Zennio ZPRHP Guide

© Zennio Avance y Tecnología S.L. Edition 1 Further information www.zennio.com Page 1/4
ALLinBOX Hospitality
Multifunction device with KNX power supply, KNX-IP Interface,
fan coil controller for 2-pipe unit and 6 a/d inputs
ZPRHP TECHNICALDOCUMENTATION
FEATURES
160 mA KNX power supply with 29 VDC auxiliary output
110-240 VAC 50/60 Hz power input
Power generation for the KNX system (with LED indicator)
Short-circuit and overvoltage protection
Reset button and overload status LED
KNXnet/IP tunnelling protocol (up to 5 connections)
Maximum APDU length of 254 bytes
Ethernet 10/100 BaseT IP with RJ45 socket
Individual output and 2-pipe fan coil control
Individual output suitable for capacitive loads, maximum 140 µF
Manual output operation through remote control
6 analogue/digital inputs
Climate control for up to 2 rooms
Output timing
20 logic functions
Clock with NTP support
Total data saving on KNX bus failure
Integrated KNX BCU (TP1-256)
Dimensions 67 x 90 x 79 mm (4.5 DIN units)
DIN rail mounting according to IEC 60715 TH35, with fixing clamp
Conformity with the CE, UKCA, RCM directives (marks on the right
side)
1. Main power supply 2. Power supply status
LED 3. Overload status LED 4. Reset button 5. Reset status LED
6. IP factory reset button 7. IP factory reset LED 8. Ethernet LED 9. KNX bus LED 10. Analog/digital inputs
11. Auxiliary power output 12. Programming/Test
button 13. Programming/Test LED 14. KNX connector 15. Fixing clamp
16. Individual output 17. Valve output 18. Fan outputs 19. Ethernet connector 20. IR input
21. Remote control (not included, ref. 9900024)
PROGRAMMING/TEST BUTTON: short press to set programming mode. If this button is held while providing main power supply to the device, it enters
the safe mode. If this button is held for more than 3 seconds, the device enters the test mode.
RESET BUTTON: long press to completely reset the bus and auxiliary power output. It is recommended to hold it for at least 5 seconds to verify the
reset of all the devices in the line.
PROGRAMMING/TEST LED: programming mode indicator (red). When the device enters the safe mode, it blinks (red) every half second. The manual
mode is indicated by the green color. During the start-up (reset or after providing main power supply) and if the device is not in safe mode, it starts a
blue blinking sequence.
POWER SUPPLY STATUS LED: it indicates the status of the power supply (green color: the device is working properly; off LED: power supply failure;
green blinking: short-circuit on KNX bus and/or auxiliary power output).
OVERLOAD STATUS LED: it indicates an overload on the KNX line or on the auxiliary power output (red blinking: cut-off due to overload/short circuit
on the KNX bus and/or the auxiliary power output*; red color: overload on bus and/or auxiliary power output line*).
*Reduce the load on the bus and/or the auxiliary power output lines until its total consumption does not exceed the maximum current specified.
KNX BUS LED: it indicates that the device is powering up the KNX bus (green color).
ETHERNET LED: it indicates that the device is connected to Ethernet and has an IP address assigned (green color).
RESET INDICATOR LED: it indicates that a reset of the KNX system has been performed by using the corresponding reset button (red blinking). To
reset the bus power supply, the Reset button should be pressed (it is recommended to hold it for at least 5 seconds to verify the reset of all the devices
in the line). The reset LED will blink slightly in red while the Reset button is pressed.
IP FACTORY RESET INDICATOR LED: it indicates that the device has just performed an IP factory reset (red color). To reset the KNX IP Interface,
the IP Factory reset button must be pressed for at least 3 seconds.
MANUAL CONTROL: In order to perform manual control of the device, an IR remote control (not included; ref. 9900024) is necessary. When the device
is in Test On mode, the manual control can be done by pressing the corresponding buttons on the IR remote control (please, be sure that the remote
IR emitter is pointing to the IR input of ALLinBOX).
Figure 1: ALLinBOX Hospitality
9
2
5
4
8
1 6 7
3
10 18
11
12 13 14 15 16
20
19
21
17

© Zennio Avance y Tecnología S.L. Edition 1 Further information www.zennio.com Page 2/4
GENERAL SPECIFICATIONS
CONCEPT
DESCRIPTION
Type of device
Electric operation control device
External
power supply
Voltage
110
-
240
VAC 50/60
Hz PF=0.5
Maximum consumption
150
mA
@
110
VAC / 75
mA
@
230
VAC
KNX supply
Voltage (typical)
29
VDC
SELV (with KNX coil)
Maximum rated current
(
I
BUS
)
160
mA
Connection type
Typical TP1 bus connector for 0.8
mm Ø rigid cable
Additional
output Voltage (typical) 29 VDC SELV
Maximum rated current
(
I
AD
)
I
AD
+ I
BUS
≤
25
0
mA
Operation
temperature
-
5 .. +45
°C
Storage temperature
-
20 .. +55
°C
Operation humidity
5 .. 95%
Storage humidity 5 .. 95%
Complementary characteristics
Class B
Protection class / Overvoltage category
II / III (4000
V)
Operation type
Continuous
operation
Device action type
Type 1
Electrical stress period Long
Degree of protection / Pollution degree
IP20 / 2 (clean environment)
Installation Independentdeviceto be mountedinsideelectricalpanelswith DINrail(IEC
60715)
Minimum
clearances
Not required
Power failure back
-
up time
110
ms
Maximum current before overload notification
300
mA
Response on KNX bus failure
Data saving according to parameterization
Response on KNX bus restart
Data recovery according to
parameterization
Operation indicator
See page 1
Weight 301 g
PCB CTI index
175
V
Housing material / Ball pressure test temperature
PC FR V0 halogen free / 75
°C (housing)
-
125
°C (connectors)
MAIN POWER SUPPLY SPECIFICATIONS AND
CONNECTIONS
CONCEPT
DESCRIPTION
Power supply protection
fuse
Voltage
110
-
240
VAC 50/60
Hz
Current
4
A
Response type
F (Fast acting)
Connection method
Screw terminal block (0.5
Nm max.)
Cable cross
-
section
1.5
-
4
mm² (IEC) / 26
-
10
AWG (UL)
AUXILIARY POWER OUTPUT SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Connection method
Screw terminal block (0.5
Nm max.)
Cable cross
-
section
1.5
-
4
mm² (IEC) / 26
-
10
AWG (UL)
OUTPUTS SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Output type / Disconnection type
Potential
-
free outputs through bistable relays / Micro
-
disconnection
Outputs per common
Individual / Valve
1
Fan
3
Different phases connection (valve and individual
outputs)
Possibility of connecting different phases between individual and valve
output. It is allowed to connect power supplies of different order, SELV with
NO SELV, in individual and valve output.
Connection method
Screw terminal block (0.4
Nm max.)
Cable
cross
-
section
0.5
-
2.5
mm² (IEC) / 26
-
12
AWG (UL)
F1
-
3 / V OUTPUTS
Rated current per output AC 8(4) A @ 250VAC (2000VA)
DC 5
A @ 30VDC (150W)
Maximum load per output
Resistive
2000
W
Inductive
1000
VA
Mechanical lifetime (min. cycles)
1 000 000
INDIVIDUAL
OUTPUT
Rated current per output AC 16(6) A @ 250 VAC (4000 VA)
DC 7
A @ 30
VDC (210
W)
Maximum load per output
Resistive
4000
W
Inductive
1500
VA
Maximum inrush current 800 A/200 μs
165
A/20
ms
Maximum response time 10 ms
Mechanical lifetime (min. cycles)
3 000 000
Electrical lifetime (min. cycles)
1
100000 @ 8
A / 25000 @ 16
A (VAC)
¹ Lifetime values could change depending on the load type.

© Zennio Avance y Tecnología S.L. Edition 1 Further information www.zennio.com Page 3/4
O
L
N
V O
L1
N
V
L2
L
L
N
F1 F2 F3
III III
WIRING DIAGRAMS
Figure 2: Wiring example (from left to right): three-speed fan, load and open/close valve,
load
and open/close valve to different phases.
* In case of using ZN1IO-DETEC-P sensor, its micro switch number 2 must be in Type B position.
** Zennio temperature probe or any NTC with known resistance values at three points in the range [-55, 150 ºC].
INPUTS CONNECTION
Any combination of the following accessories is allowed in the inputs:
Zennio temperature
probe.
Up to two motion sensors
can be plugged into the
same device input (parallel
wiring)
Screw terminal for
connecting Zennio motion
sensors*.
Temperature Probe**
Motion Sensor
Switch/Sensor/
Push button
INPUTS SPECIFICATIONS AND
CONNECTIONS
CONCEPT
DESCRIPTION
Number of inputs
6
Inputs per common
3
Operation voltage +3.3 VDC in the common
Operation current
1
mA @ 3.3
VDC (per input)
Switching type
Dry voltage contacts between input and common
Connection method
Screw
terminal block (0.4
Nm max.)
Cable cross
-
section
0.5
-
2.5
mm² (IEC) / 26
-
12
AWG (UL)
Maximum cable length 30 m
NTC probe length
1.5
m (extensible up to 30
m)
NTC accuracy (@ 25
°C) ²
±0.5
°C
Temperature resolution
0.1
°C
Maximum response time
10
ms
² For Zennio temperature probes.
⚠In order to ensure the expected status of the relays, please check that the device is connected to the main power supply before energizing the
power circuit.
⚠Commons of different devices
must not be connected together.

© Zennio Avance y Tecnología S.L. Edition 1 Further information www.zennio.com Page 4/4
Attaching ALLinBOX Hospitality to DIN rail:
Removing ALLinBOX Hospitality from DIN rail:
SAFETY INSTRUCTIONSAND ADDITIONAL NOTES
Installation should only be performed by qualified professionals according to the laws and regulations applicable in each country.
Do not connect the mains voltage nor any other external voltage to any point of the KNX bus; it would represent a risk for the entire
KNX system. The facility must have enough insulation between the mains (or auxiliary) voltage and the KNX bus or the wires of other
accessories, in case of being installed.
The facility must be equipped with a device that ensures the omnipolar sectioning. Installation of a 10 A mini-circuit-breaker is
recommended. To prevent accidents, it must remain open in case of manipulation of the device.
The device has a short-circuit protection fuse that, in case of activation, should only be rearmed or replaced by the Zennio technical
service.
This device contains a security short-circuit proof transformer.
Once the device is installed (in the panel or box), it must not be accessible from outside.
For indoor use only.
Keep the device away from water (condensationover the device included) and do not coverit with clothes, paperor any othermaterial
while in use.
The WEEE logo means that this device contains electronic parts and it must be properly disposed of by following the instructions at
https://www.zennio.com/en/legal/weee-regulation.
This device contains software subject to specific licences. For details, please refer to http://zennio.com/licenses.
INSTALLATION AND CONNECTION
This device must be exclusively installed ina 35 mm DIN rail
inside a distribution box or an electrical panel.
Ensure suitable ventilation to prevent the temperature from
exceeding the permissible range.
Main power must be connected to L, N and ground
terminals.
The coil integrated bus output must be connected through a
standard KNX connector.
The additional output connection must be connected
according to the polarity indicated on the housing.
Figure 3: Mounting ALLinBOX Hospitality on DIN rail
