Zenoah 3300E User manual

848C3593B3 (711)
CHAIN SAW
November 2007
NOTE :
1. Use ZENOAH genuine parts specified in the parts list for repair and/or replacement.
2. ZENOAH does not warrant the machines, those which have been damaged by the use of any parts
other than those specified by the company.
3. When placing orders of parts for repair and/or replacement, check if the model name and the serial
number are suitable to those specified in the parts list, then use parts number described in the
parts list.
4. The contents described in the parts list may change due to improvement.
5. The parts for the machine shall be supplied within ten (10) years after the machine is discontinued.
[It is possible that some specific parts may be subject to change of their delivery term and list price
within the limit of ten (10) years after the machine is discontinued. And it is also possible that some
parts may be available even after the limit of ten (10) years.]
APPLICABLE SERIAL NUMBERS : 712711 and up
G3300
G3300EZ
G3300E
PARTS LIST

Fig.1 POWER UNIT
G3300/G3300EZ/G3300E

Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
58 T2200-21400 PIPE OUT COMP. 1
59A 848C357111 ROTOR COMP. 1 G3300
59B 848C307111 ROTOR COMP. 1 G3300EZ
G3300E
60A 848C357121 COIL ASSY 1 G3300
60B 848C307121 COIL ASSY 1 G3300EZ
G3300E
61 2850-72110 • CAP 1
62 1400-72121 • SPRING 1
63 5500-72130 • GROMMET 1
64 1650-43230 NUT M8xP1.0 1
65 2670-55410 SCREW M4xL14 T20 2
66 3699-90032-10 SPARK PLUG 1 BPMR7A
67 T2100-31500 PIPE COMP. 1
68 2850-81900 PUMP 1
69 2850-82611 PIPE 1
70A 848C3590F0 LABEL, caution 1 G3300
70B 848C3690F0 LABEL, caution 1 G3300EZ
70C 848C3F90F0 LABEL, caution 1 G3300E
71 848C3090E0 LABEL, choke 1
72 T2990-21120 LABEL 1
73 848C1B90G0 LABEL, hot mark 1 G3300E
848C300610 GASKET KIT 1 OPTION
(✽: #2,10,27,33,34)
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848C3012A1 CYLINDER 1
2T2200-14210 GASKET, cyl 1 ✽
3848C302102 CASE ASSY 1
506030-06201 • BEARING 2
604065-03212 • SNAPRING ø32 1
72169-21210 • SEAL 1
88488AC3210 • SEAL 1
92616-21230 • STUD 1
10 848C3021D1 • GASKET 1 ✽
11 8488Y56000 SPACER 1
12 T2200-41110 PISTON 1
13 T2102-41210 RING 1
14 T2200-41310 PIN 1
15 3310-41320 RING 2
16 3310-41410 BEARING 1
17 1650-41510 WASHER 2
18 T2200-42000 SHAFT COMP. 1
19 4820-13180 BOLT TORX M5xL20 T27 8
25 T2200-15110 MUFFLER 1
26 T2200-15310 STAY 1
27 T2100-15210 GASKET 1 ✽
28 T2100-15220 BOLT 2
29 2850-15230 NUT 2
30 8488151400 SCREW M5xL14 T27 1
31 848C3014A1 INSULATOR 1
32 T2200-31120 CAP 1
33 848C3014B1 GASKET, in 1 ✽
34 3330-14121 GASKET,carb 1 ✽
35 848C3A8100 CARBURETOR ASSY 1 WT748
36 848C3082A2 MANIFOLD 1
37 2867-82210 BOLT M4x70 2
38 8488251601 SCREW TP5(P-tight)xL16 T27 1
39 848C3082F2 ROD CHOKE 1
40 T2200-83100 CLEANER 1
41 848C3031A2 COVER 1
42 T2220-51110 DRUM 3/8x6T ø60 1
43 848C305121 CLUTCH 1
44 848C3051E2 • SPRING 3
45 T2041-51210 PLATE 1
46 3310-51310 BEARING 1
49 848CA00640 OIL PUMP SET 1
• OIL PUMP 1
• WORM 1
52 2850-55211 WASHER 1
53 T2200-55610 COVER 1
54 2670-55410 SCREW M4xL14 T20 2
55 2670-54630 SCREW TP4(B-tight)xL12 T20 1
56 T2100-23200 FILTER COMP. 1
57 848C306732 PIPE IN COMP. 1
Fig.1 POWER UNIT
G3300/G3300EZ/G3300E

Fig.2 POWER UNIT
G3300

Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
59 8488251601 SCREW TP5(P-tight)xL16 T27 1
60 01640-20508 WASHER 1
65 848C355403 BRAKE ASSY 1
66 2670-54630 • SCREW TP4(B-tight)xL12 T20 4
67 848C3054A2 • GUARD 1
68 2850-54120 • SPRING 1
69 2850-54130 • SCREW 1
70 2850-54140 • SPACER 1
71 2850-54211 • SPACER 1
72 848C605423 • WEIGHT 1
73 2872-54230 • SPRING 1
74 2851-54270 • SPRING 1
75 3330-75411 • WASHER 1
76 3310-53331 • NUT 1
77 2851-54301 • LEVER COMP. 1
78 2851-54350 • ROLLER 1
79 2670-54411 • ARM 1
80 T2200-54510 • BAND 1
81 3356-24140 • ROLLER 1
82 2670-54610 • SPRING 1
83 848C3053C2 • COVER 1
86 848C3066C1 • PLATE(B) 1
88 3350-53410 NUT 1
91 848C3090K0 LABEL 1
92 848C3090L0 LABEL 1
93 848C3590B1 LABEL, cover 1
94 848C3590C1 LABEL, case 1
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848C3082H3 ROD 1
2848C3082G2 GROMMET 1
3848C3025A2 CASE 1
48488151400 SCREW M5xL14 T27 4
58488251911 SCREW TP5(P-tight)xL19 T27 1
6848C3025C2 KNOB 1
7848C3025D0 CLIP 1
8 T2200-21230 BOLT 1
9848C306612 PLATE 1
10 848C3066F2 CATCHER 1
11 8488251911 SCREW TP5(P-tight)xL19 T27 1
12 3310-53320 NUT 1
13 8488353900 SCREW 1
14 2850-74102 SWITCH ASSY 1
15 848C3072C1 CORD EARTH 1
16 848C3072B1 CORD SWITCH 1
20 848C357502 STARTER ASSY 1
21 848C3575C1 • REEL 1
22 2841-75300 • SPRING COMP. 1
23 T2044-75410 • ROPE ø3 1
25 1400-75170 • KNOB 1
26 T2044-75420 • KNOB CAP 1
27 T1812-75150 • SCREW M5xL12 1
28 848C3074B0 • CUSHION 1
29 848C3074A1 COVER 1
30 8488251911 SCREW TP5(P-tight)xL19 T27 3
31 848C3332A1 HANDLE 1
32 8488252711 SCREW TP5(P-tight)xL27 T27 4
33 848C303311 HANDLE COMP. 1
34 848C3033C1 LEVER 1
35 3356-33321 SPRING 1
36 848C3033E3 ARM 1
37 848C3033L1 COVER 1
38 8488251911 SCREW TP5(P-tight)xL19 T27 1
39 848C108512 CAP ASSY 1
40 2841-31820 • GASKET 1
41 848C208511 CAP ASSY 1
42 2841-31820 • GASKET 1
48 2850-34501 BREATHER ASSY 1
49 848C3085U0 GROMMET 1
50 848C308530 PIPE ASSY 1
51 1850-85300 FILTER 1
52 2850-34350 COLLAR 1
53 848C3037A1 SPRING F 1
54 848C3037B1 SPRING M 1
55 848C3037C1 SPRING P 1
56 8488251901 SCREW TP5(P-tight)xL19 T27 5
57 848C3037D2 HELPER 2
58 848C3037E1 BAND 1
Fig.2 POWER UNIT
G3300

Fig.3 POWER UNIT
G3300EZ

Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
60 01640-20508 WASHER 1
65 848C365401 BRAKE ASSY 1
66 2670-54630 • SCREW TP4(B-tight)xL12 T20 3
67 848C3054A2 • GUARD 1
68 2850-54120 • SPRING 1
69 2850-54130 • SCREW 1
70 2850-54140 • SPACER 1
71 2850-54211 • SPACER 1
72 848C605423 • WEIGHT 1
73 2872-54230 • SPRING 1
74 2851-54270 • SPRING 1
75 3330-75411 • WASHER 1
76 3310-53331 • NUT 1
77 2851-54301 • LEVER COMP. 1
78 2851-54350 • ROLLER 1
79 2670-54411 • ARM 1
80 T2200-54510 • BAND 1
81 3356-24140 • ROLLER 1
82 2670-54610 • SPRING 1
83 848C3053C2 • COVER 1
84 T2200-53200 • LINK A 1
85 T2200-53280 • SPRING 1
86 848C3066C1 • PLATE(B) 1
87 848C305341 • NUT ASSY 1
91 848C3090K0 LABEL 1
92 848C3090L0 LABEL 1
93 848C3090B1 LABEL, cover 1
94 848C3690C1 LABEL, case 1
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848C3082H3 ROD 1
2848C3082G2 GROMMET 1
3848C3025A2 CASE 1
48488151400 SCREW M5xL14 T27 4
58488251911 SCREW TP5(P-tight)xL19 T27 1
6848C3025C2 KNOB 1
7848C3025D0 CLIP 1
8 T2200-21230 BOLT 1
9848C306612 PLATE 1
10 848C3066F2 CATCHER 1
11 8488251911 SCREW TP5(P-tight)xL19 T27 1
14 2850-74102 SWITCH ASSY 1
15 848C3072C1 CORD EARTH 1
16 848C3072B1 CORD SWITCH 1
20 848C307502 STARTER ASSY 1
21 848C307520 • REEL COMP. 1
22 2841-75300 • SPRING COMP. 1
23 T2044-75410 • ROPE ø3 1
24 T2044-75510 • PULLEY 1
25 1400-75170 • KNOB 1
26 T2044-75420 • KNOB CAP 1
27 T1812-75150 • SCREW M5xL12 1
28 848C3074B0 • CUSHION 1
29 848C3074A1 COVER 1
30 8488251911 SCREW TP5(P-tight)xL19 T27 3
31 T2200-32100 HANDLE 1
32 8488251901 SCREW TP5(P-tight)xL19 T27 4
33 848C303311 HANDLE COMP. 1
34 848C3033C1 LEVER 1
35 3356-33321 SPRING 1
36 848C3033E3 ARM 1
37 848C3033L1 COVER 1
38 8488251911 SCREW TP5(P-tight)xL19 T27 1
39 848C108512 CAP ASSY 1
40 2841-31820 • GASKET 1
41 848C208511 CAP ASSY 1
42 2841-31820 • GASKET 1
48 2850-34501 BREATHER ASSY 1
49 848C3085U0 GROMMET 1
50 848C308530 PIPE ASSY 1
51 1850-85300 FILTER 1
52 2850-34350 COLLAR 1
53 848C3037A1 SPRING F 1
54 848C3037B1 SPRING M 1
55 848C3037C1 SPRING P 1
56 8488251901
SCREW TP5(P-tight)xL19 T27 5
57 848C3037D2 HELPER 2
58 848C3037E1 BAND 1
59 8488251601
SCREW TP5(P-tight)xL16 T27 1
Fig.3 POWER UNIT
G3300EZ

Fig.4 POWER UNIT
G3300E

Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
60 01640-20508 WASHER 1
65 848C3A5401 BREAK ASSY 1
66 2670-54630 • SCREW TP4(B-tight)xL12 T20 4
67 848C3054A2 • GUARD 1
68 2850-54120 • SPRING 1
69 2850-54130 • SCREW 1
70 2850-54140 • SPACER 1
71 2850-54211 • SPACER 1
72 848C605423 • WEIGHT 1
73 2872-54230 • SPRING 1
74 2851-54270 • SPRING 1
75 3330-75411 • WASHER 1
76 3310-53331 • NUT 1
77 2851-54301 • LEVER COMP. 1
78 2851-54350 • ROLLER 1
79 2670-54411 • ARM 1
80 T2200-54510 • BAND 1
81 3356-24140 • ROLLER 1
82 2670-54610 • SPRING 1
83 848C3053C2 • COVER 1
84 848C3066C1 • PLATE(B) 1
85 2841-53240 • SCREW 1
86 848C3366K0 • NUT 1
87 2671-53230 • GEAR 1
88 3350-53410 NUT 1
91 848C3090K0 LABEL 1
92 848C3090L0 LABEL 1
93 848C3590B1 LABEL, cover 1
94 848C3F90C1 LABEL, case 1
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848C3082H3 ROD 1
2848C3082G2 GROMMET 1
3848C3025A2 CASE 1
48488151400 SCREW M5xL14 T27 4
58488251911 SCREW TP5(P-tight)xL19 T27 1
6848C3025C2 KNOB 1
7848C3025D0 CLIP 1
8 T2200-21230 BOLT 1
9848C306612 PLATE 1
10 848C3066F2 CATCHER 1
11 8488251911 SCREW TP5(P-tight)xL19 T27 1
14 2850-74102 SWITCH ASSY 1
15 848C3072C1 CORD EARTH 1
16 848C3072B1 CORD SWITCH 1
20 848C307502 STARTER ASSY 1
21 848C307520 • REEL COMP. 1
22 2841-75300 • SPRING COMP. 1
23 T2044-75410 • ROPE ø3 1
24 T2044-75510 • PULLEY 1
25 1400-75170 • KNOB 1
26 T2044-75420 • KNOB CAP 1
27 T1812-75150 • SCREW M5xL12 1
28 848C3074B0 • CUSHION 1
29 848C3074A1 COVER 1
30 8488251911 SCREW TP5(P-tight)xL19 T27 3
31 T2200-32100 HANDLE 1
32 8488251901 SCREW TP5(P-tight)xL19 T27 4
33 848C303311 HANDLE COMP. 1
34 848C3033C1 LEVER 1
35 3356-33321 SPRING 1
36 848C3033E3 ARM 1
37 848C3033L1 COVER 1
38 8488251911 SCREW TP5(P-tight)xL19 T27 1
39 848C108512 CAP ASSY 1
40 2841-31820 • GASKET 1
41 848C2085G1 CAP ASSY 1
42 2841-31820 • GASKET 1
48 2850-34501 BREATHER ASSY 1
49 848C3085U0 GROMMET 1
50 848C308530 PIPE ASSY 1
51 1850-85300 FILTER 1
52 2850-34350 COLLAR 1
53 848C3037A1 SPRING F 1
54 848C3037B1 SPRING M 1
55 848C3037C1 SPRING P 1
56 8488251901
SCREW TP5(P-tight)xL19 T27 5
57 848C3037D2 HELPER 2
58 848C3037E1 BAND 1
59 8488251601
SCREW TP5(P-tight)xL16 T27 1
Fig.4 POWER UNIT
G3300E

Fig.5 CARBURETOR COMPONENTS
G3300/G3300EZ/G3300E
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848C3A8100 CARBURETOR ASSY 1
2848C3A0630 • REBUILD-KIT 1 (OP)
33306-81380 • • SCREEN 1
43356-81310 • • VALVE 1
52841-81270 • • SPRING 1
63310-81250 • • PIN 1
73310-81240 • • SCREW 1
83310-81230 • • LEVER 1
9T2100-06020 • • GASKET KIT 1 (OP)
10 3304-81140 • • • GASKET 1
11 1172-81150 • • • DIAPHRAGM 1
12 2850-81290 • • • GASKET 1
13 3310-81260 • • • DIAPHRAGM 1
14 2850-81120 • COVER 1
15 3310-81130 • SCREW 1
16 3310-81280 • COVER 1
17 1480-81420 • PLUG 1
18 1148-81390 • RING 1
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
19 3310-81341 • VALVE 1
20 2880-81470 • SCREW 3
21 2670-81410 • SPRING 1
22 848C3A81T0 • SHAFT 1
23 2630-81330 • SCREW 1
24 3350-81380 • SPRING 1
25 2670-81440 • LEVER 1
26 2850-81190 • SCREW 1
27 2841-81450 • VALVE 1
28 T2002-81350 • SPRING 1
29 848C3081E0 • SHAFT 1
30 2850-81430 • BUSHING 1
31 3310-81351 • SCREW 4
32 2810-81530 • SPRING 1
33 848C7180N0 • PISTON 1

Fig.6 ACCESSORIES
G3300/G3300EZ/G3300E
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
1848CB24G23 BAR 35-3/8 1
2848CC91S52 CHAIN OREGON 91VX-52E 1
33617-97110 PROTECTOR 300~350mm 1
43320-91140 WRENCH 1
52670-91150 DRIVER 1 OPTION
62850-96410 WRENCH 1 OPTION
73317-91210 FILE 1 OPTION
83310-91540 GAUGE 1 OPTION
93330-97310 GAUGE 1 OPTION
10 2670-96220 STOPPER 1 OPTION
11 2670-96510 GUIDE 1 OPTION
