ZyXEL Communications NBG5615 User manual

Quick Start Guide
www.zyxel.com
NBG5615
Simultaneous Dual-Band Wireless N750 Media Router
Version 1.00
Edition 1, 12/2012
Copyright © 2012 ZyXEL Communications Corporation
User’s Guide
Default Login Details
LAN IP Address http://192.168.1.1
(Router Mode)
http://192.168.1.2
(Access Point Mode)
Password 1234

NBG5615 User’s Guide2
IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from your product due to differences in
your product firmware or your computer operating system. Every effort has been made to ensure
that the information in this manual is accurate.
Related Documentation
•QuickStartGuide
The Quick Start Guide shows how to connect the NBG5615 and access the Web Configurator
wizards. It contains information on setting up your network and configuring for Internet access.

Contents Overview
NBG5615 User’s Guide 3
Contents Overview
User’s Guide .......................................................................................................................................13
Introduction .............................................................................................................................................15
ZyXEL NetUSB Share Center Utility .......................................................................................................21
Connection Wizard ..................................................................................................................................27
Introducing the Web Configurator ...........................................................................................................39
NBG5615 Modes .....................................................................................................................................43
Easy Mode ..............................................................................................................................................45
Router Mode ...........................................................................................................................................57
Access Point Mode .................................................................................................................................65
Tutorials ..................................................................................................................................................73
Technical Reference ..........................................................................................................................87
Monitor ....................................................................................................................................................89
WAN ........................................................................................................................................................95
Wireless LAN ........................................................................................................................................105
LAN .......................................................................................................................................................129
DHCP Server ........................................................................................................................................133
NAT .......................................................................................................................................................139
DDNS ....................................................................................................................................................149
Static Route ...........................................................................................................................................151
Firewall ..................................................................................................................................................155
Content Filtering ....................................................................................................................................161
Bandwidth Management .......................................................................................................................165
Remote Management ............................................................................................................................173
Universal Plug-and-Play (UPnP) ...........................................................................................................177
USB Media Sharing ...............................................................................................................................183
Maintenance ..........................................................................................................................................193
Troubleshooting ....................................................................................................................................203

Contents Overview
NBG5615 User’s Guide
4

Table of Contents
NBG5615 User’s Guide 5
Table of Contents
Contents Overview ..............................................................................................................................3
Table of Contents .................................................................................................................................5
Part I: User’s Guide .........................................................................................13
Chapter 1
Introduction.........................................................................................................................................15
1.1 Overview ...........................................................................................................................................15
1.2 Applications .......................................................................................................................................15
1.3 Ways to Manage the NBG5615 ........................................................................................................16
1.4 Good Habits for Managing the NBG5615 .........................................................................................16
1.5 Resetting the NBG5615 ....................................................................................................................16
1.5.1 How to Use the RESET Button ................................................................................................16
1.6 The WPS Button ...............................................................................................................................16
1.7 LEDs .................................................................................................................................................18
1.8 Wall Mounting ...................................................................................................................................19
Chapter 2
ZyXEL NetUSB Share Center Utility..................................................................................................21
2.1 Overview ...........................................................................................................................................21
2.1.1 Quick Setup .............................................................................................................................21
2.1.2 Installing ZyXEL NetUSB Share Center Utility .........................................................................21
2.2 The ZyXEL NetUSB Share Center Utility ..........................................................................................22
2.2.1 The Menus ...............................................................................................................................23
2.2.2 The ZyXEL NetUSB Share Center Configuration Window ......................................................24
2.2.3 The Auto-Connect Printer List Window ...................................................................................25
2.2.4 Exit the ZyXEL NetUSB Share Center Utility ...........................................................................26
Chapter 3
Connection Wizard .............................................................................................................................27
3.1 Overview ...........................................................................................................................................27
3.2 Accessing the Wizard ........................................................................................................................27
3.3 Connect to Internet ............................................................................................................................28
3.3.1 Connection Type: IPoE ............................................................................................................29
3.3.2 Connection Type: PPPoE ........................................................................................................30
3.3.3 Connection Type: PPTP ..........................................................................................................32
3.4 Router Password ...............................................................................................................................33

Table of Contents
NBG5615 User’s Guide
6
3.5 Wireless Security ..............................................................................................................................34
3.5.1 Wireless Security: No Security ................................................................................................34
3.5.2 Wireless Security: WPA2-PSK .................................................................................................35
Chapter 4
Introducing the Web Configurator ....................................................................................................39
4.1 Overview ...........................................................................................................................................39
4.2 Accessing the Web Configurator .......................................................................................................39
4.2.1 Login Screen ...........................................................................................................................39
4.2.2 Password Screen ....................................................................................................................40
Chapter 5
NBG5615 Modes .................................................................................................................................43
5.1 Overview ...........................................................................................................................................43
5.1.1 Web Configurator Modes .........................................................................................................43
5.1.2 Device Modes ..........................................................................................................................43
Chapter 6
Easy Mode...........................................................................................................................................45
6.1 Overview ...........................................................................................................................................45
6.2 What You Can Do .............................................................................................................................46
6.3 What You Need to Know ...................................................................................................................46
6.4 Navigation Panel ...............................................................................................................................46
6.5 Network Map .....................................................................................................................................47
6.6 Control Panel ....................................................................................................................................48
6.6.1 Game Engine ...........................................................................................................................49
6.6.2 Power Saving ..........................................................................................................................49
6.6.3 Content Filter ...........................................................................................................................50
6.6.4 Bandwidth MGMT ....................................................................................................................51
6.6.5 Firewall ....................................................................................................................................52
6.6.6 Wireless Security .....................................................................................................................52
6.6.7 WPS ........................................................................................................................................53
6.7 Status Screen in Easy Mode .............................................................................................................54
Chapter 7
Router Mode........................................................................................................................................57
7.1 Overview ...........................................................................................................................................57
7.2 Router Mode Status Screen ..............................................................................................................57
7.2.1 Navigation Panel .....................................................................................................................60
Chapter 8
Access Point Mode.............................................................................................................................65
8.1 Overview ...........................................................................................................................................65

Table of Contents
NBG5615 User’s Guide 7
8.2 What You Can Do .............................................................................................................................65
8.3 What You Need to Know ...................................................................................................................65
8.3.1 Setting your NBG5615 to AP Mode .........................................................................................66
8.3.2 Accessing the Web Configurator in Access Point Mode ..........................................................66
8.3.3 Configuring your WLAN and Maintenance Settings ................................................................67
8.4 AP Mode Status Screen ....................................................................................................................67
8.4.1 Navigation Panel .....................................................................................................................69
8.5 LAN Screen .......................................................................................................................................69
Chapter 9
Tutorials...............................................................................................................................................73
9.1 Overview ...........................................................................................................................................73
9.2 Set Up a Wireless Network with WPS ...............................................................................................73
9.2.1 Push Button Configuration (PBC) ............................................................................................73
9.2.2 PIN Configuration ....................................................................................................................74
9.3 Configure Wireless Security without WPS ........................................................................................75
9.3.1 Configure Your Notebook ........................................................................................................77
9.4 Using Multiple SSIDs on the NBG5615 .............................................................................................79
9.4.1 Configuring Security Settings of Multiple SSIDs ......................................................................80
9.5 Automatically Connecting to a USB Printer .......................................................................................84
Part II: Technical Reference............................................................................87
Chapter 10
Monitor.................................................................................................................................................89
10.1 Overview .........................................................................................................................................89
10.2 What You Can Do ...........................................................................................................................89
10.3 The Log Screen ...............................................................................................................................89
10.3.1 View Log ................................................................................................................................89
10.4 DHCP Table .................................................................................................................................90
10.5 Packet Statistics ...........................................................................................................................91
10.6 WLAN Station Status ...................................................................................................................92
Chapter 11
WAN .....................................................................................................................................................95
11.1 Overview .........................................................................................................................................95
11.2 What You Can Do ............................................................................................................................95
11.3 What You Need To Know .................................................................................................................95
11.3.1 Configuring Your Internet Connection ....................................................................................96
11.4 Internet Connection .........................................................................................................................97
11.4.1 IPoE Encapsulation ................................................................................................................97

Table of Contents
NBG5615 User’s Guide
8
11.4.2 PPPoE Encapsulation ............................................................................................................99
11.4.3 PPTP Encapsulation ............................................................................................................101
11.5 Advanced WAN Screen .................................................................................................................104
Chapter 12
Wireless LAN.....................................................................................................................................105
12.1 Overview .......................................................................................................................................105
12.1.1 What You Can Do ................................................................................................................106
12.1.2 What You Should Know .......................................................................................................106
12.2 General Wireless LAN Screen .....................................................................................................110
12.3 Wireless Security ..........................................................................................................................112
12.3.1 No Security ..........................................................................................................................112
12.3.2 WEP Encryption ..................................................................................................................113
12.3.3 WPA-PSK/WPA2-PSK .........................................................................................................115
12.3.4 WPA/WPA2 ..........................................................................................................................116
12.4 More AP Screen ............................................................................................................................118
12.4.1 More AP Edit .......................................................................................................................119
12.5 MAC Filter Screen ........................................................................................................................121
12.6 Wireless LAN Advanced Screen ...................................................................................................123
12.7 Quality of Service (QoS) Screen ...................................................................................................123
12.8 WPS Screen ..................................................................................................................................124
12.9 WPS Station Screen ......................................................................................................................126
12.10 Scheduling Screen ......................................................................................................................126
Chapter 13
LAN ....................................................................................................................................................129
13.1 Overview .......................................................................................................................................129
13.2 What You Can Do .........................................................................................................................129
13.3 What You Need To Know ..............................................................................................................129
13.3.1 IP Pool Setup .......................................................................................................................130
13.3.2 LAN TCP/IP .........................................................................................................................130
13.3.3 IP Alias ................................................................................................................................130
13.4 LAN IP Screen ..............................................................................................................................130
13.5 IP Alias Screen ..............................................................................................................................131
Chapter 14
DHCP Server .....................................................................................................................................133
14.1 Overview .......................................................................................................................................133
14.1.1 What You Can Do ................................................................................................................133
14.1.2 What You Need To Know .....................................................................................................133
14.2 DHCP Server General Screen ......................................................................................................133
14.3 DHCP Server Advanced Screen ................................................................................................134
14.4 DHCP Client List Screen ...............................................................................................................136

Table of Contents
NBG5615 User’s Guide 9
Chapter 15
NAT.....................................................................................................................................................139
15.1 Overview ....................................................................................................................................139
15.1.1 What You Can Do ................................................................................................................139
15.1.2 What You Need To Know .....................................................................................................140
15.2 General .........................................................................................................................................141
15.3 Port Forwarding Screen ...............................................................................................................142
15.3.1 Port Forwarding Edit Screen ..............................................................................................144
15.4 Port Trigger Screen .......................................................................................................................145
15.5 Technical Reference ......................................................................................................................146
15.5.1 NATPort Forwarding: Services and Port Numbers ..............................................................146
15.5.2 NAT Port Forwarding Example ............................................................................................146
15.5.3 Trigger Port Forwarding .......................................................................................................147
15.5.4 Trigger Port Forwarding Example ........................................................................................147
15.5.5 Two Points To Remember About Trigger Ports ...................................................................148
Chapter 16
DDNS..................................................................................................................................................149
16.1 Overview ......................................................................................................................................149
16.1.1 What You Need To Know .....................................................................................................149
16.2 General .......................................................................................................................................149
Chapter 17
Static Route.......................................................................................................................................151
17.1 Overview ....................................................................................................................................151
17.2 IP Static Route Screen .................................................................................................................151
17.2.1 Add/Edit Static Route ..........................................................................................................152
Chapter 18
Firewall ..............................................................................................................................................155
18.1 Overview .....................................................................................................................................155
18.1.1 What You Can Do ................................................................................................................155
18.1.2 What You Need To Know .....................................................................................................155
18.2 General Screen ............................................................................................................................157
18.3 Services Screen ............................................................................................................................157
Chapter 19
Content Filtering...............................................................................................................................161
19.1 Overview .......................................................................................................................................161
19.1.1 What You Need To Know .....................................................................................................161
19.2 Content Filter .................................................................................................................................161
19.3 Technical Reference ......................................................................................................................163
19.3.1 Customizing Keyword Blocking URL Checking ...................................................................163

Table of Contents
NBG5615 User’s Guide
10
Chapter 20
Bandwidth Management...................................................................................................................165
20.1 Overview ......................................................................................................................................165
20.2 What You Can Do .........................................................................................................................165
20.3 What You Need To Know ..............................................................................................................166
20.4 General Screen ............................................................................................................................166
20.5 Advanced Screen .........................................................................................................................166
20.5.1 Rule Configuration: Application Rule Configuration ...........................................................168
20.5.2 Rule Configuration: User Defined Service Rule Configuration .........................................169
20.5.3 Predefined Bandwidth Management Services .....................................................................171
Chapter 21
Remote Management........................................................................................................................173
21.1 Overview .......................................................................................................................................173
21.2 What You Can Do in this Chapter .................................................................................................173
21.3 What You Need to Know ...............................................................................................................173
21.3.1 Remote Management and NAT ...........................................................................................174
21.3.2 System Timeout ..................................................................................................................174
21.4 WWW Screen .............................................................................................................................174
21.5 Telnet Screen .............................................................................................................................175
21.6 Wake On LAN Screen ...................................................................................................................175
Chapter 22
Universal Plug-and-Play (UPnP)......................................................................................................177
22.1 Overview ......................................................................................................................................177
22.2 What You Need to Know ...............................................................................................................177
22.2.1 NAT Traversal ......................................................................................................................177
22.2.2 Cautions with UPnP .............................................................................................................177
22.3 UPnP Screen ...............................................................................................................................178
22.4 Technical Reference ......................................................................................................................178
22.4.1 Using UPnP in Windows XP Example .................................................................................178
22.4.2 Web Configurator Easy Access ...........................................................................................180
Chapter 23
USB Media Sharing...........................................................................................................................183
23.1 Overview .......................................................................................................................................183
23.2 What You Can Do .........................................................................................................................184
23.3 What You Need To Know ..............................................................................................................184
23.4 Before You Begin ..........................................................................................................................185
23.5 DLNA Screen ................................................................................................................................186
23.6 SAMBA Screen .............................................................................................................................186
23.7 FTP Screen ...................................................................................................................................188
23.8 Example of Accessing Your Shared Files From a Computer ........................................................189

Table of Contents
NBG5615 User’s Guide 11
23.8.1 Use Windows Explorer to Share Files .................................................................................189
23.8.2 Use FTP to Share Files .......................................................................................................191
Chapter 24
Maintenance......................................................................................................................................193
24.1 Overview .......................................................................................................................................193
24.2 What You Can Do .........................................................................................................................193
24.3 General Screen .............................................................................................................................193
24.4 Password Screen ..........................................................................................................................194
24.5 Time Setting Screen ......................................................................................................................195
24.6 Firmware Upgrade Screen ............................................................................................................196
24.7 Configuration Backup/Restore Screen ..........................................................................................198
24.8 Restart Screen ..............................................................................................................................199
24.9 Language Screen ..........................................................................................................................199
24.10 System Operation Mode Overview .............................................................................................200
24.11 Sys OP Mode Screen ..................................................................................................................201
Chapter 25
Troubleshooting................................................................................................................................203
25.1 Overview .......................................................................................................................................203
25.2 Power, Hardware Connections, and LEDs ....................................................................................203
25.3 NBG5615 Access and Login .........................................................................................................204
25.4 Internet Access .............................................................................................................................205
25.5 Resetting the NBG5615 to Its Factory Defaults ............................................................................207
25.6 Wireless Connections ...................................................................................................................207
25.7 USB Device Problems ...................................................................................................................209
25.8 ZyXEL Share Center Utility Problems ...........................................................................................209
Appendix A Pop-up Windows, JavaScript and Java Permissions...................................................211
Appendix B Setting Up Your Computer’s IP Address ......................................................................221
Appendix C Common Services........................................................................................................249
Appendix D Legal Information .........................................................................................................253
Index ..................................................................................................................................................259

Table of Contents
NBG5615 User’s Guide
12

13
PART I
User’s Guide

14

NBG5615 User’s Guide 15
CHAPTER 1
Introduction
1.1 Overview
This chapter introduces the main features and applications of the NBG5615.
The NBG5615 extends the range of your existing wired network without additional wiring, providing
easy network access to mobile users. You can set up a wireless network with other IEEE 802.11a/b/
g/n compatible devices. The NBG5615 is able to function both 2.4GHz and 5GHz networks at the
same time.
A range of services such as a firewall and content filtering are also available for secure Internet
computing.
There are two USB 2.0 ports on the side panel of your NBG5615. You can connect USB (version 2.0
or lower) memory sticks, USB hard drives, or USB devices for file sharing. The NBG5615
automatically detects the USB devices.
Note: For the USB function, it is strongly recommended to use version 2.0 or lower USB
storage devices (such as memory sticks, USB hard drives) and/or USB devices
(such as USB printers). Other USB products are not guaranteed to function
properly with the NBG5615.
Note: Be sure to install the ZyXEL NetUSBTM Share Center Utility (for NetUSB
functionality) from the included disc, or download the latest version from the
zyxel.com website.
1.2 Applications
Your can have the following networks using the NBG5615:
•Wired. You can connect network devices via the Ethernet ports of the NBG5615 so that they can
communicate with each other and access the Internet.
•Wireless. Wireless clients can connect to the NBG5615 to access network resources. You can
use WPS (Wi-Fi Protected Setup) to create an instant network connection with another WPS-
compatible device.
•WAN. Connect to a broadband modem/router for Internet access.
•NetUSB. The NBG5615 allows you to connect a USB device (such as printer, or scanner) directly
to the USB port and then share that device over the network using the NetUSB utility.

Chapter 1 Introduction
NBG5615 User’s Guide
16
1.3 Ways to Manage the NBG5615
Use any of the following methods to manage the NBG5615.
• WPS (Wi-Fi Protected Setup). You can use the WPS button or the WPS section of the Web
Configurator to set up a wireless network with your ZyXEL Device.
• Web Configurator. This is recommended for everyday management of the NBG5615 using a
(supported) web browser.
1.4 Good Habits for Managing the NBG5615
Do the following things regularly to make the NBG5615 more secure and to manage the NBG5615
more effectively.
• Change the password. Use a password that’s not easy to guess and that consists of different
types of characters, such as numbers and letters.
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it). Restoring an earlier
working configuration may be useful if the device becomes unstable or even crashes. If you
forget your password, you will have to reset the NBG5615 to its factory default settings. If you
backed up an earlier configuration file, you would not have to totally re-configure the NBG5615.
You could simply restore your last configuration.
1.5 Resetting the NBG5615
If you forget your password or IP address, or you cannot access the Web Configurator, you will need
to use the RESET button at the back of the NBG5615 to reload the factory-default configuration
file. This means that you will lose all configurations that you had previously saved, the password
will be reset to “1234” and the IP address will be reset to “192.168.1.1”.
1.5.1 How to Use the RESET Button
1Make sure the power LED is on.
2Press the RESET button for one to four seconds to restart/reboot the NBG5615.
3Press the RESET button for longer than five seconds to set the NBG5615 back to its factory-default
configurations.
1.6 The WPS Button
Your NBG5615 supports Wi-Fi Protected Setup (WPS), which is an easy way to set up a secure
wireless network. WPS is an industry standard specification, defined by the Wi-Fi Alliance.

Chapter 1 Introduction
NBG5615 User’s Guide 17
WPS allows you to quickly set up a wireless network with strong security, without having to
configure security settings manually. Each WPS connection works between two devices. Both
devices must support WPS (check each device’s documentation to make sure).
Depending on the devices you have, you can either press a button (on the device itself, or in its
configuration utility) or enter a PIN (a unique Personal Identification Number that allows one device
to authenticate the other) in each of the two devices. When WPS is activated on a device, it has two
minutes to find another device that also has WPS activated. Then, the two devices connect and set
up a secure network by themselves.
You can use the WPS button ( ) on the front panel of the NBG5615 to activate WPS in order to
quickly set up a wireless network with strong security.
1Make sure the power LED is on (not blinking).
2Press the WPS button for more than three seconds and release it. Press the WPS button on another
WPS-enabled device within range of the NBG5615.
Note: You must activate WPS in the NBG5615 and in another wireless device within two
minutes of each other.
For more information on using WPS, see Section 9.2 on page 73.

Chapter 1 Introduction
NBG5615 User’s Guide
18
1.7 LEDs
Figure 1 Front Panel
The following table describes the LEDs.
Table 1 Front panel LEDs
LED COLOR STATUS DESCRIPTION
Power Green On The NBG5615 is receiving power and functioning properly.
Blinking The NBG5615 is in the process of starting up or default
restoring.
Off The NBG5615 is not receiving power.
WAN Green On The NBG5615’s WAN connection is ready.
Blinking The NBG5615 is sending/receiving data through the WAN.
Off The WAN connection is not ready, or has failed.
LAN 1-4 Green On The NBG5615’s LAN connection is ready.
Blinking The NBG5615 is sending/receiving data through the LAN.
Off The LAN connection is not ready, or has failed.
Power LAN 1-4
WAN
2.4G WLAN USB 1/2
WPS
5G WLAN

Chapter 1 Introduction
NBG5615 User’s Guide 19
1.8 Wall Mounting
You may need screw anchors if mounting on a concrete or brick wall.
1Select a position free of obstructions on a wall strong enough to hold the weight of the device.
2Mark two holes on the wall at the appropriate distance apart for the screws.
Be careful to avoid damaging pipes or cables located inside the wall
when drilling holes for the screws.
3If using screw anchors, drill two holes for the screw anchors into the wall. Push the anchors into the
full depth of the holes, then insert the screws into the anchors. Do not insert the screws all the way
in - leave a small gap of about 0.5 cm.
If not using screw anchors, use a screwdriver to insert the screws into the wall. Do not insert the
screws all the way in - leave a gap of about 0.5 cm.
4Make sure the screws are fastened well enough to hold the weight of the NBG5615 with the
connection cables.
5Align the holes on the back of the NBG5615 with the screws on the wall. Hang the NBG5615 on the
screws.
2.4G/5G WLAN Green On The NBG5615 is ready and the 2.4GHz/5GHz wireless LAN is on,
but is not sending/receiving data through the wireless LAN.
Blinking The NBG5615 is sending/receiving data through the wireless
LAN.
Off The wireless LAN is not ready or has failed.
WPS Green On WPS is enabled.
Blinking The NBG5615 is negotiating a WPS connection with a wireless
client.
Off WPS is disabled.
USB 1/2 Green On The NBG5615 has a USB device installed.
Blinking The NBG5615 is transmitting and/or receiving data from routers
through an installed USB device.
Off There is no USB device connected to the NBG5615.
Table 1 Front panel LEDs (continued)
LED COLOR STATUS DESCRIPTION
Table 2 Wall Mounting Information
Distance between holes 13 cm
M4 Screws Two
Screw anchors (optional) Two

Chapter 1 Introduction
NBG5615 User’s Guide
20
Figure 2 Wall Mounting Example
