ZEP 17'' dual speed Manual

17” & 20” DUAL SPEED
MODELS
POLISHERS
READ THIS BOOK
This operator’s book has important information for the
use and safe operation of this machine. Read this book
carefully before starting the machine. Keep this book
and tell all operators to read the book. If you do not
follow the instructions, you can cause an injury or dam-
age equipment, furniture or buildings.
For new books write to:
Carefully inspect all components to ensure that there is
no concealed freight damage. If such damage is dis-
covered, file a “CONCEALED DAMAGE REPORT” im-
mediately with the delivering carrier.
The contents of this manual are based on the latest
product information available at the time of publica-
tion. Zep Inc. reserves the right to make changes or
improvements to its machines without notice.
FOR YOUR CONVENIENCE, RECORD THE MA-
CHINE MODEL AND SERIAL NUMBER:
MODEL_______________________________
SERIAL NUMBER_______________________
PART NUMBER_________________________
DATE PURCHASED_______________________
OPERATING & MAINTENANCE
INTRODUCTION INSTRUCTIONS
Zep Inc. - Equipment Division
1340 Seaboard Industrial Blvd.
Atlanta, GA 30318

IMPORTANT SAFETY INSTRUCTIONS
Toassurethesafeoperationofthismachine,youmustreadandunderstandall warnings and instructions in this book.
Ifyoudonot understand,askyoursupervisor.
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE
WARNING: To reduce the risk of fire, electric shock, or injury:
1. You must be trained to operate this machine. This machine is to be operated for its intended use only.
2. Do not operate this machine unless it is completely assembled.
3. Always use a three-wire electrical system connected to the electrical ground. For maximum protection against
electricalshock,usea circuit that is protected by agroundfaultcircuit interrupter. Consultyour electrical contrac-
tor.
4. To prevent electric shock, always remove the electrical plug from the electrical outlet before doing any repairs or
maintenanceand when leaving the machineunattended.
5. To prevent electric shock,keepthemachinesurfacedry. Donot subject to rain. Storethe machine in a dry building
area. Clean the machine with a dry cloth only.
6. Machines can cause an explosion when near flammable materials and vapors. Do not use this machine with or
near fuels, grain dust, solvents, thinners, or other flammable materials. Do not use flammables to clean this
machine.
7. Aqualified or authorized person must do maintenanceandrepairs.
8. Topreventdamageto thepowercord,donot movethismachineoverthe powercord. Alwaysliftthepowercordover
themachine. Donot pull or carry cord, use cordasahandle,closea door on cord, or pull cordaroundsharpedges
orcorners. Keep cord away from heated surfaces.
9. Do not use withdamagedcordorplug. Ifthe machine is not working asitshould,hasbeendropped, damaged, left
outdoors,or dropped into water, returnit to a service center.
This machine must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for electric
currenttoreducethe riskof electricshock. This machineis equipped
with a cord having an equipment-grounding conductor and ground-
ing plug. The plug must be inserted into an appropriate outlet that
is properly installed and grounded in accordance with all local
codes and ordinances.
WARNING - Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check with a
qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug
provided with the machine - if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
This machine is for use on a nominal 120-volt circuit, and has a
grounded plug that looks like the plug illustrated in figure A. A
temporary adapter that looks like the adapter illustrated in figures B
and C may be used to connect this plug to a 2-pole receptacle as
shown in figure B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly
grounded outlet (figure A) can be installed by a qualified electri-
cian. The green colored rigid ear, lug, or the like extending from the
adapter must be connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the adapter is
used, it must be held in place by a metal screw.
NOTE: In Canada, the use of a temporary adapter is not permitted
by the Canadian Electrical Code
EXTENSIONCORDS
Use only three-wire 12/3 or larger gauge approved extension
cords that have three-prong grounding type plugs and three-pole
receptacles that accept the appliance’s plug. Replace or repair
any damaged cords or plugs.
When servicing, refer to authorized person only. Use only identi-
cal replacement parts.
GroundingInstructions
NOTE: Do not use adapters shown in figures B & C in Canada
2

OPERATINGPROCEDURES
WARNING! For the safe operation of this machine
follow the instructions given in this manual and
the training given by your supervisor. Failure to
do so can result in personal injury and/or damage
to machine and property!
DONOTOPERATE MACHINEINAN EXPLOSIVEEN-
VIRONMENT!
Thismachine is intended for commercial use.
PREPARATION
Topreparethemachineforoperation,make sure it is of
correctvoltageand properly assembled.
Your new floor machine operates in the normal side to
sidemotion of a conventional single disc machine. Be
preparedbefore startingbyremovingall obstructions or
other obstacles in the area to be cleaned. Check the
proper application recommendations and procedures
found on the label of your cleaning or finish container.
IFIN DOUBT, CALL
YOURSUPERVISOR.
WARNING! NEVERUSETHIS MACHINE WITHFLAM-
MABLEOR EXPLOSIVE MATERIAL!
For Scrubbing or Polishing: Select the correct
floor pad or brush (your supplier can help you). If in
doubt,askyoursupervisor.
NEVER OPERATE THE MACHINE WITHOUT THE
FLOORPAD OR BRUSH INSTALLED!
To properly attach the brush, UNPLUG THE FLOOR
MACHINE,placethehandleinthe verticalposition,then
tiltthe machine back until the handlerestson the floor.
Straddle the handle, facing the motor, and grasp the
brush with the block toward you. Place the brush or
pad clutch plate over the three lugs on the motor drive
adapter. Twistthe brush right to lock it into position. To
removethe brush,UNPLUGTHEMACHINE andfollow
thesame procedure asabove,butby twisting thebrush
offwitha firm jerk to the left. Removethe brush or pad
driver when the machine is not in use. This will help
preventbrush damage andreducewobbleproblems.
DUAL SPEED CONTROL: Arocker switch is located
onthemotordrip cover. Presstheswitch in on the side
labeledLOWfor175RPMpadspeedor toHIGH for300
RPMpadspeed.
OPERATION
Plugthemachine’spowercableintoaproperlygrounded
outlet(see Safety Instructions). Next,adjustthehandle
heighttoa comfortable position.
Pull out on the “Watch Dog” Safety Lock button and
start the machine by depressing either the left or right
switchlevers.
Both hands should be placed on the handle when the
machine is in operation. The machine will glide side-
ways over the floor by a slight raising and lowering of
the handle. Raise the handle slightly to go to the right.
Lower the handle slightly to go left. Releasing the
switch lever stops the machine.
For Spray Buffing: A diluted spray material of about
one part water to one part solution is recommended.
Heavierspray buffsolutionswillbog downthemachine,
loadup the pad andadverselyaffectthemachine’s effi-
ciency.
MAINTENANCE
AFTER EACH USE: Store the machine in a clean dry
area. Wipe the entire machine and cord down with a
clean cloth. Remove the pad or brush and clean thor-
oughly. Wrap the machine’s electrical cord onto the
handles and the cord hook provided. CHECK the cord
and plug for nicks, cuts or damage. Report these to
yoursupervisor for correction.
WARNING! Always disconnect the machine’s elec-
trical plug from the electrical outlet before per-
forming any service, maintenance, pad changing
or inspection of the machine.
MOTOR: The motor is lubricated for life under normal
use. Nooiling orgreasingisnecessary. However,if the
machine is used in dusty areas or is used for spray
buffing, the motor should be cleaned. Blowing the mo-
tor out with compressed air or with the exhaust from a
vacuum is suggested. Keeping the motor clean will al-
low the clear passage of air for ventilation and prevent
overheating. If you have any questions regarding the
maintenance of your floor machine, ASK YOUR SU-
PERVISOR.
CARBON BRUSH INSPECTION: Long life3000-hour
carbonbrushes are installedin themotor. Themachine
is also equipped with a carbon brush wear indicator to
signalwhenacarbonbrush change is required.
3

17” & 20” DUAL SPEEDS
4
MOTOR&GEAR
ASSEMBLY

17” & 20” DUAL SPEEDS
PARTS LIST
5
ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY.
1 962002 Screw,10-32 x1/2 Oval 2 42 W502D Nut,1/2-13 Hex 2
2 504810 Interlock Assembly 1 43 962010 Screw,1/4-20 x1 HH 4
3 962011 Screw,10-32 x1 3/4 Oval 2 44 980004 Washer,1/4 Flat 4
4 486407 Cover,Switch Box 1 45 481202 Bumper,17" GrayNon-Marking 1
5 509821 Washer,Rubber 2 481203 Bumper,20" GrayNon-Marking 1
6 920005 Nut,3/8-24 HexJam 1 46 505265 Motor & Gear Assembly,1.5HP-115V 1
7 485002 Switch Kit 1 505266 Motor & Gear Assembly,1.5HP-220V 1
8 980018 Washer,#10 Countersunk 1 47 502397 Cover,Motor,Dual Speed 1
9 505121 Lever,Switch Left 1 48 962026 Screw,8-32 x1/2 3
10 505120 Lever,Switch Right 1 A 504209 Housting-Ring Gear 1
11 920001 Nut, 10-32 Nyloc Stop 1 B 902004 Bearing,Motor Bottom 1
12 509830 Washer,Handle Tube 1 C - Housing,Idler 1
13 503320 Flange,Strain Relief 1 D 902006 Bearing,Lower Pinion 1
14 505720 Nipple, Handle 2 E 960016 Screw,Ring Gear Housing 6
15 481310C Switch Box 1 F 960017 Screw,PlanetHousing 6
16 515150 Label,Warning 1 G 503117 Field & Shell Assembly 1
17 501210 Bumper,Handle 1 H 902003 Bearing,Motor Top 1
18 962003 Screw,10-32 x3/4 PHP 1 I 500903 Carbon Brush,115V 4
19 962006 Screw.1/4-20 x1/2 PHPSS 4 510901 Carbon Brush,220V 4
20 503711 Grip,Handle Gray 2 J 911127 Speed Control,115V 1
501501 Cap,Protective End (Blue) 2 911141 Speed Control,220V 1
21 980015 Washer,#10 External Tooth 2 K 908024 Cord Assembly,Motor 1
22 508520 Strain Relief, Complete 1 L 508519 Strain Relief 1
502020 Clamp, Strain Relief 1 M 505181 Light, Brush Wear 115V 1
23 962015 Screw,10-32 x3/8 PHP 1 505182 Light,Brush Wear 220V 1
24 502422 Cord Assembly, 50' Yellow 1 N 911115 Switch,High/Low 1
25 509082 Tube,Handle 1 O 509823 Washer,Felt 3/16 x3 1
26 504420 Hook,Cord 1 P 911048 Rectifier,115V 1
27 962005 Screw,1/4-20 x3/8 Set 1 911081 Rectifier,220V 1
28 502021 Clamp,Large Handle 1 Q 960018 Bolt,Motor Thru 2
29 500840 Brace,Handle 2 R 502928 End Bell, Motor Top 1
30 962009 Bolt,5/16-18 x2 1/2 Carriage 1 S 500425 Armature Assembly,115V 1
31 980007 Washer,5/16 Flat 2 500423 Armature Assembly,220V 1
32 505010 Knob,Turn 1 T - Cover,Ring Gear 1
33 908004 Cord Assembly,Handle 1 U 902015 Bearing 1
34 509920C Yoke,Handle 1 V 902005 Bearing,Upper Pinion 2
35 507480 Rod,Yoke 1 X 502460 Coupling,Motor 1
36 980002 Washer,1/4 SplitLock 6 Y 508211 Spacer Sleeve 1
37 483226 Base,17" 1 Z 503510 Gear,Pinion 1
483227 Base, 20" 1 AA 507701 Shaft,Idler 3
38 487702 Kit-Wheel Axle 1 BB 902016 Bearing,Needle 3
39 980005 Washer,Wave 2 CC 503511 Gear,Idler 3
40 962016 Screw,10-32 x3/8 Set 1 DD 502929 End Bell,MotorLower 1
41 509781 Wheel,5"GrayNon-Marking 2

SPEED
CONTROL
BLACK
ORANGE
TWO SPEED
SWITCH
BLK.
6
BLACK

NOTES
7

WARRANTY POLICY
17” & 20” DUAL SPEED POLISHER MODELS
The Zep Inc. Dual Speed Polisher has been manufactured, tested and inspected in accordance with specific engineer-
ing requirements and is WARRANTED to be free from defects in workmanship and materials as follows:
Three (3) years parts, One (1) year labor - DC Motor and Gear Unit, except motor switches, rectifiers, carbon brushes
and flex couplings which have a one (1) year waranty.
Three (3) years parts, One (1) year labor - Castings
One (1) year parts and labor - All other components unless excluded below.
This warranty extends to the original user/purchaser and only when used, operated and maintained in accordance with
Zep Inc. Operating and Maintenance instructions.
This warranty does not apply to the following wear parts and accessories of the machine including:
Part Number Part Name
Nor does it apply to damage or failure caused by improper use, abuse or neglect. Warranty credit or replacement of
return parts including motors, etc., is subject to incoming inspection of those items.
To secure repair under this warranty, the following procedure should be taken:
1) The inoperative machine or warranted parts must be delivered to the authorized dealer with shipping and delivery
charges prepaid. If unable to locate the Dealer, you may contact Zep Inc. at the address listed herein for the
location of the nearest Zep Inc. repair center or agent or for other instructions pertaining to your warranty difficulty.
2) Upon compliance with the above warranty procedure, all warranted repairs would be completed at no additional
charge or cost to the user.
3) Only Zep Inc. or its authorized dealers and agents may make no charge warranty repairs on this product. All
others do so at their own risk.
This warranty limits Zep Inc. liability to the repair of the product and/or warranted parts replacement and does not
include incidental or consequential damages arising from the use of a Zep Inc. machine whether defective or not.
This warranty is in lieu of all other expressed or implied warranties and is extended to the original purchaser/user.
8/10
502422
509781
503711
481202
481203
500903
510901
Cord Assembly
Wheel
Handle Grip, Grey
Bumper, 17”
Bumper, 20”
Carbon Brush, 115V Motor
Carbon Brush, 220V Motor
