ZEHRaster Plus
Zeh Graphic Systems, Inc. has teamed with Hewlett-
Packard in developing ZEHRaster Plus, a CALS CCITT
g4, TIFF, JPEG, and CGM-ATA printing solution for
HP DesignJet 700 Series, 1000 Series, CP Series, and
ColorPro CAD printers. HP users with Microsoft®
Windows®NT 4.0 and UNIX (AIX, LINUX, IRIX, HP-
UX, and Solaris) can now extend the power of their
DesignJet printer with the support of CALS, TIFF,
JPEG, and CGM files. Support for the CGM format is
available as a licensable option and can be downloaded
by visiting ZEHs website at www.zeh.com/zplus.
ZEHRaster Plus includes an interface that allows the
user to view the files (viewing not available for CGM on
UNIX) and then select the designated DesignJet printer
for direct output. The printer may be either attached
directly to the user workstation (e.g., via a parallel port)
or on the network (e.g., via an HP JetDirect card).
Extends the value of your
HP DesignJet printer with
the ability to handle TIFF,
JPEG, CGM, and CALS
formats.
Simplifies complicated
graphic imaging and
allows for immediate
access and printing of
graphic files.
Supports CGM (licensable
option), a standard format
in the air transport, GIS,
manufacturing, and oil &
gas industries, that is
rapidly gaining acceptance
in CAD applications.
Supports CALS, a federal
government and military
graphics file standard.
Supports TIFF, a high-
quality, photo-realistic
raster format output from
scanned images.
Supports JPEG, a highly
compressed format that is
popular for viewing images
over the internet.
Benefits
The user can quickly and easily select print settings
because of the simplicity of ZEHRaster Plus user
interface.

www.zeh.com
ZEH GRAPHIC SYSTEMS, INC.
1155 Dairy Ashford, Suite 105
Houston, TX 77079
U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected]
ZEH GRAPHIC SYSTEMS LTD.
Dorking Business Park
Dorking, Surrey RH4 1HJ
United Kingdom
Tel: [phone]
Fax: + 44 (0) 1306 740541
Email: [email protected]
ZEH GRAPHIC SYSTEMS LTD.
79-A Tanjong Pagar Road
Singapore 088500
Tel: [phone]
Fax: [phone]
Email: [email protected]
Outputs for printing TIFF, JPEG, CALS Type 1, binary-encoded CGM*, and CGM-
ATA files.
 Displays files in Preview window for file verification.
 Submits your file directly for printing.
 Provides user control of output size, scale, rotation angle, print mode, preview, and
cancel.
 Gives you the option of attaching your printer directly to your workstation or on a
network.
Supports Windows NT 4.0 and UNIX systems.
 Supports paper widths of 24, 36, and 54 inches.
 Prints files to HP 750 printers at 300 dpi and 600 dpi.
 Prints files to CP Series and ColorPro CAD printers at 600 dpi.
 Prints files to 1000 Series printers at 600 dpi and 300 dpi for color files in fast mode.
 Provides 22 Hershey fonts and 17 ZEH fonts for CGM files.
 Allows selection of three printer modes: best, normal, or fast.
 Provides Reverse Black-White colors option for CGM files.
Features
Zeh Graphic Systems, Inc. is a software development company specializing in
enterprise-wide network plotting solutions with headquarters in Houston, Texas, and
offices in London and Singapore. For over 17 years, ZEH has been recognized as the
leader in networked output management of large-format, high quality graphics. ZEH
provides complete network plotting solutions for worldwide clients with multiple
applications, systems, and plotters. ZEHs clientele include petroleum and chemical
companies, architectural and engineering firms, public utilities, government agencies,
aircraft and automobile manufacturers, universities, and service bureaus. For more
information on ZEH products, visit our website at www.zeh.com or contact our
corporate office at [phone].
*Support for CGM files is a licensable option which can be downloaded via www.zeh.com/zplus.
