Zanussi ZKT 651 D User manual

Ceramic glass induction hob
ZKT 651 D
Installation and Operating Instructions g

2
Dear Customer,
Please read these user instructions carefully and
keep them to refer to later.
Please pass the user instructions on to any future
owner of the appliance.
The following symbols are used in the
text:
1Safety instructions
Warning! Notes that concern your personal
safety.
Important! Notes that show how to avoid
damage to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Control panel layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Touch Control sensor fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switching the appliance on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Selecting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the automatic warm-up function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Locking/unlocking the control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Switching the power function on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tips on cooking and frying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cookware for induction cooking zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Tips on energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Rating Plate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warranty conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Service and Spare Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4
Operating Instructions
1Safety instructions
3Please comply with these instructions. If you
do not, any damage resulting is not covered
by the warranty.
5This appliance conforms with the following EU
Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Direc-
tive
–89/336/EEC dated 03.05.1989 EMC Directive in-
clusive of Amending Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal do-
mestic cooking and frying of food.
•The appliance must not be used as a work surface
or as a storage surface.
•Additions or modifications to the appliance are not
permitted.
•Do not place or store flammable liquids, highly in-
flammable materials or fusible objects (e.g. plastic
film, plastic, aluminium) on or near the appliance.
Child safety
•Small children must be kept away from the appli-
ance.
•Only let older children work on the appliance under
supervision.
General safety
•The appliance may only be installed and connect-
ed by trained, registered service engineers, or
competent persons.
•Built-in appliances may only be used after they
have been built in to suitable built-in units and
work surfaces that meet standards.
•In the event of faults with the appliance or damage
to the glass ceramic (cracks, scratches or splits),
the appliance must be switched off and discon-
nected from the electrical supply to prevent the
possibility of an electric shock..
•Repairs to the appliance must only be carried out
by trained registered service engineers.
Safety during use
•Remove stickers and film from the glass ceramic.
•There is the risk of burns from the appliance if used
carelessly.
•Cables from electrical appliances must not touch
the hot surface of the appliance or hot cookware.
•Overheated fat and oil can ignite quickly. When
cooking with fat or oil (e.g. frying chips) do not
leave the appliance unattended.
•Switch the cooking zones off after each use.
•Users with implanted pacemakers should keep
their upper body at least 30 cm from induction
cooking zones that are switched on.
•Risk of burns! Do not place objects made of metal,
such as knives, forks, spoons and saucepan lids
on the cooking surface, as they can get hot.
Safety when cleaning
•For cleaning, the appliance must be switched off
and cooled down.
•For safety reasons, the cleaning of the appliance
with steam jet or high-pressure cleaning equip-
ment is not permitted.
How to avoid damage to the appli-
ance
•The ceramic glass can be damaged by objects fall-
ing onto it.
•The edge of the ceramic glass can be damaged by
being knocked by the cookware.
•Cookware made of cast iron, cast aluminium or
with damaged bottoms can scratch the ceramic
glass if pushed across the surface.
•Objects that melt and things that boil over can
burn onto the ceramic glass and should be re-
moved straightaway.
•Do not use the cooking zones with empty cook-
ware or without cookware.
•The ventilation gap of 5mm between the worktop
and front of the unit underneath it must not be cov-
ered.

5
Description of the Appliance
Cooking surface layout
Control panel layout
Induction cooking zone 2200W
with power function 3000W
Induction cooking zone 1400W
Induction cooking zone 1800 W
Control panel Induction cooking zone 1800 W
with power function 2300 W
On/Off
with power indicator
Heat setting selection
Timer
Timer display
Lock
Cooking zone indicators
Timer function
Power function
Display

6
Touch Control sensor fields
The appliance is operated using Touch Control sen-
sor fields. Functions are controlled by touching sen-
sor fields and confirmed by displays and acoustic
signals.
Touch the sensor fields from above, without covering
other sensor fields.
Displays
Residual heat indicator
1Warning! Risk of burns from residual heat. Af-
ter being switched off, the cooking zones need
some time to cool down. Look at the residual
heat indicator h.
3Residual heat can be used for melting and
keeping food warm.
The induction cooking zones create the heat re-
quired for cooking directly in the base of the cook-
ware. The glass ceramic is merely heated by the
residual heat of the cookware.
The cooling fan switches itself on and off depending
upon the temperature of the electronics.
Sensor field Function
On / Off Switches appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
Timer Timer selection
Lock Locking/unlocking the control panel
Power Switching the power function on and off
Display Description
¾Cooking zone is switched off
uKeep warm setting Keep warm setting is set
¿- ÇHeat settings Heat setting is set
aAutomatic warm up function Automatic warm-up function is activated
eFault Malfunction has occurred
fPan detection Cookware is unsuitable or too small or no cookware
has been placed on the cooking zone
hResidual heat Cooking zone is still hot
lChild safety device Lock/child safety device is set.
pPower Power function is switched on
_Safety cut-out Safety cut-out has been activated

7
Operating the appliance
3Use the induction cooking zones with suitable
cookware.
Switching the appliance on
and off
3After switching on, within approx. 10 seconds
a heat setting or a function must be set, other-
wise the appliance automatically switches it-
self off.
Selecting the heat setting
3The keep warm setting ulies between ¾and
¿. The keep warm setting can be set using
or . It is used to keep food warm.
Control panel Display Pilot light
Switch on Touch for 2 seconds ¾/ hlights up
Switch off Touch for 1 second h/ none goes out
Control panel Display
Increase Touch uto Ç/ p
Decrease Touch Çto ¾
Switch off Touch and at the same time ¾

8
Using the automatic warm-up function
All cooking zones are equipped with an automatic
warm-up function. The automatic warm-up function
sets the cooking zone to the highest setting for a
certain period of time and then automatically switch-
es back to the cooking setting that was originally set.
3If during the automatic warm up aa higher
heat setting is selected, e.g. from Áto Ã, the
automatic warm up is adjusted.
3If there is still residual heat on the cooking
zone (display h), the automatic warm up is
not performed.
The length of time that the automatic warm up func-
tion operates depends on the heat setting selected.
Step Control panel Display
1. Setting the level Ç/ pÇ/ p
2. Place to one side for a moment Ç/ p
3. touch a
4. touch in order to set the desired cooking setting Æuntil ¿/ u
after 3 seconds a
Heat setting Length of the automatic warm up [min.]
v0:10
10:10
20:10
33:10
45:50
510:10
62:00
72:30
82:50
9---

9
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off”
sensor field, can be locked at any time in order to
prevent the settings being changed e.g. by wiping
over the panel with a cloth.
3When you switch the appliance off, the locking
function is automatically switched off.
Using the child safety device
The child safety device prevents unintentional use of
the appliance.
Setting the child safety device
Releasing the child safety device
Overriding the child safety device
The child safety device can be released in this way
for a single cooking session; it remains activated af-
terwards.
Control panel Display
Switch on Touch l(for 5 seconds)
Switch off Touch previously set heat setting
Step Control panel Display/Signal
1. Switch on the appliance
(Do not set a heat setting)
¾
2. Touch until the signal sounds Acoustic signal
3. Touch l
Appliance switches off. The child safety device is set.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch until the signal sounds Acoustic signal
3. Touch
Appliance switches off. The child safety device is released.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch and at the same time ¾/ acoustic signal
Until the appliance is next switched off, it can used as normal.

10
Switching the power function on and off
The power function makes more power available
to the induction cooking zones, e.g. to bring a large
quantity of water to the boil quickly.
The power function is activated for 10 minutes. After
that the induction cooking zone automatically
switches back to heat setting 9.
Power Management
The cooking zones have a maximum power available
to them.
If this power range is exceeded by switching on the
power function, Power Management reduces the
heat setting of another cooking zone.
The display for this cooking zone alternates for two
minutes between the set heat setting and the maxi-
mum possible heat setting. Thereafter the actual
heat setting is displayed.
Example:
3If the power function has ended, the cooking
zones automatically switch back to the heat
setting set previously.
Control panel Display
Switch on Touch p
Switch off Touch Ç
Touch Ç
Last
cooking zone switched
on
Other cooking zone
set
heat setting
set
heat setting
display actual
heat setting
p97 alternating with 97

11
Using the timer
All cooking zones can use each use one of the two
timer functions at the same time.
3If a cooking zone is switched off, the timer
function set is also switched off.
3If a heat setting is set on this cooking zone in
addition to a countdown timer, the cooking
zone is switched off after the time set has
elapsed.
Selecting a cooking zone
3If the pilot light is flashing more slowly, the
heat setting can be set or modified.
3If other timer functions are set, after a few sec-
onds the shortest remaining time of all the tim-
er functions is displayed and the
corresponding pilot light flashes.
Function Condition Outcome after the time has
elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone switches off
Countdown timer cooking zones not in use acoustic signal
00 flashes
Step Control panel Display
1. Touch once Pilot light of the first cooking zone flashes
2. º Touch once Pilot light of the second cooking zone flashes
3. Touch once Pilot light of the third cooking zone flashes
4. Touch once Pilot light of the fourth cooking zone flashes

12
Setting the time
Switching off the timer function
Changing the time
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected flashes
2. Touch or for the cooking
zone selected
00 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected flashes faster
The time remaining is displayed
2. Touch for the cooking zone se-
lected
The time remaining counts down to 00.
The pilot light goes out.
The timer function for the selected cooking zone is switched off.
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected flashes faster
The time remaining is displayed
2. Touch or for the cooking
zone selected
01 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. Select cooking zone Pilot light of the cooking zone selected flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch Acoustic signal to acknowledge.
Acoustic signal stops.

13
Safety cut-out
Cooking surface
•If after switching on the cooking surface, a heat
setting is not set for a cooking zone within approx.
10 seconds, the cooking surface automatically
switches itself off.
•If one or more sensor fields are covered for longer
than approx. 10 seconds, e.g. by a pan placed
upon it, a signal sounds and the cooking surface
switches off automatically.
•If all cooking zones are switched off, the cooking
surface automatically switches itself off after ap-
prox. 10 seconds.
Control panel
3Moisture (e.g. a wet cloth) or liquid boiling over
onto the control panel immediately switches
all cooking zones off.
Induction cooking zones
•In the event of overheating (e.g. when a pan boils
dry) the cooking zone automatically switches itself
off. _is displayed. Before being used again, the
cooking zone must be set to 0and allowed to cool
down.
•If cookware that is not suitable is used, fflashes
in the display and after 10 minutes the display for
the cooking zone switches itself off.
•If one of the cooking zones is not switched off after
a certain time, or if the heat setting is not modified,
the relevant cooking zone switches off automati-
cally.
Heat setting Switches off after
V, 1 - 2 6 hours
3 - 4 5 hours
54 hours
6 - 9 1.5 hours

14
Tips on cooking and frying
3Information about acrylamides
According to the latest scientific research, in-
tensive browning of food, especially in prod-
ucts containing starch, may present a health
risk due to acrylamide. Therefore we recom-
mend cooking at low temperatures and not
browning foods too much.
Cookware for induction cooking zones
3Cookware for induction cooking zones is la-
belled as suitable by the manufacturer.
Test of suitability
Cookware is suitable for induction, if …
•... a little water is heated on an induction cooking
zone set to heat setting 9 within a few seconds.
•... a magnet sticks to the bottom of the cookware.
3Certain cookware can make noises when be-
ing used on induction cooking zones. These
noises are not a fault in the appliance and do
not affect operation in any way.
Pan size
Induction cooking zones adapt automatically to the
size of the cookware bottom up to a certain limit.
However the magnetic part of the cookware bottom
must have a minimum diameter depending upon the
size of the cooking zone.
3The cookware must be placed centrally on the
cooking zone.
Cookware made of suitable
Steel, enamelled steel yes
Cast iron yes
Stainless steel if appropriately labelled by the manufacturer
Aluminium, copper, brass ---
Glass, ceramic, porcelain ---

15
Tips on energy saving
2Place cookware on the cooking zone before it
is switched on.
2If possible, always place a lid on the cook-
ware.
Examples of cooking applications
The information given in the following table is for guidance only.
The power function is suitable for heating large quantities of liquid.
Heat
setting
Cooking
process suitable for Cook time Tips/Hints
0Offposition
VKeeping
food warm Keeping cooked foods warm as required Cover
1-2 Melting Hollandaise sauce,
melting butter, chocolate, gelatine 5-25 mins. Stir occasionally
Solidifying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3 Simmering
Simmering rice and milk-based
dishes
Heating up ready-cooked meals
25-50 mins.
Add at least twice as much
liquid as rice, stir milk dishes
part way through cooking
3-4 Steaming
Braising
Steaming vegetables, fish
Braising meat 20-45 mins. With vegetables add only a lit-
tle liquid (a few tablespoons)
4-5 Boiling
Steaming potatoes 20-60 mins.
Use only a little liquid, e. g.:
max. ¼l water for 750 g of
potatoes
Cooking larger quantities of food,
stews and soups 60-150 mins. Up to 3 l liquid plus ingredi- ents
6-7 Gentle
frying
Frying escalope, veal cordon
bleu, cutlets, rissoles, sausages,
liver, roux, eggs, pancakes,
doughnuts
as required Turn halfway through cooking
7-8 Heavy
frying
Hash browns, loin steaks, steaks,
Flädle (pancakes for garnishing
soup)
5-15 mins.
per pan Turn halfway through cooking
9
Boiling
Searing
Deep frying
Boiling large quantities of water, cooking pasta, searing meat (goulash, pot roast),
deep frying chips

16
Cleaning and care
1Take care! Risk of burns from residual heat.
1Important Sharp objects and abrasive clean-
ing materials will damage the appliance. Clean
with water and washing up liquid.
1Important Residues from cleaning agents will
damage the appliance. Remove residues with
water and washing up liquid.
Cleaning the appliance after each use
1. Wipe the appliance with a damp cloth and a little
washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposits
1. Place the scraper on the glass ceramic surface at
an angle.
2. Remove residues by sliding the blade over the sur-
face.
3. Wipe the appliance with a damp cloth and a little
washing up liquid.
4. Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel
can be purchased in specialist shops, supermarkets, the
parts department of your local Service Force Centre or from
www.shop.electrolux.co.uk
3Remove stubborn residues with a cleaner for
glass ceramic or stainless steel.
3Scratches or dark stains on the glass ceramic
that cannot be removed do not however affect
the functioning of the appliance.
Remove
Type of dirt immedi-
ately
when the appliance has
cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes
cleaner for glass ceramic
or stainless steel*
fat splashes --- yes
shiny metallic discolorations --- yes

17
What to do if …
Problem Possible cause Remedy
The cooking zones will not switch
on or are not functioning
More than 10 seconds have passed
since the appliance was switched
on
Switch the appliance on again.
The lock is switched on lSwitch off the lock (See the section
“Locking/unlocking the control
panel”)
The child safety device is switched
on l
Deactivate the child safety device
(See the section “Child safety de-
vice”)
Several sensor fields were touched
at the same time
Only touch one sensor field
The sensor fields are partly covered
by a damp cloth or with liquid
Remove the cloth or the liquid.
Switch the appliance on again.
Safety cut-out has been triggered Switch the appliance on again
The residual heat indicator is not
displaying anything The cooking zone was only on for a
short time and is therefore not hot
If the cooking zone is supposed to
be hot, call your local Service Force
Centre.
The automatic warm up function is
not switching itself on
There is still residual heat on the
cooking zone h
Let the cooking zone cool down
The highest heat setting is set ÇThe highest heat setting has the
same power as the automatic warm
up function
Repeated acoustic signal (6x), ap-
pliance switches off
One or more sensor fields have
been covered for longer than 10
seconds
Uncover sensor field
Acoustic signal sounds and appli-
ance switches itself on and then off
again; after 5 seconds another
acoustic signal sounds
The On/Off sensor field has been
covered up, e.g. by a cloth
Do not place any objects on the
control panel
Display is switching between two
heat settings
Power management is reducing the
power of this cooking zone
See the section “Switching the
power function on and off”
fflashes Unsuitable cookware Use suitable cookware
No cookware on the cooking zone Place cookware on the cooking
zone
The diameter of the bottom of the
cookware is too small for the cook-
ing zone
Move onto a smaller cooking zone
Use suitable cookware
_is lit Overheating protection for the
cooking zone has been triggered
Switch off the cooking zone.
Switch the cooking zone on again
eand number are displayed Electronics fault Disconnect the appliance from the
electrical supply for a few minutes
(Take the fuse out of the house’s
wiring system)
If after switching on again, eis dis-
played again, call the customer
service department

18
If you are unable to remedy the problem by fol-
lowing the above suggestions, please contact
your local Service Force Centre.
1Warning! Repairs to the appliance are only to
be carried out by qualified service engineers.
Considerable danger to the user may result
from improper repairs.
3If the appliance has been wrongly operated,
the visit from the service technician or dealer
may not take place free of charge, even during
the warranty period.
Disposal
2Packaging material
The packaging materials are environmentally
friendly and can be recycled. The plastic com-
ponents are identified by markings, e.g. >PE<,
>PS<, etc. Please dispose of the packaging
materials in the appropriate container at your
local waste disposal facilities.
2Old appliance
The symbol Won the product or on its pack-
aging indicates that this product may not be
treated as household waste. Instead it shall be
handed over to the applicable collection point
for the recycling of electrical and electronic
equipment. By ensuring this product is dis-
posed of correctly, you will help prevent po-
tential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed in-
formation about recycling of this product,
please contact your local city office, your
household waste disposal service or the shop
where you purchased the product.

19
Installation Instructions
Safety instructions
The laws, ordinances, directives and standards in
force in the country of use are to be followed (safety
regulations, proper recycling in accordance with the
regulations, etc.)
Installation may only be carried out by a qualified
electrician.
The minimum distances to other appliances and
units are to be observed.
A protective floor must be installed under the ap-
pliance.
The cut surfaces of the worktop are to be protected
against moisture using a suitable sealant.
The sealant seals the appliance to the work top with
no gap.
When building in, protect the underside of the appli-
ance from steam and moisture, e.g. from a dish-
washer or oven.
Avoid installing the appliance next to doors and un-
der windows. Otherwise hot cookware may be
knocked off the rings when doors and windows are
opened.
1WARNING!
Risk of injury from electrical current.
•The electrical mains terminal is live.
•Observe connection schematic.
•Observe electrical safety rules.
•Ensure anti-shock protection through correct in-
stallation by a qualified electrician.
•The appliance must be connected to the electrical
supply by a qualified electrician.
1IMPORTANT!
Risk of injury from electrical current.
Loose and inappropriate plug and socket connec-
tions can make the terminal overheat.
•Have the clamping joints correctedly installed by a
qualified electrician.
•Use strain relief clamp on cable.
•In the event of single-phase or two-phase connec-
tion, the appropriate mains cable of type H05BB-F
Tmax 90° (or higher) must be used.
•If this appliance’s mains cable is damaged, it must
be replaced by a special cable (type H05BB-F
Tmax 90°; or higher). Please contact your local
Service Force Center for further advice.
A device must be provided in the electrical installa-
tion which allows the appliance to be disconnected
from the mains at all poles with a contact opening
width of at least 3 mm
Suitable isolation devices include line protecting cut-
outs, fuses (screw type fuses are to be removed from
the holder), earth leakage trips and contactors.

20
Sticking on the seal
•Clean the worktop in the area of the cut-out sec-
tion.
•Stick the one-sided self-adhesive sealing tape
supplied all the way round the lower edge of the
cooking surface along the outer edge of the glass
ceramic panel. Do not stretch it. The cut ends
should lie in the middle of one side. When you
have cut it to length (add a few mm), press the two
ends flush up against one another.
