ZL electronics Technology 900C User manual

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
900C
Vehicle GPS Tr cker User M nu l
2008-03-21
1

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
Table of Contents
1. Working Directions..................................................................................................................…..3
2. GPS Tracker Installation...............................................................................................................3
2.1. Product Parts List ................................................................................................................3
2.2. Precaution before Installation ..............................................................................................4
2.3. Installation............................................................................................................................5
2.4. Wiring Descri tion................................................................................................................6
3. O erating Instructions .................................................................................................................7
4. SMS Tracking by Mobile............................................................................................................10
4.1. Position Re ort Function...................................................................................................10
4.2. Tracking Function..............................................................................................................11
4.3. Sto tracking function………………..……………………………..….……...........................11
5. GPRS Tracking by com uter....................................................................................................12
5.1. Set APN..............................................................................................................................12
5.1. Set IP and Port...................................................................................................................12
6. Take Photo function...................................................................................................................13
6.1. Take hotos.......................................................................................................................13
6.2. Take hotos by ress SOS button. ...................................................................................13
6.3. Set the time interval to take hotos. ..................................................................................13
7. LCD Screen……….....................................................................................................................13
7.1. Use as navigation...............................................................................................................13
7.2. Make and receive hone calls. ..........................................................................................13
7.3. Receive massages from control center. .............................................................................14
7.4. Receive GPS signal. ..........................................................................................................14
2

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
1. Working Directions
Thank you for your urchase of 900C Vehicle GPS Tracker. In order to realize the full functions
of this roduct, lease read this manual carefully before starting to use the roduct.
1. This roduct can only be maintained and re aired by qualified rofessional service
ersonnel. If you detach this roduct for maintenance or re air, your warranty will be
invalidated.
2. When connecting the other devices, read carefully their instruction manuals, so as to carry
out correct installation; do not connect incom atible device.
3. Please use genuine original arts and qualified batteries and eri heral equi ments, so as
to avoid damage to this roduct.
4. As this roduct is a high-tech roduct, lease read carefully this manual before starting to
use the roduct, so as to avoid ina ro riate o eration.
5. Drivers should not o erate this roduct while driving a vehicle, thereby, affecting safe
driving.
6. This roduct can work ro erly only when GSM communication is in good condition.
7. Please reduce electromagnetic wave interference to the roduct; and use it ro erly.
8. GPS communication is liable to be affected by environmental shielding; may fail to carry
out ositioning during certain circumstances. It will resume the ositioning function as soon
as it leaves the shielding environment. This is normal. Please do not worry when
encountering such roblem.
9. Each signal sent out from the system will be confirmed for successful transmission in the
base station of the mobile o erator. However, if system sto age occurs or if the mobile
tele hone is reset to a switch off state by the customer, it cannot ensure successful
transmission.
10. For safety reason, do not tell the other eo le your 900C mobile number, without taking
recautions. Otherwise, your rivacy may be com romised along with other safety roblem.
2. Wiring Installation
2.1. Product Parts List
3

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
GPS Tracker Unit
GPS Antenna
GS Antenna
Car Charger
Lighter Socket
2.2. Precaution before Installation
1 Check if all the arts are included.
2 Pre are a SIM card for GSM communication. Use some other mobile hone to confirm that
the PIN code has not been set and that it can dial out and receive tele hone calls and SMS
4

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
without roblem.
3 Before install the SIM card; make sure to cut off ower from the GPS Tracker unit. The
correct installation method is to ush the tray com letely into the GPS Tracker unit, until you
feel it is hooked by something.
4 Find a suitable lace inside the car for installing the unit.
5 Check if all the wiring has been connected correctly; then connect the GPS Tracker unit to
the ower source.
2.3. INSTALLATION
2.3.1 Step 1: Inst ll SIM C rd
1 Using a s eculate object to oke the small button of the SIM card seat, and then it will o -
u a small drawer.
2Put the SIM card in the drawer, and ut back the drawer, as direction shown in the icture.
3Make sure to turn off the ower before install the SIM card.
4 Make sure to deactivate the PIN code, so that the SIM card can o erate without PIN
rotection.
5 Before install the SIM card to the GPS Tracker, lease use a mobile hone to make sure the
SIM card can make & receive hone calls without roblem.
6Before install the SIM card to the GPS Tracker, lease use a mobile hone to em ty the
SMS storage of the SIM card.
2.3.2 Step 2: Connect GSM Antenn
1Connect the GSM Antenna to the unit.
2Fasten the connection by turning the screw in the bottom.
3Please do not swing round the antenna itself.
2.3.3 Step 3: Connect GPS Antenn
1GPS antenna is used to receive satellite signals in the sky. It should be ositioned at a
lace where it will have an unobstructed view of the sky. The ideal location is to of the
dashboard or close to the rear window of the car.
2GPS antenna can ick u signals through glass and lastic, but will not "see the sky"
through metal or other conductive surfaces. To avoid distractions of GPS signal, make sure
5

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
the antenna is not covered or shielded by any object containing metal, such as the metallic
windshield.
3If your car is with metallic windshield lease cut a hole on the windshield above the lace
where you ut the GPS antenna, so that the antenna can receive the GPS signals.
2.3.4 Step 4: Connect power ch rging
900C connects to the 6 in wires.
2.4. Wiring Description
4 pins connector
Pin Color function
1 Red ower switch
2 Red ower switch
3 Yellow Connect to door sensor
4 Green Undefined in ut.
for exam le you can use it to detect the signal of car alarm
6

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
6 pins connector
Pin Color function
1 Red DC in
In ut voltage: 8-40V
Suggestion: 12V
2 Black GND
3 Brown Out ut , starter kill relay you can use it to cut the electricity or oil of the
car
4 White SOS button
5 Green Out ut , starter kill relay you can use it to cut the electricity or oil of the
car
6 Blue ACC signal detecting
According to the relay arameter to make sure to following requirement:
The in ut voltage of relay must be suited to the car battery
3. Operating Instructions
SMS rotocol of 900C, the default assword of 900C is 000000
S S Instruction Format Remark
1 Request one osition A******,000 000: command code
******: assword, default 000000
2 Modify user assword A******,001,###### 001: command code
******: old assword , default 000000
######: new assword
3 Set a reset hone
number for SOS button
or monitoring number.
A******,002,1, Tel
Number
002: command code
******: assword, default 000000
1 : Set SOS number
7

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
Tel Number: Preset Tel. number
(Tel Number must <20 digits )
When this button is
ressed,
900C will send the SOS
and osition message to
the reset number.
A******,002,2, Tel
Number
002: command code
******: assword, default 000000
2 : Set monitoring number
Tel Number: Preset Tel. number
(Tel Number must <20 digits )
4 Set the time interval
of osition refresh to
SOS number,this
command is effective
just in SMS work mode.
A******,003,XXX 003: command code
******: assword, default 000000
XXX: (3 digital)
XXX =000,sto
XXX = 001 – 999 time internal (unit: min)
5 Set low ower alarm
When the voltage is
lower than the reset
value, tracker will send
one lower ower alarm
SMS to the control
number.
Otherwise,there is not
this function in vehicle
tracker
A******,004,X 004: command code
******: assword, default 000000
X : voltage reset value
X=0, close (default )
X =1, <3.5V send SMS alarm
X =2, <3.6V send SMS alarm
X =3, <3.7V send SMS alarm
X =4, <3.8V send SMS alarm
X =5, <3.9V send SMS alarm
6 Set over s eed alarm
When the 900C s eed
higher than the reset
value, 900C will send
one over s eed alarm
SMS to the control
number.
A******,005,XX 005: command code
******: assword, default 000000
XX : the s eed reset value
XX = 00 , close
01 ≤ XX ≤ 99 (unit: XX Km/h)
7 GPRS Status, To
check GPRS Status
A******,502 502: command code
******: assword, default 000000
8 Get IMEI A******,505 505: command code
******: assword, default 000000
9 Set GPRS internal of
osition refresh
A******,506,00030 506: command code
******: assword, default 000000
00030: Such as 30 seconds interval is 00030
8

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
10 Check GPRS interval
of osition refresh
A******,507 507: command code
******: assword, default 000000
11 Inquire GPRS
arameter
Return Including IP,
Port, APN
A******,006 006: command code
******: assword, default 000000
12 Control the out ut A******,007,P,F 007: command code
******: assword, default 000000
P: the osition of the out ut
P =1 out ut 1
P =2 out ut 2
F: the control signal
F =1 give the relay the current to drive it (cut
off the car ower).
F =0 cut off the current of the relay (comeback
the normal).
13 Time zone setting A******,008,+08 008: command code
******: assword, default 000000
+08: Set the local time zone, the default value
is +08
14 Inquire the system
arameter.
Including the software
version, assword,
interval, s eed limit,
area limit, I/O state,
GPS state, SOS
number, control number,
etc
A******,009 009: command code
******: assword, default 000000
15 GPRS switch A******,010,X 010: command code
******: assword, default 000000
X: GPRS function
=0 GPRS OFF
=1 TCP ON and u data in time interval strictly
=2 TCP ON and u data in factory mode.
=3 TCP ON and u data in save mode.
9

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
16 SET APN A******,011,APN,
username, assword
011: command code
******: assword, default 000000
APN: GPRS use this gateway to connect
internet.
Username: APN Username
Password: APN Password
The default APN is CMNET
17 Set the center IP and
Port
Set server arameter
A******,012,IP:Port 012: command code
******: assword, default 000000
IP: Platform server i
Port: Platform server ort
18 LED Light Switch A******,666, X 666: command code
******: assword, default 000000
X: LED Light Switch
X =0 LED Light OFF
X =1 LED Light ON
19 Reset to factory settings A******,888 888: command code
******: assword, default 000000
20 Restart Tracker A******,999 999: command code
******: assword, default 000000
4. S S Tracking by obile
4.1. Position Report Function
4.1.1. Get position from vehicle - w y 1:
No matter where you are, when you want to know the osition of your vehicle
Step1 Send a SMS message or make a tele hone call to the 900C.
Step2 vehicle will re ort its location back to you by SMS, which including the osition
information
10

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
Edit a message as following format, and then send it to 900C:
Command Remark
Send Format: A+Password+,+000 Get osition command code is:
000
For Example
Send message:
A000000,000 000: command code
000000: assword, default
000000
Back
information:
Lat:2232.6022N, Lon:11402.2969E This mean your osition is on
North Latitude 22 degree 32.2232
cent and East Longitude 114
degree 2.2969 cent
4.1.2. Get position from vehicle - w y 2:
A ly for one osition service by another way: you need re-storage the hone number in SIM
card:
Step1 Make a cell hone call to 900C
Step2 After listening the ring of 900C, it will hold off after two rings.
Step3 Then, after 10 second, the cell hone will receive the Position SMS. (Its means is
900C will send Position Data every 5 minute.)
4.2. Tracking Function
Tracking re ort function can be turned on or off according to the requirements of the user.
Tracking function will continually re ort vehicle osition until it get sto command .In this tracking
mode, 900C will send one osition message at a reset time interval.
Step1. Edit a message as following format, then send it to 900C
Command Remark
Send Format: A+Password+,+003,+XXX Note: XXX , if XXX=000 it is
STOP tracking
Unit: reset minute interval
Command code : 003
For example: A000000,003,003 003: command code
000000: assword, default
000000
003: 3 minute interval
It means is 900C will send
11

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
Position Data every 3 minute.
Step2. 900C will send back one SMS-----Set Time OK.
This SMS means that 900C is in tracking mode now and reset time interval is 3 minutes.
Step3. 900C will send back osition SMS at reset time interval.
In this exam le, the SMS will send back at reset time interval: 3 minute
4.3. Stop tracking function.
This function is used to turn off tracking re ort function. Edit a message as following format, and
then send it to 900C:
Command Remark
Command format: A+ asswaord+,+003+,+000
For example: A000000,003,000 003: command code
000000: assword, default
000: 0 minute interval, mean
sto back
5. GPRS Tracking by Computer
The default mode is GPRS when owering on the unit. The default setting is ours; you need to
send the following SMS to Set APN and IP, Port. (If you use our server, you only need to set APN).
5.1.Set APN
Send the SMS to the tracker as following format
Command Remark
Command format: A+Password+,+011,+APN
For example: A000000,011,CMNET 011 : Command code
000000: assword, default
000000
CMNET: APN, is gateway to
connect internet, Each country is
different,
5.2.Set IP and Port
Send the SMS to the tracker as following format:
12

ZL ELECTRONICS TECHNOLOGY (HK) CO., LIMITED
Command Remark
Command format: A+Password+,+012,+IP:Port
For example: A000000, 012,119.147.24.211:8886 012 : Command code
000000: assword, default
000000
119.147.24.211
Platform server IP
8886: Platform server software
Port
When the 900C connect to the monitor system, the ower LED flash by 1 S. Then you can login
in the tracking server to manage your car.
13
