Zotac H55 - ITX wifi series User manual

1
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with instructions
contained in this manual, may cause harmful interference to radio and television communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- REORIENT OR RELOCATE THE RECEIVING ANTENNA
- INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND THE RECEIVER
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT OF THE RECEIVER
- CONSULT THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN
NOTE:
Connecting this device to peripheral devices that do not comply with Class B requirements, or
using an unshielded peripheral data cable, could also result in harmful interference to radio or
television reception.
The user is cautioned that any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
To ensure that the use of this product does not contribute to interference, it is necessary to use
shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be copied or
reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility for
errors or omissions is assumed. Neither is any liability assumed for damages resulting from the
use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their respective
owners.
Electronic Emission Notices
WARNING!

2
Intel H55-ITX series Motherboard
Table of Contents
Motherboard Specications ---------------------------------------------------------------------------------4
Motherboard Layout--------------------------------------------------------------------------------------------6
Hardware Installation ------------------------------------------------------------------------------------------9
Safety Instructions-------------------------------------------------------------------------------------------9
Preparing the Motherboard ----------------------------------------------------------------------------------10
Installing the CPU -------------------------------------------------------------------------------------------10
Installing the CPU Fan -------------------------------------------------------------------------------------11
Installing Memory DIMMs ---------------------------------------------------------------------------------11
Installing the Motherboard---------------------------------------------------------------------------------12
Installing the I/O Shield ------------------------------------------------------------------------------------12
Securing the Motherboard into the Chassis ----------------------------------------------------------12
Connecting Cables and Setting Switches --------------------------------------------------------------13
24-pin ATX Power Connector-PW1 ---------------------------------------------------------------------14
4-pin ATX_12V power connector-PW2-----------------------------------------------------------------14
SPDIF-Out Header-CN5 -----------------------------------------------------------------------------------15
COM Header-CN4 (Optional)-----------------------------------------------------------------------------15
Front panel header-FP1 -----------------------------------------------------------------------------------15
USB Headers-FP_U1~FP_U2 ---------------------------------------------------------------------------16
Front Pannel Audio Header-FP_S1 ---------------------------------------------------------------------16
Speaker Header-SPK1-------------------------------------------------------------------------------------17
Serial-ATA (SATA) Connectors (SATA1~6)------------------------------------------------------------17
Fan Connectors ----------------------------------------------------------------------------------------------17
Expansion Slots----------------------------------------------------------------------------------------------18
Mini PCIE Slot--------------------------------------------------------------------------------------------18
PCIE x16 Slot --------------------------------------------------------------------------------------------18
Jumper Settings----------------------------------------------------------------------------------------------18
Conguring the BIOS ------------------------------------------------------------------------------------------19
Enter BIOS Setup--------------------------------------------------------------------------------------------19
Main Menu-----------------------------------------------------------------------------------------------------19
Advanced Menu ----------------------------------------------------------------------------------------------20
CPU Conguration --------------------------------------------------------------------------------------20
IDE Conguration ---------------------------------------------------------------------------------------21
Hardware Health Conguration ----------------------------------------------------------------------21
ACPI Conguration--------------------------------------------------------------------------------------21
AHCI Conguration -------------------------------------------------------------------------------------21
Intel TXT(LT) Conguration ---------------------------------------------------------------------------21
Intel VT-d Conguration--------------------------------------------------------------------------------21
MPS Conguration --------------------------------------------------------------------------------------21
PCI Express Conguration----------------------------------------------------------------------------22

3
Table of Contents
Smbios Conguration---------------------------------------------------------------------------------22
Trusted Computing ------------------------------------------------------------------------------------22
USB Conguration-------------------------------------------------------------------------------------22
PCI/PnP Menu -----------------------------------------------------------------------------------------------23
Boot Menu -----------------------------------------------------------------------------------------------------24
Security Menu ------------------------------------------------------------------------------------------------25
Chipset Menu-------------------------------------------------------------------------------------------------26
Exit Menu ------------------------------------------------------------------------------------------------------26
Flash Update Procedure ----------------------------------------------------------------------------------27
Installing Drivers and Software--------------------------------------------------------------------------------28
Driver Installation -------------------------------------------------------------------------------------------------28
Realtek HD Audio Driver Setup ------------------------------------------------------------------------------39
Getting Started -----------------------------------------------------------------------------------------------39
Sound Effect --------------------------------------------------------------------------------------------------39
Environment Simulation------------------------------------------------------------------------------39
Equalizer Selection -----------------------------------------------------------------------------------40
Frequently Used Equalizer Setting ----------------------------------------------------------------40
Karaoke Mode ------------------------------------------------------------------------------------------40
Mixer ------------------------------------------------------------------------------------------------------------41
Playback control ---------------------------------------------------------------------------------------41
Recording control --------------------------------------------------------------------------------------42
Audio I/O ------------------------------------------------------------------------------------------------------43
Speaker Conguration -------------------------------------------------------------------------------44
Connector Settings------------------------------------------------------------------------------------45
S/PDIF ---------------------------------------------------------------------------------------------------45
Speaker Calibration-----------------------------------------------------------------------------------46
Microphone----------------------------------------------------------------------------------------------------47
Noise Suppression ------------------------------------------------------------------------------------47
Beam Forming------------------------------------------------------------------------------------------47
Acoustic Echo Cancellation -------------------------------------------------------------------------47
Audio Demo---------------------------------------------------------------------------------------------------48
Information ---------------------------------------------------------------------------------------------48

4
Intel H55-ITX series Motherboard
Motherboard Specications
qChipset
v Intel® H55 Express Chipset
qSize
v MINI ITX form factor of 6.7 X 6.7 inch
qMicroprocessor support
v Supports LGA 1156 socket for Intel®CoreTM i3/CoreTM i5 processors
qOperating systems
v Supports Windows XP 32bit/64bit, Windows Vista 32bit/64bit and Windows 7 32bit/64bit
qSystem Memory
v Supports dual-channel (128 bits wide) DDRIII memory interface
v Supports DDRIII 1333/1066
v Maximum memory size: 8 GB
q USB 2.0 ports
v Supports hot plug and play
v Fourteen optional USB 2.0 ports (ten optional ports on the back panel, four via the USB
brackets connected to the internal USB headers)
v Supports USB 2.0 protocol up to 480 Mbps transmission rate
qOnboard Serial ATA ports
v Independent DMA operation on six ports (optional)
v Data transfer rates of 3.0 Gb/s
qeSATA Port
v One eSATA port on backpanel
v Supports hot plug and play
v Provide a link for 3.0 Gb/s data speed
qOnbaord LAN
v Compliant to 802.3x ow control support
v 10/100/1000 BASE-T IEEE 802.3 compliant
v Wake On LAN (WOL) power management support (optional)
qWiFi support (Optional)
v Compliant with IEEE802.11n Draft 2.0 Standard
v High speed wireless connection and enhanced wireless security
v Max transfer rate up to 300 Mbps or 150 Mbps (optional for different models)

5
Motherboard Specications
qAudio
v 7.1+2 channel High Denition Audio Codec
v All DACs support 192k/96k/48k/44.1kHz sample rate
v One SPDIF-out header on board
qGreen Function
v Support SMM, APM, ACPI
v Suspend to DRAM supported (STR)
v RTC timer to power-on the system
v AC power failure recovery
qOnboard Graphics Features
v DX10 and OpenGL 2.0 are supported
v 3D Graphics Rendering Enhancements
v Up to 2048x1536@75 Hz refresh
v HDMI/DVI port output support (DVI-VGA adaptor bundled in some model)
qPCI Express Interface
v Supports PCI Express 2.0
v Provide 16 GB/s bandwidth for platform graphics
v Wake up function is supported
v Clock spread spectrum capability
qExpansion slots
v One PCI express X16 slot
v One MINI PCI express slot (full-height)

6
Intel H55-ITX series Motherboard
120 240
121
120 240
121
1.5V
1.5V
115XLM
LG A1156
REMOVE
LOTES
1
6
SYSFAN1
CPUFAN1
PCIE1
7
SATA1
SATA2 SATA3
8
9
10
PW2
11
12 14
Chipset
15 16 17 18
DDRIII1
DDRIII2
MINI_PCIE1
1
2
51
52
K/B USB
DVI/HDMI
USB/e_SATA
LAN/USB
SD1
CN4
PW1
FP1
SPK1
CN5
FP_S1
USB
JP1
FP_U1
FP_U2
SATA4 SATA5 SATA6
2
3
4
5
SW1
13
1
Motherboard Layout
Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
Figure 1. Board Layout
1. SYS Fan Connector-SYSFAN1
2. COM Header_CN4 (Optional)
3. 24-pin ATX Power Connector-PW1
4. CPU Fan Connector_CPUFAN1
5. Front Panel Header-FP1
6. Speaker Header-SPK1
7. PCI Express x 16 Slot-PCIE1
8. 4-pin ATX_12V power connector-PW2
9. SPDIF-Out Header-CN5
10. Front pannel audio Header-FP_S1
11. Backpanel connectors
12. USB Headers (FP_U1~FP_U2)
13. Clear CMOS Jumper-JP1
14. Serial-ATA (SATA) Connectors (SATA1~6)
15. Chipset
16. CPU Socket
17. Mini PCIE Slot-MINI_PCIE1
18. DDRIII DIMM Sockets-DDRIII1~2
Figure 1

7
7.
Port 2-Channel 4-Channel 6-Channel 8-Channel
Blue Line-In Line-In Line-In Side Speaker Out
Green Line-Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange -- -- Center/Subwoofer Center/Subwoofer
Black -- Rear Speaker Out Rear Speaker Out Rear Speaker Out
Rear panel
1. Clear CMOS Button
3. HDMI Port
2. USB Ports (Optional)
4. eSATA Port
1234
8
9
56
10 7
Figure 2. Backpanel connectors
8. LAN Connector
Lan Port with LEDs to indicate status.
· Yellow/Light Up/Blink = 10 Mbps/Link/Activity
· Yellow and Green/Light Up/Blink = 100 Mbps/link/Activity
· Yellow and Orange/Light Up/Blink = 1000 Mbps/link/Activity
9. DVI Port 10. PS/2 Keyboard Port
11. WiFi antenna connectors (Optional)
This motherboard can support two WiFi antenna modules. Refer to the following to install
the WiFi antenna modules.
Step 1. Secure the MINI PCIE card into the MINI_PCIE1 slot with screws.
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA1 156
REMOVE
LOTES

MINI_PCIE1 slot
MINI PCIE card
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA1 156
REMOVE
LOTES
Screws
11
5. USB Ports 6. Optical SPDIF Output

8
Intel H55-ITX series Motherboard
Step 4. Remove the red caps from the WiFi antenna connectors.
Install the WiFi antennas to the WiFi antenna connectors, and make sure the screws
are rotated in clockwise direction.



Note: 1. Users please note that the appearance of your WiFi antenna modules may
not be exactly the same as those shown in this manual.
2. Users can install one or two WiFi antennas to the motherboard.
3. Users can bend or rotate the WiFi antennas to the best receiving direction
according to the picture below.
Step 2. Secure the bracket to the motherboard with screws according to the picture below.
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA11 56
REMOVE
LOTES
Step 3. Connect the WiFi wires to the MINI PCIE card as the following picture shows.
MINI PCIE card
Bracket
WiFi wires
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA1156
REMOVE
LOTES

Screws
Bracket




9
Hardware Installation
This section will guide you through the installation of the motherboard. The topics covered in this
section are:
q Preparing the motherboard
v Installing the CPU
v Installing the CPU fan
v Installing Memory DIMMs
q Installing the motherboard
qConnecting cables and setting switches
Safety Instructions
To reduce the risk of re, electric shock, and injury, always follow basic safety precautions.
Remember to remove power from your computer by disconnecting the AC main source before
removing or installing any equipment from/to the computer chassis.
Hardware Installation

10
Intel H55-ITX series Motherboard
Preparing the Motherboard
The motherboard shipped in the box does not contain a CPU or memory DIMM. You need to
purchase them to complete this installation.
Installing the CPU
Be very careful when handling the CPU. Make sure not to bend or break any pins on the back.
Hold the processor only by the edges and do not touch the bottom of the processor.
The following illustration shows CPU installtaion components
1. Unhook the socket lever by pushing down
and away from the socket.
2. Lift the socket lever and the load plate to
fully open position.
3. Use your thumb and forenger to lift the cap
up vertically.
● Be careful not to touch the socket contacts.
4. Hold the processor with your thumb and
forenger. Insert the processor into the socket
vertically.
● Align the CPU pin 1 mark with the pin 1
corner of the CPU socket.
5. Make sure the CPU is fully seated, and then
replace the load plate.
● Be sure that the front end of the load
plate is under the shoulder screw.
6. Secure the load lever to its locked location.

11
Installing the CPU Fan
There are many different fan types that can be used with this motherboard. Follow the instruction
that came with your fan assembly. Be sure that the fan orientation is correct for your chassis type
and your fan assembly.
Installing Memory DIMMs
Your new motherboard has two 1.5V 240-pin slots for DDR3 memory. These slots support 1
GB/2 GB/4 GB DDR3 technologies. They also support dual channel DDR3 memory technology
up to 10.7 GB/s. There must be at least one memory bank populated to ensure normal operation.
Refer to the following recommendations to install memory DIMMs.
q One DIMM: Install it into slot 1 or 2. You can install the DIMM into any slot, however, slot 1
is preferred.
q Two DIMMs: Install them into slot 1 and slot 2.
Refer to the following procedure to install memory DIMMs into the slots on the motherboard.
Note that there is only one gap near the center of the DIMM slot. This slot matches the slot on
the memory DIMM to ensure the component is installed properly.
1. Unlock a DIMM slot by pressing the module clips outward.
2. Align the memory module to the DIMM slot, and insert the module vertically into the DIMM
slot. The plastic clips at both sides of the DIMM slot automatically lock the DIMM into the
connector.
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
DDRIII1
DDRIII2
Hardware Installation

12
Intel H55-ITX series Motherboard
Installing the Motherboard
The sequence of installing the motherboard into the chassis depends on the chassis you are
using and if you are replacing an existing motherboard or working with an empty chassis. Deter-
mine if it would be easier to make all the connections prior to this step or to secure the mother-
board and then make all the connections. It is normally easier to secure the motherboard rst.
Use the following procedure to install the I/O shield and secure the motherboard into the chassis.
Note: Be sure that the CPU fan assembly has enough clearance for the chassis covers
to lock into place and for the expansion cards. Also make sure the CPU Fan assem
-bly is aligned with the vents on the covers.
Installing the I/O Shield
The motherboard kit comes with an I/O shield that is used to block radio frequency transmis-
sions, protects internal components from dust and foreign objects, and promotes correct airow
within the chassis.
Before installing the motherboard, install the I/O shield from the inside of the chassis. Press the
I/O shield into place and make sure it ts securely. If the I/O shield does not t into the chassis,
you would need to obtain the proper size from the chassis supplier.
Securing the Motherboard into the Chassis
Most computer chassis have a base with mounting studs or spacers to allow the motherboard
to be secured to the chassis and help to prevent short circuits. If there are studs that do not
align with a mounting hole on the motherboard, it is recommended that you remove that stud
to prevent the possibility of a short circuit. In most cases, it is recommended to secure the
motherboard with spacers.
1. Carefully place the motherboard onto the studs/spacers located inside the chassis.
2. Align the mounting holes with the studs/spacers.
3. Align the connectors to the I/O shield.
4. Ensure that the fan assembly is aligned with the chassis vents according to the fan assembly
instruction.
5. Secure the motherboard with screws.

13
Hardware Installation
Connecting Cables and Setting Switches
This section takes you through all the connectors and switch settings necessary on the mother-
board. This will include:
q Power Connectors
v 24-pin ATX Power Connector-PW1
v 4-pin ATX_12V Power Connector-PW2
q Internal Headers/Connectors
v SPDIF-Out Header-CN5
v COM Header-CN4 (Optional)
v Front Panel Header-FP1
v USB Header (FP_U1~FP_U2)
v Front Pannel Audio Header-FP_S1
v Speaker Header-SPK1
q Serial-ATA (SATA) Connectors (SATA1~6)
q Fan Connectors
q Expansion Slots
q CMOS Jumper Settings
See Figure 1 to locate the connectors and jumpers referenced in the following procedure.

14
Intel H55-ITX series Motherboard
24-pin ATX Power Connector-PW1
PW1 is the main power supply connector. Make sure that the power supply cable and pins are
properly aligned with the connector on the motherboard. Firmly plug the power supply cable into
the connector and make sure it is secure.
PW1-Pin Denition
Pin Signal Pin Signal
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 PWROK 20 -5V
9 +5V_AUX 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
4-pin ATX_12V power connector-PW2
PW2, the 4-pin ATX 12V power connector, is used to provide power to the CPU. Align the pins to
the connector and press rmly until seated.
PW2-Pin Denition
Pin Signal
1 GND
2 GND
3 +12V
4 +12V
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
1
PW2
PW1
1
12
13
24

15
Hardware Installation
SPDIF-Out Header-CN5
This header provides a SPDIF (Sony/Philips Digital Interface) output to digital multimedia device
through coaxial connector.
CN5 - Pin Denition
Pin Signal
1 GND
2 SPDIF-out
3 VCC
q PWRLED
Attach the front panel power LED cable to these two pins of the connector. The Power LED
indicates the system’s status.
q PWR SW
Attach the power button cable from the case to these two pins. Pressing the power button
on the front panel turns the system on and off rather than using the power supply button.
q HDD LED
Attach the hard disk drive indicator LED cable to these two pins. The HDD indicator LED
indicates the activity status of the hard disks.
q RST SW
Attach the Reset switch cable from the front panel of the case to these two pins. The system
restarts when the RESET switch is pressed.
Note: Some chassis do not have all four cables. Be sure to match the name on the
connectors to the corresponding pins.
Front panel header-FP1
The front panel header on this motherboard is
one connector used to connect the following four
cables :
CN5 12
910
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
FP1
CN4
1
COM Header-CN4 (Optional)
CN4 - Pin Denition
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 NC
FP1-Pin Denition
Pin Signal Pin Signal
1 HDD_LED+ 2 PW_LED+
3 HDD_LED- 4 PW_LED-
5 GND 6 PWR_SW
7 RESET 8 GND
9 NC 10 KEY

16
Intel H55-ITX series Motherboard
USB Headers-FP_U1~FP_U2
This motherboard contains ten optional USB 2.0 ports that are exposed on the rear panel of the
chassis. The motherboard also contains two 10-pin internal headers connector onboard.
Note: Secure the bracket to either the front or rear panel of your chassis (not all chassis
are equipped with the front panel option).
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
Front Panel Audio Header-FP_S1
The audio connector supports HD audio standard and
provides two kinds of audio output choices: the Front
Audio, the Rear Audio. The front Audio supports retask-
ing function.
Note:
In order to utilize the front audio header, your chassis must have front audio connector.
Also please make sure the pin assignment on the cable is the same as the pin
assignment on the mainboard header. To nd out if the chassis you are buying supports
a front audio connector, please contact your dealer.
2 1
10 9
FP_S1
1
FP_U1
1
FP_U2
FP_U1~FP_U2-Pin Denition
PIN Assignment PIN Assignment
1 VCC 2 VCC
3 USBP0- 4 USBP1-
5 USBP0+ 6 USBP1+
7 GND 8 GND
9 KEY 10 NC
FP_S1-Pin Denition
PIN Assignment PIN Assignment
1 MIC2(L) 2 GND
3 MIC(R) 4 -ACZ-DET
5 Front Audio(R) 6 Reserved
7 FAVDIO-JD 8 Key(No pin)
9 Front Audio(L) 10 Reserved

17
Hardware Installation
Speaker Header-SPK1
Serial-ATA (SATA) Connectors (SATA1~6)
The Serial ATA connector is used to connect the Serial ATA
device to the motherboard. These connectors support the thin
Serial ATA cables for primary storage devices. The current
Serial ATA interface allows up to 300 MB/s data transfer rate.
There are six serial ATA connectors on the motherboard that
support AHCI conguration.
SPK1-Pin Denition
PIN Assignment
1 VCC
2 NC
3 NC
4 SPK-
SATA-Pin Denition
Pin Signal
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
Fan Connectors
There are two fan connectors on the motherboard, including
system fan connector-SYSFAN1 and CPU fan connector-CPU-
FAN1.
SPK1
1
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
SATA1
CPUFAN1
GND
+12V
Sense
Control
SATA2
SATA3
SATA4 SATA6
SATA5
GND
+12V
Sense
Control
SYSFAN1

18
Intel H55-ITX series Motherboard
Mini PCIE Slot-MINI_PCIE1
There is one Mini PCIE slot, reserved for the WiFi Module.
PCIE x16 Slot-PCIE1
There is one PCIE x16 slot reserved for graphics card. The bandwidth of the PCIE x16 slot is up
to 16 GB/s complianting with PCIE 2.0 specication.
Jumper Settings
This section explains how to congure the motherboard’s hardware. Before using your
computer, make sure all jumpers and DRAM modules are set correctly. Refer to this section
whenever in doubt.
CMOS Clear Jumper-JP1
Close Open * = Default setting.
If you want to clear the system conguration, use the JP1 (Clear CMOS Jumper) to clear data.
Notice:
1. Be sure to save the CMOS setting when exit the CMOS.
2. If the CPU is frequency multiplier locked, no CPU speed change will be seen even if the
frequency multiplier setting in CMOS setup is changed.
JP1 Selection
1-2* Normal*
2-3 CMOS Clear
1
1
120 240
121
120 240
121
1.5V 1.5V
115XLM
LGA 1156
REMOVE
LOTES
151
252
MINI_PCIE1
PCIE1
Expansion Slots
The motherboard contains two expansion slots, one Mini PCIE slot and one PCIE x16 slot.

19
Conguring the BIOS
Conguring the BIOS
This section discusses how to change the system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
Enter BIOS Setup
The BIOS is the communication bridge between hardware and software. Correctly
setting the BIOS parameters is critical to maintain optimal system performance.
Refer to the following procedure to verify/change BIOS settings.
1. Power on the computer.,
2. Press the Del key when the following message briey displays at the bottom of
the screen during the Power On Self Test (POST).
Pressing Del takes you to the BIOS Setup Utility.
Note: 1. We reserve the right to update the BIOS version presented in the manual. The
BIOS pictures shown in this section are for reference only.
2. It is strongly recommended that you do not change the default BIOS settings.
Changing some settings could damage your system.
Main Menu
Note: Users please note
that the data in gray is
non-changeable, and the
others are for selection.
This menu gives you an overview of the general system specications. The BIOS
automatically detects the items in this menu.
q AMI BIOS
Displays the auto-detected BIOS information.
q Processor
Displays the auto-detected CPU specication.
q System Memory
Displays the auto-detected system memory.
q System time
Allows you to set the system time.
