Zanussi GC 20M Operating and safety instructions

X
ZANUSSI
Instructions
for the use and care
of GC 20 M cooker

Contents
Instructions for the owner
Installation. . . . . . . . ee ee ee . . . . . . Page 3
Technical data . . . . . . . . a . . . ew. Page 3
USO. ue o e mea Es as es A ss: a Page A
Gas ome... Page 6
Using the rotisserie . . . ... . . . a . 4. 2. . . . . . Page 8
Minute minder. . ...... . . . 2. . ew . . . . . Page 8
Cooking procedure. . . . .. . . . . . 2. . « . « . . . Page 9
Maintenance & cleaning . . ...... =... =. . . . . Page 10
Instructions for the installer
Installation... ...... . . . . . . . . . . . .Pagel2
Gas connection. . . . . . . . o... . . . . Page 14
Electrical connection . . . . . . . . . eee . . . o Page 14
Replacing the nozzles. . . . . . . . eee ee Page 15
Adjusting the air . . . . . . . ee ee ee we Page 18
Adjusting the minimum ............ . . . . . Page 18
Maintenance. . .... . . . 2. eee ee . Page 19
Caution:
Before you start operating the appliance, be sure to remove the plastic films protecting
the stainless steel or anodized aluminium parts.
Important: During normal cooking operations the appliance will get very hot.
Therefore, do not let children play near the appliance.

Instructions for the owner
Installation
It is mandatory that all operations required for the installation, the adjustments, the
conversion to the type of gas available etc. be carried out by QUALIFIED PERSONNEL
in accordance with existing rules and regulations.
The relevant instructions are to be found in the special chapter for the installer.
This appliance meets the requirements laid down in EEC Directive No 82/499 dated
7/6/1982 relating to the suppression of radio and TV interference.
Technical data
Model GC 20 M
Dimensions: height 900 mm
depth 598 mm
width 597 mm
Oven volume 53 dm’
Automatic lighting: worktop YES
oven and grill YES
Safety (Thermocouple): oven and grill YES
Roasting jack: multiple rotisserie YES
Oven lamp YES
Mechanical minute minder YES
Supply voltage (240V - 50Hz) YES

Care and use
Cooker
A - Cover G - Side grilles
B - Semi-rapid burner H - Grilles
C - Rapid Burner I - Dripping pan
D - Rapid burner J - Oven door
E - Auxiliary burner K - Removable drawer
F - Control panel L - Removable base
M - Front panel
Ha

Control panel
N - Grill or roasting pan
O - Reversible grill pan insert
P - Removable handles (2 Off.)
1. Minute minder
2. Oven light switch
3. Rotisserie switch
4, Lighting button
5. Oven knob
6. Rapid burner knob
7. Auxiliary burner knob
8. Rapid burner knob
9. Semi-rapid burner knob

Operation
Worktop burners
To light a worktop burner, turn the
relevant knob anticlockwise to maximum
(Fig. 1).
After opening the tap to maximum, push
button marked by a small electric spark.
As soon as the burner is lit, adjust the
flame as required.
To ensure maximum burner efficiency, 1t
is strongly recommended that you use
only pots and pans with a bottom fitting
the size of the burner used, so that the
flame will not spread beyond the bottom
of the vessel.
It is also advisable, as soon as a liquid
starts boiling, to turn down the flame so
that it will barely keep the liquid
simmering.
Important: Be very careful when frying
food in hot oil or fat as the overheated
splashes could easily flare up. |
Gas oven
The oven features an enamelled dripping-
pan to collect the gravy when grilling or
spit-roasting meat, and a shelf to grill food
or to cook it in baking-tin.
Furthermore this oven fits a device which
makes the ignition of the burner easier.
The instructions are the following:
1. Open the oven door.
2. Firmly depress the oven control knob
(fig. 2) and turn it anticlockwise to the
maximum setting and at the same time
operate on the relevant pushbutton
marked by a small electric spark. Keep
the oven control knob depressed for 10-15
secs.
3. Release the control knob and then
gently close the oven door.
To adjust the temperature, after a few
minutes turn the knob to the required
temperature setting.
Fig. 1
Oven temperature chart
Temperatures
"F °C
275 135
300 149
325 163
oe
4 300 177
5 375 191
6 400 204
T 425 218
8 450 232
9 475 246
h 521-396 275-280

Fig. 3
Fig. 4
Gas grill
To light the grill, firmly depress the oven
control knob and turn it clockwise to the
symbol (9 , then operate on the
pushbutton marked by a small spark.
Keep the control knob depressed for 10-15
secs; then release the grill control knob.
Oven safety device
The cooker features a thermocouple; if for
any reason the flame should extinguish
the device will interrupt the gas flow.
Important:
Oven and grill burner lighting is possible
only if the oven door is opened.
Pot safeguard (Fig. 3)
A particular joint system allows to fix the
pot guard in its vertical working position
and in the horizontal (resting) position
as well.
To lift the pot guard: push forwards and
rotate it at the same time.
To lower it: lift upwards and rotate it
reversely.
Oven light switch
This switch will turn on the oven light.
Using the grill
Foods to be grilled are to be placed on the
wire grid in the grill pan which can be
curved either upwards or downwards to
give the required distance from the
burner.
The pan is then placed in the required
runner position.
Important: Because the grill is in the top
of the oven, the door must be left ajar
when grilling. This means that the
escaping heat from the grill could
overheat the control panel, so to prevent
this happening it is essential that the

heat deflector provided to protect the
appliance is in place before the grill is
turned on.
The deflector is put in place as shown in
Fig. 4.
Using the rotisserie
The rotisserie can be used for either spit
roasting meat or for kebabs and smaller
pieces of meat. The accessories for either
are provided.
If you want to spit roast a large piece of
meat or poultry proceed as follows:
Firstly place one of the two prong forks
onto the spit and lock it into position with
the thumb nut. Then skewer the meat or
poultry onto the spit and secure onto the
fork.
Place the second fork onto the spit and
skewer it into the meat then lock it in
position with the thumb nut.
Place the spit onto the support frame and
ensure it turns freely and evenly.
If it does not, reposition the meat until it
does otherwise excessive wear to the
motor will result.
Place the frame and spit into the oven so
the spit engages fully into the motor in
the back of the oven and depress the
rotisserie switch.
Should you wish to use the kebab
attachments then proceed as follows:
Firstly place one of the support discs with
4 elongated slots in it onto the spit and
secure it by locking the thumb nut about
1% inches from the handle of the spit.
Next place the disc with the 8 holes onto
the spit and secure it in position with the
thumb nut. The position of this disc can
be decided by judging the distance
required against the length of the
individual kebab skewers.
Next place the third disc on the skewer
positioning it at an equal distance from
the centre disc as the first one.
Lock it in position with the thumb nut.
Prepare the 8 individual kebab skewers
and putting the pointed end through one
of the holes on the centre disc.
Lock it in position by placing the other
end in an elongated slot in one of the
outer discs and turning it.
Repeat this operation for each of the 8
skewers.
Place the spit onto the frame and ckeck
that it turns freely and evenly.
If it does not, reposition the weight of the
food until it does.
If this is not done excessive wear to the
motor will result.
Place the frame and spit into the oven so
that the spit engages fully into the motor
in the back of the oven.
Place a drip pan on a lower support.
Secure the heat deflector into its position,
close the oven door to the ajar position
and depress the rotisserie switch.
Mechanical minute minder (Fig. 5)
The minute minder can be set for any
time interval up to one hour.
The control knob should first be turned
clockwise to 60 minutes and then
reversed to the required time interval.
When cooking time is up the alarm clock
rings and then stops by itself.
However, the alarm clock will not turn off
the oven when it rings.

Hints for a correct use
of the oven and the
grill
After turning on the oven and prior to
introducing the food, it is advisable to
wait for about 10 to 15 minutes to allow
the oven to reach the required temperature.
In the case of dishes requiring a high
initial temperature or a stabilized
temperature at the centre of the oven, the
above preheating time will have to be
increased.
The food to be cooked should be placed on
the oven shelf, dripping-pan (roast meat)
or in a baking-tin placed on the shelf. To
obtain a uniform cooking, it is advisable to
use the oven lower or middle runner.
Experience will tell which is the most
suitable position in each case depending
on the cooking requirements.
The oven wire grid can be curved either
upwards or downwards to give the
required distance from the burner.
Whipped up kneadings have the required
firmness when they tend to stick to the
spoon as, otherwise, an excessive fluidity
would uselessly stretch the cooking time.
Shortbread kneadings should first be
baked in the mould on the baking-tin for
about two-thirds of the total baking time,
and then be garnished (trimmed) before
you complete the baking.
This final baking time depends on the
type and quantity of the garniture
(trimmings). Gourmets greatly appreciate
grilled food as it usually remains very
tender and savoury. All meats are suitable
for grilling, with the exception of some
lean game meats and meat-loaves.
The meat must be thoroughly drained, i.e.
kept until it becomes high (tender).
The pieces of meat to be cooked should
not weigh less than 1 Kg. boneless.
If bones are removed beforehand, this will
shorten the cooking time and it will be
easier to cut the meat. Meat needs to be
turned over only if cooking is done at
higher temperatures.
Ingredients for the gravy should be placed
in the baking-tin straightaway if cooking
is to be short. If cooking is to last long,
instead, these ingredients are to be added
during the last half-hour.
To find out if the meat is done, press it
down with a spoon.
If it is well done the meat should not give
in (yield). When the meat is done to a turn,
the gravy is grayish in colour. Cooking
time for roast-beef and fillet, the inside of
which should remain of a pink colour, is
reduced.
Wait for at least 15 minutes before
cutting the meat, so that the dish gravy
(meat juice) may settle down instead of
dripping out profusely.
The dish can be kept warm in the oven
with the burner turned off.

Maintenance
For a long service life of the appliance we
strongly recommend that you frequently
carry out a thorough cleaning operation.
Cleaning the oven
Always wait until the oven is cool before
cleaning.
All enamelled parts should be washed
with lukewarm water and detergent
without using abrasive products which
might damage them.
The oven should be cleaned inside with
the greatest care, after each use, with hot
water and detergent (or one of the special
products available on the market).
When cleaning the oven, be careful to
protect the aluminium parts of the control
panel from chemical compounds contained
in the products used to clean the
enamelled parts.
Removing the panels
Unscrew the ring nuts securing the side
grilles (Fig. 6), remove the grilles and then
remove the side panels (Fig. 7).
Cleaning the worktop
Burner caps should be frequently washed
in hot water and detergent, being careful
to remove all incrustations.
Thoroughly clean the terminal part of the
automatic lighting device, to prevent
a difficult lighting and, furthermore,
make sure that the flame spreader gas
openings are unobstructed.
Stainless steel parts should be carefully
rinsed with water, after each use, and
then dried with a clean soft cloth or with
a buckskin.
10
Fig. 7

In the case of persistent spots you may
use normal non-abrasive detergents,
currently available on the market, or some
hot vinegar.
Never use steel-wool pads, chlorine or
similar products which might scratch,
grind or etch the metal.
Also, never close the cover while the
burners are still warm.
Replacing the oven lightbulb
Disconnect the appliance from the electric
supply.
Unscrew the lightbulb glass protection
from the oven. Unscrew the lightbulb and
replace it with a new bulb suitable for
high temperature (300 °C) and having the
following technical features:
Operating voltage: 240V - 50 Hz
Power absorbed: 15 W
Removing the oven door
(Fig. 8 A-B)
To thoroughly clean the oven you should
remove the door by proceeding as follows:
1.
With the aid of a coin, turn the oven door
stops (catches) 45° to the right.
See drawing A.
2.
Raise the door to the limit stop, press it
lightly against the oven and pull it out in a
forward direction.
Grasp the door on the two sides- don’t pull
it by the handle. See drawing B.
11

Instructions for the installer
Installation
The following instructions are meant for a
qualified installer and should assist him
in carrying out all installation, adjustment
and maintenance operations in the most
correct way and in accordance with
existing laws and regulations.
Important:
Before servicing the appliance or
undertaking any maintenance work on it,
be sure to disconnect it from the electric
supply. Should it be absolutely necessary
to keep the appliance ‘live’ take all
possible precautions to prevent accidents.
Positioning
To ensure a troublefree operation of the
appliance, it is a must that it be set up
in a well ventilated kitchen (in this
connection, the installer needs only
comply with existing rules and
regulations).
The cooker may be positioned in such a A0059
way as to come into touch with the sides Fig. 9
of the kitchen furniture. However, the
latter must be able to withstand a
temperature increase of 60 °C.
The appliance incorporates a removable
base (A - Fig. 9-10) which permits the
alignment with kitchen furniture having a
height of 85 cms, plus levelling feet
(B - Fig. 9).
To remove the metal base rest the
appliance on a side, slide out the front
plastic panel (C - Fig. 9) which is push-
fitted and then unscrew the six screws
(D - Fig. 9) that secure the base to the
cabinet.
Remove the levelling feet from the base
(B - Fig. 9-10), serew them onto the cabinet
and then fit the new front panel (optional)
o - Fig. 10).

Fig. 13
Position the appliance.
The appliance incorporates a set of
adjustable feet.
By properly adjusting the feet, the
appliance can be set up at the required
height and correctly aligned with the
kitchen furniture or any other surface,
thus ensuring an even spreading out of
liquids in pans and pots.
These adjustable feet are easily accessible
after removing the dish-warming drawer.
To remove this drawer, proceed as follows:
pull out the drawer to the limit stop in
order to slide out completely the side
runners;
shift the front rollers up to the
”buttonholes” of the side runners;
lift up the drawer and slide out the front
rollers;
pull out the drawer and shift the rear rollers
up to the “buttonholes” of the side runners;
lift up the drawer and slide out the rear
rollers;
To replace the drawer, reverse the above
procedure.
Alignment of the worktop
To allow the alignment with the kitchen
unit, the worktop frames are removable:
Remove the two screws (A - Fig. 11) fixing
the gasket (E - Fig. 11) placed on the back
of the worktop and then slide out the
gasket;
Remove the two cover shock absorbers
(B - Fig. 12);
Loosen the four screws (C - Fig. 12) fixing
the side frames (D - Fig. 12) to the
worktop;
Slide forward the two side frames
(D - Fig. 12);
Block the side frames (D - Fig. 12) by means
of the four screws (C - Fig. 12) to the
worktop;
Refit the cover shock absorbers (B - Fig. 12);
Fit the gasket (E - Fig. 13) on the front
side of the worktop and fix it by means
of the two screws (A - Fig. 13).
13

Gas connection
Connect the cooker to the gas bottle or
gas mains, in accordance with existing
rules and regulations, only after making
sure that the appliance has been duly
adapted to the type of gas available.
Otherwise, carry out all operations
according to the directions to be found
under the paragraph “Conversion to other
types of gas”.
Important: To ensure a safe operation, a
lower consumption and a longer service
life of the appliance, make sure that the
feed pressure is in accordance with the
specifications given in the “burner and
nozzle features” chart.
Stiff connection
In case of connection to the gas mains by
means of a metal pipe & fittings, make
sure that this does not put any strain on
the appliance.
The cooker has a Y,” threaded gas inlet.
14
Electrical connection
The appliance features a three-pole
electric supply cable, having a plug with
fuse, and is designed to operate on
alternating current, with a single phase
voltage of 240 V - 50 Hz.
The ground wire is green & yellow
coloured.
The oven features an easily accessible
terminal board with the following
markings:
L = Live
N = Neutral -| = Farth
Connecting the supply cable to
the mains
Insert the plug into a standard wall socket
suitable for the load shown on the rating
plate.
If you require a direct connection to the
electric network (mains), it will be
necessary to fit between the cooker and
the mains on omnipole switch, with a
minimum aperture between contacts of
3 mm, suitable to carry the required load
and conforming to the ruling
specifications.
The green & yellow ground wire must not
be interrupted by the switch.
The supply cable must at any rate be
placed in such a way as to ensure that it
does not reach at any given point a
temperature 50 °C higher than the
ambient temperature.
Prior to connecting the cooker to the
electricity supply make sure that:
the protection fuse and the domestic
wiring are suitable to carry the total
electric load of the cooker (see rating
plate):

the electricity supply network (mains) has
an efficient earth connection according to
the established rules and existing
regulations;
with the cooker definitely installed, the
wall socket or the omnipole switch can
easily be reached.
The Manufacturer disclaims any liability
in case these accident-preventing rules
are not observed.
The heat insulation of the oven and grease
residues from the manufacturing process
produce smoke and an unpleasant smell
during the first minutes of operation.
It is therefore advisable, the first time
the appliance is used, to pre-heat the oven
for about 30 mins. at peak temperature
without putting any food into it.
Conversion to
other types of gas
Attention: The cooker is adjusted for
NATURAL GAS (METHANE).
To adapt the cooker to a type of gas
different from the one for which it is
adjusted, perform the following
operations in the order.
Replacing the nozzles (see chart)
Remove the pot-rests and the burners;
undo the screws securing the worktop,
lift it up (to keep it raised, use the
special supporting rod located on the
mounting of the left-hand burners),
unscrew the nozzles and replace them
with the corresponding nozzles (supplied
with the cooker) suitable for the new type
of gas.
Refit the parts reversing the above
procedure.
15

Burner and Nozzle Features Chart
| Burner Nominal Liquid gas Natural gas
| Power (Methane)
| kC kW | Nozzle! g/h | Nozzle 1/h 15 °C
mal (dia. 35 mm) 700 0,8 47 59 65 7T
| Medium (dia. 50 mm) 1400 1,6 63 118 86 155
Big (dia. 75 mm) 2600 3,0 85 219 117 288
Oven 2600 3,0 85 219 125 288
| Grill 2500 2,9 85 211 125 277
| | nom. (mbar)' 28 20
| Feed Pressure min. (mbar)* 20 18
| max. (mbar)* 35 25
* 1 mbar = 10 mm water column
Taps
Tap colour
Small 30 Red
Yellow
Black
Dia. Tap By-Pass
Oven Thermostat
Liquid gas
0,47
By-pass Pin
16

Oven burner
Undo the securing screw and remove the
oven bottom; from inside the dish-
warming drawer unscrew the wing nut
securing the bracket carrying the spark
plug and the thermocouple as well as the
one to be found in the front part of the
burner; then push the burner itself
forwards. Unscrew the nozzle and replace
it with the corresponding new nozzle.
Refit the parts reversing the above
procedure.
Grill burner
Unscrew the two screws locking the burner
to the bracket (Fig. 14), then remove the
burner by lowering it and pulling it
forward.
Unscrew the nozzle and replace it with
the corresponding new nozzle.
Refit the burner reversing the above
procedure.
Oven thermostat
Remove the control knob and replace the
by-pass pin fitted on the top of the knob
shaft with the corresponding one suitable
for the new type of gas.
17

Adjustments
Adjusting the primary air
Light the burners and check the flame. If
the primary air needs to be adjusted, set
the sliding sheet-iron ring to be found at
the entrance of the burner's Venturi tube.
By adjusting this ring it is possible to
obtain a steady flame with a correct air-
gas mixture (see Fig. 15 a/b/c).
Adjusting the minimum flame
setting
Worktop burners
Turn the gas tap to minimum, remove the
control knob and with a screwdriver turn
the adjusting screw, which is inside the
gas tap shaft, until a small and steady
flame is obtained. Check stability of flame
by quickly turning the tap from max. to
min., re-adjusting the flame if necessary.
Attention: If the cooker is adjusted for
Methane gas, to convert it to Liquid gas
it will suffice to screw completely in the
minimum adjustment screw, after
changing the main jets.
Oven burner
After keeping the oven in operation for
about 10 minutes on the max. setting
with the oven door closed, turn the
thermostat to position 1, remove the
control knob and then adjust the screw
on top of the control knob shaft until a
steady flame of the right size is obtained.
18
Too much air
Too little air
Correct flame

Maintenance
Check at regular intervals the condition
and serviceability of the gas connection
hose and pressure regulator, if any; in case
of malfunction, do not repair but replace
the whole faulty part.
To ensure a smooth and safe operation, it
is necessary to periodically grease the gas
taps.
Servicing should be carried out as follows:
remove the knobs and slide out the front
panel after removing the securing screws.
Unscrew the two screws to be found
next to the gas tap shaft.
Slide out the cone and clean it thoroughly;
finally, apply a thin layer of grease of a
type non-soluble to hydrocarbons and
suitable for gas taps.
Make sure that no excess grease obstructs
the gas tap holes.
Refit everything very carefully reversing
the above procedure.

APPLIANCE
GUARANTEE
ZANUSSI STANDARD GUARANTEE CONDITIONS
This guarantee is in addition to your statutory and other legal rights which will not be
excluded or in any way diminished by the return of the guarantee card.
We, IAZ International (UK) Ltd, undertake that if, within twelve months (24 months for
TV sets) of the date of the purchase, this ZANUSSI appliance or any part thereof is proved to
be defective by reason only of faulty workmanship or materials, we will, at our option, repair
o replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition
that:
—The appliance has been correctly installed and used only on the electricity supply stated
on the rating plate.
—The appliance has been used for normal domestic purposes only, and in accordance with
the manufacturer's operating and maintenance instructions.
—The appliance has not been serviced, maintained, repaired, taken apart or tampered
with by any person not authorised by us.
—The appliance i is still in the possession of the original purchaser.
All service work under this guarantee must be undertaken bya enue: Network Service
Centre (or the Zanussi Authorised TV Service Dealer).
Any appliance or defective part replaced shall become our property.
Exclusions
This guarantee does not cover:
—Damage or calls resulting from transportation, improper use or neglect, the
replacement of any light bulbs or removable parts of glass or plastic. _
—Costs incurred for calls to put right machines improperly installed or calls to machines
outside the UK and the Republic of Ireland.
—Appliances found to be in use within a commercial environment, plus those which are
the subject or rental agreements.
—Television receivers - routine adjustment, or poor reception resulting from a source
outside of the receiver.
ZANUSSI 5 YEAR COVER CONDITIONS
For a once-only payment you can extend your Standard Guarantee to 5 years. All the
conditions and exclusions of the Standard Guarantee apply.
Notes
1. Products supplied as “seconds”, refurbished, damaged or shop-soiled are not eligible for
Zanussi 5 year cover.
2. The issue of a cover does NOT by virtue of our having done so, nullify the exclusions.
3. The Engineer will need to check the details of your Cover card and may make a charge for
his services if it is not presented to him at the time of his call.
4. The date of purchase, or the date of initial payment (deposit) of the appliance will be
deemed the date of commencement of cover.
5. Covers issued are not refundable or transferable.
ZANUSSI
The appliance of science
R1079
