Zline FRC5117-30 Assembly instructions

Fireclay SinkS
Installation Guide
and Users Manual

Fireclay sinks are meticulously handcrafted in Italy from a unique type of
clay found in limited regions of the country. Constructed to be resistant to
bacteria, stains, cracks, and scratches, this statement sink is non-porous
and naturally sound absorbing. Fireclay sinks are hardier than traditional
ceramic sinks, allowing for a worry-free washing experience. All ZLINE
fireclay sinks are garbage disposal compatible for easy cleanup.

4
SAFETY INSTRUCTIONS 1
SINK DIMENSIONS 2
SINK INSTALLATION 10
CARE AND CLEANING 11
CONTENTS

1
The installer and/or user must read, understand, and follow these instructions before
installing the product. This product must be properly installed before it is used. If
instructions are not followed, the manufacturer will not be held responsible for any
problems or product malfunction. Failure to follow installation and/or operating
instructions voids the warranty.
We recommend that this product be installed by a certified plumber. In some states
or provinces, it is a legal requirement for this type of product to be installed by a
certified plumber, according to the plumbing and building codes effective in the
region where the sink is used.
DO NOT attempt to install this sink yourself. Injury could result from installing the unit
due to lack of appropriate plumbing and technical background. Due to the size and
weight of this sink, two people installation is recommended.
It is recommended that the cabinet maker waits until the sink is delivered to make the
cabinet.
Shut off the water valves before installing the sink or doing any maintenance.
Disconnect the power to the dishwasher and garbage disposal.
Open the sink packaging and verify that the sink is in perfect condition. Put the sink
back in its packaging to protect it until time of installation.
Safety Instructions

2
Fireclay Sink Single Bowl
FRC5117-30 (Apron Mount)
1514
29 59/64”
18 7/64” 15 23/64”
27 11/64”
10 3/64”
10 3/64”
1 3/8”
1 3/8”
26 3/8”
29 17/32”
27 11/64”
15 23/64”
2 1/8”
7 7/8”
3 1/2”
9 1/16”
16 17/32”
25 19/32”
8 15/32”
1 3/8”1 3/8”
section
760
460 390
690
254
254
35
35 35
35
670
750
690
390
45
200
3 1/2”
230
420
650
215
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 30”x18”x10”/760x460x254h
5117 white / blanc
5117 NE black / noir
5117 BS biscuit / biscuit
50110
50110
50110
kgLbs.
Item code/Article
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Sink Dimensions

3
Fireclay Sink Single Bowl
FRC5119-30 (Apron Mount)
2928
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 30”x18”x10”/760x460x254h
760
460 390
690
254
254
35
35 35
35
670
750
690
390
45
200
ø90
230
420
650
215
29 59/64”
18 7/64” 15 23/64”
27 11/64”
10 3/64”
10 3/64”
1 3/8”
1 3/8” 1 3/8”
1 3/8”
26 3/8”
29 9/4”
27 11/64”
15 23/64”
2 1/3”
7 7/8”
3 1/2”
9 1/16”
16 17/32”
25 19/32”
8 15/32”
5119 white /blanc
5119 NE black / noir
5119 BS biscuit / biscuit
74 34
74 34
74 34
Lbs. kg
Item code/Article
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
760
460 390
690
254
254
35
35 35
35
670
750
690
390
45
200
ø90
230
420
650
215
29 59/64”
18 7/64” 15 23/64”
27 11/64”
10 3/64”
10 3/64”
1 3/8”
1 3/8” 1 3/8”
1 3/8”
26 3/8”
29 9/4”
27 11/64”
15 23/64”
2 1/3”
7 7/8”
3 1/2”
9 1/16”
16 17/32”
25 19/32”
8 15/32”
Sink Dimensions

4
3130
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 24”x18”x10”/610x460x254h
610
460
390
540
254
254
35
35 35
35
610
540
390
54
200
90ø
230
420
215
24 1/64”
18 7/64”
15 23/64”
21 17/64”
10 3/64”
10 3/64”
1 3/8”
1 3/8” 1 3/8”
1 3/8”
23 5/8”
21 17/64”
15 23/64”
2 1/8”
7 7/8”
3 1/2”
9 1/16”
16 17/32”
8 15/32”
5120 white /blanc
5120 NE black / noir
5120 BS biscuit / biscuit
60 27,5
60 27,5
60 27,5
Lbs. kg
Item code/Article
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
610
460
390
540
254
254
35
35 35
35
610
540
390
54
200
90ø
230
420
215
24 1/64”
18 7/64”
15 23/64”
21 17/64”
10 3/64”
10 3/64”
1 3/8”
1 3/8” 1 3/8”
1 3/8”
23 5/8”
21 17/64”
15 23/64”
2 1/8”
7 7/8”
3 1/2”
9 1/16”
16 17/32”
8 15/32”
Fireclay Sink Single Bowl
FRC5120-24 (Apron Mount)
Sink Dimensions

5
1110
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 36”x18”x10”/914x46x254h
914
460
441
179
230
ø89
35 3535
50
230
423
35
459 350
914
254
35 31/32”
18 7/64“
17 23/64“
7 3/64“
9 3/64“
ø3 1/2”
1 61/64”
9 3/64“
16 41/64”
1 3/8” 1 3/8” 1 3/8” 1 3/8”
18 1/16“ 13 49/64“
35 31/32“
10”
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
5121 white / blanc
5121 NE black / noir
5121 BS biscuit / biscuit
71,5157
71,5157
71,5157
kgLbs.
Item code/Article
Fireclay Sink Double Bowl
FRC5121-36 (Apron Mount)
Sink Dimensions

6
2524
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 36”x18”x10”/914x460x254h
35 13/16”
18 7/64” 15 11/32”
33 1/16”
ø 3 1/2“
10”
10”
1 3/8”
1 3/8” 1 3/8”
1 3/8”
35 13/16”
15 11/32”
2 1/8”
7 55/64”
3 1/2”
9 3/64”
16 17/32”
8 29/64”
910
460 390
ø 89
850
254
254
35
35 35
35
910
390
54
200
ø90
230
420
215
5122 white /blanc
5122 NE black / noir
5122 BS biscuit / biscuit
87 39,5
87 39,5
87 39,5
Lbs. kg
Item code/Article
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Fireclay Sink Single Bowl
FRC5122-36 (Apron Mount)
Sink Dimensions

7
4140
24”x18”x10”/610x460x255h
5123 white /blanc 52 23,5
Lbs. kg
Item code/Article
24 01/57”
18 7/64”
15 74/8”
21 65/35”
9 44/88”
10 03/94”
1 18/11”
6 29/92”
12 00/79”
1 18/11”
22 44/09”
0 59/05”
9 05/51”
610
460
400
550
240
255
30
30
570x416 305
15
230
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Dual mount Kitchen Sinks/Sous plan et sur plan Dual mount Kitchen Sinks/Sous plan et sur plan
30”x 18”x10”/760x460x255h
5124 white /blanc 63 28,5
Lbs. kg
Item code/Article
760
460
400
700
240
255
30
30
720x4160 380
15
230
29 92/13”
3 54/33”
15 74/8”
15 74/8”
27 55/91”
9 44/88”
10 03/94”
1 18/11”
6 29/92”
14 96/06”
1 18/11”
28 34/65”
0 59/05”
9 05/51”
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Fireclay Sink Single Bowl
FRC5123-36 (Dual Mount)
Sink Dimensions

8
4140
24”x18”x10”/610x460x255h
5123 white /blanc 52 23,5
Lbs. kg
Item code/Article
24 01/57”
18 7/64”
15 74/8”
21 65/35”
9 44/88”
10 03/94”
1 18/11”
6 29/92”
12 00/79”
1 18/11”
22 44/09”
0 59/05”
9 05/51”
610
460
400
550
240
255
30
30
570x416 305
15
230
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Dual mount Kitchen Sinks/Sous plan et sur plan Dual mount Kitchen Sinks/Sous plan et sur plan
30”x 18”x10”/760x460x255h
5124 white /blanc 63 28,5
Lbs. kg
Item code/Article
760
460
400
700
240
255
30
30
720x4160 380
15
230
29 92/13”
3 54/33”
15 74/8”
15 74/8”
27 55/91”
9 44/88”
10 03/94”
1 18/11”
6 29/92”
14 96/06”
1 18/11”
28 34/65”
0 59/05”
9 05/51”
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Fireclay Sink Single Bowl
FRC5124-24 (Dual Mount)
Sink Dimensions

9
2726
Reversible Farmhouse Sinks/Éviers de cuisine réversibles 33”x18”x10”/840x460x254h
5131 white /blanc
5131 NE black / noir
5131 BS biscuit / biscuit
76 34,5
76 34,5
76 34,5
Lbs. kg
Item code/Article
18 11/02”
33 07/09”
ø 3 54/33”
29 52/76”
16 14/17”
10”
11 02/36”
30 31/5”
1 37/79”
15 35/43”
9 05/51”
9 05/51”
7 99/21”
1 37/79”
460
840
ø 90
750
410
254
280
770
35
390
230
230
203
35
Due to +/2% dimensions, it is recommended that the
cabinet maker waits until the sink is delivered to make
the cabinet.
Les dimensions pouvent varier de +/- 2%, il est recom-
mandé d’effectuer les découpes et ajustements dans le
meuble une fois livré l’évier.
Fireclay Sink Single Bowl
FRC5131-33 (Apron Mount)
Sink Dimensions

10
Sink Installation
Before Installation
Inspect the sink for any visible defects. Do not install the sink if defects are found. Call
customer service at 1-614-777-5004 for assistance.
Installation
1. Preparing the Cabinets
Make sure that the tank will not interfere with cabinet doors or panels. Ensure that
there is enough space for the water supply installation.
2. Build a Support Frame
Fireclay sinks need support due to their weight. Installing wooden support beams
underneath the sink will reinforce it. Ensure that the top of the sink is aligned where
you would like it. Create vertical and horizontal supports with the 2x4s.
3. Insert the Sink
Insert the sink on the support frame. Apply silicone-based sealant to each corner
between the frame and the sink.

11
Easy Cleaning Instructions
Fireclay sinks can be washed with dish soap and water. A rinse and towel drying
after each use will take care of most everyday clean ups.
Scratches
Fireclay sinks are scratch-resistant, but the matte finishes tend to show more markings.
Markings that appear to be scratches are typically residue left by metal cutlery or
pots and pans. A grid is recommended to reduce appearance of markings. Markings
can be removed with a diamond sponge or a Scotch-Brite™ pad.
Chips
Fireclay sinks are extremely resistant to chips, but if you find any small chips in your
sink, there are repair kits available at most local hardware stores.
Food
Food can easily become stuck in the corners of the fireclay sink due to its shape. Rinse
out all food particles to keep the sink clean.
Dos and Dont’s
Do rinse thoroughly after each use.
Do towel dry after each use to prevent mineral deposits from building up on the
surface of the sink.
Do clean the sink once a week.
Do wax the sink once a month.
Do Not allow soap or other household cleansers to dry on the surface of the sink.
Do Not use abrasive cleaners to clean your sink.
Care and Cleaning

Kitchen and Bath
Three Locations:
350 Parr Circle
Reno, NV 89512
916 Delaware Avenue
Marysville, OH 43040
319 Rowland Mill Road
Bruceton, TN 38317
www.zlinekitchen.com
1-614-777-5004
