ZERODE TANIWHA User manual
Ride outside the box
User manual
We have had a vision for what we wanted this bike to be since first throwing a leg over a MTB in
1992. Advances in materials and manufacturing have finally allowed us to fully deliver on this
vision with the Taniwha.
Building on early DH race origins and adding modern carbon fabrication, it is a quiet,
low-maintenance 160mm Enduro bike that in essence just makes the riding experience better.
The Taniwha is ready to race at the highest level, to take on epic back country adventures or just
to put a smile on your face on the long way home from work...
Frame Features/Specification:
Travel: 160mm
Frame material: Carbon Fibre
Wheel size: 27.5”
Internal cable routing for dropper post
Component Specifications:
Seatpost: 31.6mm
Seatpost clamp: 34.9mm
Rear shock: 216mm eye to eye x 63mm stroke
22.2mm x 8mm reducer
Headset: 44mm top/56mm bottom
Brake mount: 160mm IS
Drive train: Pinion gearbox
Rear hub: 142mm x 12mm [single speed]
Ride outside the box
User manual
Pinion Gearbox
Complete service and setup videos for the Pinion gearbox are provided at
http://pinion.eu/en/service-videos/
We strongly recommend that you consult these videos when setting up and maintaining your Pinion Gearbox.
Gearboxes offer many advantages over traditional drive trains - less wear and tear, less maintenance and better
suspension performance – however, you will need to make some small adjustments to get the best of what the
Pinion gearbox has to offer. The most important difference is that you cannot shift under load. For first-time
users this may feel a little unusual however the shift is almost instantaneous and pedalling is not required to
change gear. With a little practice eliminating load from the pedals will become second nature allowing
seamless shifting through the gear range in situations not possible with a derailleur.
There is no going back once you are familiar with the Pinion.
Shock setup
Your ZERODE Taniwha suspension should be set up to maximise small bump sensitivity while providing
adequate bottom out resistance for big hits. A starting point to acheive this should be 30 - 35% sag.
Rebound and compression settings should be adjusted to suit your personal riding style, terrain and
preferences. Consult your shock manual about how to make these adjustments.
Maintenance and inspection
It is important to properly maintain and inspect your ZERODE Taniwha.
Before any ride you should inspect the entire frame for cracks, loose pivots or bolts, and properly functioning
bearings. In addition to your pre ride frame check your entire bike should be checked prior to each ride.
Always inspect your frame in full after a crash. If you discover damage to any degree have your frame inspected
by a qualified ZERODE dealer.
Collet style hardware
The main pivot and lower link pivot use a collet style fastening system. This system requires a two step process
to tighten correctly.
Step 1. Remove the wedge bolt with a 5mm hex key, then slide out the wedge.
Step 2. Tighten the shaft ( Main pivot or Link pivot) to the specified torque with an 8mm hex key. Then replace
greased wedge and wedge bolt and tighten to the specified torque with a 5mm hex key.
Chain length
Your ZERODE Taniwha uses a 30T front chainring and 30T rear sprocket. 104 chain links are
required for correct chain length and tension.
Ride outside the box
User manual
Chain tensioner
The pinion chain tensioner requires a small modification from factory because of the gearbox orientation in
the Taniwha frame. A third spring mounting hole is drilled into the spring mount and must be used for correct
chain tension and retention.
Mount the chain tensioner to the gearbox using the middle mounting holes on the tensioner.
Warranty
The Zerode Taniwha frames are warranted against manufacturing defects in materials
and/or workmanship for three years from the date of original purchase.
This limited warranty applies only to the original owner of a Zerode Taniwha and is not
transferable to subsequent owners.
This limited warranty is void if the bicycle is subjected to abuse, neglect, improper
repair, improper maintenance, alteration, modification, an accident or other abnormal,
excessive, or improper use.
Use this spring mounting hole
Use middle mounting holes
Ride outside the box
User manual
A
BC
D
EI
G
H
F
FRAME SIZE
Seat tube length
Seat tube angle
Head tube length
Headtube angle
Chainstay length
Wheel base
Stack
Reach
BB drop
Fork Length 555mm
M
420
74.5
110
65
431
1170
588
420
1
A
B
C
D
E
F
G
H
I
L
460
74.5
120
65
431
1202
596
445
1
XL
500
74.5
130
65
431
1236
605
475
1
All lengths in mm
Geometry
Ride outside the box
User manual
Exploded View and torque settings
Proper torque is vital to ensure safe performance
and correct function in your ZERODE Taniwha.
Ride outside the box
User manual
Item# Description QTY Torque
