Zanussi DTI 6726 User manual

LAVAVAJILLAS
DISHWASHER
MAQUINA DE
LAVAR LOIÇA
DTI 6726
MANUAL DE INSTRUCCIONES
INSTRUCTION BOOKLET
INSTRUÇÕES DE UTILIZAÇÃO
152991 25/1
es
en
pt

The appliance which you have just bought is supplied not only with this instruction manual, but also with
a Warranty Card Certificate, on the back of which are written the relative conditions.
Please fill in the necessary details on the Card Certificate and send it to the Zanussi Centre relative to
the area in which the appliance is to be installed, within twenty days of the date of purchase. (See list of
Zanussi network centres).
We congratulate you on your choice. Carefully read this instruction manual and follow attentively the
recommendations it provides, and thus benefit from years of excellent service.
The appliance which you have just purchased has been very accurately controlled throughout the entire
manufacturing process. Nevertheless, should any problem arise during usage, whether it be during the
warranty period, or when such period has expired, please directly contact your nearest Zanussi
Service Centre.
The address and telephone number of said Centre can be easily found in the enclosed List or by
looking in the telephone directory, under Zanussi.
Our Zanussi Service Network is at your complete disposal, to serve you with maximum speed and
efficiency, all you have to do is call.
Attention
25 PGU01GB
The products
In order to obtain a good wash, it is necessary to use detergents specially designed for dishwashers.
To ensure that your dishwasher functions perfectly, Zanussi recommends using Calgonit System, a
unique and complete product, tested by millions of householders.
Calgonit System includes Calgonit detergent, rinse aid, salt, machine detergent and Citro-Fresh.
It is able to fulfil the main requirements for clearing both the crockery and the machine itself.

For the user
Important safety information 27
Description of the appliance 28
The control panel 29
Before use 30
Setting the water softener 30
Rinse aid 32
Use of detergent 33
Using your appliance 34
Loading your appliance 34
Adjusting the height of the upper basket 35
Hints and tips 36
Washing programmes 37
Operating sequence 38
Maintenance and cleaning 39
Internal cleaning 39
Cleaning the central filter 39
Cleaning the large filter 39
External cleaning 40
Prolonged periods of non-operation 40
Frost precautions 40
Moving the machine 40
Something not working 41
Service and spare parts 42
For the installer
Installation instruction 43
Technical specifications 43
Building-in features 43
Fitting under a counter 44
Water supply connections 44
Water outlet connection 45
Electrical connection 45
Building-in 46
The furniture door 46
Mounting the furniture door
onto the panel 46
Fixing to the adjacent units 47
Kitchen plinth adjustment 47
Contents
26 PCO04/1GB
Guide to use the instrucion book
The following symbols will be found in the text to guide you throughout the instructions:
Safety instructions
1. 2. 3. Step by step instructions
Hints and tips

Description of the appliance
27 PDA18GB
2
3
4
5
6
8
9
10
11
12
IN85
13
1
7
1. Water hardness adjustment
2. Levelling spacers
3. Upper basket stop
4. Salt container
5. Lower spray arm
6. Detergent dispenser
7. Control panel
8. Rating plate
9. Rinse aid dispenser
10.Large filter
11. Central filter
12. Upper spray arm
13. Upper basket

In this fully integrated appliance the controls are
located on the top of the door. When selecting a
programme, the door needs to be partially opened.
1. On/Off pushbutton
Depress this button to switch the dishwasher on.
Depress again this button to switch the appliance
off.
2. Economy 55°C button
By depressing this button you will reduce the
temperature of the main wash from 65°C to 55°C,
with considerable energy saving (see “Washing
programmes” chart).
3. Programme guide
This is a summary of the “Washing programmes”
chart which will help you select the correct
programme.
4. Programme marker
Depress the button corresponding to the
desired washing programme (see “Washing
programme” chart).
5. Programme selector dial
To select a programme, turn the programme
selector dial clockwise, making sure that the
programme letter you wish to select
corresponds with the programme marker on the
control panel.
At the end of the programme the machine will
stop automatically.
The control panel
28 PCP06/1GB
1 2 3 4 5

Before using your dishwasher for the first time:
1. ensure that the electrical and water
connections comply with the installation
instructions
2. remove all packaging from inside the appliance
3. set the water softener
4. pour 1 litre of water inside the salt container and
then fill with salt
5. fill the rinse aid dispenser.
Setting the water softener
The dishwasher is equipped with a water softener
designed to remove minerals and salts from the
water supply, which would have a detrimental or
adverse effect on the operation of the appliance.
The higher the content of these salts, the harder
your water is.
Water hardness is measured in equivalent scales,
for example German, French degrees, and parts
per million.
The softener should be adjusted according to the
hardness of the water in your area. Your local
Water Authority can advise you on the hardness of
the water in your area.
The dishwasher is factory set at level 2.
If this level is not suitable for your area the softener
should be adjusted.
To adjust the water softener:
With a screwdriver turn the selector on the upper
front corner of the machine until the level required
corresponds with the marker.
Before use
29 PBU01/2GB
2
AA05
1
3
5
4
2
Level Use of
salt
French
degrees
(°TH)
PPM
(Parts per
million)
German
degrees
(°dH) *
1
2
3
4
5
0-4
5-11
12-22
23-34
35-50
51-67
NO
SI
SI
SI
SI
SI
0-7
8-20
21-40
41-60
61-90
91-120
0-80
81-200
201-400
401-600
601-900
901-1200
Water hardness
*If your water hardness is below level 1 it
is already soft and therefore there is no
need to use salt.
In this case adjust the water softener on
level 1 without using salt.

Filling with salt
Only use salt specifically designed for use
in dishwashers.
All other types of salt not specifically
designed for use in dishwasher, specially
table salt, will damage the water softener.
Only fill with salt just before starting one
of the complete washing programmes (not
the Rinse and Hold programme). This will
prevent any grains of salt or salty water,
which may have been spilled, remaining
on the bottom of the machine for any
period of time, which may cause
corrosion.
To fill:
1. To fill with salt, unscrew the cap of the salt
container.
2. Pour 1 litre of water inside the container,
(this is necessary only before filling with
salt for the first time).
3. Then using the funnel provided, pour in the salt
until the container is full.
Do not worry if water over flows from the unit
when filling with salt, this is quite normal.
4. Replace the cap making sure that there is no
trace of salt on the screw thread or on the
gasket.
5. Screw on the cap tightly.
The salt container will require topping up
periodically.
The salt cap has a refill indicator window in the
centre.
Agreen floater is clearly visible when there is salt
inside the container, and almost disappears when
the salt has finished, reminding you to add salt.
30 PFS01/1GB
SALE
SALT
SALZ
SEL
SR06
SR11

Rinse aid
Rinse aid is automatically added during the last
rinse, ensuring through rinsing, spot and streak
free drying. The dispenser, which is positioned
inside the door, holds about 110 ml of rinse aid,
which is sufficient for 16 - 40 dishwashing
programmes, depending upon the dosage setting.
Filling with rinse aid
1. Open the container by turning the lid (A)
anticlockwise.
2. Add the rinse aid until the container is
completely full. The indicator (B) will be
completely dark.
3. Top up the rinse aid when the indicator (B)
becomes clear.
Ensure that the lid is closed after every refill.
Do not put liquid detergent in the rinse aid
department. Clean up any rinse aid spilt during
filling with an absorbent cloth to avoid excess
foaming during the next wash.
Adjusting the dose
According to the finish and drying results obtained,
adjust the dose of rinse aid by means of the 6
position selector (C) (position 1 minimum dosage,
position 6 maximum dosage).
Start from position 3.
Gradually increase the dose if there are drops of
water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish streaks on the
dishes.
31 PFR01/1GB
BR01
A
m
a
x
6
5
4
3
2
1
B
BR03
BR02
C
m
a
x
6
5
4
3
2
1

Use of detergent
Only use detergents specifically designed
for use in dishwashers.
To fill the dishwasher with detergent proceed
as follows:
1. Open the dispenser lid by pulling the catch (D).
2. Add the detergent according to the
recommendations in the programme chart. As
all detergents are not the same, you should
also consult the instructions on the packet
specially for tablets.
To help correctly dose the right amount of
detergent, inside the container there are two
reference marks:
- MIN = 15 g
- MAX = 30 g
3. Always close the lid.
4. If the programme has a prewash add the
required detergent over the lid of the
dispenser.
If using detegent in tablets proceed as follows:
1. For all programmes; add 1 tablet inside the
detergent dispenser.
2. Always close the dispenser lid.
3. For all programmes with prewash; add a portion
of a further tablet on the lid of the detergent
dispenser.
Insufficient quantities of detergent will produce
poor washing results, whereas an excessive
amounts of detergent will not improve washing
results and is also wasteful. Using no more than
the correct amount also contributes to reducing
pollution.
Phosphate free detergents with enzymes
In these low-alkaline compact powders the
environment unfriendly components have been
replaced by natural enzymes and other more
biodegradable substances.
These new compact powders are generally
phosphate-free.
As phosphates have water softening properties, we
suggest you add salt to the salt container even if
the hardness of your water is as low as 4°dH (7°TH).
This will avoid lime deposits on crockery and the
inner tub.
32 PUD01/1GB
D
MIN
MAX
DE07
DE02

Loading your appliance
Before placing dishes in the machine, remove any
scraps of food, to avoid clogging the filters and
consequently reducing the performance.
Do not load very small items which can
fall through the baskets.
Open the door and slide out the baskets to load the
dishes.
The lower basket
The lower basket is designed to take saucepans,
lids, plates (up to 27cm in diameter), salad bowls,
cutlery etc.
Serving dishes and large lids should be arranged
around the edge of the basket, ensuring that the
upper spray arm can turn freely.
The cutlery basket
Long bladed knives stored in an upright
position are a potential hazard.
Long and/or sharp items of cutlery such
as carvings knives must be positioned
horizontally in the upper basket.
Take care when loading or unloading
sharp items such as knives.
Cutlery should be placed in the removable cutlery
basket with the handles facing downwards. If the
handles protrude from the bottom of the basket,
obstructing the lower spray arm, load the cutlery
with the handles facing upwards.
Mix spoons with other cutlery to prevent them from
sticking together.
Teaspoons may be loaded into the special slots
provided in the cutlery basket handle.
The cutlery basket is in two parts which can be
separated to give greater loading flexibility. To
separate the two parts, slide them horizontally in
opposite directions and pull them apart. To
reassemble, reverse the procedure.
Using your appliance
33 PBA07/1GB
UI39 IEC 436 / DIN 44990
UI21
UI07
