Zotac G41-ITX series User manual

1
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with instructions
contained in this manual, may cause harmful interference to radio and television communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- REORIENT OR RELOCATE THE RECEIVING ANTENNA
- INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND THE RECEIVER
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT OF THE RECEIVER
- CONSULT THE DEALER OR AN EXPERIENCED AUDIO/TELEVISION TECHNICIAN
NOTE:
Connecting this device to peripheral devices that do not comply with Class B requirements, or
using an unshielded peripheral data cable, could also result in harmful interference to radio or
television reception.
The user is cautioned that any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
To ensure that the use of this product does not contribute to interference, it is necessary to use
shielded I/O cables.
Copyright
This manual is copyrighted with all rights reserved. No portion of this manual may be copied or
reproduced by any means.
While every precaution has been taken in the preparation of this manual, no responsibility for
errors or omissions is assumed. Neither is any liability assumed for damages resulting from the
use of the information contained herein.
Trademarks
All brand names, logos and registered trademarks mentioned are property of their respective
owners.
Electronic Emission Notices
WARNING!

2
Intel G4X-ITX series Motherboard
Table of Contents
Motherboard Specications ---------------------------------------------------------------------------------4
Motherboard Layout--------------------------------------------------------------------------------------------6
Hardware Installation ------------------------------------------------------------------------------------------9
Safety Instructions-------------------------------------------------------------------------------------------9
Preparing the Motherboard ----------------------------------------------------------------------------------10
Installing the CPU -------------------------------------------------------------------------------------------10
Installing the CPU Fan -------------------------------------------------------------------------------------11
Installing Memory Modules--------------------------------------------------------------------------------11
Installing the Motherboard---------------------------------------------------------------------------------12
Installing the I/O Shield ------------------------------------------------------------------------------------12
Securing the Motherboard into the Chassis ----------------------------------------------------------12
Connecting Cables and Setting Switches --------------------------------------------------------------13
24-pin ATX Power Connector-PW1 ---------------------------------------------------------------------14
4-pin ATX_12V power connector-PW2-----------------------------------------------------------------14
SPDIF-Out Header-CN6 -----------------------------------------------------------------------------------15
COM Header-CN9 (Optional)-----------------------------------------------------------------------------15
Front panel header-FP1 -----------------------------------------------------------------------------------15
USB Headers-FP_U1---------------------------------------------------------------------------------------16
Front Pannel Audio Header-FP_S1 ---------------------------------------------------------------------16
Speaker Header-SPK1-------------------------------------------------------------------------------------17
Serial-ATA (SATA) Connectors (SATA1~3)------------------------------------------------------------17
Fan Connectors ----------------------------------------------------------------------------------------------17
Expansion Slots----------------------------------------------------------------------------------------------18
Mini PCIE Slot--------------------------------------------------------------------------------------------18
PCIE x16 Slot --------------------------------------------------------------------------------------------18
Jumper Settings----------------------------------------------------------------------------------------------18
Conguring the BIOS ------------------------------------------------------------------------------------------19
Enter BIOS Setup--------------------------------------------------------------------------------------------19
Main Menu-----------------------------------------------------------------------------------------------------19
Advanced Menu ----------------------------------------------------------------------------------------------20
CPU Conguration --------------------------------------------------------------------------------------20
IDE Conguration ---------------------------------------------------------------------------------------20
SuperIO Conguration ---------------------------------------------------------------------------------21
Hardware Health Conguration ----------------------------------------------------------------------21
ACPI Conguration-------------------------------------------------------------------------------------21
MPS Conguration --------------------------------------------------------------------------------------21
PCI Express Conguration----------------------------------------------------------------------------21
Smbios Conguration ----------------------------------------------------------------------------------21
USB Conguration --------------------------------------------------------------------------------------21

3
Table of Contents
Trusted Computing -------------------------------------------------------------------------------------21
PCI/PnP Menu -----------------------------------------------------------------------------------------------22
Boot Menu -----------------------------------------------------------------------------------------------------23
Security Menu ------------------------------------------------------------------------------------------------24
Chipset Menu-------------------------------------------------------------------------------------------------25
Exit Menu ------------------------------------------------------------------------------------------------------26
Flash Update Procedure ----------------------------------------------------------------------------------27
Installing Drivers and Software--------------------------------------------------------------------------------28
Drivers Installation -----------------------------------------------------------------------------------------------28
Realtek HD Audio Driver Setup ------------------------------------------------------------------------------35
Getting Started -----------------------------------------------------------------------------------------------35
Sound Effect --------------------------------------------------------------------------------------------------35
Environment Simulation------------------------------------------------------------------------------------35
Equalizer Selection -----------------------------------------------------------------------------------------36
Frequently Used Equalizer Setting----------------------------------------------------------------------36
Karaoke Mode------------------------------------------------------------------------------------------------36
Mixer ------------------------------------------------------------------------------------------------------------37
Playback control ----------------------------------------------------------------------------------------37
Recording control --------------------------------------------------------------------------------------38
Audio I/O -------------------------------------------------------------------------------------------------39
Speaker Conguration --------------------------------------------------------------------------------40
Connector Settings ------------------------------------------------------------------------------------41
S/PDIF ----------------------------------------------------------------------------------------------------41
Speaker Calibration------------------------------------------------------------------------------------42
Microphone ----------------------------------------------------------------------------------------------43
Noise Suppression-------------------------------------------------------------------------------------43
Beam Forming ------------------------------------------------------------------------------------------43
Acoustic Echo Cancellation--------------------------------------------------------------------------43
Audio Demo----------------------------------------------------------------------------------------------44
Information ----------------------------------------------------------------------------------------------44

4
Intel G4X-ITX series Motherboard
Motherboard Specications
qChipset
v Intel®G41+ICH7
qSize
v MINI ITX form factor of 6.7 X 6.7 inch
qMicroprocessor support
v Supports LGA 775 socket for Intel®CoreTM 2 Quad, CoreTM 2 Duo, Pentium®, Celeron®
processors
v Supports Front Side Bus (FSB) Frequency of 1333/1066/800 MHz
qOperating systems
v Supports Windows XP 32 bit/64 bit, Windows Vista 32 bit/64 bit and Windows 7 32bit/64bit
qSystem Memory
v Supports dual-channel (128 bits wide) DDRII memory interface (For G41ITX-A)
v Supports dual-channel (128 bits wide) DDRIII memory interface (For G41ITX-B)
v Supports DDRII 800/667 (For G41ITX-A)
v Supports DDRIII 1066/800 (For G41ITX-B)
v Maximum memory size: 8 GB
q USB 2.0 ports
v Eight USB 2.0 ports (six on the back panel, two via the USB brackets connected to the
internal USB headers)
v Supports USB 2.0 protocol up to 480 Mbps transmission rate
qOnboard Serial ATA
v Independent DMA operation on three ports (Optional)
v Data transfer rates of 3.0 Gb/s
qeSATA Port
v One eSATA port on backpanel
v Provide a link for 3.0 Gb/s data speed
qOnboard Lan
v Compliant to 802.3x ow control support
v 10/100/1000 IEEE 802.3 compliant
v Wake On LAN (WOL) power management support
q Onboard High Denition Audio
v Supports 6-channel
v Supports Jack-Sensing function

5
Motherboard Specications
v One SPDIF-out header on board
qGreen Function
v Support SMM, APM, ACPI
v Suspend to DRAM supported (STR)
v RTC timer to power-on the system
v AC power failure recovery
qOnboard Graphics Features
v DX10 and OpenGL 2.0 are supported
v 3D Graphics Rendering Enhancements
v Up to 2048x1536@75 Hz refresh
v HDMI/DVI port output support (DVI-VGA adaptor bundled in some model)
qPCI Express Interface
v Supports PCI Express 1.0
v Wake up function is supported
v Clock spread spectrum capability
qExpansion slots
v One PCI express X16 slot
v One MINI PCI express slot (half-height)

6
Intel G4X-ITX series Motherboard
Motherboard Layout
Figure 1 shows the motherboard and Figure 2 shows the back panel connectors.
Figure 1. Board Layout
1. 24-pin ATX Power Connector-PW1
2. Clear CMOS Jumper-JP1
3. SYS Fan Connector-SYSFAN1
4. PCI Express x 16 Slot-PCIE1
5. Speaker Header-SPK1
6. Front Panel Header-FP1
7. Serial-ATA (SATA) Connectors (SATA1~3)
8. SPDIF-Out Header-CN6
9. Front pannel audio Header-FP_S1
10. Mini PCIE Slot-MINI_PCIE1
11. Backpanel connectors
12. 4-pin ATX_12V power connector-PW2
13. USB Headers (FP_U1)
14. CPU Fan Connector_CPUFAN1
15. South Bridge
16. CPU Socket
17. North Bridge
18. COM Header_CN9 (Optional)
19. DDRII DIMM Sockets-DDRII1~2 (G41ITX-A)
DDRIII DIMM Sockets-DDRIII1~2 (G41ITX-B)
Figure 1
2
1
3
PW1
JP1
SYSFAN1
PCIE1
SPK1
FP1
54
6
7
SATA1
SATA2
SATA3
8
9
CN6
FP_S1
11
10
12
CPUFAN1
FP_U1
1314 15
Southbridge
North bridge
16 17
CN9
18 19
DDRII1 DDRII2
PW2
MINI_PCIE1MINI_PCIE1
1
2
51
52
U_KB1
HDMI/DVI1
U_SATA1
U_LAN1
SD1

7
Rear panel
5. Port 2-Channel 4-Channel 6-Channel
Blue Line-In Line-In Line-In
Green Line-Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In
Orange -- -- Center/Subwoofer
Black -- Rear Speaker Out Rear Speaker Out
Grey -- -- --
1. PS/2 Keyboard Port
2. USB Ports
3. HDMI Port
4. eSATA Port
1
2345
67
2
Figure 2. Backpanel connectors
6. LAN Connector
Lan Port with LEDs to indicate status.
· Yellow/Light Up/Blink = 10 Mbps/Link/Activity
· Yellow and Green/Light Up/Blink = 100 Mbps/link/Activity
· Yellow and Orange/Light Up/Blink = 1000 Mbps/link/Activity
7. DVI Port
8. WiFi antenna connector (Optional)
Refer to the following to install the WiFi antenna modules.
Step 1. Secure the MINI PCIE card into the MINI_PCIE1 slot with screws.
8

MINI_PCIE1 slot
MINI PCIE card
Screws

8
Intel G4X-ITX series Motherboard
Step 4. Remove the red cap from the WiFi antenna connector.
Install the WiFi antenna to the WiFi antenna connector, and make sure the screw is
rotated in clockwise direction.



Note: Users can bend or rotate the WiFi antenna to the best receiving direction according
to the picture below.
Step 2. Secure the bracket to the motherboard with screws according to the picture below.

Screws
Bracket
Step 3. Connect the WiFi wire to the MINI PCIE card as the following picture shows.
MINI PCIE card
Bracket
WiFi wire




9
Hardware Installation
This section will guide you through the installation of the motherboard. The topics covered in this
section are:
q Preparing the motherboard
v Installing the CPU
v Installing the CPU fan
v Installing Memory Modules
q Installing the motherboard
qConnecting cables and setting switches
Safety Instructions
To reduce the risk of re, electric shock, and injury, always follow basic safety precautions.
Remember to remove power from your computer by disconnecting the AC main source before
removing or installing any equipment from/to the computer chassis.
Hardware Installation

10
Intel G4X-ITX series Motherboard
Preparing the Motherboard
The motherboard shipped in the box does not contain a CPU or memory. You need to purchase
these to complete this installation.
Installing the CPU
Be very careful when handling the CPU. Make sure not to bend or break any pins on the back.
Hold the processor only by the edges and do not touch the bottom of the processor.
The following illustration shows CPU installtaion components
1. Unhook the socket lever by pushing down and
away from the socket.
2. Lift the load plate. There is a protective socket
cover on the load plate to protect the socket
when there is no CPU installed.
3. Remove the protective socket cover from the
load plate.
4. Remove the processor from its protective cover,
making sure you hold it only by the edges.
It is a good idea to save the cover so that
whenever you remove the CPU, you have a
safe place to store it.
5. Align the notches in the processor with the
notches on the socket.
6. Lower the processor straight down into the
socket without tilting or sliding it into the socket.
Note: Make sure the CPU is fully seated and
level in the socket.
7. Close the load plate over the CPU and press
down while you close and engage the socket
lever.

11
Installing the CPU Fan
There are many different fan types that can be used with this motherboard. Follow the instruction
that came with your fan assembly. Be sure that the fan orientation is correct for your chassis type
and your fan assembly.
Installing Memory Modules
Your new motherboard has two 1.8V 240-pin slots for DDR2 (G41ITX-A)/1.5V 240-pin slots
for DDR3 (G41ITX-B) memory modules. These slots support 512 MB/1 GB/2 GB/4 GB DDR2
(G41ITX-A)/1 GB/2 GB/4 GB DDR3 (G41ITX-B) technologies. They also support dual channel
DDR2 (G41ITX-A)/DDR3 (G41ITX-B) memory technology up to 10.7 GB/s. There must be at
least one memory bank populated to ensure normal operation. Refer to the following recommen-
dations to install memory modules.
q One DIMM: Install it into slot 1 or 2. You can install the DIMM into any slot, however, slot 1
is preferred.
q Two DIMMs: Install them into slot 1 and slot 2.
Note that a memory module has a notch, so it can only t in one direction. Refer to the following
procedure to install memory modules into the slots on the motherboard.
1. Unlock a DIMM slot by pressing the module clips outward.
2. Align the memory module to the DIMM slot, and insert the module vertically into the DIMM
slot. The plastic clips at both sides of the DIMM slot automatically lock the DIMM into the
connector.
DDRII1/DDRIII1
DDRII2/DDRIII2
Hardware Installation

12
Intel G4X-ITX series Motherboard
Installing the Motherboard
The sequence of installing the motherboard into the chassis depends on the chassis you are
using and if you are replacing an existing motherboard or working with an empty chassis. Deter-
mine if it would be easier to make all the connections prior to this step or to secure the mother-
board and then make all the connections. It is normally easier to secure the motherboard rst.
Use the following procedure to install the I/O shield and secure the motherboard into the chassis.
Note: Be sure that the CPU fan assembly has enough clearance for the chassis covers
to lock into place and for the expansion cards. Also make sure the CPU Fan assem
-bly is aligned with the vents on the covers.
Installing the I/O Shield
The motherboard kit comes with an I/O shield that is used to block radio frequency transmis-
sions, protects internal components from dust and foreign objects, and promotes correct airow
within the chassis.
Before installing the motherboard, install the I/O shield from the inside of the chassis. Press the
I/O shield into place and make sure it ts securely. If the I/O shield does not t into the chassis,
you would need to obtain the proper size from the chassis supplier.
Securing the Motherboard into the Chassis
Most computer chassis have a base with mounting studs or spacers to allow the motherboard
to be secured to the chassis and help to prevent short circuits. If there are studs that do not
align with a mounting hole on the motherboard, it is recommended that you remove that stud
to prevent the possibility of a short circuit. In most cases, it is recommended to secure the
motherboard with spacers.
1. Carefully place the motherboard onto the studs/spacers located inside the chassis.
2. Align the mounting holes with the studs/spacers.
3. Align the connectors to the I/O shield.
4. Ensure that the fan assembly is aligned with the chassis vents according to the fan assembly
instruction.
5. Secure the motherboard with screws.

13
Hardware Installation
Connecting Cables and Setting Switches
This section takes you through all the connectors and switch settings necessary on the mother-
board. This will include:
q Power Connectors
v 24-pin ATX Power Connector-PW1
v 4-pin ATX_12V Power Connector-PW2
q Internal Headers/Connectors
v SPDIF-Out Header-CN6
v COM Header-CN9 (Optional)
v Front Panel Header-FP1
v USB Header-FP_U1
v Front Pannel Audio Header-FP_S1
v Speaker Header-SPK1
q Serial-ATA (SATA) Connectors (SATA1~3)
q Fan Connectors
q Expansion Slots
q CMOS Jumper Settings
See Figure 1 to locate the connectors and jumpers referenced in the following procedure.

14
Intel G4X-ITX series Motherboard
24-pin ATX Power Connector-PW1
PW1 is the main power supply connector. Make sure that the power supply cable and pins are
properly aligned with the connector on the motherboard. Firmly plug the power supply cable into
the connector and make sure it is secure.
1
PW2
PW1
PW1-Pin Denition
Pin Signal Pin Signal
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 PWROK 20 -5V
9 +5V_AUX 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
4-pin ATX_12V power connector-PW2
PW2, the 4-pin ATX 12V power connector, is used to provide power to the CPU. Align the pins to
the connector and press rmly until seated.
PW2-Pin Denition
Pin Signal
1 GND
2 GND
3 +12V
4 +12V
1
12
13
24

15
Hardware Installation
SPDIF-Out Header-CN6
This header provides a SPDIF (Sony/Philips Digital Interface) output to digital multimedia device
through coaxial connector.
CN6 - Pin Denition
Pin Signal
1 GND
2 SPDIF-out
3 VCC
q PWRLED
Attach the front panel power LED cable to these two pins of the connector. The Power LED
indicates the system’s status.
q PWR SW
Attach the power button cable from the case to these two pins. Pressing the power button
on the front panel turns the system on and off rather than using the power supply button.
q HDD LED
Attach the hard disk drive indicator LED cable to these two pins. The HDD indicator LED
indicates the activity status of the hard disks.
q RST SW
Attach the Reset switch cable from the front panel of the case to these two pins. The system
restarts when the RESET switch is pressed.
Note: Some chassis do not have all four cables. Be sure to match the name on the
connectors to the corresponding pins.
CN6
1
2
910
Front panel header-FP1
The front panel header on this motherboard is
one connector used to connect the following four
cables :
1
FP1
CN9
1
COM Header-CN9 (Optional)
CN9 - Pin Denition
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7RTS 8 CTS
9 RI 10 NC
FP1-Pin Denition
Pin Signal Pin Signal
1HDD_LED+ 2 PW_LED+
3 HDD_LED- 4 PW_LED-
5 GND 6 PWR_SW
7 RESET 8 GND
9 NC 10 KEY

16
Intel G4X-ITX series Motherboard
USB Header-FP_U1
This motherboard contains six USB 2.0 ports that are exposed on the rear panel of the chassis.
The motherboard also contains one 10-pin internal header connector onboard.
Note: Secure the bracket to either the front or rear panel of your chassis (not all chassis
are equipped with the front panel option).
Front Panel Audio Header-FP_S1
The audio connector supports HD audio standard and
provides two kinds of audio output choices: the Front
Audio, the Rear Audio. The front Audio supports re-task-
ing function.
Note:
In order to utilize the front audio header, your chassis must have front audio connector.
Also please make sure the pin assignment on the cable is the same as the pin
assignment on the mainboard header. To nd out if the chassis you are buying supports
a front audio connector, please contract your dealer.
1 9
102
FP_U1
21
10 9
FP_S1
FP_U1-Pin Denition
PIN Assignment PIN Assignment
1 VCC 2 VCC
3 USBP0- 4 USBP1-
5 USBP0+ 6 USBP1+
7 GND 8 GND
9 KEY 10 NC
FP_S1-Pin Denition
PIN Assignment PIN Assignment
1 MIC2(L) 2 GND
3 MIC(R) 4 -ACZ-DET
5Front Audio(R) 6 Reserved
7 FAVDIO-JD 8 Key(No pin)
9Front Audio(L) 10 Reserved

17
Hardware Installation
Speaker Header-SPK1
SPK1
1
Serial-ATA (SATA) Connectors (SATA1~3)
The Serial ATA connector is used to connect the Serial ATA device to the
motherboard. These connectors support the thin Serial ATA cables for
primary storage devices. The current Serial ATA interface allows up to 300
MB/s data transfer rate.
SPK1-Pin Denition
PIN Assignment
1 VCC
2 NC
3 NC
4 SPK-
SATA-Pin Denition
Pin Signal
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
Fan Connectors
There are two fan connectors on the motherboard, including
CPU fan connector and system fan connector.
SATA1
1
CPUFAN1
GND
+12V
Sense
Control
SYSFAN1
Sense
+12V
GND
SATA2 SATA3
1 1

18
Intel G4X-ITX series Motherboard
Jumper Settings
This section explains how to congure the motherboard’s hardware. Before using your
computer, make sure all jumpers and DRAM modules are set correctly. Refer to this section
whenever in doubt.
CMOS Clear Jumper-JP1
Close Open * = Default setting.
If you want to clear the system conguration, use the JP1 (Clear CMOS Jumper) to clear data.
Notice:
1. Be sure to save the CMOS setting when exit the CMOS.
2. If the CPU is frequency multiplier locked, no CPU speed change will be seen even if the
frequency multiplier setting in CMOS setup is changed.
JP1 Selection
1-2* Normal*
2-3 CMOS Clear
1
1
1
51
2
52
MINI_PCIE1
PCIE1
Expansion Slots
The motherboard contains two expansion slots, one Mini PCIE slot and one PCIE x16 slot.
Mini PCIE Slot-MINI_PCIE1
There is one Mini PCIE slot, reserved for the WiFi Module.
PCIE x16 Slot-PCIE1
There is one PCIE x16 slot reserved for graphics or video card that is fully compliant to PCI
Express 1.0.
Note: The PCIE x16 slot supports PCIE graphics cards, but does not support any PCIE
x1 device.

19
Conguring the BIOS
Conguring the BIOS
This section discusses how to change the system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
Enter BIOS Setup
The BIOS is the communication bridge between hardware and software. Correctly
setting the BIOS parameters is critical to maintain optimal system performance.
Refer to the following procedure to verify/change BIOS settings.
1. Power on the computer.,
2. Press the Del key when the following message briey displays at the bottom of
the screen during the Power On Self Test (POST).
Pressing Del takes you to the BIOS Setup Utility.
Note: 1. We reserve the right to update the BIOS version presented in the
manual. The BIOS pictures shown in this section are for reference only.
2. It is strongly recommended that you do not change the default BIOS
settings. Changing some settings could damage your system.
Main Menu
Note: Users please note
that the data in gray is
non-changeable, and the
others are for selection.
This menu gives you an overview of the general system specications. The BIOS
automatically detects the items in this menu.
q AMI BIOS
Displays the auto-detected BIOS information.
q Processor
Display the auto-detected CPU specication.
q System Memory
Displays the auto-detected system memory.
q System time
Allows you to set the system time.
