Zanussi ZMD 905 W Specification sheet

2
BUILT-IN
DOUBLE OVENS
ZMD 905 W/K
35668 - 2001
OPERATING AND INSTALLATION MANUAL
ZANUSSI

3
Warnings and guidance
It is most important that this instruction book should be retained with the appliance for future
reference. Should the appliance be sold or transferred, always ensure that the book is left with the
appliance in order that the new owner can get to know the functions of the appliance and the
relevant warnings.
These warnings are provided in the interest of safety. You MUST read them carefully before
installing or using the appliance.
This oven incorporates new Electronic
Technology and therefore may work differently
from a traditional product which you have
become accustomed to.
The heating elements will become hot very
quickly and care should be taken when placing
or removing items from the oven.
If you are concerned about the operation of the
oven, please study the instruction book
carefully, as it contains advice about how to
achieve excellent results from your new oven.
BEFORE INSTALLATION
• This oven is heavy and care must be taken
when moving it.
• Ensure that all packaging, both inside and
outside the cooker, has been removed before
the cooker is used.
• The oven must be installed according to the
instructions supplied. Any electrical work
must be undertaken by a qualified electrician/
competent person.
• It is dangerous to alter the specifications in any
way.
• After installation, please dispose of the
packaging with due regard to safety and the
environment.
DURING OPERATION
• Do not use this oven if it is in contact with
water and never operate it with wet hands.
• Ensure that the anti-tip oven shelves are
installed in the correct way.
• This oven is designed to be operated by adults
and children under supervision. Young
children must not be allowed to tamper with
the controls or play near or with the cooker.
• CAUTION - accessible parts, especially
around the grill area, may become hot when
the cooker is in use. Children should be kept
away until it has cooled.
• Take great care when heating fats and oils as
they will ignite if they become too hot.
• This oven has been designed for cooking
edible foodstuffs only and must not be used for
any other purposes.
• Never place plastic or any other material
which may melt in or on the oven.
• Only clean this oven in accordance with the
instructions.
• Take care to follow the recommendations
given for tending the food when grilling. Use
the handles provided in the recommended
way.
•Always grill with the oven door closed.
• Always remove the grill pan handles when
grilling.
• Always use oven gloves to remove and replace
food in the oven. Similarly always use oven
gloves to remove and replace the grill pan
handles, before and after grilling.
• Ensure that you support the grill pan when
removing it from the oven.
• Never line any part of the oven with
aluminium foil. Do not allow heatproof
cooking material, e.g. roasting bags, to come
into contact with oven elements.
• Always stand back from the oven when
opening the oven door, to allow any build-up
of steam or heat to release.
• Stand clear when opening the drop down oven
door. Do not allow it to fall open - support it
using the door handle, until it is fully open.
• Do not place sealed cans or aerosols inside the
oven. They may explode if they are heated.
• Do not hang towels or clothes from the oven
or its handle. They are a safety hazard.

4
WARNING
Please remember that an appliance used for cooking does get hot, so make sure that children are
kept well away it is in use.
AFTER USE
• Ensure that all control knobs are in the OFF
position when not in use.
• For hygiene and safety reasons, this oven
should be kept clean at all times. A build-up of
fats or other foodstuffs could result in a fire,
especially in the grill pan.
• Always allow the cooling fan to cool the oven
down before switching off at the electrical
supply prior to carrying out any cleaning or
maintenance work.
• Do not leave utensils containing foodstuffs,
e.g. fat or oil in or on the oven in case it is
inadvertently switched ON.
• Ovens and hobs become very hot, and retain
their heat for a long period of time after use.
Children should be kept well away from the
cooker until it has cooled.
• The timer display should show only the time
of day when the oven is not in use.
• Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried
out by inexperienced persons may cause injury
or serious malfunctioning. Refer to your local
authorised Service Centre. Always insist on
genuine Zanussi spare parts.

5
Contents
Warnings and Guidance Page 3
Technical specification Page 5
Installation into Built in Units Page 6
Electrical Connection Page 7
Use and Care - How to Set the Main Functions Page 8
Control Panel Page 9
Timer Display (upper onven - lower oven) Page 11
Using the Programmes Page 12
Cooking Tips Page 17
Cooking Charts Page 18
Helpful Hints Buying and Preparing Food Page 23
Cleaning the Oven Page 24
Cleaning the Hinged Grill Page 25
What Happens if Something Goes Wrong Page 26
Technical Assistance Page 26
UPPER OVEN
Dimensions: Power Absorbtion:
Height 320 mm Traditional System 2.0 kW
Width 420 mm Convection Oven 2.5 kW
Depth 390 mm Fan Only (Defrost) 30 W
Capacity 52,5 litres Convection With Bottom Element 3.5 kW
Small Grill System 1.8 kW
Large Grill System 2.8 kW
Oven Light 25 W
Cooling Fan 25 W
LOWER OVEN
Dimensions: Power Absorbtion:
Height 185 mm Traditional System 2.0 kW
Width 425 mm Large Grill System 2.8 kW
Depth 400 mm Oven Light 25 W
Capacity 31 litres
Maximum Power Absorbed 6.4 kW
Voltage 240 V
Frequency 50 Hz
Technical specification

6
Installation into built in units
It is important that the dimensions and materials of
the surround or cabinet into which the oven will be
built are correct and will withstand a temperature
increase of at least (60°C); and that proper
arrangements are made for a continous air supply
to the oven so it does not averheat.
Dimensions of the appliance and recess required
are given below.
Fig. 1
Dimensions of the recess for building into a kitchen unit (mm).
Fig. 2
Fig. 3
50
7 min
560 min
600
550
50
7 min
FO 0793
FO 0929
594
888
20
863
5
560
540 20
594
556
19 19
Important
To ensure an efficient ventilation, it is necessary to
leave the vents provided at the bottom of the oven
clear.
Securing The Oven To The Cabinet
Fit the appliance into the cabinet recess.
Open the oven door and secure the oven to the
kitchen cabinet with six wood screws which fit
exactly the holes provided in the oven frame (Fig.
3).

7
Electrical connection
remove the plate at the back of the oven to reach
the terminal block. Connect the brown insulated
wire to the terminal marked "L".
Connect the blue insulated wire to the terminal
marked "N".
Connect the green and yellow insulated wite to the
terminal marked .
Tighten the cable clamps ensuring that there is no
strain on the mains terminal.
Replace the cover and tighten securing screws.
Important
After installation and connecting, the cable must
be placed so that it cannot at any point reach a
temperature of more than 50°C above the ambient
temperature.
Before the appliance is connected, check that the
main fuse and the domestic installation can
support the load; and that the power supply is
properly earthed.
The manufacturer disclaims any responsibility
should these safety measures not be carried out.
This appliance meets the requirements laid down
in EEC Directive No. 89/336 relating to the
suppression of radio and TV interference.
The oven designed to be connected to 240V
(50Hz) electricity supply.
The oven has an easily accessible terminal block
which is marked as follows:
Letter L - Live Terminal
Letter N - Neutral Terminal
- Earth
THIS APPLIANCE MUST BE
EARTHED
The cable used to connect the oven to the
electrical supply should have the characteristics
indicated in the table.
If you require a direct connection to the electric
network (mains), it is necessary that you install an
omnipole switch between the appliance and the
mains, with a minimum gap of 3 mm between the
switch contacts and of a type suitable for the
required lead in compliance with the current rules.
This switch must be easily accessible to the user
on completion of the installation and must not
break the yellow and green earth cable at any
point.
In order to connect the oven it is necessary to
Models Upper Lower Cable cross
oven oven section mm
2
Fuse
rating rating and type of the cable
ZMD 905 W/K 3580 W 2825 W 4.0 HO7 RR-F 30 A

8
SELECTING A PROGRAMME
To switch on the oven press button 3 then press large button
9 to select the required programme. To decrease or increase
the programme temperature press the large buttons 10 or 11.
12356784
AUTOMATIC FUNCTION
(COOKING TIME END OF COOKING)
Select the required programme and temperature. Then press
button 6 and either large button 11 to set the required cooking time
(max h 9, 59 min.). Press button 7, then button 11 to set the
required end cooking time.
123 56784
SELECTING THE OVEN CAVITY
Press button 4 to change the cavity display.
1235678 911
10
4
123 5678
CLOCK-SETTING THE TIME OF DAY
Press button 6 and 7 at the same time, release them and
enter the time pressing large buttons 10 or 11.
4
CHILD SAFETY
123 56774
Press buttons 1 and 3 simultaneously for about 5 seconds. The padlock symbol
will be displayed when this functions is entered. It is only possible to select a
programme if button 1 is pressed at the same time as function button 8.
HOWTO SETTHE MAIN FUNCTIONS
CHILD SAFETY
OVEN OFF
OVEN ON
MEAT PROBE
END OF COOKING
MINUTE MINDER
COOKING TIME
OVEN CAVITY
123 567 91011 48
PM
MEAT PROBE
Insert the probe into the meat . Place the jackplug into the socket inside
the oven. Select the required cook function. Then press button 5 and
large button 11 to increase or decrease the required temperature.
123 56774
SEMI AUTOMATIC FUNCTION
COOKING TIME
Select the required cook function and temperature then
press button 6 and either large button 11 to set the required
cooking time.
123 56784

9
Control Panel
PM
CHILD SAFETY
OVEN CAVITY
UPPER OVEN
LOWER OVEN
TEMPERATURE TIME
PROBE
COOKING TIME
END OF COOKING
TIMER
TECNICAL
ASSISTANCE
PM
I N
B U I L T
FUNCTIONS SETTING
CHILD
SAFETY OFF ON OVEN SELECTOR PROBE TEMP COOK TIME MINUTE MINDER
STOP
TIME
IN CREASE
11
DECREASE
10
FUNCTION SELECTOR
9
MEAT PROBE
COOKING TIME
5
END OF COOKING
MINUTE MINDER
678
OVEN SELECTOR
OVEN OFF
OVEN ON
1
CHILD
SAFETY
2 3 4
Large Push Buttons
9 Oven Function Selector
10 Decrease Temperature or Time
11 Increase Temperature or Time
12 Hinged grill elements
13 Interior light (oven light)
14 Fan
15 Grease filter
16 Grill / roasting pan
17 Grill trivet
18 Removable handle (2)
MEANING OF PROGRAMME BUTTONS
Small Push Buttons
1 Child Safety
2 Oven Off
3 Oven On
4 Oven Selector
5 Meat Probe
6 Cooking Time
7 End of Cooking
8 Minute Minder
18
16
17
12
13
14
15

10
General information
RATING PLATE
These numbers can be found on the rating plate on
the lower front frame of the cooker upon opening
the oven door.
The oven must be protected by a suitable rated
fuse or circuit breaker. The rating of the oven is
given on the rating plate.
GENERAL NOTES ON USING THE OVENS
We suggest that you run all the elements for a
short period, to burn off any residue from their
surfaces.
During this period, an unpleasant odour may be
emitted. It is therefore advisable to open a window
for ventilation.
Select the Fan ducted and conventional
oven programmes. Select a temperature of
170°C for approximately 30 mins. on each
programme.
ABOUT CONDENSATION AND STEAM
When food is heated, it produces steam in the
same way as boiling a kettle. The oven is vented to
allow some of this steam to escape. However,
always stand back from the oven when opening
the oven door to allow any build up of steam or
heat to release.
If the steam comes into contact with a cool surface
on the outside of the oven, e. g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the oven.
To prevent any discolouration, regularly wipe
away condensation any soilage from surfaces.
COOKWARE
Baking trays, oven dishes, etc. should not be
placed directly against the grid covering the fan at
the back of the oven, or placed on the oven base.
Do not use baking trays larger than 30 cm x 35 cm
(12 in x 14 in) as they will restrict the circulation
of heat and may affect the performance. Advice on
the effect of different materials and finishes of
bakeware is given in "Hints and Tips" in the
appropriate oven section.
(See page 20)
MEAT PAN AND GRID
When grilling and roasting, food can be placed on
the grid in the pan. Fat and meat juices will drain
into the base and can be poured off and used to
make gravy.
Important notes:
1) The meat tin should not be placed on a hotplate
as this may cause the enamel to crack.
2) Do not line the meat pan will aluminium foil.
THE COOLING FAN
The cooling fan comes on immediately when the
oven is in use, and switches off when cooking is
completed.
During the initial period, the cooling fan may cycle
ON and OFF. This is quite normal.
It may run on after the oven or grill is switched off
to keep the controls cool.
Always allow the cooling fan to cool the cooker
down completely before switching off at the wall
prior to carrying out any cleaning or maintenance
work.
NOTE: The action of the cooling fan will depend
on how long the oven or grill has been used and at
what temperature settings, it may not operate
where the grill or oven has only been used for a
short time.
CONTROL PANEL INDICATOR
DISPLAY
This indicates whenever the oven or grill is
switched ON. The display also indicates when the
set temperature has been reached.
If the display indicator does not operate as the
instructions on page 12-13-14-15, the controls
have been incorrectly set. Depress the "OFF"
button and reset following the instructions for the
required setting.

11
Timer display (upper oven)
Meaning Of Symbols
FAN DUCTED
OVEN
CONVENTIONAL
OVEN
GRILL ECONOMY GRILL
THERMAL
GRILLING PIZZA OVEN TOP ELEMENT BOTTOM ELEMENT
BREAD PROVING DEFROST COLD FAN
CONVENTIONAL
OVEN TOP ELEMENT ECONOMY GRILL
GRILL
Timer display (lower oven)

12
Using the programmes
ELECTRONIC PROGRAMMER
All the oven functions are controlled by an electronic programmer. This programmer permits you to
select a particular type or combination of heating elements, cooking temperature and automatic timing.
The function selected will be displayed on the programme display panel as shown on page 10.
Different ways of using each programme are detailed under the individual cooking functions.
123 5678
CLOCK-SETTING THE TIME OF DAY
4
SETTING THE TIME OF DAY
The oven has 24hr clock.
When the oven is connected to the electrical supply,
the display will automatically show 12:00.
To set the clock, press buttons 6 and 7 at the same
time, release them and enter the required time by
pressing either button 11 to increase the time or
button 10 to decrease the time.
NOTE: The clock will automatically revert back to
12:00 if the time is not selected within 3 seconds.
In the event of a power failure, the clock will revert
to 12:00 and will require resetting.
ON/OFF SWITCH
To switch the appliance "ON" press button 3,
the symbol will appear on the programmer display.
To switch the appliance "OFF" press button 2,
the symbol will dear on the programmer display and
the oven cavity lamp will go out and the display will
show the time of day.
OVEN CAVITY SELECTION:
Whentheoven hasbeenswitched ontheoven cavity
display will illuminate. The top oven will be
automaticallyselected,toselectthelowerovenpress
button 4.
If you wish to use both ovens simultaneously, make
the section of the oven function and temperature as
detailed in "Selecting a Programme", then press
button4 to selectthelower oven andthe display will
clear, select the oven function and temperature.
The lower oven function and temperature will be
displayed on the control panel.
Tochecktheupperovenselection,pressbutton4and
the functions will be displayed.
SELECTING A PROGRAMME
Whenselectingacookingprogramme,theprocedure
is the same whether you select fan oven cooking,
grilling or any other function. Bread proving has a
pre-set temperature, which cannot be altered.
Each programme is detailed separately but detailed
below is the procedure for the complete range of
symbols and oven functions. Each symbol and oven
function will be explained in further detail on the
relevant pages in the instruction book.
If at any time you wish to cancel a programme,
switchtheovenOFFbypressingbutton2"OFF"and
reselect.
OVEN OFF OVEN ON
123 5674 8
PM
SELECTING A PROGRAMME
12356784

13
1. Switch the oven "ON" by pressing button 3. The
interiorlightwillilluminateandtheovenfanwill
come into operation.
2. Press the function selector (button 9) until the
required programme is displayed on the control
panel.
3. Selecttherequiredtemperaturebypressingbutton
10 to decrease, or 11 to increase the
temperature.
The selected temperature will be displayed on the
control panel. After a few seconds, the temperature
will indicate the current temperature of the oven.
AUTOMATIC COOKING
(UPPER & LOWER OVENS)
It is possible to programme a delay cook start and
cook time so that the food can be cooked
automatically.
It is also possible to programme the oven to switch
off only (semi automatic).
TO SET THE COOKING TIME
Select the required programme and temperature as
previously described on page 13.
Press button 6 and select the cooking time using
buttons 10 and 11.
If a selection is not made within 5 seconds, the
oven will revert back to the time of day.
Now the appliance is in manual functioning, the
light and the cooling fan are on.
Using cooking time only will enable you to
manually switch off the oven.
TO SET THE OVEN FOR
AUTOMATIC COOKING
It is possible to set the timer which will switch the
oven on and off automatically. The maximum
programmable time is 9 hours 59 minutes.
1. Place the food in the oven.
2. Press button 3 "ON"
3. Press button 9 to select the required oven
function.
4. Press button 6, then buttons 10 or 11 to set the
required cooking time.
5. Press button 7, then button 11 to set the
required end cooking time. The oven will
automatically work out when to switch on.
6. The oven controls should now only indicate
the time of day and also the function.
7. When the oven switches on, the oven function
and oven light will illuminate.
At the end of the cook time, the programmer will
give a series of audible signals over approximately
2 minutes, and the display will flash. To cancel the
audible signals, press button 2 "OFF".
SEMI AUTOMATIC FUNCTION
COOKING TIME
123 56784
AUTOMATIC FUNCTION
(COOKING TIME END OF COOKING)
123 56784

14
AUTOMATIC SWITCH OFF
Should you forget to switch the oven off after a
programme, or if the "ON" button is pressed
accidentally, the oven will switch off
automatically.
In fact, in the case of manual functioning, the
programmer will switch the oven off automatically
if no other button is activated after a certain time.
This time varies according to the temperature
setting of the oven, and ranges from a minimum of
2 hours for temperatures above 230°C, up to 8
hours for those below 120°C.
At the end of automatic cooking, the oven will
switch off after a period of time, this depends on
the temperature selected.
The time varies between 2 hours for temperatures
above 230°C, up 8 hours for those below 120°C.
CHILD SAFETY
To avoid children altering a selected programme
or temeperature, the Child Safety facility can be
operated.
Press buttons 1 and 3 simultaneously for
approximately 5 seconds.
The padlock symbol will be displayed.
It is now only possible to select any programme
while simultaneously pressing button 1 "Child
safety".
To cancel the Child Safety Feature, press button 3
"ON". Then press button 1 and 2 simultaneously
for approximately 5 second and the padlock
symbol will disappear from the display.
Minute minder
Press button 8 and then buttons 10 or 11 to set the
desired time. This function can be used without
having to switch the oven on (ie: for boiling an
egg on a hob).
Call for technical assistance
The programmer display carries out a self check,
in order to verify that it is working correctly. If a
problem is identified the spanner symbol will be
displayed in the event of a breakdown a NUMBER
will appear. If NUMBERS 001 or 002 appear it
means that the meat probe is at fault and needs to
be replaced; if a higher number appears, please
contact your nearest Zanussi Service Force Centre
quoting the number of Fault Code.
NOTE:
Generally after about 8 seconds from pressing a
function button the programmer will allow the
selected function to operate. Should another button
be pressed during the operation of a function the
display will show momentarily details of the
function in progress. For the new command to be
accepted it will be necessary to press the other
button again.
CHILD SAFETY
123 56774

15
MEAT PROBE (Upper Oven Only) (Fig. 4)
The meat probe is a feature which will control the
cooking of meats by informing you of the exact
temperature at the centre of the meat. It is not
necessary to weigh the meat, the sensor determines
the cooking time. However, the cooking time is
obviously influenced by the cooking temperature.
The probe consists of a skewer like sensor at one
end of a heat resistant cable, and a plug at the
other end.
First raise the meat probe socket cover (1), which
is located in the top of the left hand side of the
oven and plug the probe connecting pin into its
socket (2).
Insert the probe sensor into the centre of the meat,
taking care to avoid touching any bone or pockets
of fat as this will give a false temperature reading.
Place the meat, in a suitable tin, into the oven
cavity.
As poultry is a difficult shape with a great deal of
bone it is difficult to register a correct finish
temperature, please ensure it is cooked thoroughly.
To select temperature probe press button 5, the
display will show the pre-set temperature of 60°C
and the C symbol will flash for about 8 seconds.
Then select the finished internal meat temperature
by pressing buttons 10 or 11.
Not all the cook functions allow the use of the
probe. If you have selected an incorrect function,
the probe symbol will flash red. For a correct
function, the symbol will flash white.
Select the required cooking function by pressing
button 9.
The probe will register 60°C to start with then
continue to register the internal meat temperature
throughout the cooking period and convey the
information to the programmer. This will give a
visual read-out as cooking continues, and switch
off the oven when the selected temperature has
been reached.
Press button 2 to turn the oven off.
Open the oven door and remove the probe from
the meat, then remove the probe from the socket.
Do not submerge the meat probe in water, just
wipe with a clean damp cloth.
Remove the meat probe after use.
Do not leave the meat probe in the oven when
cooking other items.
If the oven has just been previously used and
the interior is hot, it may not be possible to use
the meat probe.
If the interior temperature exceeds the meat
probe max temperature, upon selection the
Technical assistance display will appear.
Remove the meat probe from the oven and
after a few minutes the Technical assistance
display will disappear.
You can either cook the meat without the probe
or wait until the interior temperature of the
oven has dropped to below the meat probe pre-
set temperature.
12
FO 0710
MEAT PROBE
123 56774
Roasting Chart - Internal Temperatures
Pork Well done 80°C
Lamb Medium 70°C
Well done 80°C
Beef Rare 60°C
Medium 70°C
Well done 80°C
Chicken Well done 82°C
The temperatures quoted above are given as a guide only.
Fig. 4

16
Should any of the functions not be available for a particular programme you will hear an audible signal.
OVEN FUNCTION Meat Probe Auto Upper Lower
Upper Oven Only Timer oven oven
FAN DUCTED X X X
CONVENTIONAL OVEN X X X X
GRILL X X
ECONOMY GRILL X X
THERMAL GRILLING X X X
PIZZA OVEN X X
BOTTOM ELEMENT X X X
TOP ELEMENT X X X X
BREAD PROVING X X
DEFROST COLD FAN X X
OVEN FUNCTIONS
The following table lists the functions available for each type of programme.

17
FAN DUCTED OVEN
The air inside the oven is heated by the element
around the fan situated behind the back panel. The
fandrawsairfromtheoven,theelementheatstheair
whichiscirculatedintotheovenviathetop,baseand
sides of the back panel. The advantages of cooking
with this function are:
Faster Preheating
Becausethefanovenquicklyreachestemperature,it
isnotusually necessarytopreheattheoven although
you may find that you need to allow an extra 5-7
minutesoncookingtimes. Forrecipeswhichrequire
higher temperatures, best results are achieved if the
oven is preheated first, e.g. bread, pastries, scones,
souffles, etc.
Lower Temperatures
Fan oven cooking generally requires lower
temperatures than conventional cooking.
Follow the temperatures recommended in the charts
or remember to reduce temperatures by about 20-
25°C for your own recipes which use conventional
cooking.
Even Heating for Baking
The fan oven has uniform heating on all runner
positions. This means that batches of the same food
canbecookedintheovenatthesametime.However,
the top shelf may brown slightly quicker that the
lower one.
This is quite usual. There is no mixing of flavours
between dishes (see Fig. 5).
With this type of oven, it is possible to cook by using fan ducted, conventional, thermal grilling and
grilling functions. We have also added two extra functions Pizza and Bread Proving.
The following pages contain an explanation of each type or cook function and methods of using them.
Further guidelines can be found in your Zanussi Cookbook.
Cooking tips
Fig. 5
FAN DUCTED OVEN
TEMPERATURE SELECTION 50°C - 250°C
PRE-SET TEMPERATURE 170°C
HINTS AND TIPS
Runner positions are not critical, but make sure the
shelves are evenly spread.
When cooking more than one dish in the fan oven,
place dishes centrally on the shelves rather than
several dishes on one shelf.
Whentheovenisfull,youmayneedtoallowslightly
longer cooking time.
Ashelf maybeplaced onthe floorofthe oven.Place
dishes on a shelf in this position rather than on the
oven base, to allow air circulation around the food.
When the oven is full of the same food, e.g. equal
trays of small cakes or equal size victoria sandwich
cakes, then they will be cooked in the same time and
removed from the oven together. When different
sizesof traysortypes offood, e.g.biscuits andcakes
are cooked, they will not necessarily be ready
together.
FO 0061

18
The fan oven can be used to heat foods through
without thawing first, e.g. fruit tarts, mince pies,
sausage rolls, and other small pastry items. Use a
temperature of 190-200°C and allow 20-40
minutes (depending on the quantity of food in the
oven).
The use of too high temperatures can cause uneven
browning. Check with the recommendations for
oven temperatures given in the cooking charts, but
be prepared to adjust the temperature by 10°C if
necessary. Remember to reduce temperatures by
about 20-25°C for your own conventional recipes.
Only experience will enable you to determine the
proper settings for your personal cooking needs.
The temperatures are intended as a guide only. It
may be necessary to increase or decrease the
temperature to suit your individual requirements.
*The items marked by an asterisk should be performed in an oven pre-heated for 10 minutes.
If you need to cook items on more than one shelf, place them on the levels between brackets.
The times quoted above are given as a guide and should be adjusted to suit personal taste.
Cooking chart
Shelf Shelf
4
3
2
1
4
3
2
1
TYPE OF COOKING
Cooking
time
Temp. Temp.
° C ° C
QUANTITY
gr.
* 1500 English roast beef 2 220 2 200 40-60
* 1200 Roast beef 2 200 2 175 50-70
* 1200 Roast pork 2 200 2 175 100-130
* 1200 Roast veal 2 200 2 175 90-120
1000 Pork shins 2 180 2 (1,3) 160 100-120
2000 Leg of lamb 2 175 2 160 120-140
3000 Goose 2 190 2 170 140-180
1800 Duck 2 180 2 160 120-150
3500 Turkey 1 190 1 175 120-150
1200 Chicken 2 200 2 180 60-80
1200 Rabbit 2 190 2 175 60-80
1500 Fish 2 200 2 (1,3) 175 80-100
* Cannelloni/lasagne 2 200 2 (1,3) 175 40-60
* Short pastry flan case 2 190 2 (1,3) 170 25-35
* Ricotta tart 1 170 2 150 60-80
* Sponge 1 180 2 170 40-50
* Fruit cake 1 175 1 160 40-50
* Sponge cake 1 175 1 160 40-50
* Strudel 1 175 2 (1,3) 160 60-80
* 500 Small cakes/biscuits 1 190 2 (1,3) 170 10-20
* 1000 White bread 1 200 2 180 45-65
* 500 Bread rolls 1 210 2 (1,3) 190 20-30
FAN DUCTED - CONVENTIONAL OVEN
If at the end of a cooking time you want heat in
the lower or upper part of the oven, select the
required function.

19
CONVENTIONAL OVEN
Thisfunctionusesthetopandlowerelementstogive
single level cooking. This is particularly suitable for
dishes which require extra base browning such as
pizzas, quiches and flans. Gratins, lasagnes and
hotpots which require extra top browning also cook
well in the conventional oven. This form of cooking
gives you the opportunity to cook without the fan in
operation.
HINTS AND TIPS
The middle shelf position allows for the best heat
distribution.Toincreasebasebrowningsimplylower
the shelf position. To increase top browning, raise
the shelf position.
The material and finish of the baking traus and
dishes used will affect base browning. Enamelware,
dark, heavy or non-stick utensils increase base
browning, while oven glassware, shiny aluminium
orpolishedsteeltraysreflecttheheatawayandgiven
less base browning.
Always place dishes centrally on the shelf to ensure
even browning.
Standdishesonsuitablysizedbakingtraystoprevent
spillageonto thebaseof theoven andmakecleaning
easier.
Do not place dishes, tins or baking trays directly on
theovenbaseasitbecomesveryhotanddamagewill
occur.
For faster preheating use the fan oven function to
preheat the oven until the oven indicator neon goes
out,thenswich the selector tothe conventional oven
setting.
Singlelevelcookinggivesbestresults.Ifyourequire
more than one level cooking use the fan or zoned
oven functions.
DEFROST COLD FAN
The defrosting function allows you to defrost frozen
foods. The oven fan operates without heat and
circulates the air, at room temperature, inside the
oven.Thisincreasestherateatwhichdefristingtakes
place.
This function is particularly suitable for delicate
food which could be damaged by heat, e.g. cream
filled gateaux, iced cakes, pastries, bread and other
yeast products.
Care must always be taken when henadling foods in
the home. Always follow the basic rules of food
hygiene to prevent bacterial growth and cross
contaminationwhendefrosting, preparing, cooking,
cooling and freezing foods.
CONVENTIONAL OVEN
TEMPERATURE SELECTION 50°C - 250°C
PRE-SET TEMPERATURE 200°C
DEFROST COLD FAN
NO TEMPERATURE SELECTION

20
GRILL, ECONOMY GRILL
TEMPERATURE SELECTION
Important
All grilling must be carried out with the oven
door closed and the grill pan handle removed
from the pan.
Most foods should be placed on the grid in the grill
pan to allow maximum circulation of air to lift the
foodoutofthefatsandjuices.Foodsuchasfish,liver
and kidneys may be placed directly on the grill pan,
if preferred
Adjustthe gridand grillpan runnerposition toallow
for different thicknesses of food. Position the food
close to the element for faster cooking and further
away for more gentle cooking.
Food should be thoroughly dried before grilling to
minimisesplashing.Brushleanmeatsandfishlightly
with a little oil or melted butter to keep them moist
during cooking
Accompaniments such as tomatoes and mushrooms
may be placed underneath the grid when grilling
meats
When toasting bread, we suggest that the top runner
position is used with the grid in its 'high' position
Preheat the grill on a full setting for a few minutes
before sealing steaks or toasting. Adjust the heat
setting and the shelf as necessary, during cooking
The food should be turned over during cooking, as
required.
NOTE:
Forsafetyinuse,thegrillelementiscontrolledby
thethermostat.Duringcooking,thegrillcycleson
and off to prevent overheating.
ECONOMY GRILL
GRILL
A setting of up to 200°C is recommended
PRE-SET TEMPERATURE 250°C
GRILL - ECONOMY GRILL
TYPE OF
COOKING
PIECES
QUANTITY
gr.
pre-heat
minutes cooking time
upper
4
3
2
1
shelf Temp.
° C
lower
800 4 Beef fillets - 4 200 8-10 4-6
600 4 Pork chops - 4 200 8-10 5-8
800 8 Spare ribs - 4 200 6-8 4-6
500 8 Sausages - 4 200 8-10 4-6
700 4 Kebabs - 4 200 10-12 5-7
500 4 Chicken breasts - 4 200 10-12 5-7
500 6 Sole - 4 200 6-8 4-6
6 Toast bread - 4 200 3-4 1-2
The times quoted above are given as a guide and should be adjusted to suit personal taste.

21
THERMAL GRILLING
Use of thermal grilling
Thermal grilling offers an alternative method of
cooking food items normally associated with
conventional grilling.
The grill element and the oven fan operate
alternately, circulating hot air around the food.
The need to check and turn food is reduced.
Thermal grilling helps to minimise cooking smells
in the kitchen and allows you to grill with the oven
door closed. With the exception of toast and rare
steaks, you can thermal grill all the foods you
would normally cook under a conventional grill.
The lower part of the oven can be used to cook
accompaniments at the same time, e.g. tomatoes
and mushrooms with a mixed grill or breakfast.
Dishes prepared in advance such as shepherd's pie,
lasagne and au gratins can be heated through and
browned on the top using the thermal grilling
function.
NOTE:
Thermal grilling helps to minimise cooking smells
in the kitchen and is carried out with the main
oven door closed, and with the grill pan handle
removed.
THERMAL GRILLING
TEMPERATURE SELECTION 50°C - 250°C
IT IS ADVISABLE NOT TO EXCEED 200°C
PRE-SET TEMPERATURE 190°C
The times quoted above are given as a guide and should be adjusted to suit personal taste.
TYPE OF
COOKING
PIECES
QUANTITY
gr.
cooking time
upper
shelf Temp.
° C
lower
pre-heat
min.
4
3
2
1
It is advisable not to select temperatures over 200 ° C
THERMAL GRILLING
1000 2 Rolled joints - 3 180 30-40 20-30
800 4 Quartered chicken - 3 200 25-30 15-20
1000 2 Chickens - 3 190 30-35 25-30
800 1 Guinea fowl - 2 180 35-40 30-35
500 2 Pigeons - 3 180 35-40 30-35
500 4 Quail - 3 200 25-30 20-2
Vegetable gratin - 3 200 15-25 -
4 Toasted sandwiches - 3 200 3-5 1-2
9 St. Jacques shells - 3 200 15-20 -
600 2 Mackerel - 3 200 10-20 6-8
800 4 Fish slices - 3 200 10-15 8-10
Beef
Lamb
Pork
{
