180 INNOVATIONS KD-2250 User manual

DIGITAL TEMPLE THERMOMETER
KD-2250
Safety Instructions...................................................1
Device Description and Intended Use.......................2
About Body Temperature..........................................3
Contraindications.....................................................3
Device/Display Overview & Quick Start
Device Overview....................................................4
Display Overview...................................................4
Quick Start............................................................4
Explanation of Symbols............................................5
Battery Installation...................................................5
Setting
Memory Function......................................................7
Use
Measurement Consideration..................................8
Doing a Measurement............................................8
Cleaning & Disinfection..........................................9
Care and Storage....................................................10
Product Specification..........................................11
Troubleshooting.....................................................12
Warranty .................................................................12
FCC STATEMENT.....................................................13
Table of Contents
INSTRUCTION MANUAL
Distributed by : 180 INNOVATIONS LAKEWOOD,CO 80215
Manufactured by: K-jump Health Co.,Ltd.
Made in China www.180innovations.com

1 2
Safety Instructions
18.Performance of the thermometer may be degraded if: operated or
stored outside stated temperature and humidity ranges or if the
patient's temperature is below the ambient (room) temperature.
19.Only use the thermometer indoors and do not use it near mobile
phones or microwave ovens. In the case of thermometer whose
maximum power exceeds 2 W, the minimum distance from
thermometer should be 3.3 meters (11 feet).
20.The reading is for reference, if you feel sick or uncomfortable,
please contact the physician.
CAUTIONS:
1. Do not scrape or scratch the probe as it will hamper the
effectiveness of the device.
2. Do not dismantle the device except when replacing the battery.
3. Wait at least thirty minutes after exercising, bathing or eating
before taking a measurement.
4. If the subject’s body temperature is lower than the room
temperature, a false reading may occur.
5. To ensure the best performance of the device, please follow
the PRODUCT SPECIFICATION "Storage condition" regarding
temperature and humidity ranges for storing the device.
6. Dispose of the device and batteries according to your local
regulatory or environmental protection agency.
Device Description and Intended Use
The thermometer is an electronic device intended to measure the
human body temperature using the forehead as measurement site. It
can be used with adult or pediatric patients in household environment.
Safety Instructions
WARNINGS:
1. Read the entire instruction manual before trying to operate the
device.
2. The device is delivered non-sterile; please clean the device before
measuring.
3. Stop using the device if malfunctions appear or if it operates
abnormally.
4. Children should not use the device without the supervision of an
adult. Keep out of reach of unsupervised children.
5.Donotusethedevicewhenammablematerialsarearound.
6. Do not place the device on scarred tissue, open wounds or
abrasions.
7. Some medications may cause a rise in skin temperature which can
consequently lead to incorrect measurements.
8. Taking a measurement after skin has been exposed to an extreme
conditionsuchasdirectexposuretosunlight,replace/heateror
airconditionerow,mayleadtoincorrectreadings.
9. If the device has been kept or stored in extreme temperatures,
wait at least one hour for the device to return to room temperature
before measuring.
10.Do not touch the probe, unless the device is taking a measurement.
11.The device is not water resistant, please keep dry.
12.Do not drop the thermometer or expose it to heavy shock.
13.Do not bite or swallow the probe and the battery cover.
14.Do not let thermometer come into contact with any thinner or
chemical solvents
15.Components may be harmful if swallowed. Contact a physician
immediately should this occur.
16.Do not use it if the display malfunctions or it operates irregularly.
17.Do not put this unit in dishwasher.

3 4
About Body Temperature
A person’s normal body temperature can range from 95.9°F to
100.0°F throughout the day. We recommend taking your temperature
at different times during the day when you are NOT sick. This will give
you a preliminary reference to know what your normal temperature is
andhowituctuatesduringanormalday.Then,whenyoufeelsick
or uncomfortable, knowing this information will provide an index for a
reliable diagnosis of a fever.
Contraindications
The thermometer is contraindicated:
1. Place the thermometer probe on scarred tissue or tissue
compromised by any disorders of measuring site.
2. Place the thermometer probe on skin exposed to direct sunlight,
replaceheat,coldcompresstherapies,airconditionerow,etc.
3. Patients in trauma or treat with certain drug therapies.
Device Overview
Display Overview
Quick Start
1. Install batteries into the device. Make sure the polarity
(+ and -) of the batteries matches as shown in the
battery compartment.
2.PressandreleasetheON/OFFbutton,thedevicewill
be turned on then ready for measurements.
3. Place the probe on the measuring site and wait for a
few seconds.
4. The measurement is completed with beep.
5. Read the temperature on the display.

5 6
Explanation of Symbols
Power on, off
Low battery indicator
MEM Memory indicator
Delete memory
Wait for next measurement
Device is off
Manufacturer
Please read thoroughly before using
Warning and Caution
YYMM : Lot Number composed by year(Y) and
month(M) of manufacture.
Battery Installation
Battery Installation
REPLACE BATTEY
1. Remove the battery cover to insert batteries.
2.Conrmthepolarity(+and-)ofbatteriesarecorrectas indicated
inside the compartment and insert batteries accordingly.
3. Replace the battery cover.
Setting
Setting °C or °F Scale
1. To set or reset the scale (°C or °F) you must begin
with the device being powered off.
2.PressandreleasetheON/OFFbuttontoturnon
the device.
3. As soon as you hear a short beep, immediately
presstheON/OFFbuttonagainbutholddownfor
about 2 seconds until you see the °C or °F change.
Release the button as soon as change occurs.
4.PressandholdtheON/OFFbuttonagainfor2
seconds to switch back and forth from °C to °F.
5.WhicheverscaleshowswhenyoureleasetheON/
OFF button will be the scale the device will show
for the measurement.
6. The device will be ready for measuring after the
hourglass disappears and you hear two short
beeps.
WARNING
Use only same type of alkaline batteries to avoid incompatibility.
1. Replace with 2 new AAA batteries simultaneously when the low
battery indication appears.
2. Remove batteries if the device is not likely to be used for a long
period of time.
3.Donotdisposethebatteriesinare,thebatterieswillexplode.

7 8
Use
Measurement Consideration
CAUTION
1. Make sure the measuring site is dry, clean and free of sweat and
cosmetics prior to measurement taking.
2. Clean the probe before and after each measurement to prevent
cross-contamination, see Cleaning & Disinfection.
3. After cleaning and disinfecting the probe, please wait at least 2
minutes to do a measurement.
1. Place the probe on the temple. Temple area is located between the
outer corner of the eye and the hairline, right on top of the temporal
artery area.
2. For the most accurate measurements, be sure to hold the probe
rmly(butnottoohard)ontemple.
3. Once you have placed the probe on the temple, do not move
before the measuring is done.
Doing a Measurement
1.PresstheON/OFFbuttontoturnonthedevice,itwill
auto self-diagnosis.
2. When all symbols appear on the display, the self-
diagnosisisnished,itisreadyformeasuring.
3. After the device beeps twice, place the probe on
the measuring site.
4. The measurement is done when you hear one
long beep.
5. Read the temperature on LCD.
6. Backlight will light up in accordance with the reading.
Please refer to Table 1.
7. The device’s fever alarm will beep continuously when
the temperature reading is higher than 99.5°F.
Memory Functions
Recall memory
1. To recall a memory, you must begin with the device
being powered off.
2.PressandholdtheON/OFFbuttonuntilthelast
record shows.
3.PressandreleasetheON/OFFbuttontorecall up
to 9 previous records.
4. If no operation, the device will beep twice indicating
it is ready for measuring.
Delete memories
1. Repeat RECALL MEMORY step 1 and step 2.
2.PressandholdtheON/OFFbuttonforabout3
seconds until “dEL”.
3.PressandreleasetheON/OFFbuttonagainto
delete all stored records in device.
4. The device will power off automatically.
Otherwise,
5. To stop deleting memory, no operation when you
see “dEL”.
6. The device will be ready for measuring after 2
seconds.

9 10
Use
8.PressandholdtheON/OFFbuttontoturn offthedeviceorthe
device will shut off automatically within 60 seconds of inactivity.
Temperature (°C) Temperature (°F) Backlight
T≤37.1 T≤98.9 Green Backlight
37.2≤T≤37.4 99≤T≤99.4 Yellow Backlight
37.5≤T 99.5≤T Red Backlight
Cleaning & Disinfection
1. To clean and disinfect the device, use a cotton swab or pad
moistened with 70% alcohol to wipe the Sensor and Probe.
2. Use a cloth dampened with water or neutral detergent to clean
and dry the device.
3. Do not use thinner, benzene, and other harsh cleaners for cleaning
the device.
4. Do not immerse the unit in water or liquid of any kind. The unit is
not water proof.
Do not submerse or expose the device to water.
Do not use corrosive detergent to clean the device. Clean and
disinfect the thermometer before and after use.
Cleaning process:
1. Pre-cleaning with cold water wash several times.
2. Clean the probe with a solution of 5-10% mild detergent about 10-
15 seconds.
3. Continuously clean with cold water to avoid of any chemical
residues remaining on the device.
4. Rinse the device with drinking water or distilled water to ensure the
removal of all remnants of the cleaning agent.
5. If necessary, repeat step 2 through step 4 in order to make sure the
device is clean.
6.Analwipedownbyacleanwipeisnecessarytoavoidofwater
stains.
Cleaning & Disinfection
Disinfection process:
1. To disinfect the device when completed the cleaning process.
2. Wipe the probe with a cloth dipped in a disinfectant solution such
as70-75%isopropyl(rubbing)alcoholsolution:contacttime≥10
minutes for disinfection.
3. The disinfectant free rinse without residues.
Drying process
1. After cleaning and disinfection process above.
2. Put the device to air-dry in the room temperature (68-86°F),
exposure time around 30-60 minutes.
Care and Storage
1. Do not drop or crush the device. It is not shock proof.
2. Do not dismantle or modify the device other than changing the
batteries.
3. Do not store the device in an extreme environment with direct
sunlight,high/lowtemperaturesorinalocationwithhighhumidity
or severe dust.
Please contact your local agents or distributors if the device does not
functionproperlyasspeciedunderProduct Specication.

11 12
Product Specification
Measuring site Temple
Measuring time 6 seconds
Measuring Range 95.0~107.6°F (35.0~42.0°C)
Accuracy
<96.4°F or >106.0°F : ±0.5°F
<35.8°C or >41.0°C : ±0.3°C
96.4~98.0°F or 102.0~106.0°F : ±0.3°F
35.8~37.0°C or 39.0~41.0°C : ±0.2°C
98.0~102.0°F : ±0.2°F
37.0~39.0°C : ±0.1°C
Resolution 0.1°F (0.1°C)
Measurement unit °F (°C)
Memory sets 9 sets
Operating condition 60.8~104.0°F (16~40°C), R.H. of 15~95%
non-condensing
Storage condition -4°F~120°F (-20~50°C), R.H. of 15~95%
non-condensing
Battery AAA battery x 2pcs
Battery Life More than. 1000 measurements.
Auto Shut Off After 60 seconds of inactivity
Dimension 87mm x 26mm x 26mm
Weight 45g including battery
Warranty 1 year
Guarantee of
Quality
Certication ISO 13485
Comply with ASTM-E1112
This device complies with all requirements of ASTM 1112 Standard
Specification for Electronic Thermometer for Intermittent Determination of
Patient Temperature.
Product Specification
Troubleshooting
The reading is higher than measuring range, please
redo a measurement.
Out of operating condition.
Poor contact or movement caused the device to stop
measuring. Make sure both skin and probe are clean
then measure again. Make sure the Sensor is close
in contact with temple and avoid body movement
while taking measurement
Device self-diagnostic error, please contact the
distributor.
Warranty Information
Warranty:
The device itself (battery excluded) comes with one year warranty
from purchasing date if it is operated under normal circumstances
without evidence of tampering. See exclusions below.
Warranty exclusions:
1. If user does not properly operate the device according to the
instructions as described in this manual.
2.Ifthedeviceshowssignsoftamperingorattemptedmodication.
3. Improper handling, such as dropping, liquid or cleaner damage.
4.Naturaldisasters(suchasre,ood,earthquake,lightningstrike).
5. If you do not have a receipt or proof of purchase showing date of
purchase.

13
Serial Number Information
S/N(YYMM)onthedevicelabelmeanstheyearandmonth
of manufacturing. For example, "1712" means the unit was
manufactured in December, 2017.
FCC Statement
POTENTIAL FOR RADIO/TELEVISION INTERFERENCE
This product has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. The product generates, uses,
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If the product
does cause harmful interference to radio or television reception,
which can be determined by turning the product on and off, the user
is encouraged to try to correct the interference by one or more of the
following measures:
●Reorientorrelocatethereceivingantenna.
●Increasetheseparationbetweentheproductandthereceiver.
●Connecttheproductintoanoutletonacircuitdifferentfromthatto
which the receiver is connected.
●Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changes or modifications not expressly approved by 180
INNOVATIONS may void the user's authority to operate this devise.
Made in China
REV. 20171206 PN.822250XXXX
