6COM 6C-400A User manual

6COM TECHNOLOGY CO.,LTD Page 1 of 3
Tel:+86-755-82782669 Fax:+86-755-81487760 JUL 2 8 / 200 4
Web:www.6comgiga.com v1. 2
E-mail: S ales@6comgiga.com
Gigabit
Gigabit
Gigabit
Gigabit Ethernet
Ethernet
Ethernet
Ethernet Converter
Converter
Converter
Converter 1
1
1
1 Tx
Tx
Tx
Tx port
port
port
port &1
&1
&1
&1 SFP
SFP
SFP
SFP slot
slot
slot
slot
1
1
1
1 .
.
.
. Overview
Overview
Overview
Overview
This series converters are designed to meet the massive needs for Gigabit network deployment and able
to extend a copper based Gigabit network via fiber cable to a maximum distance up to 80KM.
This series converters are fully compliant with IEEE802.3z & 802.3ab standards.
It
can be installed into a
Standard Converter Chassis. The installation & operation procedures are simple & straightforward.
Operation status can be locally monitored through a set of Diagnostic LED located in the front panel.
Features
1000Base-T to 1000BASE-SX/LX Converter
Standard : IEEE 802.3z & 802.3ab
Interface: 1 x RJ-45 connector
1 x SFP Slot
MDI/MDIX Auto-Crossover supported
LED: Power , DUP,FP-LINK,RX,1000,TX
Plug-and-Play installation
Support Link Alarm
Support Jumbo Frame (64-9216 Byte)
Support Voltage Monitor
2
2
2
2 .
.
.
. Installation
Installation
Installation
Installation
• Attach fiber cable from the SFP transceiver installed in the converter to fiber network. The fiber
connections must be matched – transmit socket to receive socket.
• Attach a UTP cable from the 1000BASE-T network to the RJ-45 port on the converter.
•
Connect the power adapter to the converter and check that the Power LED lights up. The TP-Link and RX LEDs
will light up when all the cable connections are satisfactory.

6COM TECHNOLOGY CO.,LTD Page 2 of 3
Tel:+86-755-82782669 Fax:+86-755-81487760 JUL 2 8 / 200 4
Web:www.6comgiga.com v1. 2
E-mail: S ales@6comgiga.com
3
3
3
3 .
.
.
. LED
LED
LED
LED Description
Description
Description
Description
LED function status Description
DUP
UTP port
duplex LED
ON Full duplex
OFF Half duplex
FP-LINK
Fiber port
link/action
status LED
ON Fiber link is ok.
OFF Fiber link is fail.
PWR Power LED
ON Power is ON.
OFF Power is Fail.
RX
UTP port
link/action
status LED
ON The TP link in ok
Blink Data is been received or transmit t ed
OFF The TP link in fail
1000
UTP port
speed LED
ON 1000M speed
OFF 100M speed
TX
UTP port
link/action
status LED ON The data send out
4
4
4
4 .
.
.
. Technical
Technical
Technical
Technical Specifications
Specifications
Specifications
Specifications
1000Base-T to 1000Base-SX/LX Media Converter With SFP Slot
1. Standard Protocol: IEEE802.3 10 Base-T standard
IEEE 802.3u 100Base-TX/FX standard
2.C onnector :one RJ-45 connector ,one SFP slot
3. Operation mode
:
full duplex mode or half duplex mode
4. Power supply parameter: outside: 5V DC 1A
5. E nvironmental temperature
:
0℃-60 ℃
6. R elative humidity: 5%-90%
7. TP cable: Cat5 UTP cable

6COM TECHNOLOGY CO.,LTD Page 3 of 3
Tel:+86-755-82782669 Fax:+86-755-81487760 JUL 2 8 / 200 4
Web:www.6comgiga.com v1. 2
E-mail: S ales@6comgiga.com
8.Fiber :50/125,62.5/125um multi-mode fiber ; 9/125,10/125um single-mode fiber.
9. Dimensions:
External power supply: 26mmx 71mm x 94mm
5.Cautions:
5.Cautions:
5.Cautions:
5.Cautions:
1. This product is suitable for indoor application.
2. Put on the dust cover of fiber interface when not used.
3. It is forbidden to stare at the TX fiber- transfer end with naked eyes.
6.
6.
6.
6. Copyright
Copyright
Copyright
Copyright Statement
Statement
Statement
Statement
This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior
consent has been obtained .
7.
7.
7.
7. FCC
FCC
FCC
FCC Warning
Warning
Warning
Warning
This series converters have been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These standards are designed to provide reasonable protection
against harmful interference when these devices are operated in a commercial environment. These
devices generate, use, and can radiate radio frequency energy and may cause harmful interference to
radio communications unless installed in accordance with this User ’ s Guide. Operation of these devices
in a residential area is likely to cause harmful interference which will make the user responsible for the
appropriate remedial action at his / her own expense.
8.
8.
8.
8. CE
CE
CE
CE Mark
Mark
Mark
Mark Warning
Warning
Warning
Warning
These are Class A products. In a domestic environment these products may cause radio interference in
which case the user will need to consider adequate preventative methods.
9.
9.
9.
9. Order
Order
Order
Order Information
Information
Information
Information
Description
Description
Description
Description Part
Part
Part
Part number
number
number
number
10/100M Ethernet to fiber media converter with 1 FE SFP
Slot (without SFP transceiver installed inside)
6C- 300A
1000M Ethernet to fiber media converter with 1 GE SFP
Slot (without SFP transceiver installed inside)
6C - GE -SFP -A
10/100/1000M Ethernet to fiber media converter with 1 GE
SFP Slot (without SFP transceiver installed inside)
6C- 400A
This manual suits for next models
