ZANKER TT 160 ICE User manual

B/Z/8. (03.)200364624
GEBRUIKSAANWIJZING
MODE D`EMPLOI
GEBRAUCHSANLEITUNG
INSTRUCTION BOOK
KOELKAST
REFRIGERATEUR
KÜHLSCHRANK
REFRIGERATOR
TT 161 B (TT 160 ICE)
NL
FR
DE
GB

48
Before installing and using the appliance read this user's instruction book carefully. It contains safety
precautions, hints, information and ideas. If the refrigerator is used in compliance with the
instructions written, it will operate properly and provide you with greatest satisfaction.
The symbols below help you to find things more easily:
Safety precautions
Warnings and information at this symbol serve safety for you and your appliance.
Hints, useful information
Environmental information
Symbol for ideas
At this symbol ideas can be found according to food and its storing.
GB
From the Electrolux Group. The worlds No.1 choice.
The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux
Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of
approx. USD 14 billion in more than 150 countries around the world.

49
GB
Cont
Contents ents
Important safety information ..................................................................................................50
General safety precautions....................................................................................................50
Precautions for child safety....................................................................................................50
Safety precautions for installation ...........................................................................................50
Instructions for the User.........................................................................................................51
General information ..............................................................................................................51
Description of the appliance, main parts ..................................................................................51
Handling the appliance .........................................................................................................52
Putting it into use.............................................................................................................52
Controlling the temperature, setting....................................................................................52
Hints for storage..............................................................................................................52
Storage time and temperature of foods ..............................................................................53
How to use the ice-making compartment.............................................................................53
How to use the fresh food compartment..............................................................................53
How to make ice cubes ....................................................................................................53
Some useful information and advice........................................................................................53
Hints and ideas ...............................................................................................................53
How to save energy .........................................................................................................53
The appliance and environment .........................................................................................54
Maintenance .......................................................................................................................54
Defrosting ......................................................................................................................54
Regular cleaning .............................................................................................................54
When the refrigerator is not in use......................................................................................54
Trouble shooting..................................................................................................................54
How to change the bulb ...................................................................................................55
If something does not work ...............................................................................................55
Instructions for the Installer....................................................................................................56
Technical data.....................................................................................................................56
Installing the appliance .........................................................................................................56
Transportation, unpacking.................................................................................................56
Cleaning ........................................................................................................................56
Placement ......................................................................................................................57
Change of door opening direction ......................................................................................58
Electrical connection........................................................................................................59
Storage time chart.................................................................................................................60
Warranty and service .............................................................................................................61
Guarantee conditions ...........................................................................................................61
Service and spare parts ........................................................................................................61
Declaration of guarantee terms .............................................................................................62

50
Im
Impor port tant saf ant safe et ty inf y infor ormation mation
Precautions for child safety
Do not allow children to play with the packaging of
the appliance. Plastic foil can cause suffocation.
Adults must handle the appliance. Do not allow
children to play with it or its controlling parts.
Safety precautions for
installation
Put the appliance to the wall to avoid touching or
catching warm parts (compressor, condenser)
to prevent possible burn.
When moving the appliance take care of the plug
not to be in the socket.
When placing the appliance take care not to
stand it on the power cord.
Adequate air circulation should be around the
appliance, lacking this leads to overheating. To
achieve sufficient ventilation follow the
instructions relevant to installation.
If the appliance is not placed on floor level,
provide appropriate fixing (e. g. using sucking
disks).
For the safety of life and property keep
the precautions of these user's
instructions as the manufacturer is not
responsible for damages caused by omission.
General safety precautions
Keep these instructions and they should remain at
the appliance when moving away or changing
owner.
This appliance is designed for storing food,
domestic use and being used according to these
instructions only.
Specialised companies that are qualified to do
so by the manufacturer must carry out service
and repairs including repairing and changing
the power cord. Accessory parts supplied by
them should be used only for repairing. Otherwise
the appliance can be damaged or can cause other
damage or injury.
The appliance is out of circuit only in that case if the
plug is removed from the socket. Before cleaning
and maintenance always unplug it (do not get it by
the cable). If the socket is difficult to reach, switch
off the appliance by cutting off the current.
Power cord must not be lengthened.
Without the lamp cover of interior lighting you must
not operate the appliance.
When cleaning, defrosting, taking out frozen food
or ice tray do not use sharp, pointed or hard
devices, as they can cause damage to the
appliance.
Be careful not to allow liquids to the temperature
control.
Ice and ice-cream can cause hurt if they are eaten
immediately after removal from the ice-making
compartment.
After dissolving frozen food must not be refrozen, it
must be used up as soon as possible.
Store pre-packed frozen food in accordance with
the frozen food manufacturer's instructions.
You must not make defrosting faster with any
electric heating appliance or chemicals.
Do not put hot pot to the plastic parts of the freezer.
Do not store flammable gas and liquid in the
appliance, because they may explode.
Do not store carbonated drinks, bottled drinks and
bottled fruits in the freezer.
GB
If you are discarding the appliance pull the plug
out of the socket, cut the connection cable (as
close to the appliance as you can) and remove
the door to prevent playing children to suffer
electric shock or to close themselves into it.

51
Ins
Instr tructions f uctions for the User or the User
General information
The official designation of the appliance is home
refrigerator with a ice-making compartment.
According to this the appliance is suitable for storing
frozen and deep-frozen food for limited time and
making ice.
The appliance can meet the requirements of
standards between different temperature limits
according to the climate class.
The letter symbol for class of climate can be found
on the data label.
Description of the appliance, main parts
1. Ice-making compartment
2. Drip tray
3. Wire shelf
4. Glass shelf
5. Vegetable box
6. Data label
7. Adjustable feet
8. Ice tray
9. Butter compartment
10. Lighting box
11. Door shelf
12. Gasket
13. Bottle shelf
14. Egg tray
15. Air circulation
16. Air grid
17. Condenser
18. Compressor
GB

52
Handling the appliance
Putting it into use
Place the accessories into the refrigerator then plug to
the mains socket. To start cooling turn the control dial
from "0" clockwise according to the figure. In 0
position the appliance is out of operation.
The next paragraph will give instructions for setting.
Hints for storage
When placing the different kinds of food take into
consideration the sketch below in figure:
1. Storing frozen foods, making ice and ice-cream.
2. Confectionery, ready-cooked foods
3. Foods in dishes
4. Opened cans
5. Milk, dairy products
6. Fresh meat, cold cuts, sausages, etc.
7. Fruits, vegetables, salads
8. Cheese, butter
9. Eggs
10. Yoghurt, sour cream
11. Bottles, drinks
GB
Controlling the temperature, setting
The thermostatic controller interrupts the operation of
the appliance automatically for more or less time
depending on the setting then restarts it assuring the
required temperature.
Turning the control button towards the bigger numbers
cooling becomes more and more intensive.
In the ice-making compartment can be reached -2 °C
or lower temperature if the knob of the thermostatic
control is set according to following table:
Ambient temperature Thermostat setting
from 10 °C to 16 °C 1-2
from 16 °C to 25 °C 2-3
from 25 °C to 32 °C 3-4
from 32 °C to 38 °C 3-4
In this case the temperature starting automatically in
the fresh food compartment is about +5 °C or below.
The setting 5 are suitable for quick chill of big quantity
goods.
The temperature coming about in the refrigerator is
effected by not only the position of the thermostatic
control but the ambient temperature, frequency of
door openings and the quantity of food put into it
newly etc.
In the maximum i.e. 5 position - in case of
increased demand e.g. during heatwaves -
without disconnecting continuous operation can
occur. This does not cause damages to the appliance.

53
Storage time and temperature of
foods
The enclosed chart at the end of the instruction books
gives information about storage time in the fresh food
compartment.
The storage time can not be determined exactly in
advance, as it depends on the freshness and handling
of the cooled food. That is why the storage time made
known is only informative.
It is safe to store quick-frozen food only that way if they
were not dissolved even for a short time until placing
them into the ice-making compartment.
How to use the ice-making
compartment
In the ice-making compartment -2 °C or below can be
held depending on setting of thermostatic control.
It is suitable for quickly refrigerating and storing foods
in small quantity and for making ice-cubes.
How to use the fresh food
compartment
For adequate cooling developing interior air
circulation is necessary. For this reason you are
asked not to cover the whole surface of the wire
shelves with paper, trays, etc.
Do not put hot food into the refrigerator.
Allow it to reach room temperature naturally.
In this way the unnecessary frost building up can
be avoided.
Foods can take over odours from each
other. So it is essential to put foods in closed
dishes or wrap them in cellophane, aluminium
foil, grease-proof paper or cling film before
placing them into the refrigerator. This way foods
will keep their moisture e.g. vegetables will not
dry out after some days.
How to make ice cubes
To make ice cubes fill the enclosed ice cube tray with
water and put it to the ice-making compartment or on
top of it. Wetting the bottom of the tray and setting
thermostatic control knob to maximum stage can
shorten preparing time. After finishing do not forget to
reset the thermostatic control to the suitable stage.
Ready ice cubes can be taken out of the tray under
running water then twist or hit it.
Some useful information and
advice
The variable shelves are worth paying
attention to, which increases the usefulness
of the fresh food compartment considerably.
Rearranging the shelves is also possible when the
door is open at an angle of 90°.
Hints and ideas
In this chapter practical hints and ideas are given
about how to use the appliance to reach maximum
energy saving and there is environmental
information about the appliance as well.
How to save energy
Avoid putting the appliance in a sunny place and
near anything that gives off heat.
Be sure that the condenser and the compressor
are well ventilated. Do not cover the sections
where ventilation is.
Wrap products in tightly closing dishes or cling
film to avoid building up unnecessary frost.
Do not leave the door open longer than
necessary and open it when it is needed.
Put liquid into the appliance only in a closed
dish.
Put warm foods and liquid in the appliance only
when they are at room temperature.
Defrost the appliance when the ice in the
ice-making compartment is more than 4 - 5
mm thick.
Keep the condenser clean.
GB

54
The appliance and environment
This appliance does not contain gasses which could
damage the ozone layer, in either its refrigerant circuit
or insulation materials. The appliance shall not be
discarded together with the urban refuse and rubbish.
Avoid damaging the cooling unit, especially at the rear
near the heat exchanger. Information on your local
disposal sites may be obtained from your municipal
authorities.
The materials used on this appliance marked with the
sympol are recyclable.
Maintenance
Defrosting
Bleeding part of the moisture of cooling chamber in
form of frost and ice goes with the operation of the
refrigerator.
Thick frost and ice has an insulating effect, so it
reduces cooling efficiency as the temperature
increases, it needs more energy, at a certain
thickness it does not allow the door of the ice-making
compartment to open, possibly the door can be
broken.
We recommend to defrost the ice-making
compartment once a week and when the
frost is more than 4-5 mm.
How to defrost it:
Break the circuit of the appliance or turn thermostatic
control knob into 0 position.
Empty the ice box. Wrap foods inside into newspaper
and put them on a cool place or into another
appliance.
Leave the door of the appliance and ice-making
compartment open.
Defrosting usually takes several hours. When finished,
pour defrost water gathered out of the tray and wipe
the surfaces dry.
Apply voltage to the appliance or turn thermostatic
control knob to middle (3) position.
Put foods taken out back to their places.
Regular cleaning
It is recommended to wash the inside of the
refrigerator in 3-4 weeks time.
Household cleaner or soap must not be used.
After you made it no-current wash the appliance
using lukewarm water and wipe it.
Clean the magnet door rubber profile with clean
water.
After cleaning plug the appliance to the mains
socket.
It is practical to clean and defrost the ice-making
compartment at a time and when it is empty.
Dust and dirt collected on the back of the
refrigerator, condenser is recommended to be
removed once or twice a year.
When the refrigerator
is not in use
In case the appliance will not be used for a long
time follow these steps:
Break the circuit of the appliance.
Remove foods from the refrigerator.
Defrost and clean it as written before.
Leave the door open to avoid a build up of air
inside.
GB

55
Trouble shooting
During operation of the appliance some smaller but
annoying trouble can often occur, which does not
require calling a technician out. In the following chart
information is given about them to avoid unnecessary
charges on service.
We draw your attention that operation of appliance goes
with certain sounds (compressor- and circulating
sound). This is not trouble, but means normal
operation.
We draw it to your attention again that the
appliance operates discontinuously, so the
stopping of compressor does not mean being no-
current. That is why you must not touch the electrical
parts of the appliance before breaking the circuit.
How to change the bulb
Should the light fail to work you can change it as
below:
Break the circuit of the appliance.
Unscrew the plate screw fixing the lamp cover, then
take the lamp cover off in the direction of arrow and
the bulb can be changed. (Type of the bulb: Mignon
322, 230 V, 15 W, E 14 thread)
After changing bulb replace the lamp cover, screw the
plate screw and apply voltage to the appliance.
The lack of light does not influence operation of the
refrigerator.
If something does not work
Problem
The appliance does not
cool sufficiently
The appliance cools too
hard
The appliance does not
cool at all
The appliance is noisy
Possible cause
The thickness of the frost is greater than 4-5 mm on
the cooling plate.
Thermostatic control is set too low.
Too many foods to be cooled were put in.
Very warm foods were put in.
Door is not shut properly.
There is no inside cool air circulation.
The thermostatic control is set too high.
Plug is not connected to the mains socket properly.
There is no voltage in the mains socket.
Thermostatic control is in 0 position.
The appliance is not supported properly.
Solution
Defrost the appliance.
Set higher position.
Put fewer foods to be cooled.
Put foods max. at room temperature.
Check if the door is shut.
Provide inside cool air circulation.
Set lower position.
Check if the connection is proper.
Check if there is voltage.
Check setting of thermostatic control.
Check if the appliance stands stable.
Inasmuch as the advice does not lead to result, call the nearest brand-mark service.

56
Ins
Instr tructions f uctions for the Ins or the Inst taller aller
Technical data
TT 161 B (TT 160 ICE)
Ice-making comp.: 7
Fresh food comp.: 153
Ice-making comp.: 7
Fresh food comp.: 148
550
850
600
0,57
208
B
80
35
Model/Type
Gross capacity (l)
Net capacity (l)
Width (mm)
Height (mm)
Depth (mm)
Energy consumption (kWh/24h)
(kWh/year)
Energy class, according to EU standards
Rated power (W)
Weight (kg)
Installing the appliance
Transportation, unpacking
It is recommended to deliver the appliance in
original packaging, in vertical position
considering the protective warning on packaging.
After each transportation the appliance must not be
switched on for approx. 2 hours.
Unpack the appliance and check if there are damages
on it. Report possible damages immediately to the
place you bought it. In that case retain packaging.
Cleaning
Remove every adhesive tape, which ensure the parts
not to move in the appliance.
Wash the inside of the appliance using lukewarm
water and mild detergent. Use soft cloth.
After cleaning wipe out the inside of the appliance.
