ZURI FORD ADJUSTABLE DESK User manual

(888) 968-ZURI (9874) [email protected]
FORD ADJUSTABLE DESK
Please contact us at (888)-968-ZURI (9874) or [email protected] if you have
questions on the product or installation.

(888) 968-ZURI (9874) [email protected] PAGE 1 of 16
Things to know
Do not move this desk without disassembling rst.
Moving this desk aer assembly may cause damage.
IMPORTANT:
Find the small RED RIBBON on the corner of the shipping
box. This ribbon is aached to the required assembly
hardware.
NOTE:
Some products include mulple shipping boxes only one
box will contain the RED RIBBON and hardware.
Place all parts on a clean and smooth surface such as a
rug or carpet to avoid the parts being
scratched or damaged.
Check and make sure that you have all parts
and hardware before beginning assembly.
Remove all wrapping materials, including staples &
packing straps before starng to assemble.
DO NOT over-ghten any screws.
Keep all hardware and parts out of reach of children.
Two people are required to complete the assembly.
Please read all steps before starng.
Please contact us at (888) 968-ZURI (9874) or
[email protected]om
if you have quesons on the product or installaon.

(888) 968-ZURI (9874) [email protected] PAGE 2 of 16
Desk Top
1 Piece
1
Right Pedestal
1 Piece
4
Privacy Panel
1 Piece
2
Hang Panel
1 Piece
3
Le Pedestal
1 Piece
5
Metal Leg
2 Pieces
6
Control Panel
1 Piece
8
1.85′
Cam Lock Pin
3 Pieces
295mm
Filing Bar
2 Pieces
Cam Lock
3 Pieces
Allen Wrench
2 Pieces
Washer
24 Pieces
Cable Management
Cover
2 Pieces
Feet
8 Pieces
Cable Clip
4 Pieces
Bolt 6mm x 50mm
16 Pieces
Screw 4mm x 16mm
6 Pieces
Bolt 6mm x 20mm
8 Pieces
Bolt 6mm x 12mm
8 Pieces
File Clip
4 Pieces
Screw 4mm x 20mm
15 Pieces
Regular Cable
1 Piece
Extension Cable
1 Piece
Zip Tie
6 Pieces
L Brackets
3 Pieces
AI B
J
C
K
D
L
E
M
F
N
HG
O P Q R
NOTE: A screw driver is needed to assemble this product
Cable Management Column
1 Piece
7

(888) 968-ZURI (9874) [email protected] PAGE 3 of 16
1
Two people are needed for this step. Turn Right Pedestal (4) and Le Pedestal (5) upside down. Install the
Feet (D) x8 using Bolt (E) x16 and Washer (C) x16 on the boom of the Right and Le Pedestals (4, 5). When
nished, turn the Right and Le Pedestals (4, 5) right side up.
5
4
E
C
D

(888) 968-ZURI (9874) [email protected] PAGE 4 of 16
2Insert the Metal Legs (6) x2 into Le Pedestal (5) and Right Pedestal (4) separately.
5
4
6
6

(888) 968-ZURI (9874) [email protected] PAGE 5 of 16
3Use Bolts (F) x8 and Washers (C) x8 to aach Metal Legs (6) x2 to Pedestals (4, 5). Do not ghten Bolts (F) x8
completely. These must be kept loose unl later steps for the desk to be assembled correctly.
C
F
4
5
6
6
For beer screw alignment in the
Metal Legs, remove the drawers
from the Pedestal (4) by using the
toggle levers. Push the levers on
each side of the drawer down at the
same me and pull the drawer out
slowly.

(888) 968-ZURI (9874) [email protected] PAGE 6 of 16
4
Before aaching the Privacy Panel (2), ensure the desk is placed in the desired locaon. Once the Privacy Panel
(2) is aached to the Le Pedestal (5) and Right Pedestal (4), the desk cannot be moved without risking dam-
age to the Privacy Panel (2). Connect the Privacy Panel (2) to Le Pedestal (5) and Right Pedestal (4) using the
receivers.
4
5
2

(888) 968-ZURI (9874) [email protected] PAGE 7 of 16
Screw Cam Lock Pin (A) x3 to the underside of the desk. Remove the plasc lm from the Control Panel (8).
Aach the Control Panel (8) to the le side of the boom of the Desk Top (1) and secure it with Screw (M) x2.
If you would like to aach the control panel to the right side, please see addional instrucons below.
5
M
A
8
8
1
If aaching the control panel to the right side, unscrew the controller from the boom of the desk and ip the
controller around so the ports are now facing the other direcon.

(888) 968-ZURI (9874) [email protected] PAGE 8 of 16
6
7
Two people are required to li up the Desk Top (1) and connect it to Metal Legs (6) x2.
Secure the Desk Top (1) to the Metal Legs (6) x2 using Screw (N) x8. Make sure the Desk Top (1) is aached
completely before moving on to the next step. If aached improperly, desk will not funcon as intended.
4
4
5
5
6
1
1
N

(888) 968-ZURI (9874) [email protected] PAGE 9 of 16
8Return to Bolts (F) x8 from step 3. Tighten Bolts (F) x8. All screws and bolts installed so far should now be fully
ghtened.
4
5
1
F

(888) 968-ZURI (9874) [email protected] PAGE 10 of 16
9
Connect the wires as per the diagram below. Use the Zip Tie (H) to secure the connecng wires so they don’t
sag. Plug the Power Cord into a 110v wall outlet. It is recommended to plug the desk into a surge protector if
available. Raise the Desk Top (1) to the highest posion and prepare for next assembly step.
16
6
8
RQ
Note that the extension cable should always be used to connect to the furthest leg from the controller. If the
controller is orientated to the le (viewed from a seated/standing posion) then the extension cable would be
used to connect the le leg. If the controller is orientated on the right then the extension cable would be used to
connect the right leg.
8
MAKE SURE NO OBSTACLES ARE IN THE DESKS PATH.
MAKE SURE ALL CORDS ARE OF A LENGTH THAT WILL
ACCOMMODATE THE CHANGE IN HEIGHT.
Plug the Power Cord into a 110v outlet.
IMPORTANT!
You must RESET the desk prior to use.
Press and hold the DOWN buon on the Handset (8)
unl the desk reaches its lowest height. Release the
DOWN buon. Press and hold the DOWN buon
again for about 10 seconds unl the desk lowers a
lile bit more, slightly rises and stops. Release the
DOWN buon.
Your desk Control Panel is now set up for use.
To program up to four presets:
Use the up/down buons to nd a desired height,
then press “M” followed by a number 1-4.
For addional instrucons, please see the end of
assembly instrucons pamphlet.

(888) 968-ZURI (9874) [email protected] PAGE 11 of 16
11 Aach Hang Panel (3) by pushing panel onto Cam Lock Pins (A) x3 currently aached to the boom of Desk Top
(1). Insert Cam Locks (B) x3 into the Hang Panel’s exterior holes, then rotate to secure.
B5 4
Cam Lock Operaon
3
2
1
L
L
1
10 Tear o the thin lm on the back of the Cable Clip (L) and ghten up the cord of Control Panel (8) to secure it.

(888) 968-ZURI (9874) [email protected] PAGE 12 of 16
12 Secure the L Brackets (O) x3 to the boom of the Desk Top (1) and the Hang Panel (3) using Screws (P) x15. Use
the Zip Tie (H) to secure the connecng wires, so they don’t sag.
PO
5
2
4
1
3
A screw driver is
required for this step.
Cable Management
Covers (K) can be swapped
out if more space for cable
organizaon is needed.

(888) 968-ZURI (9874) [email protected] PAGE 13 of 16
13
Using Screw (M) x2, secure the top of the Cable Management Column (7) to the underside of the Desk Top (1)
and Wire Management Cover (K). The opening of the Cable Management Column (7) should line up with the
circle opening of the Wire Management Cover (K).
M
7

(888) 968-ZURI (9874) [email protected] PAGE 14 of 16
14 Install the File Clip (G) and Filing Bar (I) into the Pedestal drawer.
NOTE: Use the supplied touch-up pen
to x any scratches or marks that may
have occurred during the shipping or
assembly process.
I
G

(888) 968-ZURI (9874) [email protected] PAGE 15 of 16
ADDITIONAL FEATURES AND INSTRUCTIONS
FOR THE HEIGHT ADJUSTMENT CONTROL PANEL
Notice: The control panel MUST be xed to under the desktop for functions to work. An error code
will display if the control panel is not attached rmly.
To Reset: Hold the down buon for 5 seconds. A sound will play. The control panel has now been reset.
An-Collision Detecon
• This feature is controlled by a sensor and an electric current in the control panel that will cause the liing
mechanism to change direcons when a foreign object or heavy force is detected. To protect users from
injury and the desk from damages, this desk will display an error code (E 8) that will require the control panel
to be reset.
Memory Presets
• This desk can store 4 preset height sengs. To set or change these sengs, adjust the desk to the desired
posion. Press the “M” buon and release. This will cause the control panel to change modes. Once the
display reads, S- you can now choose the number you wish to be associated with this height. The control
panel will return to the regular mode once the number is pushed.
Automac Tesng Funcon
• This feature allows for tesng when assembled and for any troubleshoong for the display screen on the
control panel. Presets 1 and 2 will need to be set before performing this funcon. At the same me, press
the up, down and M buon for 2 seconds. The display will show all the decimal points and then perform the
automac test paern. Once complete, you can exit this seng by pressing the up, down, and M buon at
the same me.
Seng the Minimum and Maximum Height Limits
• To set the minimum height limit, adjust to the desired posion and press and hold the M and down buon at
the same me. A sound will play, and the height limit is now set.
• To remove the minimum height limit, press and hold the M and down buon at the same me. A sound will
play, and the minimum height limit has been removed.
• To set the maximum height limit, adjust to the desired posion and press and hold the M and up buon at
the same me. A sound will play, and the height limit is now set.
• To remove the maximum height limit, press and hold the M and up buon at the same me. A sound will
play, and the minimum height limit has been removed.
Height Adjusng Lock/Unlock Feature
• This feature will prevent any buons on the control panel from acvang the li mechanism. To lock the
control panel, press the up and down buon at the same me for 5 seconds. The display will read LOC. The
control panel will not be funconal unl it is unlocked.
• To unlock the control panel, press and hold the up and down buons for 5 seconds. The display will return to
the regular screen.

(888) 968-ZURI (9874) [email protected] PAGE 16 of 16
ERROR CODE
Error
code
E1
E2
E3
E4
E6
E7
E8
E09/Hot
E11
E12
E13
E14
E15
E16
E17
E18
E21
E22
E23
E24
E25
E26
E27
E28
E40
E41
E42
E43
8.8.8
What Error Means
Main power is too high
Screw clearance over 1cm
Control Panel is not connected
Control Panel communicaon
error
Main power start error
Main power protecon shutdown
Table is not level
Temperature is too high
Motor 1 Not Connected
Motor 1 Current sampling error
Motor 1 Loose motor cable
Motor 1 Li Error
Motor 1 Phase Short
Motor 1 Blocked
Motor 1 Direcon Error
Motor 1 Overload
Motor 2 Not Connected
Motor 2 Current sampling error
Motor 2 Loose motor cable
Motor 2 Li Error
Motor 2 Phase Short
Motor 2 Blocked
Motor 2 Direcon Error
Motor 2 Overload
Tandem cable error
Tandem signal error
Eeprom error
Gyro-sensor error
Control panel error
Soluon
Check the main power
Check for obstrucons. Reset Control
Check power to control
Check power to control. Make sure
connecons are secure
Replace Control Panel
Reconnect controller power
Level desk and reset control panel
Wait for temperature to cool down
Check motor cable connecon
Change control panel
Check the motor cable connecon
Check the li cable connecon
Change motor
Reset motor
Cables are reversed
Reduce the load
Check motor cable connecon
Change control panel
Check the motor cable connecon
Check the li cable connecon
Change motor
Reset motor
Cables are reversed
Reduce the load
Check the tandem cable
Check tandem cable or change control
Change control panel
Change control panel
Unplug control box and handset, wait
2 min., then plug in. Reset desk. If
error connues, change control box
and headset
