4tek ECO Series Operating instructions

Operating and Maintenance Manual
ECO Line oil-less
air compressors
4tek S.r.l.
Viale dell’Industria 66 - 20037 Paderno Dugnano (MI) ITALY
Tel. [phone] - Internet: www.4-tek.it
ENGLISH translation of the original ITALIAN instructions
Before using the compressor, read this document
carefully and keep it safe for future reference.
Rev. 0 - 2021

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual 0 - 01
Contents Chapter/Page
List of Models and Technical Specications 0 - 02
General information
Foreword - Symbols used in the Manual - Important Warning 1 - 01
Contents and purpose of the manual - References to applicable Directives and Legislation 1 - 02
Operator skill requirements 1 - 03
CE plate 1 - 04
General notes on delivery - Final Testing - Preparatory work to be performed by the end-user 1 - 05
Description
Description of the compressor and its component parts 2 - 01
Intended use - Reasonably foreseeable misuse 2 - 03
Noise level values - Operating and environmental conditions - permissible limits 2 - 04
Safety
General information 3 - 01
Warning labels - Residual Risks 3 - 02
Installation
Handling - Unpacking - Assembly 4 - 01
Electrical connection 4 - 02
Compressed air connection 4 - 03
Operation
Basic operation rules 5 - 01
Fill times table 5 - 03
Automatic thermal protector - Reset button 5 - 04
Maintenance
Safety precautions - Qualication of maintenance personnel
Competences of qualied personnel - Specic safety precautions 6 - 01
Routine maintenance 6 - 03
Major servicing 6 - 04
Troubleshooting 6 - 06
Disposal 7 - 01
Warranty 8 - 01
How to order: spare parts 9 - 01
Exploded views and spare parts tables 9 - 02

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
List of Models and Technical Specications
NOTE
The cross in the grey box shows the purchased Compressor Model.
0 - 02
ECO3N
ECO3E
ECO3E
ECO3N
ECO3N
ECO3E
ECO3N
REF
Lcm (W x D x H) kg
Weight in kg
dB
(A)
48 x 48 x 63
48 x 60 x 81.5
48 x 50 x 63
48 x 46 x 88
48 x 46 x 81.5
48 x 60 x 88
50 x 75 x 75
25
40
25
50 V
40
50 V
50
41
53
46
50
48
55
50
70
70
70
70
70
70
70
Meaning of the symbols in the table on this page and on the following pages.
NOTE The electrical data are shown on the CE plate a󰀩xed to the compressor
and reproduced on page 1- 04 of this document.
3-cylinder
head
2-cylinder
head
Dryer (Blue dot if
present)
Twin head
3-cylinder
Twin head
2-cylinder
Compressor
model
Triple head
3 cylinder
REF Air
receiver
capacity
Dimensions in
cm (W x D x H) Noise level
dB (A)

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual 0 - 03
ECO3E
MONSTER3N
TOP3E
ECO6N
MONSTER6E
MONSTER3N
MONSTER3E
ECOSIL3N
ECO6E
ECO9N
MONSTER3E
TOP3N
ECOSIL3E
MONSTER6N
REF
Lcm (W x D x H) kg dB
(A)
50 x 75 x 75
50 x 76.5 x 108
40 x 90 x 57
53 x 120 x 78
78 x 143 x 105
50 x 76.5 x 101.5
50 x 76.5 x 108
50 x 92 x 82
67 x 120 x 78
53 x 127 x 81
50 x 76.5 x 101.5
40 x 90 x 57
50 x 92 x 82
76.5 x 143 x 105
50
50
30
100
150
40
50
50
100
150
40
30
50
150
55
56
85
102
124
54
61
90
112
140
59
80
95
114
70
64
59
71
65
64
64
54
71
73
64
59
54
65

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual 0 - 04
ECO9E
ECO2N
ECO2E
MONSTER2N
MONSTER2E
ECO2N
ECO2E
ECO2N
MONSTER2E
TOP2N
ECO2E
ECO2N
ECO2E
MONSTER2N
REF
Lcm (W x D x H) kg dB
(A)
55 x 127 x 81
48 x 46 x 81.5
48 x 60 x 88
50 x 76.5 x 101.5
50 x 76.5 x 108
48 x 48 x 63
48 x 60 x 81.5
40 x 75 x 75
50 x 76.5 x 101.5
40 x 90 x 57
48 x 50 x 63
48 x 46 x 88
40 x 75 x 75
50 x 76.5 x 108
150
40
50 V
40
50
25
40
50
40
30
25
50 V
50
50
150
45
52
51
58
38
50
47
56
77
43
47
52
53
73
68
68
62
62
68
68
68
62
57
68
68
68
62

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual 0 - 05
TOP2E
ECO4N
MONSTER4E
ECOSIL2N
ECO4E
ECOSIL2E
MONSTER4N
REF
Lcm (W x D x H) kg
dB
(A)
40 x 90 x 57
53 x 120 x 78
78 x 143 x 105
50 x 92 x 82
67 x 120 x 78
50 x 92 x 82
76.5 x 143 x 105
30
100
150
50
100
50
150
82
97
119
87
107
92
109
57
69
63
52
69
52
63

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Symbols used in the manual
This manual uses symbols to attract the reader's attention and highlight critically important
sections.
The following table contains a list of the symbols used and illustrates their meanings.
MEANING and NOTESSYMBOL
CAUTION - General warning
This indicates an important warning.
Pay the utmost attention to text blocks marked with this symbol.
WARNING - Mandatory information
Text blocks containing information that it is mandatory to follow in every
detail.
NOTE - Additional information
Text containing additional information is preceded by this symbol.
IMPORTANT WARNING
This manual is an integral part of the product and it must remain with it
throughout its entire life cycle until it is scrapped.
Authorised operators and maintenance technicians must be able to consult
the manual at all times so it must be kept in a safe place near the equipment.
General information
Foreword
This manual will remain available for 10 years after the product to which it refers is
discontinued.
The contents of this document cannot be used, reproduced or transferred to third parties
without the express written permission of 4tek S.r.l.
4tek S.r.l. reserves the right to change the specications of the product to which this
document refers, without notice.
The product meets the requirements of the Medical Devices Regulation MDR (EU) 745/2017.
1 - 01

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Contents and Purpose of the Manual
This manual contains technical specications, performance details, transport and installation
instructions, operating instructions and preventive and corrective maintenance operations of
the equipment manufactured by 4tek S.r.l.
Any change, addition, or removal of elements, components or functions of the equipment,
unless agreed beforehand with 4tek S.r.l., will automatically relieve the manufacturer of all
liability.
This manual, which is intended for the users of the equipment and technicians entrusted with
its maintenance, provides the main technical data of the system, a technical description of the
various functional units of which it is composed, as well as the main operating procedures and
information needed to perform preventive and corrective maintenance operations.
The manual is addressed to persons with a sound knowledge of the manufacturing or
processing method and is intended for the use both of operators and of service technicians.
This manual contains information on the equipment to ensure conditions of safety for all users
and to guarantee perfect e󰀩ciency of the equipment throughout its entire working life.
To ensure correct use of the equipment, the workplace must be compliant with current health
and safety regulations.
1 - 02
References to applicable directives and standards
EU Directives
Reference Title
2014/35/EU Low Voltage Directive
2017/745/EU European Medical Devices Regulation
2014/29/EU Simple Pressure Vessels Directive
2014/68/EU Pressure Equipment Directive
EU Standards
Reference Title
UNI EN ISO 14971 Medical Devices - Risk Management
CEI EN 60601-1-6 Medical electrical equipment. General requirements for basic safety
and essential performance
CEI EN 60601-1-2 Electromagnetic compatibility
CEI EN 60601-1-6 Usability
CEI EN ISO 15223-1 Medical devices - Symbols to be used with medical device labels,
labelling and information to be supplied - Part 1: General requirements
EN IEE 82079-1 Preparation of instructions for use - structuring, content and
presentation

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Operator skill requirements
Personnel responsible for running or servicing the equipment must be in possession of
specic professional qualications for each of the required tasks.
Operators must be suitably trained and therefore familiar with the tasks assigned to them and
for which they are responsible.
The following is a description of the professional proles required for personnel/operators
entrusted to work with the equipment.
Operator
A qualied person capable of performing simple operating tasks and basic
maintenance.
Maintenance Electrician
A qualied technician capable of performing all electrical adjustment,
maintenance, and repair tasks.
Maintenance Mechanic
A qualied technician capable of working on mechanical parts to perform all
adjustment, maintenance, and repair tasks.
Qualied technicians can be provided by the manufacturer if
necessary, to perform complex operations in special situations or
in accordance with the agreements entered into with the user.
1 - 03
Manufacturer's Maintenance Mechanic and Electrician
Handling Operative
A person with specic skills in lifting techniques and equipment, slinging
techniques and safe handling of loads.

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
The CE plate is a󰀩xed to the compressor and
reproduced here alongside in the window.
It gives information related to the CE mark.
It is prohibited to remove the CE plate or replace it
with plates from compressors of the same model in the
possession of the user.
If the CE plate is damaged or becomes detached from
the compressor, the user must inform 4tek S.r.l.
1 - 04
4tek S.r.l.
Via dell’Industria 66
20037 Paderno Dugnano (MI)
ITALY
Ref. MONSTER3E - 00000000
kW 0.0 - V 000 - Hz 00 - μF 00
0000
Original CE plate a󰀩xed also to the
compressor.
CE plate
Identication of 4tek S.r.l. as the manufacturer of the
equipment machine in compliance with the statutory
legislation by means of the following deeds:
Instruction Manual
CE marking (CE plate)
Declaration of Conformity in compliance with Regulation (EU) 2017/745 (MDR)
CE data plate description
1
2
3
4
5
6
7
8
9
10
11
12
13
1 - Manufacturer's
identication symbol
2 - Manufacturer's logo
3 - Compressor model
4 - Electrical technical data
5 - CE logo
6 - Symbol showing
obligation to read the
Instruction Manual
7 - Identication symbol for
disposal of electrical and
electronic components
8 - Manufacturer's contact
details
9 - Serial number
10 - Medical Device
identication symbol
11 - Manufacturing date
identication symbol
12 - Year of manufacture
13 - UDI
Tel. [phone]- Internet: www.4-tek.it
NOTE
All equipment with more than one head must,
in addition to the CE Plate, have an additional
plate showing the serial number of each head.

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
General notes on delivery
On receipt of the compressor, check that:
The items supplied are in compliace with the order
specications.
No damage has occurred in transit or due to other causes.
If you nd any damage or missing parts, inform the shipping agent or 4tek S.r.l. immediately,
providing full details of the problem.
NOTE
When contacting 4tek s.r.l. or any of its service
centres, always quote the serial number of the
compressor.
Final Testing
The equipment is tested directly by the manufacturer
during production in compliance with the company's quality
system.
The equipment is supplied complete with a Declaration
of Conformity for the product and its main components,
i.e. the air receiver, the safety valve, and the dryer tank, if
present.
4tek S.r.l. shall be held liable for the compressor in its original condition.
4tek S.r.l. shall not be held liable for improper use of the compressor and for any damage
caused by failing to act in compliance with this manual or by acting unreasonably.
Preparatory work to be performed by the end-user
Unless contractually agreed otherwise, the following are normally provided by the end-user:
perfectly level non-slip oor with no irregularities;
preparation of the place of installation;
preparation of utilities suitable for the electrical system requirements;
preparation of the electrical system in compliance with statutory legislation in force in the
country of installation;
equipment power supply matching the values shown on the data plate;
ventilation and/or climate control to ensure temperature and humidity in the place of
installation in compliance with the prescriptions given on page 2-04.
1 - 05
4tek S.r.l.
Via dell’Industria 66
20037 Paderno Dugnano (MI)
ITALY
Ref. MONSTER3E - 00000000
kW 0.0 - V 000 - Hz 00 - μF 00
0000
Tel. [phone]- Internet: www.4-tek.it

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Description of the compressor and its component parts
The equipment is an oil-less compressor designed
to supply compressed air for dental and/or medical
applications.
Exploiting the rotation of the crankshaft, the pistons draw in air from the place where the
compressor is installed via the air-intake lter, pressurise it, and transfer it to the air receiver
for storage.
This operation is regulated by a pressure switch, which is typically set at between
6bar and 8.5 bar; the process is ultimately controlled by the safety valve: if the pressure
switch malfunctions and the air receiver pressure exceeds the safety valve setting, the valve
will crack open to vent the overpressure and eliminate the risk of bursting.
Class I appliance in relation to the new medical devices regulation (MDR) 2017/745
The product is not designed to withstand immersion in liquid (IPX0)
Class I: electrical insulation
Oil-less air compressor, 3-cylinder (ECO3E), 2-cylinder (ECO2E), applicable also to all the
following models in the same product family.
2 - 01
ECO3E compressor composed of:
3-cylinder head, equipped with single-phase or three-
phase motor, characterised by an air inlet of 300 l/min,
air delivery at 5bar 225 l/min
1 air receiver capacity: 50 l
ECO2E compressor composed of:
2-cylinder head, equipped with single-phase or three-
phase motor, characterised by an air inlet of 200 l/min,
air delivery at 5bar 150 l/min
1 air receiver capacity: 50 l
Available also in the following versions:
25 l air receiver
40 l vertical air receiver
50 l vertical air receiver
ECO3
MONSTER3
MONSTER3E
TOP3
TOP3E
ECOSIL3
ECOSIL3E
ECO6
ECO6E
ECO9
ECO9E
MONSTER6
MONSTER6E
ECO2
MONSTER2
MONSTER2E
TOP2
TOP2E
ECOSIL2
ECOSIL2E
ECO4
ECO4E
MONSTER4
MONSTER4E
All models are available also without a dryer.
If the device is enclosed in a cabinet, it will be equipped
with a cooling fan and associated control thermostat.

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
11109
8
7
5
4
3
21
2 - 02
Mechanical pressure switch [230 V versions] (Fig. 1)
Mechanical pressure switch [MDR3 - 400V three-phase versions] (Fig. 2)
Mechanical pressure switch [MDR5 - 400V three-phase versions] (Fig. 3)
Safety valve (Fig. 4)
Non-return valve [For compressors with dryer] (Fig. 5)
Dryer [Only if model is identied
with letter “E”] (Fig. 6)
3-way non-return valve (Fig. 7)
[For compressors without dryer]
2-way N.O. 1/8” solenoid valve
(Fig. 8)
Pressure gauge [Only for TOP
Line versions] (Fig. 9)
Pressure gauge [All other
versions] (Fig. 10)
Miscellaneous ttings
Miscellaneous accessories
Pressure reducer
with pressure gauge (Fig. 11)
6

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
CAUTION!!!
The compressor is NOT suitable for use in potentially explosive atmospheres.
Reasonably foreseeable misuse
Any work process not classied as intended use is deemed to be improper use of the
compressor and could result in damage to property and/or injury to persons.
The compressor cannot be used:
Outdoors in an area directly exposed to the weather
In areas exposed to corrosive and/or abrasive vapour, fumes, or dust
Also the following are examples of improper use:
The instinctive reaction of persons in the event of a malfunction, accident, or fault
during use of the compressor
Behaviour resulting from distraction or carelessness
Behaviour resulting from external pressure to keep the compressor running in all
circumstances
Behaviour of certain people (e.g. untrained personnel)
Failure to read the compressor Instruction Manual, entirely or in part.
Intended use
The products are designed to supply compressed air to dental surgeries and orthodontic
laboratories; they are normally installed in a plant room or anyway an area separated from the
operating area.
2 - 03

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
CAUTION
In zones with noise level > 85 dB, the operator must use suitable
personal protective equipment such as ear defenders or ear plugs.
Noise level values
A-weighted equivalent sound pressure below 80 dB (A)
C-weighted maximum instantaneous sound pressure < 130 dB
K correction factor
The stated noise values are emission levels and are not necessarily safe operating levels.
Even though there is a relationship between emission levels and exposure levels, this cannot
be used to reliably establish the need for further precautions.
The factors that determine the noise levels to which the workforce is exposed include duration
of exposure, workplace characteristics, other noise sources, etc.
Legally allowed exposure levels may vary from country to country.
In any case, this information will allow the compressor user to better assess the noise hazard
and risk.
Operating and environmental conditions - permissible limits
Although the compressor is designed for use only indoors, cabinet enclosed versions can also
be installed outdoors.
In order to ensure trouble-free operation in conditions of complete safety, the following
parameters must be observed:
Operating temperature: 0 °C to +40 °C
Maximum relative humidity: 80% for temperatures above 31 °C falling to 50% for
temperatures above 40 °C.
Power supply tolerance: +/- 10%
Pollution level: 2
2 - 04

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Safety
CAUTION
Do not use the compressor if the power cable
or plug are damaged.
If the compressor is not working correctly, if it has su󰀨ered impact, is damaged, or has
come into contact with water or other liquids: contact technical service to have it checked
over and/or repaired.
Do not use the product if it is exposed to the rain or high humidity levels.
Keep the power cable well clear of hot surfaces.
All electrical connections can produce heat.
To avoid burns, NEVER touch the compressor while it is running or immediately after it has
been shut down.
The compressor outer surface can reach temperatures of up to 120°C.
Do not obstruct the cylinder head or electric motor fan grilles; obstructing the grilles
prevents compressor ventilation leading to overheating and possible re risks.
Use the compressor only in well ventilated places.
Do not insert ngers or objects in the compressor air intake grilles.
Protect the compressor from contaminants and dirt.
Do not dismantle the compressor.
Incorrect compressor disassembly or reassembly can cause electric shock and/or serious
damage to property or injury to persons in the vicinity of the compressor.
Have the work performed by a specialised service centre/qualied technician.
Maintenance work must be carried out by qualied technicians.
Do not touch the compressor with wet hands.
Unplug the power cable immediately.
To reduce re or explosion risks, do not use the equipment near explosive substances or in
areas subject to the presence of explosive gas.
Do not use the equipment near open ames.
Tampering or unauthorised replacement of one or more parts of the compressor and the
use of accessories that change its operation can result in an injury risk.
The employer must inform its personnel of all injury risks.
Mandatory notication of serious incidents.
The user and/or patient must inform the manufacturer and the competent authority in the
member state in which they reside of any serious incidents concerning the product.
Mandatory guarantee of product traceability.
All economic operators are required to guarantee product traceability throughout the entire
distribution chain.
3 - 01

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Warning Decals
Warning; Hot surface
Code W017
Warning; Electricity
Code W012
Mandatory sign:
Refer to instruction
manual/booklet
Code M002
Mandatory sign:
Check guard
Code M027
CAUTION
Operators and Maintenance technicians must comply strictly with all the
warnings shown by the safety symbols.
It is strictly forbidden to interfere with or remove these labels.
Mandatory signs Circular shape with white images on blue background.
Triangular shape with black images on yellow background and black
border.
Danger
The compressor bears safety and warning labels with the following information.
The symbol codes refer to UNI CEI EN ISO 15223-1 and ISO 7010.
3 - 02
Residual Risks
Residual risk of electrical shock
This risk arises if work must be carried out on
the compressor with power connected.
Work of this kind must be carried out only by
qualied Maintenance electricians.

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Residual risk of burns
There is a residual risk of burns associated with contact with the zone shown in Figures 1 and 2.
In case of checks carried out on the compressor and/or maintenance
operations, it is MANDATORY to wear protective gloves.
3 - 03
1 2

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Installation
Handling
The entire area in which the compressor is
handled, including the transport vehicle parking
area and the area designated for installation of
the compressor, must be specied and inspected
beforehand in order to allow the identication of
“DANGER ZONES”. Personal protective equipment
4 - 01
All compressors are shipped on a pallet that can be handled by a forklift or pallet truck.
Except for the smallest models, all other compressors must be moved using suitable
handling equipment.
Take care during handling, lifting and transport to prevent damage to the compressor or
other property and personal injury.
Check the weight of the compressor and use a forklift truck or suitable lifting equipment.
When lifting the compressor use caution to avoid damage.
While transporting the compressor lash securely it to the vehicle both crosswise and
lengthwise.
Packs of the same weight can be stacked up to three high.
Unpacking
Remove the compressor from the pack carefully.
Keep the pack for possible future shipping requirements.
If the pack shows signs of damage, sign the shipping agent's delivery note
under reservation and keep the pack for possible inspection by the transport
company.
If you need to contact the distributor or the manufacturer, always quote the
compressor serial number to aid rapid identication.
The equipment serial number is always transcribed on the transport document.
Assembly
Install the compressor indoors or anyway in a place where it is not directly exposed to the
weather.
The room in which the compressor is installed must be well ventilated and not damp;
if the compressor is installed in a plant room air circulation must be su󰀩cient for all the
equipment installed; ambient temperature must be no higher than 40°C and no lower than
0°C.
The product feet are tted with rubber vacuum cups. These are essential because they
reduce vibration and thus help to reduce the noise level while also limiting any movement of
the unit while it is running.

This manual is the property of . No part of it may be reproduced in any form.
ECO Line Compressors Instruction Manual
Most models are equipped with handles so they can be safely lifted.
The compressor should be installed in a clean environment.
We recommend creating the compressed air circuit with a classic “ring” type circuit
using Rilsan Pa12 tubing (or an equivalent type of plastic compressed air tubing);
specically:
Main line: Ext. D 18 mm
Secondary line / connection between ring and dental chair: Ext. D 14 mm
Electrical connection
The main connections must be made by specialized technicians. To guarantee correct
installation, check the current and voltage value of the building electrical supply. Connecting
the compressor to an electrical supply with the incorrect voltage can cause serious damage.
CAUTION
Do not replace the electrical power cable if not expressly authorised by the supplier
or by an authorised installer: replacing the cable could lead to interference with other
nearby equipment and/or faults.
Beware of the risk of electric shock!
Disconnect the power at the main disconnect switch before connecting the compressor.
Install the equipment in a place where it cannot come into contact with water or other
liquids.
Make sure the electrical power line is su󰀩cient for the compressor, following the data shown
on the motor rating plate.
Failure to comply with these instructions could lead to death, re, or
electrocution.
4 - 02
