Quick Start Guide & Warranty
Safety Instructions / Declaration of Conformity
Quick Start Guide
Your 360fly has landed.
Build your profile and join the 360°
uprising at 360fly.com
(If you’re one to forget these types
of things, maybe write it here.)
360fly password:
360fly
Tilt Mount
Power Cradle
USB Cable
Baseplate: Flat Pouch
Baseplate: Curved
BONUS Action
Camera Adapter
Mic Plug
& Strap
What’s in that tube?
Congratulations on
your new camera!
With the world’s widest single lens field of view and your
unique POV, you now have the power to step outside the
border. Beyond the frame. And into the fully immersive,
interactive world of 360° video.
You’re now part of a new community of visual
storytellers, one that will fundamentally change
the way we see and experience everything.
Join them now and share your best footage
and edits at 360fly.com.
Let’s do this.
Step 1: Download our 360fly app. The 360fly app
is key to capturing your entire world. Just
search “360fly” in the App Store or Google
Play and download it to your mobile device.
Launch the app to set up your camera
and build a 360fly profile.
Remember, the app allows your mobile device to serve
as your camera’s remote and viewfinder, giving you
the power to edit and share clips on the fly. In other
words, get it already.
Step 2: Remove camera from the packaging
and Tilt Mount.
NOTE: DO NOT THROW AWAY the Tilt Mount.
(For ins and outs, see the Tilt Mount section.)
Step 3: Charge your camera for at least 30 minutes
by placing it on its magnetic Power Cradle
while it’s plugged into a power source.
Step 4: Remove camera from its Power Cradle and
turn it on by holding the OnePush button
down for 4 seconds.
Step 5: Connect your mobile device and camera
by tapping the “Camera” icon in the app.
Now tap the camera drop down arrow to
add or select a camera.
Step 6: Follow the in-app directions to name your
camera, create a profile and complete
the setup.
NOTE: For iOS, exit the app, go to your device’s
“Settings” and connect to your camera’s wifi.
Step 7: Stick your baseplates and mounts
on anything that moves… then start
capturing and sharing everything
around you in 360 degree HD video.
Power to fly.
Your 360fly is powered on, records and powers off
with its OnePush button. It also vibrates to inform
you of its state.
To power on your 360fly, press and hold the OnePush
button for 4 seconds. The camera will vibrate three
times. When the LED turns solid blue, the camera’s
ready to record.
To record, use the control in the app or press the
OnePush button. The camera will vibrate once and
the light will turn red. Just remember, when it’s red,
it’s recording.
To stop recording, press the OnePush button.
The camera will vibrate two times and the light
will return to blue.
To power off your 360fly, press and hold the
OnePush button for 3 seconds. The camera will
vibrate 3 times.
LED states.
Visit 360fly.com/LED to get to know the light
that lets you know what your camera’s doing.
Capturing full 360° video.
Your 360fly isn’t just a camera. It’s the new eye of
social media, putting you at the center of the action
while allowing viewers to explore every angle, every
POV and every visual sensation of your adventures.
To record through the 360fly app, select the “Camera”
icon. Select the “Live View” tab. You’re now seeing
from your camera’s point of view.
Tap the white Record button in the center to start
capturing. Your camera will vibrate and its LED will
turn from blue to red. To stop recording, tap the
now red Record button. You can review any footage
recorded on your camera by going to the “On My
Camera” tab.
If you don’t have access to our 360fly app on your
mobile device, you can record directly to your camera.
Power it up and press the OnePush button to turn the
camera’s light from blue to red. To stop recording,
press the button again.
360fly edits and sharing.
360fly gives you the power to capture, edit and share
online up to 2 minutes of your most epic footage
directly from your mobile device.
To edit and share footage you’ve captured, launch
the 360fly app, tap the “Camera” icon and select
the “On My Camera” tab. Videos stored on your
camera will be listed here.
Select the video you want to edit and you’ll enter the
Player view. Tap the Edit button, bottom right. Three
options for editing your clip will appear: Clip Capture ,
Watch Me and Still Capture . These easy-to-use
features will allow you to edit your footage, add filters,
create slo-mo / fast-motion segments, even add
a soundtrack. And once you’re done, share your
creation online with just the push of a button
For more information on editing via the app,
check out 360fly.com/editing.
A new reality in virtual reality.
360fly’s footage is designed to work seamlessly
with Google Cardboard VR Viewers.
To watch your footage using a Google Cardboard
VR Viewer, just tap the “Viewer” icon top right when
you’re in the Player screen. Words don’t do it justice,
so be sure to get a headset and explore 360fly VR
for yourself.
Footage, memory space
and a good trashing.
Your 360fly is a lens, camera and storage device
all in one. Its internal battery and 32GB memory
gives you the power to capture approximately
2 hours of 360° HD footage each time out.
To view footage on your mobile device, open the
360fly app, tap the Camera icon and select the
“On My Camera” tab.
To view, edit and explore 360° footage on your
computer, download the 360fly Director at
360fly.com/Director.
Use your Power Cradle to connect your camera to
your computer and then simply drag the clips you
wish to view from your camera to the Director.
Google Cardboard VR Viewer

www.360fly.com
facebook.com/360fly twitter.com/360fly
FILE NAME: FLY008-3A_QS+Warranty_download_A4 SIZE: 8.27” x 11.69” (A4 paper size)
CREATED: 06/04/15 TRIM: 8.27” x 11.69”
DUE DATE: 09/30/15 BLEED: 1/8in
FILELOCATION:Macintosh HD:Users:carinebrown:Dropbox (360fly):360fly CREATIVEIN PROGRESS:••360FlyIn-Progress••:FLY008_Camera Packaging:**REGION-US (Masters):FLY008-3B_Quickstart Guide_NewVersion:FLY008-3A_QS+Warranty_download_A4.indd
Be sure to save your most epic moments to your mobile
device, computer or external drive.
You can delete your clips either through the 360fly
app or straight from your desktop. In the app, simply
swipe to the left on iOS or press and hold on a clip on
Android to reveal the “Trash” icon. From your desktop,
dock the camera to your computer, select the clips
you want to remove and drag them to the trash. Once
they have been placed into the trash, your videos
have been erased. Just make sure you’ve saved your
favorite content and edits to an external device.
Charging.
To charge, insert USB cable into a compatible USB
outlet adapter (Eg: most smartphone chargers).
For best results, charge while the device is off.
Stick your landings.
Attach your 360fly camera to helmets, boards and
virtually any of the gear you’ve got with its flat and
curved baseplates.
Attaching baseplates.
First, be sure to use the baseplate that matches
the surface’s curvature. Now follow the three
steps on the next page to ensure a secure fit.
Action Camera Adapter.
The Action Camera Adapter included with your 360fly
lets you attach your camera to most other popular
action camera mounts you already own, making it
even easier for you to capture every angle of every
ride, turn, slope, wave, game, race and adventure.
Keep it clean.
A clean lens means cleaner footage. 360fly’s lens can
be cleaned using a clean, soft cloth. Lens cleaning
solution, water or isopropyl alcohol can be used for
additional cleaning.
Always remember to insert the Mic Plug and wash
off your camera after saltwater use. Failure to do so
can cause damage over time and void the warranty.
Use your pouch,
friend.
Return your 360fly
to its pouch after use
to help protect its
lens from scratching,
chipping or any
other damage.
The rare reset.
On rare occasions, it might become necessary to reset
your 360fly if it becomes unresponsive.
Step 1: Locate the reset button on the bottom
of the unit.
Step 2: Use a dull pointed object such as a paper
clip to quickly press and release the
reset button.
The 360fly’s LED will
flash blue during the
reset process.
After about 30 seconds,
the LED will turn a solid
blue when it is ready
for use.
Resetting will not
wipe the contents
of your camera.
Long live your 360fly.
Your 360fly camera is built to stand up to rigors of your
active lifestyle. That said, there are a few things you can
do to help it capture cleaner footage for years to come.
Power Cradle
Bottom of Camera
LED
Straphole
OnePush
Button
MIC Hole
Reset
Button
Lock
Guide
Tilt Mount
Buttons
Mic Plug
Hole
USB
12
Press and hold both
Tilt Mount buttons.
Turn the Tilt Mount
counter clockwise.
43
Remove the Tilt Mount
from the baseplate.
Twist the 360fly camera
off the Tilt Mount.
Know and love your 360fly.
Attaching Tilt Mounts.
Removing Tilt Mounts.
1
Align 360fly and
Tilt Mount.
Turn clockwise to lock.
2Tilt Mount Camera
360fly can only be attached to
the Tilt Mount in one direction.
(i.e. snowboard, table) (i.e. helmet)
FLAT CURVED
Remove backing paper
on baseplate adhesive.
Make sure the surface
is cleaned and dry.
1 2
Attach the baseplate
with the arrow facing FRONT
(i.e. front of the helmet).
Attaching baseplates to surfaces.
The all-important Mic Plug.
1
3
2
Attaching Tilt Mounts
to baseplates.
Align 360fly and Tilt Mount.
Turn the Tilt Mount
clockwise...
...until you hear “click”
to fully lock.
Push the Mic Plug into the
microphone hole to insert it.
Push and turn to fully
secure the Mic Plug.
When using the Mic Plug,
audio will NOT be available.
2
1
4
3
Use Mic Plug when 360fly
could be submerged.
Failure to use the Mic
Plug voids warranty.
When not using the Mic
Plug, store it in the hole on
the side of the Tilt Mount.
The all-important Mic Plug.
With its Mic Plug securely in place, your 360fly camera
is water resistant down to 5ATM.
Always, always use the Mic Plug to protect your camera
in and around water. Failure to use it as recommended
could lead to water damage and void the warranty.
NOTE: The Mic Plug should always be stored on the
side of your Tilt Mount when not in use.
Audio will NOT be recorded when it is in use.
Bottom of Camera
Reset Button

www.360fly.com
facebook.com/360fly twitter.com/360fly
FILE NAME: FLY008-3A_QS+Warranty_download_A4 SIZE: 8.27” x 11.69” (A4 paper size)
CREATED: 06/04/15 TRIM: 8.27” x 11.69”
DUE DATE: 09/30/15 BLEED: 1/8in
FILELOCATION:Macintosh HD:Users:carinebrown:Dropbox (360fly):360fly CREATIVEIN PROGRESS:••360FlyIn-Progress••:FLY008_Camera Packaging:**REGION-US (Masters):FLY008-3B_Quickstart Guide_NewVersion:FLY008-3A_QS+Warranty_download_A4.indd
Warranty
Safety Instructions / Declaration of Conformity
12-Month Limited Warranty
360fly, Inc. (the Company) warrants to the original
retail purchaser of this product that should this
product or any part thereof, under normal use
and conditions, be proven defective in material or
workmanship within 12 months from the date of
original purchase, such defect(s) will be repaired
or replaced with reconditioned product (at the
Company’s option) without charge for parts and
repair labor.
To obtain repair or replacement within the terms
of this Warranty, the product is to be delivered
with proof of warranty coverage (e.g. dated bill
of sale) specification of defect(s), transportation
prepaid. To obtain assistance with an RMA
and where to deliver the product, please visit
www.360fly.com/support for more information.
This Warranty does not extend to water damage
caused by failure to properly seal the microphone
opening, with the included Mic Plug, to costs
incurred for installation, removal or reinstallation
of the product, to damage to digital memory/media
devices, or accessories, or loss of media, files
or stored data.
This Warranty does not apply to any product or part
thereof which, in the opinion of the Company, has
suffered or been damaged through alteration,
improper installation, mishandling, misuse,
neglect, accident, or by removal or defacement
of the factory serial number/bar code label(s).
The extent of the company’s liability under this warranty
is limited to the repair or replacement provided above
and, in no event, shall the company’s liability exceed
the purchase price paid by the purchaser for the
product. The company assumes no liability for
accident, death, injury, or other loss arising from or
resulting from use of the product or any part thereof.
This Warranty is in lieu of all other express warranties,
implied warranties, or liabilities. Any action for
breach of any warranty hereunder, must be brought
within a period of 24 months from date of original
purchase. In no case shall the company be liable
for any consequential or incidental damages for
breach of this or any other warranty. No person or
representative is authorized to assume any liability
for the Company other than expressed herein
in connection with the sale of this product.
Some states do not allow limitations on how long
an implied warranty lasts or the exclusion or
limitation of incidental or consequential damage
so the above limitations or exclusions may not
apply to you. This Warranty gives you specific legal
rights and you may also have other rights which
vary from state to state.
Product Safety
Exercise caution. When using your 360fly camera
in your active lifestyle, always be aware of your
surroundings to avoid injury to yourself and others.
You’ve been warned. Failure to follow these
instructions/warnings could result in fire, electrical
shock and other injuries or damage to your 360fly
and other property.
Handle this. Your camera contains sensitive
components. Do not toss, drop, disassemble, open,
crush, roll, deform, shred, kick, microwave, paint,
incinerate or insert foreign objects into the camera.
Damage alert. Do not use the 360fly if it has been
damaged. For example, if it’s cracked, punctured or
has other visible damage.
Charge safely. To avoid shock when charging, do not
handle the plug or charger with wet hands.
Attempting to use any charger other than the
360fly’s magnetic cradle can damage the camera.
If you do not know the voltage and current of
a charger, use the included USB cable to charge
from a computer.
Don’t force it. Never force-fit connectors into ports.
Check for obstructions and make sure connectors
match and are aligned correctly.
Water-wise. Do not use the 360fly in rain or in other
wet locations without plugging in its Mic Plug. Do not
dry a wet 360fly using external heat sources such
as hair dryers, heater vents, ovens or microwaves.
Simply pat dry with a clean, soft cloth or towel.
Helmet warning. If using your camera with a 360fly
baseplate or the Action Camera Mount on a helmet,
always select a helmet that meets the applicable safety
standards. Inspect your helmet to ensure it’s in good
condition and follow the manufacturer’s instructions.
That’s glass. Your 360fly’s lens is glass. Should it
break, care should be taken to avoid cuts or other
injuries. Keep out of reach of children.
Running hot and cold. Avoid exposing camera and
its internal battery to extreme heat or cold. Very
low or high temperatures can shorten the battery’s
life or stop the camera from working. Avoid instant,
dramatic changes in humidity and temperature so
condensation doesn’t form on or in the camera.
Be smart, legal and cool. Abide by all local laws
when using this camera. There may be laws in your
jurisdiction related to the use of the camera in a
particular way. Some jurisdictions prohibit the use of a
video camera as an attachment to certain equipment
such as firearms or use in invasions of privacy.
Lithium batteries: A primary battery shall be marked
with the word “WARNING” and the following or an
equivalent statement: “Risk of fire and burns. Do not
recharge, open, crush, heat above (the manufacturer’s
specified temperature rating), or incinerate.” If space
does not permit marking on the battery, the marking
may be on the smallest unit package.
Do not get the battery wet; water will damage the
battery, which could cause an explosion or fire.
Risk of explosion or personal injury if batteries
are mutilated, or exposed to conducting materials,
liquids, fire, or heat (above 54° C or 130° F). Do
not use or recharge damaged rechargeable
batteries. Do not mix battery types. Dispose
of spent or damaged batteries according to
manufacturer instructions and local laws.
Industry Canada Statements:
Complies with the Canadian ICES-003
Class B specifications.
This device complies with RSS 210 of
Industry Canada.
This Class B device meets all requirements
of the Canadian interference-causing
equipment regulations.
FCC Compliance Statement:
This device complies with part 15 of the FCC rules.
Operation is subject to the following conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Declaration of Conformity
360fly, Inc.
1000 Town Center Way, Suite 200
Canonsburg, PA 15317, USA
Declares under our sole responsibility
that the product:
Product Type: Action Camera
Model Number: 360FLYBLK
FCC Identifier: 2ADDK-360FLYBLK
Conforms to the following Product Specifications:
Health and Safety
EN 60950-1:2006 + A2:2013
EN 62311 :2008
EN 62209-2:2010
EN 50360+A1: 2012
EN 62479: 2010
Spectrum
EN 300 328 V1.8.1
EMC
EN 301 489-1 V1.9.2
EN 301 489-17 V2.2.1
EN 55022: 2010
EN 55024: 2010
RoHS
EN 50581: 2012
The product specified above is in conformity with the
essential requirements and other relevant requirements
of the R&TTE Directive (1999/5/EC) and the following
Directives. The product carries the CE mark accordingly.
EMC Directive: 2004/108/EC
LVD Directive: 2006/95/EC
RoHS Recast Directive: 2011/65/EU
Peter Adderton
Position: CEO
Date: 8th June, 2015
©2015 360fly, Inc. All Rights Reserved.
360fly, the Fly Icon and 360fly(icon) are trademarks of 360fly, Inc. All other trademarks are property of their respective owners.
For a complete list of patents, please visit www.360fly.com/patents Part# XXXXXX
