4xem 4X-FD8361 User manual

2-megapixel Day/Night
Vandal Proof Fixed Dome
Network Camera
4X-FD8361
Need more information?
Visit www.4XEM.com or call
1-866-999-4XEM
Includes 32 camera professional monitoring & recording software•
2-megapixel CMOS Sensor•
3 ~ 9 mm Vari-focal, Auto-iris Lens•
Removable IR-cut Filter for Day & Night Function•
Built-in IR Illuminators, eective up to 20 Meters•
Real-time H.264, MPEG-4 and MJPEG Compression (Triple Codec)•
Simultaneous Multiple Streams•
Video Cropping for Bandwidth Saving•
ePTZ for Data Eciency•
Activity Adaptive Streaming for Dynamic Frame Rate Control•
Tamper Detection for Unauthorized Changes•
Vandal-proof and IP66-rated Weather-proof Housing•
Built-in 802.3af Compliant PoE•
Built-in SD/SDHC Card Slot for On-board Storage•
Built-in Heater and Fan, supported by PoE•
3-axis Mechanical Design for Ceiling/Wall Mount Installation•
Supports ONVIF Standard to Simplify Integration and Enhance•
Interoperability
Features:
The 4X-FD8361 is the latest professional-series outdoor xed dome
network IP Security camera featuring superb megapixel image quality
and exceptional bandwidth eciency. With day & night functionality
and a weatherproof housing, it is especially suitable for tough outdoor
surveillance environments such as parking lots and streets.
Featuring a 2-megapixel sensor, the 4 X-FD8361 IP camera is able to
provide extremely wide coverage with the nest details. Additionally, the
camera is incorporated with high performance H.264 compression tech-
nology, and has adopted a number of innovative bandwidth-ecient
technologies built into the camera, including cropping, ePTZ, and activity
adaptive streaming.
In order to adapt to constantly changing outdoor lighting conditions,
the 4X-FD8361 features an auto-iris lens to perform better image quality
under dierent lighting environment.The camera also comes with a re-
movable IR-cut lter and IR illuminators for superior image quality around
the clock. For protection against the elements, the camera is furnished
with an IP66-rated housing and vandal-proof casing to withstand rain,
dust, and vandalism. The PoE-powered heater and fan further enhance
the 4X-FD8361’s performance and reliability in extremely cold and warm
weather.
The integrated BNC connector allowing the 4X-FD8361 to be connected directly to an analog monitor provides enhanced exibility and
usability and ease of installation. Other advanced features include a 3-axis mechanism for exible installation, 802.3af PoE, SD/SDHC card
slot, tamper detection, and SIP-enabled two-way audio. With the included ST7501 32-CH central management software, the 4X-FD8361 is
the ultimate camera for demanding outdoor environments. This camera is identical to the Vivotek FD8361.
www.4XEM.com
FREE 32 Camera
Monitoring & RecordingSoftware
Day/Night
Built-in SD/SDHC
Card Slot for On-board Storage
2 YEAR Warranty
2
YEAR
SD
card
Slot

Camera Specications
Image Sensor 1/3.2”CMOS in 1600x1200
Resolution
Lens f = 3 ~ 9 mm
F 1.2 (wide)
F 2.1 (tele)
auto iris
Board lens
Removable IR-cut lter for day
& night function
Angle ofView 31.7° ~ 93.0° (horizontal)
23.8° ~ 68.4° (vertical)
Electronic Shutter Speed 1/5 ~ 1/40,000 sec.
Min. Illumination 0 Lux / F1.2 ( IR LED on )
IR Illuminators Built-in IR illuminators,
Eective up to 20 meter
Dimensions 170mm (D) x 133mm (H)
Weight Net: 2,184g
System
CPU TI DM365 SoC
Flash 128MB
RAM 256MB
Embedded OS Linux 2.6
Image Settings
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Congurable brightness, contrast, saturation, sharpness,
white balance and exposure
AGC AWB AES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
Installation, Management, and
Maintenance
3-axis mechanism for exible ceiling and wall mount
installation
Drop-ceiling mount installation
Camera angle adjustment:
Pan range: 350°
Tilt range: 85°
InstallationWizard 2
32-CH central management software
Supports rmware upgrade
Networking
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE,
CoS, QoS, SNMP and 802.1X
Video Specications
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous multiple streams•
H.264 streaming over UDP, TCP, HTTP or HTTPS•
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS•
MPEG-4 multicast streaming•
MJPEG streaming over HTTP or HTTPS•
Supports activity adaptive streaming for dynamic frame•
rate control
Supports video cropping for bandwidth saving•
Supports ePTZ for data eciency•
Supports 3GPP mobile surveillance•
Frame rates:
H.264: Up to 30 fps at 1280x720, Up to 15 fps at•
1600x1200
MPEG-4: Up to 30 fps at1280x720, Up to 15 fps at•
1600x1200
MJPEG: Up to 30 fps at 1280x720, Up to 15 fps at•
1600x1200
BNC connector for video output•
NTSC/PAL video output switch•
Alarm & Event Management
Triple-window video motion detection
One D/I and one D/O for external sensor and alarm
Event notication using HTTP, SMTP, or FTP
Local recording of MP4 les
Tamper Detection
System Requirements
OS: MicrosoftWindows 2000/XP/Vista
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
QuickTime: 6.5 or above
Miscellaneous
Audio: Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to
12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to
128 kbps
G.711 audio encoding, bit rate: 64 kbps, μ-Law or
A-Law
Interface:
External microphone input
Audio output
Supports two-way audio via SIP protocol
Supports audio mute
Security:
Multi-level user access with password protection
IP address ltering
HTTPS encrypted data transmission
802.1X port-based authentication for network
protection
LED Indicator:
System power and status indicator
Power
12V DC
24V AC
Power consumption: Max. 5.3W
Power consumption: Max. 9.9W ( with heater )
802.3af compliant Power-over-Ethernet
EMI & Safety
Certication CE, C-Tick, FCC, LVD, VCCI
Operating Environment
OperatingTemp. -20~50˚C (-4~122˚F)
Operating Humidity 20 ~ 95% RH
Users
10 clients on-line monitoring at the same time
On-Board Storage
SD/SDHC card slot
Stores snapshots and video clips
Need more information? Visit www.4XEM.com or call 1-866-999-4XEM
2-megapixel Day/Night Vandal Proof
Fixed Dome Network Camera
4X-FD8361
Bundled Software
IPNV32 Security & Remote Monitoring Software:
Remote conguration and control of up to 32 devices
Fast/slow forward, replay, and pause
Scheduled backup
Event-triggered, scheduled, and manual recording
Instant search with preview windows
Hard disk quota warning
AVI format export
