Zanussi ZDC82B4PW User manual

GETTING
STARTED?
EASY.
User Manual
ZDC82B4PW
EN User Manual
Tumble Dryer

VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair information:
www.zanussi.com/support
SAFETY INFORMATION
Before beginning the installation and use of this appliance,
carefully read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result of
incorrect installation or usage. Always keep the instructions in a
safe and accessible location for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons with very
extensive and complex disabilities shall be kept away from the
appliance unless continuously supervised.
•Children of less than 3 years of age should be kept away from
the appliance unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when the door
is open.
•If the appliance has a child safety device, it should be activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
GENERAL SAFETY
•Do not change the specification of this appliance.
2

•If the tumble dryer is put on top of a washing machine, use the
stacking kit. The stacking kit, available from your authorized
vendor, can be used only with the appliance specified in the
instructions supplied with the accessory. Read it carefully
before installation (refer to the Installation leaflet).
•The appliance can be installed as freestanding or below a
kitchen counter with correct space (refer to the Installation
leaflet).
•Do not install the appliance behind a lockable door, a sliding
door or a door with a hinge on the opposite side, that would
prevent the appliance door from being fully open.
•The ventilation opening in the base must not be covered by a
carpet, mat, or any floor covering.
•WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by a utility.
•Connect the mains plug to the mains socket only at the end of
the installation process. Make sure that the mains plug is
accessible after installation.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre or
similarly qualified persons to avoid an electrical hazard.
•Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
•Do not use the appliance if items have been soiled with
industrial chemicals.
•Wipe away lint or packaging debris that has accumulated
around the appliance.
•Do not run the appliance without a filter. Clean the lint filter
before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot
water with an extra amount of detergent before being dried in
the tumble dryer.
3

•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the
tumble dryer.
•Fabric softeners, or similar products, should only be used as
specified by the product manufacturer’s instructions.
•Remove all objects from items that could be a source of fire
ignition such as lighters or matches.
•WARNING: Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
SAFETY INSTRUCTIONS
INSTALLATION
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with
the appliance.
• Always take care when moving the appliance as
it is heavy. Always use safety gloves and
enclosed footwear.
• Do not install or use the appliance where the
temperature can be lower than 5°C or higher
than 35°C.
• The floor area on which the appliance is to be
installed must be flat, stable, heat resistant and
clean.
• Make sure that there is air circulation between
the appliance and the floor.
• Always keep the appliance vertical when it is
being moved.
• The rear surface of the appliance must be put
against a wall.
• When the appliance is in its permanent position,
check if it is levelled correctly with the aid of a
spirit level. If it is not, adjust the feet accordingly.
ELECTRICAL CONNECTION
WARNING! Risk of fire and electric
shock.
• WARNING: This appliance is designed to be
installed / connected to a grounding connection
in the building.
• Make sure that the parameters on the rating
plate are compatible with the electrical ratings
of the mains power supply.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and extension
cables.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains plug
with wet hands.
USE
WARNING! Risk of injury, electric
shock, fire, burns or damage to the
appliance.
• This appliance is for household (indoors) use
only.
• Do not dry damaged (torn, frayed) items that
contain padding or fillings.
• If laundry has been washed with a stain remover,
carry out an additional rinse cycle before
starting a drying cycle.
• Dry only fabrics that are suitable to dry in the
appliance. Follow the cleaning instruction on the
item label.
• Do not drink or prepare food with the
condensed water/distilled water. It can cause
health problems to people and pets.
• Do not sit or stand on the open door of the
appliance.
4

• Do not dry dripping wet clothes in the
appliance.
CARE AND CLEANING
WARNING! Risk of injury or damage
to the appliance.
• Do not use water spray and steam to clean the
appliance.
• Clean the appliance with a moist soft cloth. Use
only neutral detergents. Do not use abrasive
products, abrasive cleaning pads, solvents or
metal objects.
SERVICE
• To repair the appliance contact the Authorised
Service Centre.
• Use original spare parts only.
• Concerning the lamp(s) inside this product and
spare part lamps sold separately: These lamps
are intended to withstand extreme physical
conditions in household appliances, such as
temperature, vibration, humidity, or are intended
to signal information about the operational
status of the appliance. They are not intended to
be used in other applications and are not
suitable for household room illumination.
DISPOSAL
WARNING! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to the
appliance and dispose of it.
• Remove the door catch to prevent children or
pets from becoming trapped in the drum.
• Dispose of the appliance in accordance with
local requirements for the disposal of Waste
Electrical and Electronic Equipment (WEEE).
5

EASY START
PRODUCT DESCRIPTION
1 2
5
3
4
7
10
9
8
11
6
1Water container
2Control panel
3Appliance door
4Primary Filter
5Airflow slots
6Adjustable feet
7Condenser door
8Button for condenser door
9Condenser cover
10 Locks for condenser lid
11 Rating plate
For ease of loading laundry or ease of
installation the door is reversible. (see
separate leaflet).
CONTROL PANEL
1
89
4
7
6
5
3
2
1Programme knob and OFF switch
2Indicators
3Display
4Time Dry touchpad
5Delay Start touchpad
6Delicate touchpad
7Long Anticrease touchpad
8Start/Pause touchpad
6

9On/Off button Press the touch buttons with your
finger in the area with the symbol or
name of the option. Do not wear
gloves when you operate the control
panel. Make sure that the control panel
is always clean and dry.
Indicators
Indicators Description
Drying phase
Cooling phase
Crease guard phase
Condenser
Water container
Filter
Delay start
Child lock
Acoustic signals
Programme duration
- Time Drying duration
- Delay start duration
PROGRAMME TABLE
Programme Load 1) Properties / Fabric type2)
3) Cotton Eco 8 kg
Cycle to be used to dry cotton with
"cotton cupboard" dryness level, with
maximum energy saving. /
Cotton
Extra Dry 8 kg Drying level: extra dry. /
Cotton
Cupboard Dry 8 kg Cycle defined to dry all types of cot- ton ready to store (cupboard dry). /
7

Programme Load 1) Properties / Fabric type2)
Cotton
Iron Dry 8 kg Drying level: suitable for ironing. /
Synthetics
Extra Dry 3,5 kg Drying level: extra dry. /
Synthetics
Cupboard Dry 3,5 kg Drying level: cupboard dry. /
Delicates 4 kg Delicate fabrics such as viscose, ray-
on, acrylic, and their blends. /
Time Dry 5 kg
With this programme you can use the
Time Dry option and set the pro-
gramme duration.
Drying time should be adequate to the
load, e.g. 2h for 5 kg of cotton.
/
Refresh 1 kg Refreshing textiles that were in storage.
Easy Iron 1 kg (or 5
shirts)
Easy care fabrics for which a minimum
of ironing is necessary. The drying re-
sults can be different from one type of
fabric to another. Shake the items be-
fore putting them in the appliance.
When the programme has ended, im-
mediately remove the items and put
them on a hanger.
/
Sportwear 2 kg Sportswear, thin and light fabrics, mi-
crofiber, polyester. /
Denim 8 kg
Leisure clothing such as jeans, sweat-
shirts of different material thicknesses
(e.g. at the neck, cuffs and seams). /
Bedlinen 3kg Bed linen such as single and double
sheets, pillowcases, duvet cover. /
Mix EasyDry 3kg
Cotton and synthetic fabrics. Low
temperature programme. Delicate pro-
gramme with warm air. /
1) The maximum weight refers to dry items.
2) For fabric mark meaning see chapter HINTS AND TIPS: Preparing the laundry.
3) The Cotton Cupboard Dry ECO programme is the “Standard cotton programme” according to
UK Ecodesign and Energy Labelling Regulations. It is suitable for drying normal wet cotton laundry and it is
the most efficient programme in terms of energy consumption for drying wet cotton laundry.
OPTIONS
TIME DRY
This option is applicable only to the Time Dry
programme. You can set the programme duration,
from a minimum of 10 minutes to a maximum of 2
hours. The setting of the duration is related to the
quantity of laundry in the appliance.
8

We recommend that you set a short
duration for small quantities of laundry
or for only one item.
LONG ANTICREASE
Extends up to 90 minutes the anticrease phase (30
minutes) at the end of the drying cycle. After drying
phase drum rotates time to time what prevents the
clothes from creases. Laundry can be removed
during the anti-crease phase.
DELICATE
With this option you can set a delicate drying
programme that has a low temperature. Use this
option with a fabrics that have the symbol on
the fabric label (e.g. acrylic, viscose).
OPTIONS TABLE
Programmes1) Long Anticrease Time Dry Delicate
Cotton Eco ■
Cotton
Extra Dry ■■
Cotton
Cupboard Dry ■■
Cotton
Iron Dry ■■
Synthetics
Extra Dry ■■
Synthetics
Cupboard Dry ■■
Delicates ■■
Time Dry ■ ■ ■
Refresh ■
Easy Iron ■■
Sportwear ■
Denim ■■
Bedlinen ■
Mix EasyDry ■
1) Together with the programme you can set 1 or more options. To activate or deactivate them, press the
related touch button.
9

SETTINGS
A
D
B
C
E
A. Time Dry touchpad
B. Delay Start touchpad
C. Delicate touchpad
D. Long Anticrease touchpad
E. Start/Pause touchpad
CHILD LOCK FUNCTION
This option prevents children to play with the
appliance while a programme operates. The
programme knob and the touchpads are locked.
Only the on/off button is unlocked.
Activating the child lock option:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold touchpads (A) and (D) at the
same time. The child lock indicator comes on.
The child lock indicator comes on.
It is possible to deactivate the child
lock option while a programme
operates. Press and hold the same
touchpads until the child lock indicator
goes off.
ADJUSTMENT OF THE REMAINING
LAUNDRY MOISTURE DEGREE
To change the default degree of the remaining
moisture of the laundry:
1. Press the on/off button to activate the
appliance.
2. Wait approximately 8 seconds.
3. Press and hold buttons (A) and (B) at the same
time.
One of the these indicators comes on:
• the maximum dry laundry
• the more dry laundry
• the standard dry laundry
4. Press the button (E) again and again until the
indicator of the correct level comes on.
5. To confirm the adjustment, press and hold
buttons (A) and (B) at the same time for
approximately 2 seconds.
BUZZER ON/OFF
To deactivate or activate the acoustic signals, press
and hold for approximately 2 seconds touch
buttons (B) and (C) at the same time.
BEFORE FIRST USE
Rear drum locks are removed
automatically when dryer is activated
for the first time. Possible to hear
some noise.
To unlock the rear drum locks:
1. Switch on the appliance.
2. Set any programme.
3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks are
automatically deactivated.
Before you use the appliance to dry items:
• Clean the tumble dryer drum with a moist cloth.
• Start a 1 hour programme with moist laundry.
UNUSUAL SMELL
The appliance is tightly packed.
After product unpacking you can feel an unusual
smell. This is normal for brand new products.
Appliance is built of several different types of
material which all together can generate unusual
smell.
Over usage time, after few drying cycles unusual
smell gradually disappears.
10

NOISES
Different noises may be heard at
different times during the drying cycle.
They are perfectly normal operating
sounds.
Rotating drum.
Working fans.
Working pump and transferring condensation
to the tank.
DAILY USE
START A PROGRAMME WITHOUT DELAY
START
1. Prepare the laundry and load the appliance.
CAUTION! Make sure that when
you close the door, the laundry
does not get caught between the
appliance door and the rubber
seal.
2. Press the on/off button to activate the
appliance.
3. Set the correct programme and options for the
type of load.
The display shows the programme duration.
Real drying time will depend on type of
the load (quantity and composition),
the room temperature and the humidity
of your laundry after spin drying phase.
4. Press the Start/Pause touch button.
The programme starts.
STARTING THE PROGRAMME WITH DELAY
START
1. Set the correct programme and options for the
type of load.
2. Press the delay start button again and again
until the display shows the delay time you want
to set.
11

You can delay the start of a
programme from a minimum of 30
minutes to a maximum of 20
hours.
3. Press the Start/Pause touchpad.
The display shows the countdown of the
delay start.
When the countdown is completed, the programme
starts.
CHANGE A PROGRAMME
1. Press the on/off button to deactivate appliance
2. Press the on/off button to activate the
appliance.
3. Set the programme.
AT THE END OF THE PROGRAMME
When the programme is completed:
• An intermittent acoustic signal operates.
• The indicator flashes.
• The indicator flashes.
• The Start/Pause indicator is on.
The appliance continues to operate with the crease
guard phase for approximately other 30 minutes.
The crease guard phase prevents creases from
your laundry.
You can remove the laundry before the crease
guard phase is completed. We recommend, for
better results, that you remove the laundry when the
phase is almost completed.
When the crease guard phase is completed:
• The indicator is on but does not flash.
• The indicator is on but does not flash.
• Start/Pause indicator goes off.
1. Press the on/off button to deactivate the
appliance.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
Possible causes of unsatisfactory drying results:
• Inadequate default dryness level settings. See
chapter Adjustment of default dryness level
Always clean the filter and empty
the water container when a
programme is completed.
STAND-BY FUNCTION
To decrease the energy consumption, this function
automatically deactivates the appliance:
• After 5 minutes if you do not start the
programme.
• After 5 minutes from the end of the programme.
HINTS AND TIPS
PREPARING THE LAUNDRY
Very often the clothes after washing
cycle are kneaded and tangled
altogether.
Drying kneaded and tangled clothes is
inefficient.
To assure proper air flow and even
drying it is recommended to shake and
load one by one the clothes to the
tumble dryer.
To assure proper drying process:
• Close the zips.
• Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g. apron
ribbons). Tie them before you start a
programme.
• Remove all items from pockets.
• Turn items with the internal layer made of cotton
inside out. Cotton layer must be faced
outwards.
• Always set the programme suitable for the type
of laundry.
• Do not put light and dark colours together.
• Use suitable programme for cottons, jersey and
knitwear to reduce shrinkage.
• Do not exceed the maximum load stated in the
programmes chapter or shown on the display.
• Dry only the laundry that is suitable for tumble
drying. Refer to the fabric label on the items.
• Do not dry large and small items together. Small
items can be trapped inside the large items and
remain wet.
• Shake the large clothes, fabrics before placing
in the tumble dryer. It is to avoid moist places
inside the fabric after the drying cycle.
12

Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
CARE AND CLEANING
CLEANING THE FILTER
CAUTION! Clogged filter leads to the
emergency heater shutdown. As a
consequence the laundry remains cold
and wet. The display shows 1 min or
few minutes to the cycle end for a
longer time.
The filter cleaning fixes above
problems.
CAUTION! Avoid the use of water to
clean the filter. Instead throw away lint
in the dustbin ( avoid dispersion of
plastic fiber in water ambient).
To achieve the best drying
performances clean the filter regularly ,
clogged filter lead to longer cycles and
energy consumption increase.
Use your hand to clean the filter , and
if necessary , a vacuum cleaner .
1. 2.
1
2
3. 4.
13

5.
2
1
EMPTYING THE WATER CONTAINER
1. 2.
3. 4.
You can use the water from the water
container as an alternative to distilled
water (e.g. for steam ironing). Before
you use the water, remove dirt
residues with a filter.
CLEANING THE CONDENSER
1. 2.
2
1
14

3.
11
2
1
1
4.
5. 6.
7.
11
1
2
2
3
CLEANING THE HUMIDITY SENSOR
CAUTION! Risk of humidity sensor
damage. Do not use abrasive materials
or steel wool to clean the sensor.
To assure best drying results the appliance is
equipped with metal humidity sensor. It is placed
on the inner side of the door area.
Over usage time the surface of the sensor may get
dirty what deteriorates the drying performance.
We recommend to clean the sensor at least 3 or 4
times or if you observe the drop of drying
performance.
To clean you can use harder side of dish-washing
sponge and bit of vinegar or dish soap.
To clean the sensor:
1. Open the loading door.
2. Clean the surfaces of the humidity sensor
wiping off the metal surface several times.
CLEANING THE DRUM
WARNING! Disconnect the appliance
before you clean it.
Use a standard neutral soap detergent to clean the
inner surface of the drum and drum lifters. Dry the
cleaned surfaces with a soft cloth.
CAUTION! Do not use abrasive
materials or steel wool to clean the
drum.
15

CLEANING THE CONTROL PANEL AND
HOUSING
Use a standard neutral soap detergent to clean the
control panel and housing.
Use a moist cloth to clean. Dry the cleaned
surfaces with a soft cloth.
CAUTION! Do not use furniture
cleaning agents or cleaning agents
which can cause corrosion.
CLEANING THE AIRFLOW SLOTS
Use a vacuum cleaner to remove fluff from the
airflow slots.
TROUBLESHOOTING
WARNING! Refer to Safety chapters.
ERROR CODES
The appliance does not start or it stops during operation.
First try to find a solution to the problem (refer to the table). If the problem persists, contact the Authorised
Service Centre.
WARNING! Deactivate the appliance before carrying out any check.
In case of major problems, the acoustic signals operate, the display shows an error code and
the Start/Pause button may flash continuously:
Error code Possible cause Remedy
E5A
Appliance motor overloaded.
Too much laundry or entrap in the
drum.
The programme was not completed.
Remove the laundry from the drum,
set the programme and restart the cy-
cle.
E97
Internal fail. No communication be-
tween electronic elements of the ap-
pliance.
The programme was not finished
properly or the appliance stoped too
early. Switch the appliance off and on
again.
If the error code appears again, con-
tact the Authorised Service Centre.
EH0
The mains supply is unstable. When the appliance is showing EH0,
please wait until main supply is stable
than press start. If the appliance
pause the cycle without any indication
then press the cycle start. If the warn-
ing will occur check the power cord /
socket integrity or main supply.
If the display shows other error codes, deactivate and activate the appliance. If the problem continues,
contact the Authorised Service Centre.
In case of different problem with the tumble dryer check the table below for possible solutions.
16

TROUBLESHOOTING
Problem Possible solution
You cannot activate the appliance. Make sure that the mains plug is connected to
the mains socket.
Check fuse in fuse box (domestic installation).
The programme does not start. Press Start/Pause.
Make sure that the appliance door is closed.
The appliance door does not close. Make sure that the installation of the filter is cor-
rect.
Make sure that the laundry does not catch be-
tween the appliance door and the rubber seal.
The appliance stops during operation. Make sure that the water container is empty.
Press Start/Pause to start the programme again.
Load is too small, increase the load or use the
Time Dry programme.
The cycle time is too long or unsatisfactory dry-
ing result.1)
Make sure that the weight of the laundry is appli-
cable to the duration of the programme.
Make sure that the filter is clean.
The laundry is too wet. Spin the laundry in the
washing machine again.
Ensure that the room temperature is higher than
+5°C and lower than +35°C. Optimal room tem-
perature is 18°C to 25°C.
Set the Time Dry or the Extra Dry programme.2)
The tumble dryer does not heat up. The laundry
inside is cold and wet.
The filter is clogged. The emergency heater shut-
down.
Clean the filter (see chapter CARE AND
CLEANING).
Display shows 1 min or few minutes to the cycle
end for longer time. The laundry inside is cold
and wet.
The filter is clogged. The emergency heater shut-
down.
Clean the filter (see chapter CARE AND
CLEANING).
The display shows Err. If you want to set a new programme, deactivate
and activate the appliance.
Make sure that the options are applicable to the
programme.
17

Problem Possible solution
The display shows an Error code (e.g. E51). Deactivate and activate the appliance. Start a
new programme. If the problem occurs again,
contact the Service.
1) After maximum 6 hours, the programme ends automatically.
2) It can happen that some area remains humid when drying big items (e.g. bed sheets ).
If the drying results are not satisfactory
• The set programme was incorrect.
• The filter is clogged.
• The condenser is clogged.
• There was too much laundry in the appliance.
• The drum is dirty.
• Incorrect setting of the conductivity sensor
( See chapter "Settings - Adjustment of the
remaining laundry moisture degree " for better
setting).
• The airflow slots are clogged.
• Room temperature is too low or too high
( optimal room temperature 18°C to 25°C )
TECHNICAL DATA
Height x Width x Depth 850 x 596 x 615 mm (maximal 647 mm)
Max. depth with the appliance door open 1084 mm
Max. width with the appliance door open 945 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 118 l
Maximum load volume 8kg
Voltage 230-240 V
Frequency 50 Hz
Sound power level 66 dB
Necessary fuse 13 A
Total power 2800 W
Energy efficiency class B
Energy consumption on the standard cotton pro-
gramme with the full load. 1)
4,81 kWh
Energy consumption on the standard cotton pro-
gramme with the partial load. 2)
2,52 kWh
Annual energy consumption3) 560,5 kWh
Left-on mode power absorption 4) 0,05 W
Off mode power absorption 4) 0,05 W
Type of use Household
18

Allowed ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid parti-
cles and moisture ensured by the protective cov-
er, except where the low voltage equipment has
no protection against moisture
IPX4
1) With reference to BS EN 61121. 8 kg of cotton centrifuged at 1000 rpm.
2) With reference to BS EN 61121. 4 kg of cotton centrifuged at 1000 rpm.
3) Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme at
full and partial load, and the consumption of the low-power modes. Actual energy consumption per cycle
will depend on how the appliance is used (according to UK Ecodesign and Energy Labelling Regulations).
4) With reference to BS EN 61121.
The information given in the chart above is compliant with the UK Ecodesign and Energy Labelling Regula-
tions.
CONSUMPTION DATA
Programme Spun at / residual humidity Drying time1) Energy con-
sumption2)
Cotton Eco 8 kg
Cupboard Dry 1400 rpm / 50% 125 min. 4,10 kWh
1000 rpm / 60% 145 min. 4,81 kWh
Cotton 8 kg
Iron Dry 1400 rpm / 50% 97 min. 3,11 kWh
1000 rpm / 60% 115 min. 3,82 kWh
Cotton Eco 4 kg
Cupboard Dry 1400 rpm / 50% 71 min. 2,18 kWh
1000 rpm / 60% 82 min. 2,52 kWh
Synthetics 3,5 kg
Cupboard Dry 1200 rpm / 40% 55 min. 1,57 kWh
800 rpm / 50% 71 min. 1,89 kWh
1) For partial loads, the cycle time is shorter and appliance uses less energy.
2) Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase
the energy consumption.
PRODUCT INFORMATION SHEET ACCORDING TO UK ECODESIGN
PRODUCT INFORMATION SHEET
ACCORDING TO UK ECODESIGN
FOR ENERGY-RELATED
PRODUCTS AND ENERGY
INFORMATION REGULATIONS
19

Product Information Sheet
Trade Mark ZANUSSI
Model ZDC82B4PW
PNC916098948
Rated capacity in kg 8
Air vented or condenser tumble dryer Condenser
Energy efficiency class B
Energy consumption in kWh per year, based on 160 drying cycles of the
standard cotton programme at full and partial load, and the consumption
of the low-power modes. Actual energy consumption per cycle will de-
pend on how the appliance is used.
560,5
Automatic tumble drier or non-automatic tumble drier Automatic
Energy consumption of the standard cotton programme at full load in
kWh
4,81
Energy consumption of the standard cotton programme at partial load in
kWh
2,52
Power consumption of the off-mode in W 0,05
Power consumption in left-on mode in W 0,05
Duration of the left on mode in minutes 10
The 'standard cotton programme' used at full and partial load is the
standard drying programme to which the information in the label and the
fiche relates, this programme is suitable for drying normal wet cotton
laundry and it is the most efficient programme in terms of energy con-
sumption for cotton.
Weighted programme time of the 'standard cotton programme at full and
partial load' in minutes
109
Programme time of the 'standard cotton programme at full load' in mi-
nutes
145
Programme time of the 'standard cotton programme at partial load' in mi-
nutes
82
Condensation efficiency class on a scale from G (least efficient) to A
(most efficient)
B
Average condensation efficiency of the standard cotton programme at full
load as a percentage
81
Average condensation efficiency of the standard cotton programme at
partial load as a percentage
81
Weighted condensation efficiency for the 'standard cotton programme at
full and partial load'
81
Sound power level in dB 66
Built in appliance Y/N No
20
