Zipit Wireless Messenger 2 User manual

Page i
JUMP START
Getting online with your Zipit Wireless Messenger 2 is quick
and easy! All you need is an existing Instant Messaging
account and wireless Internet access. Then just…
1. Plug it in. Connect the included AC adapter to the back
of your Zipit device and to an AC power outlet.
2. Turn it on. Press the green Power button for one second.
3. Hook it up. Follow the prompts to configure your device
to use up to 3 existing IM accounts.
4. Lose the PC.Press the MyFriendz button to start
chatting, or access other options such as MyTunez or
MyPhotoz through the HOME button. Check out the 411!
Explore more options at Zipitwireless.com.
Page ii
TABLE OF CONTENTS
JUMP START.........................................................I
CHECK IT OUT.....................................................1
Getting Started........................................................2
Locating Controls.....................................................3
Charging the Battery................................................4
Turning the Zipit Device On and Off ...........................4
Using Standby and Sleep Modes ................................5
GET CONNECTED .................................................6
Connecting to Your Wireless Network .........................6
Defining Your Messaging Accounts ...........................11
Using the Home Menu ............................................13
SPEAK OUT ....................................................... 14
Using the MyFriendz List.........................................14
Using the Chat Window...........................................15
Sending Emoticonz and Special Characters................16
Receiving an IMAlert and Using IMResponse..............17
Receiving Messages from Zipit.................................17
Using Messaging Menu Options................................18
LISTEN UP ........................................................ 20
MyTunez Player Controls.........................................21
Playing MyMusic from a Mini-SD Card.......................22
Using MyStationz Internet Radio..............................24
Controlling Audio Settings.......................................25
SHOW YOUR STYLE............................................ 26
LOCK IT DOWN.................................................. 27
GO BEYOND ...................................................... 29
Page iii
TROUBLESHOOTING........................................... 31
Understanding Setup Error Messages .......................31
Handling Network Setup Errors................................34
Recovering from Lost Connections and Chats.............34
FCC DECLARATION OF COMFORMITY.................... 35
Page 1 Check It Out
CHECK IT OUT
Congratulations on your new
Zipit®Wireless Messenger 2!
The Zipit®Wireless Messenger 2 is a
portable instant messaging device with a
built-in full-function audio player and a
high resolution photo player. With this personal media
device, you can easily
Instant message (IM) your friends — up to 99
simultaneous chats — using MyFriendz™ buddy lists for
AIM, MSN, and Yahoo
Manage your IM accounts and MyFriendz profiles
Use IMAlert™ to track multiple chats
Customize your IM display and sounds
Listen to your MyTunez™ (MP3 and WMA files) from
–A Mini-SD memory card
–Streaming Internet Radio
View your MyPhotoz™
And, through the Zipitwireless.com web site, you can
Play games
Write the dictionary on IM lingo
Trick out your Zipit device and express yourself with cool
color Themez™, backgrounds, and other fun stuff
ZIPIT EX. 2022, pg.1

Page 2 Check It Out
Getting Started
You can use some features of your Zipit Wireless Messenger
2 without being connected to the Internet. To get started,
though, or to use instant messaging, you must have
wireless Internet (Wi-Fi® network) access
an existing instant messaging (IM) account
Wi-Fi Access
If you are using your Zipit device at home, you will need a
wireless access point or router that is connected to a
broadband Internet service (like a cable or DSL connection).
If you are in a public area or business, you will need wireless
access through a public Wi-Fi “hotspot.” A public Wi-Fi
hotspot is an open hotspot that does not require a browser or
a fee for access.
Check this out! Lots of businesses, hotels, and restaurants
have public hotspots that are free to their
customers.
The Zipit Wireless Messenger 2 contains an 802.11g radio
and will work with both 802.11b and 802.11g networks.
IM Account
If you don’t have an IM account, you can set one up for free
on any Internet-connected PC. Go to Zipitwireless.com for
more information. When you set up a new account, you will
choose or be provided with a screen name and a password.
Page 3 Check It Out
Locating Controls
Power. Press and hold for 1 second to turn your device on or off.
MyFriendz. Open or close the MyFriendz List of buddies who are logged in to the
IM service(s) you are using.
Home. Press for Home Menu to access main functions.
Options. Context-sensitive menu of actions that match active function.
MyEmoticonz ( ☺) . Press to add an emoticon (smiley) to your IM.
* Cursor Arrows (Up, Down, Left, Right). Navigate.
* Select. Select (highlight) or execute function.
* Alt: Press once to access Alternate function; twice to set Alt Lock.
Up Arrow (↑): Press once to capitalize next letter; twice to set Shift Lock.
Backspace (←BS): Delete typed characters.
Enter: Execute selected function.
Previous and Next. Context-sensitive; back up or go forward in the active function:
–in menu, one level
–in chat, one open conversation
–in audio player, one song
–in photo player, one slideshow
–in setup, one screen
–in MyFriendz or audio list, one page
*: Different function for audio; see “MyTunez Player Controls” on page 21.
Select
Power
Mini-SD card slot
AC adapter
Cursor arrows
Enter
Backspace
MyFriendz
Alt
Close chat/
Special
character
Up arrow
MyEmoticonz
Options Home
Volume
Page 4 Check It Out
Charging the Battery
Plug the AC adapter into the DC input jack on the back side
of your Zipit device and into an AC power outlet. You can
start using your device immediately. Charge the battery for
at least 3 hours before removing the power adapter.
An LED on your Zipit device shows the status of your battery.
If the battery is charging (on AC power), the battery LED will
be solid amber. The LED will turn solid green when the
battery is completely charged.
If the battery charge gets low, the LED will blink in amber,
the battery icon in the chat window header will flash.
Turning the Zipit Device On and Off
To turn your Zipit device On or Off, press and hold the Power
button for at least one second.
Caution: Your Zipit Wireless Messenger 2 automatically
checks for software updates when you go online. If
an update is available and ready to install, do not
power off until the installation is complete.
Page 5 Check It Out
Using Standby and Sleep Modes
Your Zipit device enters Sleep mode when you close the lid or
after 5 minutes with no activity. In Sleep mode, the device
turns off its display but remains connected to network
applications (IM) unless you move out of range of the
network. Your IM buddies will see your Away message, and
you can continue to play music. When you open the lid, your
device will wake up and return to your most recent
application. Because Sleep mode saves your battery power,
it is a good idea to close the lid if you are taking a long break
from using your Zipit device.
Your Zipit device enters Suspend mode after 4 hours in Sleep
mode. When it enters Suspend mode, your device closes all
applications but does not shut down all the way. Your Zipit
device will stay in Suspend mode for up to 4 days with a fully
charged battery. If the battery power gets too low, your
device will turn itself Off.
You can return to On mode from Sleep or Suspend very
quickly, by opening the lid, pressing any key, or pressing the
Power button. You can customize the time limits for entering
Sleep and Suspend modes through the global settings.
ZIPIT EX. 2022, pg.2

Page 6 Get Connected
GET CONNECTED
The first time you turn on your Zipit Wireless Messenger 2,
the Setup Wizard will help you
Search for and connect to your wireless network
Enter the screen names and passwords for your IM
accounts (up to one each for AIM, MSN, and Yahoo)
You can update your setup information later if you need to.
Connecting to Your Wireless Network
Wireless networks can be set up in several ways, with
different types of security and connection requirements.
Networks can be encrypted or open. Encrypted networks
require you to provide a special access code called a “WEP
key” or “WPA key” to get connected. This means that only
authorized people who know the key can use them. Open
networks are available to any user within range.
Some networks are hidden, which means you have to know
their names to be able to find and use them.
Some networks use dynamic DHCP addressing, which means
that the network automatically tells a device how to get to
the Internet when it joins the network. Other networks use
static IP addressing and require you to know the address for
connecting to the Internet.
For more information about network connections, see the
Support page at Zipitwireless.com.
Page 7 Get Connected
Your Zipit device is designed to make the wireless
connection process as automated and simple as
possible.
Whether your network is open or encrypted, hidden, or uses
dynamic DHCP or static IP addressing, the Zipit Setup Wizard
will guide you through the connection process.
When you turn on your Zipit device, it will search for all
available wireless networks and try to connect to the
strongest open network first, then other open networks;
followed by the strongest encrypted network and then other
encrypted networks. If your network is open (most home
and public hotspot networks are), you probably will not need
to provide any information. If it is hidden or encrypted, or
uses static IP addressing, the Setup Wizard will prompt you
to enter the information it needs.
If you know that your network is hidden and know how to set
up networks, you can interrupt the automatic connection and
configure the network yourself.
When you connect to a network, the Setup Wizard will show
a Connected screen and the network status LED will turn
solid green.
Page 8 Get Connected
Connecting Automatically
Follow these steps to get up and running:
1. Turn on your Zipit device. The Welcome screen appears.
2. Press NEXT. The Zipit logo spins, showing you that your
device is searching for a network. This can take several
seconds.
3. The Scanning for Wireless Networks screen displays the
number of networks found.
4. The next screens that you see depend upon what type and
number of networks your Zipit device found.
–If one open network was found, the Automatically
Connecting screen will appear, your device will connect
automatically, and the message “Connected to (your
network’s name)” will appear.
–If one encrypted network was found, your device will
ask you to enter a special access code called a WEP
key or WPA key. Type in the code and press NEXT. If
you make a mistake while typing, use the backspace
key or the ←cursor key to back up and correct it. Your
device will use the information to connect, or will
prompt you to confirm the information.
–Your Zipit device will not find a hidden network until
you tell it where to look; then it can connect. If no
networks were found, your device will assume that a
hidden network is available and will prompt you to
enter the network’s name (SSID). Enter your
network’s name in the SSID field and press NEXT. (If
you don’t know your SSID, your access point or
router’s documentation or a label on your access
point/router can tell you how to find it. If you still need
help, check out the Support area at Zipitwireless.com.)
Page 9 Get Connected
If you entered the name incorrectly or if the network is
encrypted, the Setup Wizard will show an “Unable to
Connect” screen. Double-check the way you entered
the SSID and change it if you need to. (Use the
backspace or ←cursor key to back up and correct it.)
If you typed it correctly, your network is both hidden
and encrypted. Enter your network key code at the
prompt and press NEXT.
–If your Zipit device found several networks, which is
common in public areas, the Setup Wizard will
automatically try to connect to the open network with
the strongest network signal, then weaker open
networks, and then encrypted networks.
If you want to choose which network to use, or want to
specify a hidden network, you’ll need to interrupt the
Setup Wizard by pressing NEXT. The Setup Wizard
shows the networks it found. Use the ↑and ↓cursor
keys to select a network and then press NEXT to
connect to the network. If you choose to add a
network, the Setup Wizard will ask you to enter its
SSID (network name).
Where to next?
If you’re connected to a network, see “Defining Your
Messaging Accounts” on page 11.
If you got an error message, skip to “Understanding Setup
Error Messages” on page 31.
ZIPIT EX. 2022, pg.3

Page 10 Get Connected
Connecting Manually
If you do not want to let the Setup Wizard set up your
network connection automatically, you can interrupt the
connection process and set up the connection manually. You
should know how to set up networks before trying this
process.
To set up your network connection manually, follow these
steps:
1. When the Setup Wizard tells how many networks it found,
press NEXT to interrupt it.
2. The Setup Wizard displays a manual configuration screen
and prompts you to enter the configuration information.
Type in the requested information and press NEXT.
3. The Setup Wizard connects using the information you
provided.
Where to next?
If you’re connected to a network, see “Defining Your
Messaging Accounts” below.
If you got an error message, skip to “Understanding Setup
Error Messages” on page 31.
Page 11 Get Connected
Defining Your Messaging Accounts
Once your Zipit device has connected to the Internet, you’ll
enter your instant messaging account information. You can
save a username and password for three different accounts
—one on AOL, one on MSN, and one on Yahoo. With the
Zipit Wireless Messenger 2, you can log into all of your
accounts at once, seeing buddies from all three services.
1. When the Setup Wizard prompts you to define your IM
accounts, press NEXT.
2. Your Zipit device will ask if you have an AOL account.
Choose “Yes” or “No” and press NEXT. (Change answers
by pressing the “Y” or “N” button, the space bar, or the
→or ←cursor button.)
3. If you selected “Yes,” enter your account information
when prompted. If you make a mistake while typing, use
the backspace key to delete characters. Press NEXT.
4. Repeat Steps 2 and 3 to define your MSN and Yahoo
accounts.
Note: If you have an MSN account, you must enter your
complete email address, not simply your screen name.
Page 12 Get Connected
Congratulations —your setup is complete!
Press the MyFriendz button to start chatting. Or
press HOME to check out all of your other
options.
Listen up! Did you know you can play your
tunes while you chat? Just start MyTunez.
The standard background for the Zipit Wireless Messenger 2
has orange bubbles, like the screenshots in this user guide.
You can customize the theme or background and change the
display fonts through the Zipitwireless.com website. Some of
the Themez have their own menu icons for the standard
functions.
Also, as we add new features, Zipit sometimes releases
software with updated screen layouts and icons. Your Zipit
device will look like the current standard configuration when
you get it. Want to try a new look? Check the customization
options at Zipitwireless.com, or see the section “Using
Messaging Menu Options” on page 18.
Page 13 Get Connected
Using the Home Menu
The HOME key lets you access the Zipit device functions.
1. To get to the Home Menu
at any time, press HOME.
2. Use the ↑and ↓cursor keys
to scroll through the list
and highlight a list entry.
3. Press the Select button,
ENTER, or the →cursor key
to select the highlighted
entry.
4. Press the ←cursor key to
back up one level in the
open menu.
Navigation Example
From the Home Menu with Messaging highlighted, press to
see the Messaging Menu. Press again to open the
MyFriendz function. Press to return to the Messaging
Menu, or HOME to return to the Home Menu.
Quick Tips
If 411 is the first entry in the Home Menu, Zipit has a new
message for you. After you read it, the 411 listing will
drop to the bottom of the menu.
The MyPhotoz option appears if a Mini-SD card is in place.
If you are using MyTunez or MyPhotoz, Now Playing or
Now Showing appear in the Home Menu. Select these
entries to return to the audio or video players from
another function.
ZIPIT EX. 2022, pg.4

Page 14 Speak Out
SPEAK OUT
Speak out with the Messaging functions!
They let you chat, control your IM account,
and set IM options. Most of these functions
are accessed through the Messaging Menu.
Using the MyFriendz List
The MyFriendz list shows all of your friends who are logged
into the IM service(s) you are using, and shows you their
status. Navigate to the MyFriendz listing in the Messaging
Menu and press →or ENTER, or just click the MyFriendz
button. Then use the cursor keys to scroll through the list,
and press ENTER to start chatting.
The top of your MyFriendz list shows the people you’re
chatting with now, listed alphabetically in bold type. Below
that, the list shows friends who are online but not chatting
with you. They are listed in a regular font if idle, or in italics if
they are away from their computers.
Quick Tips
Select the name of someone already chatting with you to
make that chat window jump to the top.
Type a letter, or several letters, to jump to the first name
in the list that matches what you typed.
Press PREV or NEXT to navigate the list a page at a time.
Select a name and press the →cursor key to see a
friend’s status message.
Page 15 Speak Out
Using the Chat Window
Each chat session uses a full window. If you are chatting with
several people, the windows are stacked in the order in which
they were started. You can page through them by using the
PREV and NEXT buttons or the →and ←cursor arrows.
The chat window has three parts:
Header bar:
Current buddy: Screen name and service provider.
Counter: Updates when you open or close chats. This is the first of 2 open chats.
New message status: Pulses if you have any unread 411 or message. Press
MyFriendz to see buddy list, and look for animated logos to find new messages.
Network status: Shows whether you are online and signal strength.
Special key status: Shows whether Alt function is on (A) or locked (A), or whether
Shift function is on (↑) or locked (↑). See Quick Tips below for details.
Battery status: If running on battery, shows 1 to 4 bars of remaining power. Blinks
slowly if battery is getting low – connect to AC power soon. Blinks quickly when
critically low and enters Standby as soon as possible. If charging, shows .
Text entry window: Type your message here and press ENTER to
send. Use Backspace to erase or ←to back up and insert additional
text. Any letter you type while in the chat window will appear here.
Header bar: From left to right,
shows service logo and ID of
your current buddy, window
counter, new message status,
network status, special key
status, and battery status.
(See below for details.)
History window: Shows most
recent 12-15 lines of chat.
Lines you typed are labeled
“Me.” Use ↑and ↓to reread.
Page 16 Speak Out
Quick Tips
Press ALT once to enable the secondary function on any
one of the blue keys on the keyboard, including the
numeric keys, special accent keys, and the Close Window
(⌧) key. Press ALT twice to use more than one secondary
function. Press ALT again to return to normal mode.
Press the Up Arrow (↑) once to enable the Shift function
and type one uppercase character. Press ↑twice to lock
this function and type everything in uppercase. Press ↑
again to return to normal mode.
Press PREV or NEXT to move through your open chat
windows, in the order that they were connected.
Press the MyFriendz key and type a few letters of your
friend’s name to jump to a specific conversation.
Press ALT + ⌧together to close the active chat.
Sending Emoticonz and Special Characters
To add Emoticonz (smileys) to your messages, press the
MyEmoticonz key ( ☺). A pop-up window of available
characters will appear. (Your choices will depend upon the
IM service you are using.) Scroll through the window, select
a character, and press ENTER to add it to your message. The
pop-up will disappear after one use.
Go to the Zipitwireless.com website to
download new Fontz that match your
personality!
To add a special character, press the “. . .” key located above
the ALT key. Select the character from the pop-up window.
Page 17 Speak Out
Receiving an IMAlert and Using IMResponse
When you receive a new
message, unless you are in the
Setup Menu or MyFriendz list, an
IMAlert will pop up for 3 seconds
on top of any open window. A
swooshing sound will also play.
If you want to read the new message, press the Up Arrow (↑)
+ NEXT while the IMAlert is showing to jump to that chat
window. (If you receive several IMAlerts, you can only jump
to the first one.) You can also press the MyFriendz key to
see who has sent you messages—their IM service logos will
be flashing.
Receiving Messages from Zipit
Zipit uses 411 messages and dynamic alerts to tell you
important info about your Zipit device, or about new features
and offers. You read the 411s when you choose to, by
selecting 411 from the Home Menu. If you have an unread
message, 411 appears at the top of the menu.
When Zipit needs to get your attention quickly, we’ll send
you a dynamic alert. After reading it, simply press ENTER to
return to your previous activity.
ZIPIT EX. 2022, pg.5

Page 18 Speak Out
Using Messaging Menu Options
The options available through the Messaging
Menu let you change your IM settings:
MyFriendz: See your MyFriendz list,
check status, and start chat sessions.
Same function as the MyFriendz button.
Add MyFriendz:Add a friend’s screen
name and IM service to your MyFriendz list so you can
chat with them from your Zipit device or PC. To use this
feature, you must be logged into the service of your
friend’s account.
To add a friend, choose Add MyFriendz from the
Messaging Menu. Follow the screen prompts to enter the
info as requested. Press PREV to cancel, or NEXT to save
the addition and return to your previous activity.
Delete MyFriendz: Delete someone from your MyFriendz
list. Select the name and press CTRL + D. Press NEXT to
return to your previous activity. Careful ⎯you can’t undo
this! If you delete a name, you’ll have to add it back
before you can chat with this person again.
Page 19 Speak Out
Manage Accounts: Use this if you have several screen
names on one IM service, to change the IM accounts you
configured through the Setup Wizard. Or, use it to add
accounts that you didn’t initially define.
Select Manage Accounts from the Messaging Menu. Follow
the screen prompts to tab through the three IM services
and enter the requested info. You can enable or disable
the current accounts, or change the username and
password for any service.
Your device will close all
open chat windows, log out
of all accounts, login to the
newly enabled accounts,
and return to the MyFriendz
list. Changing account
settings for a service makes
the new account the
primary account until you
change it again.
IM Options: Enable/disable your IMAway message,
change your display fonts, or change your audio settings.
To change your IMAway settings,
select IM Options from the
Messaging Menu. Select IMAway
[Enable]; then select the default
message or create one of your own.
When your friends IM you, they’ll
automatically be sent this as a
response. When you return from
being away, select IM Options and
IMAway [Disable].
Page 20 Listen Up
LISTEN UP
Listen up! Your Zipit Wireless Messenger 2
isn’t just a full-function IM device. Use it to
listen to all of your favorite music. It plays
MP3 and WMA files from your Mini-SD
memory card and even plays Internet radio!
Start MyTunez, plug in your earphones, and
close the lid ⎯your Zipit device will play
your entire playlist. Or relax and play tunez while you chat
or look at a slideshow.
While you are listening to MyTunez, other device sounds will
be disabled.
Quick Tips
If you are playing music in the background of another
function, a Now Playing entry shows at the top of the
Home Menu. Click there to jump straight back to your
tunez.
The Now Playing screens vary slightly for the MyMusic and
MyStationz audio options.
If you press HOME while a song is playing, the Home
Menu will appear and your song will continue playing.
Press HOME again to return to the Now Playing screen.
Use the player controls to change your tunez without
leaving the open screen.
Use the OPTIONS menu while in MyTunez to add or
change your Shuffle and Repeat settings, and control your
playlists.
Page 21 Listen Up
MyTunez Player Controls
Once you’ve started MyTunez, use these controls to navigate
through songs or adjust the volume without changing what’s
open on your screen:
Options: For MyMusic, press to
–Add to Playlist
–Shuffle
–Repeat
Prev: If in player, restart playing song. If in chat, press ALT + PREV. If using
MyMusic, hold down to rewind; let go to continue playing from there. If in
MyNetwork guide menu, press the Up Arrow (↑) + PREV to page up the list.
Next: If in player, skip to next song. If in chat, press ALT + NEXT. If using
MyMusic, hold down to fast forward; let go to continue playing from there. If in
MyNetwork guide menu, press the Up Arrow (↑) + NEXT to page down the list.
Play: If in player, play the highlighted item. If the song was stopped, resume from
where it was stopped and continue through the playlist. If in chat, press ALT +
PLAY to play the last selected song.
Stop: If in player, stop the currently playing song. If in chat, press ALT + STOP.
Volume Down (- ; right side of device): Press once to decrease volume one step.
Volume Up (+; right side of device): Press once to increase volume one step.
Previous
Next
Options
Play Stop
Select
ZIPIT EX. 2022, pg.6

Page 22 Listen Up
Playing MyMusic from a Mini-SD Card
If you have a library of tunez on your computer, you can play
them from your Zipit device as easily as from an MP3 player.
And with the Zipit Wireless Messenger 2, you can listen to
your tunez while you chat, view pictures, or use online tools.
First, copy your MP3 and WMA tunez from your computer to a
directory called Music on a Mini-SD memory card. Then
follow these steps:
1. Slide the Mini-SD card into
the bottom of your Zipit
device.
2. Your device builds its music
library and displays “SD
Card” as a choice in the
MyTunez Menu.
3. From the MyTunez Menu,
select SD Card. Use the
↑and ↓buttons to select the
way you want to view your
library, and the →button to
see sublists. Press ENTER
or the Select button to play
tunez.
Music plays from the point where you press ENTER. For
example, (except in Shuffle mode) if you are in the Artist
menu, your Zipit device plays all songs by all artists, in
order by artist and then album. If you are in an Album
menu, it plays all songs on that album, beginning with the
song number you selected.
Page 23 Listen Up
The Now Playing screen for MyMusic shows all of the info that
was found about the current song:
Beside cover art (if any)
–Song title (in bold)
–Artist
–Album
–File type
–Track number
–Song length
Bottom of screen
–Elapsed song time
–Song number of total
on album
–Remaining song time
Create a dynamic playlist – a Zipit
exclusive! Queue up the songs you
want to listen to; then save them as a
playlist. While in the audio player,
navigate to another album, artist, or
playlist. Press OPTIONS and select
Add to Playlist. Save your special mix
as a custom playlist ⎯it will be
available until the next time you rebuild
the music database by changing the
contents of the Mini-SD card.
Page 24 Listen Up
Using MyStationz Internet Radio
If you don’t have a Mini-SD memory card, or just want
access to a wider range of tunez, use MyStationz to listen to
radio stations that stream over the Internet.
First, go to Zipitwireless.com, select Customization Options,
and enter your serial number when prompted. Next, check
the list of available MyStationz and select up to eight for your
own presets.
Now, from the Zipit device Home Menu, select MyTunez and
then MyStationz. Scroll through the menu and select the
station to listen to now.
The MyStationz audio player screen looks similar to the
MyMusic player, with the functions limited to Play and Stop.
Page 25 Listen Up
Controlling Audio Settings
Use the MyTunez Audio Settings option to set the audio
player to Shuffle and Repeat tunez on your Mini-SD card.
From the MyTunez Menu, select Audio Settings.
Select Shuffle or Repeat and use the
→cursor arrow to toggle the setting
On or Off. When either setting is On,
its icon appears in the bottom right
corner of the audio player.
ZIPIT EX. 2022, pg.7

Page 26 Show Your Style
Sample backgrounds
GreenWaves theme
SHOW YOUR STYLE
There are lots of ways to customize your
Zipit Wireless Messenger 2! Change these
settings as often as you’d like to match your
style or your mood:
Change your fontz, IMAway message, and
sounds for chatting through the IM
Options selection in the Messaging Menu.
Play your tunez and watch slideshows of the pictures you
save to a Mini-SD memory card.
Set your favorite types of music for the MyStationz
Internet radio feature.
Download special backgrounds, Themez (including
function-specific backgrounds and system-wide color
scheme), and Fontz from Zipitwireless.com. We add new
ones regularly, so check back often to see what’s new!
Page 27 Lock It Down
LOCK IT DOWN
Your Zipit Wireless Messenger 2 has built-in
security ⎯it is immune to viruses, does not
allow pop-ups, and only allows connections by
buddies you know. You can enhance this
security through the Tools menu:
Enable / Disable Password: Set a
password to prevent others from accessing your IM
accounts. From the Home Menu, select Tools, then Enable
Password. Enter 4-6 characters (any mix of uppercase,
lowercase, and digits).
You must enter the password before changing account
setup or enabling or disabling an IM account.
If password protection is enabled, the Tools Menu displays
the option Disable Password. Enter and confirm the
password to turn off this security feature.
Owner: Fill in the Owner name and address fields, then
lock them with a device password. Your Owner data will
stay in your Zipit device and cannot be accessed by
anyone without your password.
Page 28
Other options in the Tools Menu allow you to connect to
wireless networks, control the display backlight, view
configuration info, or return your Zipit device to its factory
settings:
Wireless Settings: Scan for wireless networks, login, and
login to defined IM accounts. If you are on a network
already, your connection will be closed and you will lose
any open chats.
Backlight: Change backlight
settings. Select a setting and
use the Select key or →
cursor arrow to decrease or
increase the value. Choose
lower settings to save the
battery and maximize your
fun time with your Zipit
device.
Set Defaults: Erase everything stored in your Zipit device
and return it to its original out-of-the-box settings.
System Info: Look up technical information you may need
if you contact Zipit for support.
Page 29 Go Beyond
GO BEYOND
Your Zipit Wireless Messenger 2 has a
high-resolution display perfect for viewing
graphics and slideshows.
Just load your favorite graphics in a
directory called Pictures on your Mini-SD
memory card. If you organize your
graphics in subdirectories in the Pictures folder, your Zipit
device will treat each subdirectory as a separate slideshow.
Now follow these steps:
1. Insert the Mini-SD card in
your device and select
MyPhotoz from the Home
Menu.
2. Scroll through the list of
slideshows and select the
one you want to view.
3. Use the PREV, NEXT,
PLAY/PAUSE, and STOP
buttons to control your
slideshow.
ZIPIT EX. 2022,, pg.8

Page 30 Go Beyond
The Now Showing player displays your slideshow. The bottom
of the player indicates whether the show is playing or
paused, lists the picture captions, and indicates the current
and total number of pictures in the show.
Ready to chill? Start MyTunez and
listen to your favorite music while you
watch your slides.
Page 31
TROUBLESHOOTING
Understanding Setup Error Messages
There are 4 types of network error messages you might see
while trying to connect to a network:
Automatic connection failed: The Setup Wizard found at
least one network but could not connect to it.
DHCP error: There was a problem with your router’s IP
address.
DNS error: Your Internet connection is down or there was
a problem with the DNS server.
Proprietary network: You are trying to connect to a
private network that requires a password and/or
subscription.
Page 32
If you see any of these error messages, you can press PREV
to retry the connection. You can also press NEXT to
configure the network yourself. Follow these steps:
1. The Setup Wizard
displays an error
message.
2. Press NEXT to enter
the configuration
information yourself
and connect to the
network manually.
3. The Setup Wizard asks you to enter manual settings. (If
you do not know it, you can get this information from your
network service provider.) Enter the requested
information and press NEXT.
4. The Setup Wizard retries the connection process. When
you see the Connected screen, continue to the section
“Defining Your Messaging Accounts” on page 11. If you
still cannot connect, see below for additional options.
Possible Error Message Causes and Solutions
Automatic connection failed
Your device is not in range of any wireless access points.
–Make sure that your access point is turned on and is functional.
–Move closer to known wireless access points.
Available access points are not broadcasting their SSID.
–Manually enter the SSID of the network (refer to the
setup/configuration page of the access point) in the space
provided.
Page 33
DHCP error
You entered an invalid SSID or an invalid WEP key.
The access point has been configured to disable DHCP.
The Internet connection is down.
The access point configuration is set incorrectly.
The DHCP server is providing incorrect network information.
The only networks available are “for fee” Hotspots.
–From the “Uh Oh” screen, select the network that you want to
access. You will be given a brief list of the possible reasons for
the failure and a method to correct the failure condition.
–Check your access point/router’s configuration screen to make
sure that the Authentication type is set to Open and that the
Preamble is set to Long.
DNS error
You entered an invalid SSID or invalid WEP key.
The access point has been configured to disable DHCP.
The DHCP server on your access point is providing incorrect
network information (this is very uncommon).
–From the DHCP error screen, press NEXT to verify the SSID
and WEP information.
–Verify that your access point/router has DHCP enabled. If not,
enable it and re-scan; or press NEXT after verifying the SSID
and WEP to enter the Static IP configuration screen. Confirm
the required information from your access point/router.
Proprietary network
The Internet connection is down.
–Verify that you can access the Internet from a PC. If not, check
the status of your cable or DSL modem to see if it is receiving
data from the Internet.
The DHCP server on your access point is providing incorrect
network information.
–See “DNS Error” above.
ZIPIT EX. 2022, pg.9

Page 34
Handling Network Setup Errors
During setup, your Zipit device might connect to a network
but be unable to connect to an instant messaging account. If
this happens, check the following:
Do you have an existing IM account with AIM, MSN, or Yahoo?
You cannot create an account through your Zipit device.
–Go to http://www.aim.com, http://messenger.yahoo.com, or
http://messenger.msn.com to setup one or more accounts.
–Restricted AOL accounts (such as KAOL) are not supported.
Did you enter your username and password correctly?
–MSN accounts require the full account name, not just the
screen name. For example, if you have a Hotmail account, you
must add “@hotmail.com”to the login.
Are your router’s firewall settings preventing access to IM
accounts?
–Open the following ports to allow the IM traffic to pass through
the firewall: 1863, 5190, 6891, 6901.
Recovering from Lost Connections and Chats
If you are logged into an IM service on your Zipit device and
log in again from another Zipit device, a phone, or a PC, your
connection on the first device will be “bumped” (logged off).
You will have the option to change IM accounts, reconnect, or
stop chatting but continue with other services.
If you are chatting and lose your network connection, the
message “Network Lost” will flash in the header bar of the
chat window. Your chats will still be displayed, but you will
not be able to enter any new text. Once you have finished
reading the open chats, press the MyFriendz key. Your Zipit
device will scan for available networks and reconnect if
possible.
Page 35
FCC DECLARATION OF COMFORMITY
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Product: Zipit Wireless Messenger 2
Model: ZWM2
Responsible Party: Zipit Wireless, Inc.
200 N. Main Street, Suite 300
Greenville, SC 29601
Zipitwireless.com
Customer Support Toll Free: 1-866-92 ZIPIT
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
Page 36 Page 37
ZIPIT EX. 2022, pg.10
