keep cooked foods warm as necessary Cover
1-2 Melting Hollandaise sauce,
to melt butter, chocolate, gelatine 5-25 mins. Stir occasionally
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3 Simmer-
ing on low
heat
To simmer rice and milk-based
dishes
To heat up ready meals 25-50 mins. Add minimum twice as much
liquid as rice, stir milk dishes
some times
3-4 Steaming
Braising To steam vegetables, fish to braise meat 20-45 mins. With vegetables add only
some liquid (some table-
spoons)
4-5 Boiling
To steam potatoes 20-60 mins. Use only some liquid, e.g.:
max. ¼l water for
750 g potatoes
To cook larger quantities of food,
stews and soups 60-150 mins. 3 l liquid maximum plus ingre- dients
6-7 Gentle
Frying
Tofryescalopes,vealcordonbleu,
cutlets, rissoles, sausages, liver,
roux, eggs, pancakes, doughnuts Steady frying Turn occasionally
7-8 Heavy
Frying
Hash browns, loin steaks, steaks,
Flädle (pancakes for garnishing
soup) 5-15 mins.
per pan Turn occasionally
9
Boiling
Searing
Deep
frying
To boil large quantities of water, to cook pasta,
to sear meat (goulash, pot roast), deep frying chips

15
Cleaning and Care
1Take care! Risk of burns from residual
heat.
1Warning! Sharp objects and abrasive
cleaning materials will damage the appli-
ance. Clean withwaterandwashingup liq-
uid.
1Warning! Residues from cleaning
agents will damage the appliance. Re-
moveresidueswithwaterand washingup
liquid.
Cleaning the appliance after each
use
1.Wipe the appliance with a damp cloth and a
little washing up liquid.
2.Rub the appliance dry using a clean cloth.
Removing deposits
1.Placeascraperontheglassceramicsurface
at an angle.
2.Remove residues by sliding the blade over
the surface.
3.Wipe the appliance with a damp cloth and a
little washing up liquid.
4.Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless
steel can be purchased in specialized shops
3Remove stubborn residues with a cleaner
for glass ceramic or stainless steel.
3Scratches or dark stains on the glass ce-
ramic that cannot be removed do not how-
everaffectthefunctioningoftheappliance.
Remove
Type of dirt immedi-
ately when the appliance has cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes cleaner for glass ceramic
or stainless steel*
fat splashes --- yes
shiny metallic discolouration --- yes

16
What to do if …
Problem Possible cause Remedy
The appliance cannot be switched
on or is not operating More than 10 seconds have passed sincetheappliancewasswitchedon Switch the appliance on again.
The lock is switched on lSwitch off the lock (See the section
“Locking/unlockingthecontrolpanel”)
The child safety device isswitched
on lDeactivate child safety device (See the section “Child safety device”)
Several sensor fields were touched
at the same time Only touch one sensor field
Automatic switch off has been trig-
gered Remove any objects (pan, cloths, etc.) that are lying on the control
panel. Switch the appliance on
again
Dirty control panel The sensor fieldsmust be dry and
fat-free.
The cooking zones automatically re-
duce the cooking level to ¾Thesensorfieldsare partly covered by a damp cloth or with liquid Remove the cloth or the liquid. Reset the cooking level required.
The residual heat indicator is not
displaying anything The cooking zone was only on for a short time and is therefore not hot If the cooking zone is supposed to be hot, call the Customer Service
Department.
acoustic signal sounds, appliance
switches off One or more sensor fields have been covered for longer than
10 seconds
Uncover sensor field
Asignalsoundswhen theappliance
is switched off Thecontrol panel is partiallyorcom- pletely covered by objects Remove the objects
The appliance switches off, a signal
sounds repeatedly The control panel was covered too long Theappliancewillbefullyfunctional after about 50 seconds
Thesensor fieldscannotbe operated A single sensor field was covered
for a short period The sensor field is automatically re- leased after about 10 seconds
Display is switching between two
heat settings Power management is reducing the power of this cooking zone See the section “Switching the pow- er function on and off”
flights up Unsuitable cookware Use suitable cookware
No cookware on the cooking zone Place cookware on the cooking
zone
The diameter of the bottom of the
cookware is too smallfor the cook-
ing zone
Move onto a smaller cooking zone
Use suitable cookware
_lights up Automatic switch-off has been trig-
gered Switch off the cooking zone. Switch the cooking zone on again

17
If you are unable to remedy the
problem by following the above
suggestions, please contact your
local Service Force Centre.
1Warning! Repairs to the appliance are
only to be carried out byqualified service
engineers. Considerable danger to the
user may result from improperrepairs.
3If the appliance has been operated incor-
rectly, the engineer'svisit will bechargea-
ble, even during the warranty period.
eand number are displayed Electronics fault Disconnect the appliance from the
electrical supply for a fewminutes
(Take thefuseoutofthehouse’swir-
ing system)
Ifafter switchingonagain, eis dis-
played again, call the customer
service department
Problem Possible cause Remedy

18
Operating noises
Depending on the materialand the processing
of thebase, the followingnoises may occur
when using induction cooking zones.
•Cracking noise (1)
when using cookware made of different ma-
terials (Sandwich construction)
•Whistling (1)
when using an individual cooking zone or
several cooking zones with high powers
when the cookware is made of different ma-
terials (Sandwich construction)
•Humming (2)
can occur at high power levels
•Clicking (2)
during electric switching processes
•Hissing, buzzing (3)
The device is fitted with a fan for cooling the
electrics.Awhiringnoisecanbeheardwhen
operatingthefanwhichmaydeviatedepend-
ingontheperformanceandmaycontinuefor
a while after the appliance isswitched off.
The noises described are normal
and do not refer to any defects.
3
2
1

19
Disposal
2Packaging material
The packaging materials are environmen-
tally friendly and can be recycled. The
plasticcomponents are identified by mark-
ings, e.g. >PE<, >PS<, etc. Please dis-
pose of the packaging materials in the
appropriate container at the community
waste disposal facilities.
2Old appliance
The symbol Won the product oron its
packaging indicates that this product may
not be treated as household waste. In-
stead it shall be handed over to the appli-
cablecollection pointfor the recycling of
electricalandelectronicequipment.Byen-
suringthisproduct isdisposed ofcorrectly,
you will help prevent potential negative
consequencesfortheenvironmentandhu-
man health, which could otherwise be
causedby inappropriatewastehandlingof
thisproduct.Formoredetailedinformation
about recyclingofthisproduct,pleasecon-
tact yourlocal city office, yourhousehold
waste disposal service or the shop where
you purchased the product.

20
Installation Instructions
1Safety instructions
Warning! This must be read!
Thelaws,ordinances,directivesandstandards
inforcein thecountryofuseareto befollowed
(safety regulations, proper recycling in accord-
ance with the regulations, etc.)
Installationmay only be carriedout by a quali-
fied electrician.
The minimum distancesto other appliances
and units are to be observed.
Anti-shock protection must be provided by the
installation, for example drawers may only be
installed with a protective floor directly under-
neath the appliance.
The cut surfaces of the worktop are to be pro-
tected against moisture using a suitable seal-
ant.
Thesealantsealstheappliancetotheworktop
with no gap.
Do not use silicon sealant between the appli-
ance and the work top.
When building in, protect the underside of the
appliancefromsteamandmoisture,e.g.froma
dishwasher or oven.
Avoidinstallingtheappliancenexttodoorsand
under windows. Otherwise hot cookware may
be knocked off the rings when doors and win-
dows are opened.
zRisk of injury from electrica
current.
•The electrical mains terminal is live.
•Makeelectrical mains terminal free of voltage.
•Follow connection schematic.
•Observe electricalsafety rules.
•Ensure anti-shock protection by installing
correctly.
•The appliance must be connected to the
electrical supplyby a qualified electrician.
zRisk of injury from electrical
current.
•Loose andinappropriate plugand socket
connectionscanmaketheterminaloverheat.
•Have the clamping connections correctly in-
stalled by a qualified electrician.
•Use strain relief clamp on cable.
•In the event of single-phase or two-phase
connection, the appropriate mains cable of
type H05BB-F Tmax 90°C(or higher) or an
equivalent type must be used.
•Ifthisappliance’smainscableisdamaged,it
must be replaced by a specialcable(type
H05BB-F Tmax 90°C;or higher) oran equiv-
alent type. The latter is availablefrom the
Customer Care Department.
A device must be provided in the electrical in-
stallation which allows the appliance to be dis-
connected from the mains atall poles with a
contact opening widthof at least 3 mm.
Suitable isolation devices include line protect-
ing cut-outs, fuses (screw type fuses are tobe
removed from the holder), earth leakage trips
and contactors.
