ZYLIA ZR-1 User manual

ZYLIA ZR-1 Portable Recorder
Reference manual
2020-04-24
Zylia sp. o.o.
v1.0



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#


This manual, as well as the software described in it, is furnished under license and may be
used or copied only in accordance with the terms of such license. The content of this
manual is furnished for informational use only, is subject to change without notice, and
should not be construed as a commitment by Zylia. Every effort has been made to ensure
that the information in this manual is accurate. Zylia assumes no responsibility or liability
for any errors or inaccuracies that may appear in this book.
Except as permitted by such license, no part of this publication may be reproduced, edited,
stored in a retrieval system or transmitted, in any form or by any means, electronic,
mechanical, recording or otherwise, without the prior written permission of Zylia.
Zylia and the Zylia Logo are trademarks of Zylia sp. o.o. All other product and company
names are trademarks or registered trademarks of their respective holders.



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#


1
2
3
3
456

7+8
9:;2$
<#
(2#
32=2#
82=2#
)#
9;>2#
)?2%
<?::&
)3&
<&
+&
@
A??:2
@?:2



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

 
 !
The ZR-1 device can be powered via:
1) batteries – 8 x AA (1.5V)
2) external power supply:
a) power bank
b) DC adapter
In case of external power supply, please make sure you have source that provides 5V, 2.5A
DC.
!!
The ZR-1 is designed to record audio from the ZYLIA ZM-1 microphone. Supported
models: 1C, 1D, 3E.
!!!
The ZR-1 contains 3.5mm jack socket. Connect your headphones to live monitor the
sound from connected ZM-1 microphone.
"!#
Buon name State of the
device
Acon Result
-.B-CC 9D ;?* 8=6
9 ;?* 8=6D
(

;?* 8=D
3 ;?& (?;=
(+< 8= ; (



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

Buon name State of the
device
Acon Result

(

; (>;
7+8 A
7+8
(
; 9;A7+8(::60E
=2:D=
A
7+8
(D
; 9;A7+8(
(<
F:
G
.
=
; ZR-1 device becomes visible and
ready to pair
= ; No event action
= ;?* ZR-1 disconnectsfrom remote
control application
4 .6 ; No event action
6 ; Skip to previous recording
6 ;H; Rewind – fast backward
 8=

; Play last recorded le
 ; Pause played le
 ; ontinue playing recorded le
(

; No event action
C .6 ; No event action
6 ; Skip to next recording
6 ;H; Fast forward



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

$
All recorded data is stored on SDXC card. MicroSDXC/microSDHC card can be used as
well with an micro-to-SD adapter.
%&'!(
)*( +! '(!
ON/OFF Continuous red Device is fully turned ON, operating system is
booted, ZR-1 is ready to use.
Blinking red System is booting up, ZR-1 is not ready to use,
user should wait until there is continuous red
light.
Blinking orange Battery pack level is low. If user is recording,
he/she should stop recording and change
batteries before next session.
None (off) ZR-1 is OFF, system is not booted, ZR-1 is ready to
be powered on and booted (provided that the
batteries are inserted or external power supply is
connected).
REC Continuous red Audio is being recorded to SD card.
Blinking red SD card is busy, user should wait before starting a
new recording or removing SD card.
None (off) a) if ON/OFF indicator lit continuous red light:
device is ready to record.
b) if ON/OFF indicator is off: device is turned off.
GAIN Continuous red Extreme case, represents prolonged clipping, user
should adjust the gain.
Blinking red Indicates clipping of the input signal, user should
adjust the gain.
None (off) a) if both ON/OFF and REC indicators lit



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

continuous red light: gain level is ?ne.
b) if ON/OFF indicator is off: device is turned off.
RC
(remote control)
Continuous blue Device is paired with remote control
application.
Blinking blue ZR-1 is ready to pair, it is visible for other
devices.
None (off) a) if ON/OFF indicator lit continuous red light:
device is not paired with ZR-1 remote control
application.
b) if ON/OFF indicator is off: device is turned off.
SD CARD None (off) SD card contains enough space to continue
recording.
Blinking red Space on the card ends, if the user is
recording he/she should stop recording and
replace SD card.
Continuous red a) There is no SD card plugged into ZR-1.
b) Error with SD card.
c) SD card is not detected.
d) No more space on SD card to start next
recordings.
*((
ZR-1 supports Timecode synchroni ation. Timecode generated by an external device can
be sent to ZR-1 through a break-out cable provided in the box set. Connect the Timecode
generator with a mini-jack cable to red socket in a break-out cable and plug it to a ZR-1
headphone output. Timecode signal is recorded along with the signal captured by the ZM-
1 and stored in a separate ?le with ?lename containing “TC”.
,*(
This feature is not yet implemented.



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

-* !
The ZR-1 ?rmware can be updated with specially prepared ?les provided by ZYLIA. In
order to perform the update user have to upload provided update ?les to pendrive.
Pendrive with the ?les needs to be connected to USB socket before user launch ZR-1. Next
step is to launch the device, press and hold Play and REC button at the same time until RC,
SD CARD and GAIN LED indicators light up. Then user can release the buttons and update
process will begin. ZYLIA recommends that during the update ZR-1 should be connected
to external power supply. When update process ends, ZR-1 will power off.

Clean the surface of the device with a soft dry cloth. To prevent damage to the ?nish or
casing, do not expose the device to chemical products.
,
Before using the ZYLIA ZR-1 recorder for the ?rst time, register the device at:
(.
Use the serial number located on the device and provide your contact information.
By registering, you can access technical support, activate your warranty. Registering also
keeps you informed of all the latest software updates and ZYLIA products.
/!
Additional information on this product and answers to frequently asked questions can be
found at (.0(*
In case of any technical problems please check our online support center at
(.!
If you have any questions regarding the recording process or device operation and you
cannot ?nd the answer on the website, please contact !1
The most up to date version of this manual is available online at (
(((2(
Dimensions: 206 x 196 x 58 mm
Weight: 880 g
Data storage: cards compatible with SDXC speci?cations (class 10), si e up to 2 TB



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

Supply voltage: 5V DC
Supported power sources: batteries – 8 x AA (1.5 V); external power supply via micro USB
socket – 5V, 2.5 A.
Current consumption: max. 1.44 A
Number of microphones that can be connected to the ZR-1 device: 1
Type of microphone that can be connected the to the ZR-1 device: ZM-1 models 1C, 1D, 3E
Supported audio ?les formats: .WAV, Wave64
Supported synchroni ation system: Timecode
/!(!
Handle the device with special care, avoiding sudden shocks such as dropping or hitting
into other objects.
To reduce ?re or shock ha ard, do not expose the unit to rain, moisture or high
temperatures. Do not use near heaters or other heat sources.
Always turn the power off before connecting any cables.
Do not apply excessive force to plugs when they are connected to the ZR-1 device.
In case of using battery power supply:
Always use commercially-available 1.5 V dry cell batteries.
Carefully study warning indications on batteries before use.
Always keep the battery cover closed during use.
Install batteries with correct +/- orientations.
Do not use new and old batteries together. Do not use batteries of different brands or
types together.
Remove the batteries when the device will not be used for a long time.



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
./!00*#&#

In case of using external power supply:
Always use an DC power source (DC wall adapter or power bank) speci?ed for this
product: 5V, 2.5 A. Carefully study the warning indicators of the DC power supply before
use.
Disconnect the DC adapter from the outlet when the unit will not be used for a long time
and whenever there is lightning.
If static electricity or electromagnetism causes data transfer failure, restart the device.
Do not open the case or make alterations.
All repairs may be performed only by authori ed service. The user is not allowed to repair
the device himself.
**
$/
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.



 
!"#$%&

'()!&&&&$&%*
(+,-.!&$$#&$
