ZLAN ZLAN8303 User manual

1
ZLAN8303/8303-5(N)
3G/4G Serial Device
Server
User Manual
RS232/485 to 3G/4G Converter
Modbus RTU to 3G/4G Modbus TCP
RS232/485 P2P 3G/4G Serial Device Server
CopyRight©2008 Shanghai ZLAN Information Technology Co., Ltd. All right
reserved
Document DI: ZL DUI 20141016.1.0

2
CopyRight©2008 Shanghai ZLAN Information Technology Co., Ltd. All right reserved
Version Information
The History of the revision to this document:
History
Date
Version
Document ID
Revising content
2014-10-16
Rev.1
ZL DUI 20141016.1.0
Release
2016-02-19
Rev.2
ZL DUI 20141016.2.0
Update
Copyright information
Information in this document is subject to change without notice. It is against the law to copy the
document on any medium except as specifically allowed in the license or nondisclosure
agreement. The purchaser may make one copy of the document for backup purposes. No part
of this manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or through information storage and retrieval
systems, for any purpose other than for the purchaser’s personal use, without the express
written permission of Shanghai ZLAN information Technology Co., Ltd.

3
Content
1. Summary......................................................................................................................................... 4
1.1 Normal 3G/4G DTU........................................................................................................... 5
1.2 Multi-host and Modbus Gateway.................................................................................. 7
1.3 P2P 3G/4G Serial Device Server ................................................................................... 7
2. Features .......................................................................................................................................... 9
3. Technical Parameters.................................................................................................................. 9
4. Function........................................................................................................................................ 10
4.1 Hardware Instruction..................................................................................................... 10
4.2 Power Saving Mode ....................................................................................................... 13
4.3 Device Configuration and Usage................................................................................ 13
4.4 Used as 3G/4G Router................................................................................................... 13
4.5 P2P usage......................................................................................................................... 13
4.6 485 Character................................................................................................................... 13
5. Appendix....................................................................................................................................... 14
5.1 Power On Process.......................................................................................................... 14
5.2 Model Selection............................................................................................................... 16
6. After-service................................................................................................................................. 16

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
4
1. Summary
ZLAN8303 is 3G/4G network solutions launched by Shanghai ZLAN after ZLAN8100. The
serials contain 4 sub-models: 8303 (support Telecom 3G), 8343 (Support Modbus TCP
Gateway), 8303-5 (Support Mobile and Unicom 3G/4G), 8303N (Support P2P). The
function of Modbus TCP and P2P can add to models 8303 or 8303-5 such as
ZLAN8343N-5.
Figure 1 ZLAN8303 Appearance
8303 has RS232/485 interface, can send the data collected by RS232/485 to the cloud
server. Combined with ZLAN P2P technology, the users can collect data anytime and
anywhere without building server, the collecting method can also be a virtual serial port. If
be 8343N, can convert Modbus TCP protocol to Modbus RTU, the users use Modbus TCP
to collect data of RTU devices on the computer. ZLAN8343N and ZLAN8343N-5 are the
most functional serial server separately applied to P2P Modbus Gateway of Telecom and
Mobile/Unicom, suitable for PLC monitoring and field data collection very well.
8303 also has the Ethernet port, can use it to communication in the places with Ethernet,

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
5
users can save the 3G/4G traffic. In addition 8303 can be used as 3G/4G router to achieve
Ethernet port converting to 3G/4G.
Applications:
PLC remote monitor
Industrial remote control/sensing/measurement
Public Utilities
Meteorological Data Acquisition
Three-Proofing & Hydrology Monitor
Finance, GPRS, etc.
The following is the application of each sub-model respectively. Please refer to section 5
below for model selection.
1.1Normal 3G/4G DTU
The normal 3G/4G DTU can be as TCP Server connected by other network devices,
since the 8303 IP is not fixed when under 3G/4G mode, usually it isn’t as TCP Server,
but mostly as TCP Client to connect an fixed IP (or domain name) Server, and send its
collecting data. The software on Server ask data through polling style. The RS485/232
of 8303 can connect with serial device and PLC needed collected, sending polling
command to PLC, and upload the returned data to server. Shown as Figure 2.
Figure 2 Normal 3G/4G DTU Mode
In this way the purpose of the 8303 IP must be set to the server IP, that is to say the

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
6
user must lease a server with a public network IP. However, for some application users
may not have a public network server, because the user dial-up through the router, then
the router must be set on the "port mapping" and "dynamic domain name" to send 8303
data to the server. "Port mapping" and "dynamic domain name" have the following
problems:
1) Some routers are standard telecom, cannot log in so cannot do some settings.
2) "Port mapping" for the average user may be too specialized, set up trouble.
3) "Dynamic domain name" free program may exist stability, real-time problems.
Of course, for the public network IP server users, ordinary ZLAN8303 is also very
convenient to use. The following lists the differences between ZLAN8303 and
ZLAN8303-5.
In this way, the Destination IP of 8303 must be set to the server's IP, which means that
the user must rent a server with a public network IP. But for some applications the user
may not have a public server, because the user access Internet through a router dial-up,
at this time user must set “Port Mapping "and" Dynamic Domain Name "on the router so
that can send 8303 data to the server. There are some problems with "port mapping"
and " Dynamic Domain Name":
1) Some routers are Telecom standard matched, unable to log in so that some
Settings cannot be done.
2) "Port Mapping" may be too specialized for regular users as setting up with trouble.
3) The free scheme of "Dynamic Domain Name" may have stability and real-time
problems.
Of course, for users with public network IP servers, it is also convenient to use the
normal ZLAN8303. The differences between ZLAN8303 and zlan8303-5 are listed
below.
Model
Support Mode
ZLAN8303
CDMA2000, Telecom 3G network. If you use a Telecom 4G card, you
can also communicate, but in 3G mode. 3G speed is enough for data
monitoring. So you don't have to deal with 3G CARDS.

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
7
ZLAN8303-5
Support 5 operating modes, support Mobile, Unicom card, Telecom 4G
card (but does not support telecom 3G/2G card).
1.2Multi-host and Modbus Gateway
The model with this function is ZLAN8343 or zlan8343-5. These two models have the
following two functions:
1) Modbus Gateway can be configured. As long as set the “Device/Advanced
Parameter/Transformation Protocol” to "Modbus TCP to RTU", it is switched to
Modbus Gateway mode. The upper computer can be queried with Modbus TCP,
while PLC can use RTU instructions. The Modbus of 8343 is storage Modbus
Gateway, and the polling is more real-time.
2) Multiple hosts. When set to Modbus Gateway, multiple host queries can be made,
and 8303 will answer separately to realize multi-host query. In the non-Modbus
Gateway mode, for the 8343 model, you just check the "multi-host" support in more
advanced options it can also implement the multi-host queries.
ZLAN-multi-host technology is a technology developed for multi-host monitoring a
device at the same time. In the ordinary serial device server or DTU, when there isA, B
two monitoring computer, A and B can send data to the device, but data the device
received from the serial port will be sent to theAand B at the same time. In other words,
when A and the device communicate, B will receive unwanted data, which will interfere
B's communication. Many software protocols will not be able to adapt to this situation
and may not work.
The ZLAN multi-host technology can can achieve the communication scheduling
betweenAand B computers.WhenAcommunicates with the device, the response data
of the device is only sent to A; When B needs to communicate, you can quickly switch
to B. ZLAN8343 will enable multiple computers to monitor the same device
simultaneously.
1.3P2P 3G/4G Serial Device Server
The model with this function is ZLAN8303N or ZLAN8303N-5. This model integrates

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
8
ZLAN's P2P technology, which can solve the inconvenience of "Port Mapping" and
"Dynamic Domain Name" in general 3G/4G DTU.
Figure 3 3G/4G DTU Mode of P2P
As shown in FIG. 3, compared with FIG. 2, (a) we increase the ZLAN P2P server, (b)
the user computer replaces the monitoring server. Instead of using the server for
monitoring, users can monitor their laptops whenever and wherever they are.
At the beginning of the communication, the P2P software on the user's
computer---ZLVircom, communicated with the ZLAN P2P server. At the same time,
8303 can also communicate with ZLAN P2P server, which can establish direct
communication between 8303 and ZLVircom (without the P2P server forwarding) after
the negotiation is done. The software on the user's computer can communicate via a
virtual serial port provided by ZLVircom or a TCP mock port.
When used, the user only needs to enter the serial number of 8303 that needs to be
monitored in ZLVircom software to establish the P2P connection. The P2P approach
allows users to get rid of the "Port Mapping", "Dynamic Domain Name" and the server
of a public network IP, which can easily and conveniently do monitoring anytime and
anywhere.
The combination of P2P technology and 3G/4G wireless technology has implemented
an innovative monitoring method, which has the following characteristics:
1) Easy to use, users only need to add the serial number of 8303 so can go to

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
9
operate, no need any professional operation such as Port Mapping.
2) No additional cost, users no need to lease public server.
3) Support virtual serial port, no need to modify client PLC software, like local serial
communication.
4) As no need to transfer through server, but direct P2P communication, shorten data
communication time, improve the communication real-time, reduce the load of
center server.
5) Support communication type of encryption and user name authentication to ensure
the security of communication.
2. Features
1) The supporting 3G/4G network
a) 8303/8343/8303N/8343N: support EVDO/CDMA2000, Telecom 3G network
b) 8303-5/8343-5/8303N-5/8343N-5: support 5 modes, TD-LTE/ FDD-LTE/ WCDMA/
TD-SCDMA/ GSM, Unicom 4G/3G/2G, Mobile 4G/3G/2G and Telecom 4G network
2) Provide an Ethernet port, can be used as 3G router. Can be used as Ethernet DTU to
save traffic when on the cable network, same as serial port server.
3) Support P2P connection, no need fixed IP and server, convenient to communicate and
connect.
4) Support Modbus Gateway, as Modbus TCP converting to Modbus RTU.
5) Support multiple hosts monitoring, no interference between each other.
6) SIM card installation in drawer type without disassembly.
7) 8303 can be controlled in dormancy via serial port to operate in low power.
3. Technical Parameters
Support Model
8303/8343/8303N/8343N：SYS EVDO/CDMA2000, Telecom 3G/2G network

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
10
8303-5/8343-5/8303N-5/8343N-5 ：Support 5 modes, TD-LTE/ FDD-LTE/
WCDMA/ TD-SCDMA/ GSM, Unicom 4G/3G/2G, Mobile 4G/3G/2G and
Telecom 4G network
Transmission Rate
3G network speed: uplink 5.76Mbps download 7.2Mbps
4G network speed: uplink 2Mbps download 68Mbps
SIM Card
Voltage: 3V, 1.8V; Size: Big Card（Small card can buy card sets）
Antenna Interface
Optional 50Ω/SMA glue stick antenna or sucker antenna
Serial Port Type
RS-232/RS-485
Serial Port Parameter
Baud Rate: 1200~115200bps; Data bit: 5～9; Stop bit：1～2; Flow Control:
Hardware, Software; Check bit: None, Odd, Even, Mark, Space
Power Supply
Q2.1 outlet, can be customized to power terminal input
Input Voltage
DC9V~24V
Working Current
< 200mA@9V
Operating
Temperature
-40~85℃
Running temperature:
-40~90℃
Storage temp:
0~95% Non - Condensing
Size:
L×W×H=9.4cm×6.5cm×2.5cm
4. Function
4.1Hardware Instruction
The front view of ZLAN8303/N is shown as FIG. 4.

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
11
Figure 4 ZLAN8303 Front View
Panel Light:
Indicato
r
Green
BLUE
Active
There is data passing serial port
There is data input from serial port
Link
The network function module has
been initialized
Always bright: the TCP connection is established
Blinking: P2P initialization completed
SYS
Always bright: system in startup
Flashing: the system startup finished
Rapidly flashing: 3G in connection
Always bright: 3G connection success

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
12
Figure 5 Interface Diagram 1
1) The front interface of ZLAN8303 is shown in figure 5:
a) Power input: interface form Q2.1 socket, DC+9V ~ +24VDC, power needs
over 12W. The default adapter is 9V. Can be customized to power terminal
type input.
b) RS485 signal input.
c) RJ45 interface, Ethernet access end. 3G connection no need to connect RJ45.
If the RJ45 has light on some model, the indicator light flashes indicates that
the network port data is active.
2) The back interface of ZLAN8303 is shown in figure 6:
Figure 6 Interface Diagram 2
a) Antenna: 8303 antenna interface using 50Ω/SMA(female), if external antenna
must use the antenna suitable for 3G/4G working band. ZLAN can provide a
gel antenna and a suction antenna that can be sucked onto a metal shell (by
default 2M).
b) SIM card installation: ensure that the device isn’t power on when installing the

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
13
SIM card. Use the pen and screwdriver to push out the SIM card slot, and the
SIM metal surface pushes down into the card slot.
c) DB9: RS232 signal input, support flow control. Among them, the 9th pin is
dormant control, and the high level gives 8303 dormant state.
4.2Power Saving Mode
3G devices sometimes don't work long hours and have alarm data opened, which can
save traffic and save batteries. Thus the resting function is designed for 8303/8303-5,
as long as the RS232 pin9 connect to high level 5V, it can cut off almost all the power
of the device. Without connecting pin9, or set to 0, the system is power re-supply.
4.3Device Configuration and Usage
Please install ZLVircom software on your computer, then connect the Ethernet port of
the computer to ZLAN8303 Ethernet port. The device can be searched by ZLVircom
after normal operation with power on, and the serial parameters and IP parameters of
the device can be configured after being searched out. Specific configuration method
please refer to file <User Guide of Networking Products>.
If configured as 3G access network (not the Ethernet port access), please use
ZLVircom to configure the device's gateway to 192.168.10.1, the IP to 192.168.10.200,
DNS domain name server to 192.168.10.1, and IP can also be obtained dynamically. If
8303N needs to enable P2P, then go to "More Advanced Settings", check "Enable
P2P", and then click ok and modify Settings.
4.4Used as 3G/4G Router
For more configuration of routers, refer to the instructions of ZLAN8300 3G/4G router.
4.5P2P usage
Please refer to the file for the use of P2P products.
4.6485 Character
ZLAN8303 meet the RS485 standard, each ZLAN8303 can be with 32 terminal 485

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
14
devices. The maximum communication distance is 1200 meter, the resistance of 485
terminal is 120 ohms, usually must use terminal resistance when wiring over 300m.
Pay attention to the wiring, 485+ and 485- must be a twisted-pair, in order to reduce
signal interference.
5. Appendix
5.1Power On Process
Here is a list of the changes of the 8303 power on process indicator light to help users
analyze the steps of the device to help troubleshoot problems.
Table 1 8303-5 Power-on Process (Configured as DHCP Mode)
Time(s)
Status
SYS
LINK
0～1
Power on reset
BLUE
OFF
1～18
System in startup
GREEN
OFF
18～42
The system is started and the
network is initialized
GREEN flash,
frequency is 1 second
OFF
42～60
The 4G module initialization
begins
GREEN flash,
frequency is 1 second
GREEN for 1 second,
then off
60～82
4G first dial-up connection
BLUE flash, frequency
is 0.2 seconds/time
82～126
4G ready for a second dialing
GREEN flash,
frequency is 1 second
OFF
126 ～
150
4G the second dialing
BLUE flash, frequency
is 0.2 seconds/time
OFF
150～
4G in connection
BLUE (with faint
GREEN flash)
The BLUE blinks after
P2P connection.
Table 2 8303 Power-on Process
Time(s)
Status
SYS
LINK
0～1
Power on reset
BLUE
OFF

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
15
1～12
System in startup
GREEN
OFF
12～29
The system is started and the
network is initialized
GREEN flash,
frequency is 1 second
OFF
29～31
The network initialization is
completed, 3G module initialization
begins
GREEN flash,
frequency is 1 second
GREEN
31～52
3G is Connecting
BLUE flash, frequency
is 0.2 seconds/time
GREEN
52～73
3G connecting success
BLUE (with faint
GREEN flash)
GREEN
73～87
P2P initialization is completed (this
step only P2P products set to P2P
mode)
BLUE
BLUE flash,
frequency is 1
second
If you use the ZLAN8303-5, the user's card is a 3G card, then need to dial twice, the
first time using the 4G mode dial-up if failed it will use 3G dial-up, this time dialing time
will be slower. But using 2G Mobile card will be one time dialing success in
ZLAN8303-5.
Table 3 Ethernet Connection (SIM card not installed) Power-on Process
Time(s)
Status
SYS
LINK
0～1
Power on reset
BLUE
OFF
1～3
System in startup
GREEN
OFF
3～6
The network initialization is
completed
GREEN
GREEN
6～15
P2P initialization is completed
(this step only P2Pproducts set to
P2P mode)
GREEN
BLUE flash,
frequency is 1
second
15～29
System initialization is complete,
normal operation.
GREEN flash,
frequency is 1
second
GREEN(BLUE flash
if P2P Mode)
3G dialing. Although there is no
BLUE flash,
GREEN

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
16
SIM card installed, 3G dialing is
done every time, dial for 2
minutes, and then idle for 1
minute. Repeatedly, in dial-up
periods Ethernet data
communication is not affected.
frequency is 0.2
seconds/time
5.2Model Selection
The following list of selection steps for the 8303 series are provided for users'
reference::
1) Select the model:
A Field
4: support for multi-host and Modbus Gateway functions; 0: multi-host and
Modbus Gateways are not supported.
B Field
N: support for P2P function; Empty: no P2P function.
C Field
-5: support the 3G/4G model of Unicom and Mobile card; Empty: support
Telecom 3G model.
2) Antenna selection:
Can choose glue stick antenna or suction dish antenna, the suction dish antenna is
2M by default, can be customized 3M antenna.
3) Power input:
The default is the plug type Q2.1 socket, which can be customized for wiring
terminal type power input.
6. After-service
Shanghai ZLAN Information Technology Co., Ltd.

Shanghai ZLAN Information Technology Co., Ltd Tel: [phone] http://www.zlmcu.com
17
Address: 12 floor, D building, No. 80 CaoBao road, Xuhui District, Shanghai, China
Phone: [phone]
Fax: [phone]
Web: http://www.zlmcu.com
Email: [e-mail]
