This guide describes how to install, start up, troubleshoot, and maintain the
NETBuilder II
®
Dual Processor Engine (DPE) module. The DPE module is a central
processor for all NETBuilder II systems and comes in two models, the DPE 40
and the DPE 80.
This guide is intended for
the system administrator,network equipment installer,or
network manager who is responsible for installing and managing the network
hardware.It assumes a working knowledge of network operations,but does not
assume prior knowledge of 3Com® internetworking equipment.
If the information in the release notes shipped with your product differs from
the information in this guide, follow the release notes.
Conventions Table 1 and Table 2 list conventions that are used throughout this guide.
Table 1 Notice Icons
Icon Notice Type Alerts You To...
Information note Important features or instructions
Caution Risk of personal safety, system damage, or loss of data
Warning Risk of severe personal injury

2 A BOUT T HIS G UIDE
Table 2 Text Conventions
Convention Description
Syntax The word “syntax” means you must evaluate the syntax provided and
supply the appropriate values. Placeholders for values you must
supply appear in angle brackets. Example:
Enable RIPIP by using the following syntax:
SETDefault !<port> -RIPIP CONTrol = Listen
In this example, you must supply a port number for <port>.
Commands The word “command” means you must enter the command exactly
as shown in text and press the Return or Enter key. Example:
To remove the IP address, enter the following command:
SETDefault !0 -IP NETaddr = 0.0.0.0
This guide always gives the full form of a command in uppercase and
lowercase letters. However, you can abbreviate commands by
entering only the uppercase letters and the appropriate value.
Commands are not case-sensitive.
Screen displays This typeface represents information as it appears on the screen .
The words “enter”
and “type” When you see the word “enter” in this guide, you must type
something, and then press the Return or Enter key. Do not press the
Return or Enter key when an instruction simply says “type.”
[Key] names Key names appear in text in one of two ways:
■
Referred to by their labels, such as “the Return key” or “the
Escape key”
■
Written with brackets, such as [Return] or [Esc].
If you must press two or more keys simultaneously, the key names
are linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del].
Menu commands
and buttons
Menu commands or button names appear in italics. Example:
From the Help menu, select Contents .
Words in italicized
type Italics emphasize a point or denote new terms at the place where they are defined in the text.
Words in boldface
type Bold text denotes key features.

1
I
NSTALLING THE
DPE M
ODULE
The Dual Processor Engine (DPE) module is the central processor for the
NETBuilder II
®
system. It includes a flash memory drive for the system software
as well as a second flash memory drive for back-up. Firmware parameters set
with the software SysconF command and with the firmware boot monitor are
stored on the flash PROM (FPROM). A console port on the front of the module
provides local management. The DPE module, in combination with the 800
Mbps backplane, delivers consistently high throughput for all interface ports.
This chapter describes how to install the DPE module into the NETBuilder II
system and includes information on the following:
■
DPE models
■ Upgrading to a DPE
■
Preparing your system for installation
■
Installing in the NETBuilder II 4- or 8-Slot chassis
■ Installing in the NETBuilder II 8-Slot Extended chassis
■
Connecting a PC, terminal, or modem
■
Installing the software
■ Attaching the flash memory drive cover
If you have a NETBuilder II EZBuilt system with a preinstalled DPE module, go to
“Connecting a PC, Terminal, or Modem” on page 1-5.
The software flash memory card does not ship with the stand-alone DPE
module and must be purchased separately from 3Com.
DPE Models The DPE module is available in two models, the DPE 40 and the DPE 80.
The DPE 40 has 32 MB of instruction and data memory (upgradeable to 64 MB)
and 8 MB of shared (packet) memory.
The DPE 80 has 64 MB of instruction and data memory and 16 MB of shared
(packet) memory.
The DPE 40 cannot be upgraded to a DPE 80.
Upgrading from a
CEC to a DPE
The DPE module has two built-in flash memory drives and does not support
either the floppy disk drive or the internal flash memory drive. The CEC module
uses the internal flash memory drive to boot. Refer to
Upgrading NETBuilder
Family Software
for more information about upgrading your software.
When you replace the DPE module, the firmware parameters that were
previously configured by the SysconF command in the software are not
automatically updated to the FPROM of the replacement DPE module. You must
reconfigure these parameters. Refer to the software guide
for configuration
information.

1-2 C HAPTER 1: I NSTALLING THE DPE MODULE
Before Installing the
Module Before you install the DPE module into the NETBuilder II system, follow
these steps:
1Observe appropriate electrostatic discharge (ESD) precautions.
ESD can damage circuit board components. Failures resulting from ESD may not
be covered under your warranty. To prevent ESD damage, follow these
procedures:
■Keep the module in its antistatic shielded bag until you are ready to install it.
■Do not touch pins, leads, or solder connections on the board.
■Handle the board by the edges only.
■Store or ship the module in static-protective packaging.
Observe proper grounding techniques when handling the module: Use a foot
strap and grounded mat, or wear a grounded static-discharge wrist strap.
2Unpack and inspect the module for shipping damage.
If you find any damage, file a report with the shipping company. If the module
must be returned to your network supplier, ship it in its original shipping carton.
If the original carton was damaged in shipment, repack the system in a carton
that provides equivalent protection.
3Write down the serial number and MAC address from the labels on the
component side of the module.
You will need this information if you have to contact your network supplier.
Serial number example: S/N:4FTE123456
MAC address example: 08000 21A4B5C
.
Serial number:
Mac address:
Serial number
MAC address
®
DPE
CONSOLE
RUN
LOAD
TEST
4321
STATUS PACKET
FORWARD POWER/
FAULT RESET ATTENTION
A
B

Installing in the 4- or 8-Slot Chassis 1-3
Installing in the 4- or
8-Slot Chassis To install the DPE module into the NETBuilder II 4- or 8-Slot chassis, follow these
steps. If you own the Extended chassis, refer to the next section.
Although it is not required, 3Com recommends that you turn off the system
before you install or remove a DPE module. If you do not turn off the system,
the bridge/router will automatically reset when you install the DPE module.
You will need a small, flatblade screwdriver.
1Insert the module into the top slot.
Although the figure shows an 8-Slot chassis, the procedure for the 4-Slot
chassis is exactly the same.
2Hand-tighten the captive screws, then gently tighten them with a small
(1/8 in. – 3/16 in.) screwdriver. Do not overtighten the screws.
A solid connection of the front panel to the chassis is required for proper
operation. Do not use the screws to force the board into place.
You are now ready to install the I/O modules. Refer to the appropriate I/O
module installation guides. After installing your I/O modules, refer to
“Connecting a PC, Terminal, or Modem” on page 1-5.
c
a
b
d
1
2
3
4
8
7
6
5
®
DPE
PACKET
FORWARD POWER/
FAULT
RUN
LOAD
TEST
RESET ATTENTION
4321
STATUS
CONSOLE
A
B
Grasp left
and right
sides of
LED panel.
Make sure module
is right side up.
Push ejector tabs all
the way closed until the
module is flush with the chassis.
Slide module along
guide rails until it
engages the notches
of ejector tabs.

1-4 CHAPTER 1: INSTALLING THE DPE MODULE
Installing in the
Extended Chassis To install the DPE module into the NETBuilder II Extended chassis, follow these
steps. If you own the 4- or 8-Slot chassis, refer to the previous section.
Although it is not required, 3Com recommends that you turn off the system
before you install or remove a DPE module. If you do not turn off the system,
the bridge/router will automatically reset when you install the DPE module.
You will need a small, flatblade screwdriver.
1Insert the module into the left-most slot marked A.
2Hand tighten the captive screws, then gently tighten them with a small
(1/8 in. – 3/16 in.) screwdriver. Do not overtighten the screws.
A solid connection of the front panel to the chassis is required for proper
operation. Do not use the screws to force the board into place.
You are now ready to install the I/O modules. Refer to the appropriate I/O
module installation guides. After installing your I/O modules, refer to the next
section, “Connecting a PC, Terminal, or Modem.”
Grasp left and right sides of
LED panel.
a
Turn the board so the 3Com logo is
on the bottom.
b
Slide board along guide rails until it
engages ejector tab notches.
c
Push ejector tabs closed until the
module is flush with the chassis.
d
®
FAST ETHERNET
100BASE-TX
®
DPE
PACKET
FORWARD POWER/
FAULT
RUN
LOAD
TEST
RESET ATTENTION
4321
STATUS
CONSOLE
A
B

Connecting a PC, Terminal, or Modem 1-5
Connecting a PC,
Terminal, or Modem
After the I/O modules are installed and cabled according to the appropriate I/O
module installation guides, connect a PC running a terminal emulation program,
a terminal, or a modem to the CONSOLE port on the DPE module front panel.
You will use the PC, terminal, or modem to:
■
Configure the bridge/router software .
■
Use the boot monitor.
■
Review startup and system operation messages. Some of the messages
displayed by the terminal are more detailed than information displayed on
the LCD. These detailed messages may help you troubleshoot startup or
operation problems.
To connect a PC, terminal, or modem to the DPE module, follow these steps:
1 Obtain a cable to connect the console to the CONSOLE port on the DPE module
front panel.
Figure 1-1 shows the pinouts for a 9-pin female to 9-pin female PC cable. A
null modem-type cable may be used.
Figure 1-2 shows the pinouts for a 9-pin female to 25-pin terminal cable. A
null modem-type cable may be used.
Figure 1-3 shows the pinouts for a 9-pin female to 25-pin male modem cable. A
straight-through-type cable may be used.
WARNING: To eliminate cable noise emission in excess of FCC Part 15, Subpart
J, and EN55022 B, this device cable should be shielded and have connectors
with metallic backshells.
Figure 1-1 9-pin to 9-pin PC Cable (Null Modem-Type)
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
Name Abbr Pin Pin Abbr Name
9-pin female connector
9-pin female connector
2
3
1
8
7
5
4
6
3
2
7
8
1
5
6
4
TxD
RxD
RTS
CTS
CD
GND
DSR
DTR
RxD
TxD
CD
CTS
RTS
Gnd
DTR
DSR
Transmit Data
Receive Data
Request to Send
Clear to Send
Carrier Detect
Signal Ground
Data Set Ready
Data Terminal Ready
Receive Data
Transmit Data
Carrier Detect
Clear to Send
Request to Send
Signal Ground
Data Terminal Ready
Data Set Ready
To CONSOLE port To PC serial port

1-6 CHAPTER 1: INSTALLING THE DPE MODULE
Figure 1-2 9-pin to 25-pin Terminal Cable (Null Modem-Type)
Figure 1-3 9-pin to 25-pin Modem Cable (Straight-Through-Type)
2Connect one end of the cable to the CONSOLE port on the DPE front panel and
the other end to the serial port on the back of your console.
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25
5 4 3 2 1
9 8 7 6
Name Abbr Pin Pin Abbr Name
25-pin male or female connector
9-pin female connector
2
3
1
8
7
5
4
6
2
3
4
5
8
7
6
20
TxD
RxD
RTS
CTS
CD
GND
DSR
DTR
RxD
TxD
CD
CTS
RTS
GND
DTR
DSR
Transmit Data
Receive Data
Request to Send
Clear to Send
Carrier Detect
Signal Ground
Data Set Ready
Data Terminal Ready
Receive Data
Transmit Data
Carrier Detect
Clear to Send
Request to Send
Signal Ground
Data Terminal Ready
Data Set Ready
To CONSOLE port To terminal
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25
5 4 3 2 1
9 8 7 6
25-pin male connector
9-pin female connector
To CONSOLE port To modem
Name Abbr Pin Pin Abbr Name
3
2
4
8
5
7
6
20
Receive Data
Transmit Data
Request to Send
Carrier Detect
Clear to Send
Signal Ground
Data Set Ready
Data Terminal Ready
RxD
TxD
RTS
CD
CTS
GND
DSR
DTR
TxD
RxD
RTS
CD
CTS
GND
DSR
DTR
Transmit Data
Receive Data
Request to Send
Carrier Detect
Clear to Send
Signal Ground
Data Set Ready
Data Terminal Ready
3
2
7
1
8
5
6
4

Installing Software 1-7
3Verify that configurable parameters of your console match the configuration
settings of the CONSOLE port specified in Table 1-1.
4Turn on the console.
Installing Software If you have bought the software from 3Com preinstalled on a flash memory
card, insert the card into drive A, the top flash memory drive. The default boot
and configuration file paths are to a directory on drive A.
Refer to the release notes for approved vendors of blank flash memory cards for
backup. The software guide describes how to format a blank card.
For information about configuring the NETBuilder II software, refer to the
software guides that shipped with your software package.
Table 1-1 CONSOLE Port Configuration Settings
Characteristic Setting
Baud rate 9600
Databits 8
Parity None
Stop bits 1
DTR Ignored
Duplex Full
Echo Off
Flow control X-on/X-off

1-8 CHAPTER 1: INSTALLING THE DPE MODULE
Attaching the Flash
Memory Drive Cover To ensure that the flash memory card is not accidentally ejected when the eject
button is pressed, attach the cover as shown:
Match notches with slots
RESET ATTENTION
A
B
Install screw. Do not
tighten all the way.
Slide shield toward center of
front panel until screw fits in
the narrow end of the slot.
Tighten screw. Do not
overtighten.
RESET ATTENTION
A
B

2TROUBLESHOOTING AND REPLACING
THE DPE MODULE
This appendix provides information on troubleshooting and replacing the
DPE module.
Startup Problems Table 2-1 lists symptoms of DPE module startup problems (abnormal LED
patterns and error messages).
.
Table 2-1 Troubleshooting the DPE Module
Symptom Cause and Action
LEDs fail to light at initial power-on or during a reset. No power to the system or the DPE module connectors are
not properly mated with the backplane connecters.
1Turn off the NETBuilder II system.
2Verify that the power cord is plugged properly into the
system’s power supply module and into a working outlet.
3Inspect the system’s in-line power fuse and replace it, if
necessary. Use the appropriate procedure in the
NETBuilder II Bridge/Router Installation Guide.
4Turn on the system.
5If the LEDs still do not light, remove and reinstall the DPE
module.
6If the LEDs still fail to light, contact your network supplier.
LCD and terminal displays freeze and nothing happens when
either the Enter or Return key is pressed. Reset the system by pressing the two outer buttons on the LCD control panel.
If this does not resolve the problem, call your network
supplier.

2-2 CHAPTER 2: TROUBLESHOOTING AND REPLACING THE DPE MODULE
LED Patterns The nine LEDs display the diagnostic and operational activity of the NETBuilder II
bridge/router. Table 2-2 describes the LEDs during normal operation. Table 2-3
describes the LEDs during an error condition.
Table 2-2 Normal Operation of LEDs
RUN LOAD TEST
G = green
Y = yellow
x = any value
- = off
F= flashing
PACKET FORWARD POWER/FAULT
STATUS Meaning
G G Y G G G G G Y Initial power-on or reset value
- - Y - - - G - G Performing DRAM test
- - Y - - G - - G Loading firmware
- - Y - G - x - G Firmware initialization
- - Y G - - x - G Performing non-essential, board-level, power-on self-tests
- - Y G - G x - G Performing corebus loopback test
- - Y G G - x - G Performing UART and shared memory test
- - Y G G G x - G Validating firmware parameters
- - Y - G G x - G Updating firmware
- G - - - - x - Y Waiting for boot monitor command
- G - - G - x - Y Performing TFTP get of bridge/router image
- G - - - G x - G Awaiting response to “enter boot monitor?”
- G - - G - x - G Reading bridge/router image composite file into shared
memory
- G - - G G x - G Validating composite file
- G - G - - x - G Auto-updating from composite file
- G - G - G x - G Decompressing bridge/router software
- G - G G - x - G Loading bridge/router software
- G G G G x - G Bridge/router software initializing
G - - x x x x x G Bridge/router software running

LED Patterns 2-3
Table 2-3 Error indications of LEDs
RUN LOAD TEST
G = green
Y = yellow
x = any value
- = off
F= flashing
PACKET FORWARD POWER/FAULT
STATUS Meaning
G G Y G G G G G Y Board hung very early in firmware load
Return module for repair.
- - Y - - - G - YF DRAM test failed
Reseat or replace SIMM.
- - Y - - G - - YF Firmware load failed
Return module for repair.
- - Y - - G G - YF ATTENTION buttons pressed
Reset system to reboot.
- - Y - G - x - G Hang during firmware initialization
- - Y G - - x - G Hang during board-level tests
Return module for repair.
- - Y G - G x - YF Corebus loopback test failed
Reseat DPE.
- - Y G G - x - YF Serial port or shared memory test failed
Return module for repair.
- - Y G G G x - YF FPROM contents corrupted
Return module for repair.
- G - - G - x - YF Unable to load bridge/router image; unable to load from
flash memory, or TFTP get failed
Replace flash memory card with a backup or verify TFTP
parameters and setup.
- G - - G G x - YF No valid bridge/router image file found; bad checksum or
magic number
Replace flash memory card with a backup.
- G - G G - x - YF No valid bridge/router image; unable to load
Replace flash memory card with a backup.
- G - G G G x - G Hang during bridge/router initialization
G - - x x x x x YF Bridge/router software has crashed and entered the debug
monitor, as specified by the RA command in the boot
monitor or by the SysconF command in the software.

2-4 CHAPTER 2: TROUBLESHOOTING AND REPLACING THE DPE MODULE
Replacing the
DPE Module To replace the DPE module, follow these steps. You will need a small, flatblade
screwdriver.
Although it is not required, 3Com recommends that you turn off the system
before you remove and reinstall a DPE module.
1Prevent ESD-related damage to the DPE module by following the ESD guidelines
presented in Chapter 1.
2Disconnect any cables, if necessary.
3Remove the DPE module from the chassis.
aLoosen the two captive screws with the flathead screwdriver.
bPress outward firmly and evenly on the ejector tabs.
The DPE module will eject from the slot.
4Install the new DPE module by following the procedure in Chapter 1.
When you replace the DPE module, the firmware parameters that were
previously configured by the SysconF command in the software are not
automatically updated to the FPROM of the replacement DPE module. You must
reconfigure these parameters. Refer to the software guide for configuration
information.

3FEATURES AND SPECIFICATIONS
This chapter describes the features and specifications of the DPE module.
Features Table 3-1 summarizes the DPE module features.
Table 3-1 DPE Module Features
Feature Summary
AMD 29040 RISC main
processors Operates at 50 MHz. It handles network interfaces and network protocol processing for supported media and
protocols and manages data down to the packet level.
Memory
DPE 40 32 MB (upgradeable to 64 MB) of instruction and data
memory and 8 MB of shared (packet) memory provides
optimal performance compared with single memory-based
systems. See Appendix A for upgrade instructions.
DPE 80 64 MB of instruction and data memory and 16 MB of
shared (packet) memory provides optimal performance
compared with single memory-based systems.
Two flash memory drives PCMCIA flash memory provides non-volatile, non-rotating,
high-capacity base media for software.
Flash PROM Allows update of firmware without swapping PROMs.
Real-time clock Allows stamping of date and time for error logs regardless
of the state of the network.
Analog-to-digital converter Allows voltage and temperature monitoring of the DPE
module.

3-2 CHAPTER 3: FEATURES AND SPECIFICATIONS
LEDs There are nine LEDs on the front panel of the DPE module:
■RUN and LOAD — green
■TEST — yellow
■STATUS — four green LEDs
■PACKET FORWARD — green
■POWER/FAULT — green or yellow
Refer to “LED Patterns” on page 2-2 for LED patterns and their meanings.
LEDs on the Chassis
There are two LEDs on the front of the chassis. The green POWER LED indicates
whether the system is off or on. The STATUS LED is exactly the same as the
POWER/FAULT LED on the DPE module. Refer to “LED Patterns” on page 2-2 for
more information.
Connectors Table 3-2 describes the module connectors.
CONSOLE
connector
Flash memory
drives (A, B)
STATUS
LEDs
(1,2,3,4)
ATTENTION
LED
RESET
LED
Backplane
connectors to
NETBuilder II
J1 J3
J2
J5
J4 J6
®
DPE
PACKET
FORWARD POWER/
FAULT
RUN
LOAD
TEST
RESET ATTENTION
4321
STATUS
CONSOLE
A
B
RUN
LOAD
TEST
LEDs
POWER/
FAULT
LED
PACKET
FORWARD
LED
Table 3-2 DPE Module Connectors
Location Connectors Features Device Type Purpose
Backplane
connectors J1, J2, J3, J4, J5, and J6 48-pin - Connects module to the core bus.
Front LED/connector
panel CONSOLE connector 9-pin male D-subminiature (RS-232) DTE Connects module to a modem or terminal. See “Connecting a PC, Terminal, or Modem” on
page 1-5 for more information.
